SoundLogic CAB-92080 User manual

1
CAB‐92080
TailgateWirelessSpeakerSystem


INSTRUCTIONMANUAL
PLEASEREADALLINSTRUCTIONSCAREFULLYAND
RETAINFORFUTUREUSE


2
GettingStarted
Removetheunitfromthebox.
Removeanypackagingfromtheproduct.
Pleaseretainallpackagingafteryouhavecheckedandcountedallthepartsandthecontents
againstthelist.

PackageContents
Bluetoothportablespeaker
AC/DCpoweradapter
Aux‐incable
InstructionManual

ProductFeatures
Blastyourmusicanywhere,anytimeyouwant
PowerfulspeakersystemforiPhone,iPad,iPod,Androidsmartphones,MP3playersandother
audiodevices
StreamsmusicfromanyBluetoothenableddevices
Perfectforparties,BBQ’sandmore
Microphonemicinputx2
Built‐inAuxjack
Built‐inrechargeablebattery
Speakerincludesruggedwheelsandtelescopinghandle

SAFETYINSTRUCTIONS
Keeptheunitawayfromheatsources,directsunlight,humidity,waterandanyotherliquids.
Donotusetheunitifithasbeendroppedordamagedinanyway.
Repairstoelectricalequipmentshouldonlybeperformedbyaqualifiedelectrician.Improper
repairsmayplacetheuseratseriousrisk.
Donotusetheunitwithwethands.
Donotputobjectsintoanyoftheopenings.
Keeptheunitfreefromdust,lintetc.
Donotusethisunitforanythingotherthanitsintendeduse.
Keeptheunitoutofreachofchildren.
Thisunitisnotatoy.




3
DescriptionofParts


LocationofControls



4

1DCIN8ECHO
2CHARGEINDICATOR9MAINVOLUME
3AUXIN10POWERON/OFFSWITCH
4LEDINDICATOR11SOURCEBUTTON
5MICINPUT112PLAY/PAUSEBUTTON
6MICINPUT213PAIRBUTTON
7MICVOLUME

INSTRUCTIONSFORUSE
ChargingtheTailgateBluetoothSpeaker
Forbestresults,fullychargetheunitbeforeuse.
1. ConnecttheprovidedadaptertotheDCINofthespeakerandplugtheadaptertoawallport.
2. Whilecharging,chargeindicatorturnsREDinPOWERONmode,anditwillturnORANGEwhen
fullycharged.
Note:Beforeusingtheunitforthefirsttime,pleasechargeitforaround5hoursoruntilthecharge
indicatorturnsORANGE.

Turnon/offtheSpeaker
PressPOWERON/OFFSWITCHtoONpositiontoturnonthespeaker,orOFFpositiontoturnoffthe
speaker.

PairingyourdevicewiththeSpeaker–
YourBluetoothTailgateSpeakercanstreamwirelessaudiofromanyBluetoothenableddevicewithin
therangeof27‐33Feet.Simplyfollowthebelowsteps.
1. Turnonthespeaker.
2. BlueLEDlightwillbegintoblink.Thespeakerisnowinpairingmode.
3. TurnontheBluetoothonyourMobilePhoneorTabletorComputer.
4. ItwillsearchforavailableBluetoothdevices.
5. BluetoothTailgateSpeakerwouldappearas“SLTAILGATESPK”,inthelistofsearcheddevices.
Selectitfromtheavailablelistofdevices.
6. Ifrequired,enterthepassword‘0000’toconfirmpairing.
7. Oncepairedsuccessfully,theBlueLEDwillstayon.
8. Ifyoufailtopairitwithinafewsecondsoryouwanttopairitwithanewdevice,pleaserepeat
abovesteps.

PlayyourfavoritesongontheBluetoothsourcedeviceandmusicwouldnowstreamthroughthe

5
speaker.

ListeningtoWirelessMusic
Pleaseensurethatyourdevice(iPhone,TabletorOtherSmartPhone)ispairedwiththespeakerto
streamwirelessmusic.Onceitispaired,playmusicfromyourdevice.

FunctionOperationButton
Increase/
DecreaseVolume
PlayingmusicTurnMAINVOLUMEknoblocatedonthecontrolpaneltoadjust
thevolumetoyourdesiredlevel,
or
Adjustvolumefromthesourcedevice.
PausePlayingmusicShortpressPLAY/PAUSEbuttononcetopausemusic
PlayPauseShortpressPLAY/PAUSEbuttononcetoresumemusic

Tips!!
1. ShortpresstheSOURCEbuttontoswitchdifferentfunctionsofthespeaker.Thefunctionsare–
Bluetooth/AUX.
2. Whenthespeakerisnotinuse,turnOFFthedevicetosavethebatterypower.
3. Alwaysusetheadapterincludedwiththepacktochargetheinternalbatteryofthespeaker.
Chargingthroughunauthorizedadaptormaydamagetheproduct,andwillterminateall
warrantyprivilegesinstantly.
4. Donotoverchargethespeaker.

Do’sandDon’ts
•Donotplaymusicatexcessivelevelsasdamagetohearingand/orequipmentmayresult.
•Donotuseoutdoorsinwetorindampsurroundings.

ListeningtoMusicusingAUX‐In
1. Turnonthespeaker.
2. Plugthe3.5mmAux‐incable(included)intotheAUXINportofthespeakerforAUXfunction.
And,theotherendofthecabletotheaudiodevice(suchascomputer/tablet/MP3Player
etc.).
3. PresstheSOURCEbuttontoAUXfunctionuntiltheLEDIndicatorshowspurple.
4. Selectyourfavoritesongatthesourcedevice.
(Note:WhileusingAUXINfunction,functionssuchasplay/pausecanbecontrolledonlythroughyour
sourcedevice).

6

UsingtheMicrophone
1. Turnonthespeaker.
2. InserttheplugoftheMicrophone(notincluded)intotheMICINPUT1or2ofthespeaker.
3. TurnontheMicrophone,andspeakformicrophoneoperationorsingforKaraokeoperation.
4. TurnMICVOLUME(andECHOknob)toadjustthedesiredlevel(andechooutput)respectively.

Careandmaintenance
Cleantheunitwithasoft,drycloth.Neverusechemicalsorhardabrasives.
Keepthisunitawayfromwetordampsurroundings.

ProductSpecifications:
Bluetoothversion :2.1+EDR
Speakeroutput :10Watts
Unitsize :18.8”x11.3”x7.9”
Unitweight :17.9lb
Powersupply  :AC/DCadaptor(Input:AC100‐240V50/60Hz0.5A,Output:DC9V1300mA
centrepositive)
Bluetoothrange :27‐33Feet
Built‐InRechargeableBattery:Li-ion Battery 7.4V, 2000mAh

TROUBLESHOOTING
ProblemPossibleCauseSolution
NopowerAC/DCadapterplugnotconnectedto
thewalloutlet
Plugtothewalloutlet.

Nosound Volumeinminimumposition.

Theconnecteddeviceisnotinplay
mode.

Inputsourceincorrect.
TurnMAINVOLUMEknobtoincrease
thevolume.
Playthemusicintheconnecteddevice
andmakesurethevolumelevelisin
highlevel.
PresstheSOURCEbuttontosetthe
inputsourcetothedesiredfunction.
SounddistortionVolumeleveltoohighTurnMAINVOLUMEknobