SoundLogic XT HP-135 User manual

1
HP-135
TRUE WIRELESS DIGI-BUDS
RECHARGABLE STEREO EARBUDS
WITH DIGITAL DISPLAY STORAGE CASE
INSTRUCTION MANUAL
PLEASE READ ALL INSTRUCTIONS CAREFULLY
AND RETAIN FOR FUTURE USE

2
Getting Started
•Remove the product from the box.
•Please re tain all packaging and instructions. Check the contents against the Package
Contents list below.
Package Contents
•True Wireless Bluetooth Stereo Earbuds
•Recharging Case
•USB Charging Cable
•Instruction Manual
Features
•True Wireless Bluetooth Stereo Earbuds
•Charging Case with LCD screen, helps to show remaining battery
•Small and elegant design, good fit for your ears
•Supports Android or iOS
•Supports hands-free call pick-up
•Supports wireless streaming of music
•Charging Case included
•Auto-pairs once re moved from the case
•Charging time: approx. 1-2 hours; play time approx. 2-3 hours on single charge
•Charging Case provides up to 8hours of playback time
•Rechargeable battery capacity: 200mAh
•Digital display show
•Earbuds battery capacity: 40mAh
Safety Instructions
Keep the unit away from h e at sources, direct sunlight, humidity, water and any other liquids.
Do not operate the unit if it has been exposed to wate r, mo isture or any other liquids to
prevent against electric shock, explosion and/or injury to yourself and damage to the unit.
Do not use the unit if it has been dropped or damaged in any way.
Repairs to electrical equipment should only be performed by aqualified electrician.
Improper repairs may place the user at serious risk.
Do not use the unit with wet hands.
Do not put objects into any of the openings.
Keep the unit free from dust, lint etc.
Do not use this unit for anything other than its intended use.
Keep the unit out of reach of children.
This product is not atoy.
Do not use the he adset at excessive volume levels, as damage to hearing may occur.

3
Description of Parts:
INSTRUCTIONS FOR USE
Charging Instructions
The Recharging Case and Bluetooth Earbuds come with abuilt-in rechargeable battery.
Be fore using it for the first time we recommend you charge the battery fully. Please recharge
the battery by following either methods every time they drain out.
To charge the Recharging Case (without Bluetooth Earbuds)
Plug the Micro USB end of the included USB charging cable into the charging port of the
Recharging Case.Plug the other end into asuitable USB port such as the one on your
computer or other devices made for USB charging. The LCD screen will flash with battery
capacity value to indicate that its being charged.
It takes less than 2hours for the case to charge fully. When the battery is fully charged, the
LCD screen will display battery capacity value 100.
To charge the Bluetooth Earbuds
1. After fully recharging the Recharging Case, disconnect it from charging.
2. Put the Bluetooth Earbuds into re spective charging slots correctly.
3. The LED light indicator on the Earbuds turns red to indicate that the battery is being
charged. It takes less than 2hours for the Earbuds to fully charge. When the battery
1
Charging Port
2
Charging Connectors
3Charging Slot
4
Recharging Case LCD Screen
5
MF (Multi-Function) /Phone Button
6LED Indicator /Built-In Microphone

4
is fully charged, the red LED light will turn off, and the LCD screen will also turn off.
Turning on/off the Bluetooth Earbuds
Take out the Earbud from the Recharging Case, it will turn on automatically ( O r, if the Earbud
is not sto re d inside the Recharging Case, press and hold the MF button for 3seconds to turn
ON.)
Press and hold the MF button of the Earbud for 6seconds to turn OFF the device. ( O r, put
the Earbud back to the Recharging Case, it will turn off for recharging automatically.)
Pairing either one Bluetooth Earbud with Bluetooth devices (phone or tablet that
support call-answering)
•Take out one Earbud from the Recharging Case, it will turn on automatically and the
LED flashes red and blue ( Or, if the Earbud is not st ore d inside the Re charging Case,
press and hold the MF button for 3seconds to turn ON. An indication tone will be
he ard and the LED flashes red and blue.)
•Place the Bluetooth Earbud and Bluetooth device (phone or tablet that support call
answering) no further than 1m apart from each other;
•Activate the Bluetooth function on your mobile device. Ple ase refer to the
manufacturer’s instructions for instructions on enabling Bluetooth on your device.
•Once you have activated Bluetooth on your mobile device, select the “Digi-Buds”
from the list of available Bluetooth devices.
•You might be prompted with “Pair with Digi-Buds?” message on your source device,
with “Cancel”and “OK”options. Please click “OK”.
•If re quired, enter the password ‘0000’to confirm &finalize pairing.
•Once paired successfully, an indication tone will be he ard and the LED will flash blue
slowly.
•You can now start to use the Earbud.
•If pairing is unsuccessful, turn off the device first and then re-pair following the
above steps.
•Once you have paired the Bluetooth Earbud with amobile device, the earbud will
remember this mobile device and will pair automatically whe n its Bluetooth is
activated within the range, during subsequently pairing. You do not need to re-pair
any previously connected devices.
•The Bluetooth Earbud will attempt to automatically connect to the last device it was
paired with when switched on. If you want to pair it with anew device, please follow
the steps outlined above.
Making acall with the Bluetooth Earbud in Bluetooth mode
Basic operation
Function Operation Button
Answer incoming
call
Incoming Call Short press the Phone button to answer an
incoming call.

5
Reject Incoming Call Incoming Call Press and hold the Phone button for 1.5
seconds and release
End call Incoming Call After your phone conversation, Short press
the Phone button
Redial last number Standby mode and
connected to adevice
Short press the Phone button twice
Listening to Music Wirelessly
Please ensure that your device (iPhone, Table t or Other Smart Phone) is paired with the
Bluetooth Earbud to stream music wirelessly. Once it is paired, play music from your device.
Function Operation Button
Pause Playing music Short press the MF button will pause the music
Play Pausing Short press the MF button will resume the music
Previous track (for
left Earbud only)
Playing music Press and hold the MF button for 1second and release
Next track (for
right Earbud only)
Playing music Press and hold the MF button for 1second and release
Note: Other functions including volume increase/decrease, Next track for left Earbud,
Previous track for right Earbud, you may need to control through your source device.
Pairing both Bluetooth Earbuds with Bluetooth devices (smart phone or tablet etc)
•Take out both Earbuds from the Recharging Case, it will turn on automatically and
the LED flashes red and blue (* Or, if both Earbuds are not sto re d inside the
Recharging Case, press and hold the MF button for 2seconds to turn ON. An
indication tone will be he ard and the LED flashes red and blue.)
•After few seconds, you would hear another indication tone when both Earbuds
connected together. The LED light indicator on one Earbud will flash red and blue,
and the LED light indicator on the other Earbud will flash blue slowly.
•At this point, activate the Bluetooth function on your mobile device, and s e arch for
Bluetooth devices near you.
•Once you have activated Bluetooth on your mobile device, select the “Digi-Buds”
from the list of available Bluetooth devices.
•You might be prompted with “Pair with Digi-Buds?” message on your source device,
with “Cancel”and “OK”options. Please click “OK”.
•Once paired successfully, an indication tone will be he ard and the LED on both units
will flash blue slowly.
Making acall with the Bluetooth Earbuds in Stereo pairing mode
Basic operation
Function Operation Button

6
Answer incoming
call
Incoming Call Short press the Phone button of one Earbud
to answer an incoming call.
Reject Incoming Call Incoming Call Press and hold the Phone button of one
Earbud for 1.5 seconds and release
End call Incoming Call After your phone conversation, short press
the Phone button of one Earbud
Redial last number Standby mode and
connected to adevice
Short press the Phone button of one Earbud
twice
Note: both Earbuds support phone conversation.
Listening to Music Wirelessly in Stereo pairing mode
Please ensure that your device (iPhone, Table t or Other Smart Phone) is paired with the
Bluetooth Earbuds to stream music wirelessly. Once it is paired, play music from your device.
Function Operation Button
Pause Playing music Short press the MF button of one Earbud will pause the
music
Play Pausing Short press the MF button of one Earbud will resume the
music
Previous track Playing music Press and hold the MF button of left Earbud for 1
seconds and release
Next track Playing music Press and hold the MF button of right Earbud for 1
seconds and release
Note: Other functions including volume increase/decrease, you may need to be controlled
through your source device.
Voice Assistant Operation
Voice Assistant is abuilt-in interactive feature that allows you to Start Conversation with Your
Siri or Google Assistant, with short press the MF button of the Earbud (or either Earbud
when using both Earbuds) 3times quickly.
This feature enables you to ask questions and seek assistance on anumber of things from
your Voice Assistant, even when you’re several feet away from your phone. Below are some
of the many example s listed below.
Note: Google Assistant is available on eligible Android 5.0 devices or lat e r. Works on Lollipop,
Marshmallow and Nougat Android Phones with Google Play Services, >1.5GB of memory and
720P or higher screen resolution. Please ensure Google Assistant App is downloaded and
made as default Voice Assistant on your mobile device.
While the Earbud is paired (or both Earbuds are paired) using Bluetooth, short press the
MF button of the Earbud (or either Earbud when using both Earbuds) 3times quickly and
release to start conversation with your Siri or Google Assistant. An indication tone would

7
be heard before you speak into the Earbud.
oEx ample 1: Short press the MF button of the Earbud (or either Earbud when using both
Earbuds) 3times quickly and release, then speak into the Earbud(s), how’s the weather
today?
Voice Assistant will re ply with something like: mainly cloudy with afew showers.
oEx ample 2: Short press the MF button of the Earbud (or either Earbud when using both
Earbuds) 3times quickly and release, then speak into the Earbud(s), what’s the time
now?
Voice Assistant will re ply with something like: it is 8pm now.
oMore examples:
Set an alarm for 7am tomorrow.
Play some music.
What’s in the news?
Troubleshooting
Symptom Solution
No Sound
•
Power On the Earbud(s) and charge the battery
•Increase the volume on your mobile device and
music source
•Move your mobile device closer to the
Earbud(s) and away from any interference or
obstructions
•User adifferent music source
•Connect another mobile device
Poor Sound Quality
•
User adifferent music source
•Connect another mobile device
•Move your mobile device closer to the
Earbud(s) and away from any interference or
obstructions
Battery Won’t Charge •Se cure the e nds of the USB charging cable
•Try another charging source
Your Google Assistant not
responding
•This is only available for Android Mobile
Devices
•Make sure Google Assistant is downloaded on
your mobile device and set to default voice
assistant
•Make sure your Android Mobile Device is
Bluetooth paired with Earbud
•Make sure you are in acountry where Google
Assistant is available
•For additional support, visit
www.support.google.com/assistant

8
Loud Dial Tone Noise When
Activating Google Assistant
•Make sure you have latest version of Google
Assistant App
•On your Android mobile device, go to Settings >
Apps >Google App >Disable. After that, tap
Enable (If you have uninstalled Google App,
please uninstall and reinstall the App).
Care and Maintenance
Read the following recommendations before using the Bluetooth Earbuds. Following these
you will be able to enjoy the product for many years.
•Don’t expose the Bluetooth Earbuds to liquid, moisture or humidity to avoid the
product’s internal circuit being affected.
•Don’t use abrasive cleaning solvents to clean the device.
•Don’t expose the device to extremely high or low temperature as this will shorten the life
of electronic devices, destroy the battery or distort certain plastic parts.
•Don’t dispose of the device in afire as it will result in an explosion.
•Don’t expose the device to contact with sharp objects as this will cause scratches and
damage.
•Don’t let the device fall on the floor. The internal circuit might get damaged.
•No user serviceable parts.
Specifications
Bluetooth specification
Bluetooth 5.0
Operating distance 10m
Working time 2to 3hours (moderate volume)
Charging input voltage
DC 5V
Charging time less than 2hours
Built-In Battery Recharging Case: 200mAh
Bluetooth Earbud: 40mAh (each)
Size Recharging Case: 54.6mm (L) x34.0mm (D) x33.5mm
(H)
Bluetooth Earbud: 20.1mm (L) x23.3mm (D) x21.8mm
(H) (each)
Weight Recharging Case: 23g
Bluetooth Earbud: 3g (each)
(Note: Battery life &charging time may vary based on usage &types of devices used.)
FCC Instructions
Caution: Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the product.
NOTE: This product has been tested and found to comply with the limits for aClass Bdigital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable

9
protection against harmful interference in aresidential installation. This product generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. Ho weve r, there is
no guarantee that interference will not occur in aparticular installation. If the product does
cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference
by one or more of the following measures :
-Reorientor relocate the receiving antenna.
-Increase the separation between the product and receiver.
-Connect the product into an outlet on acircuit different f rom that to which the receiver
is connected.
-Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Ope rat io n is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
Imported by Osiris Inc. L6T 4M6/
Osiris America Inc. 14020
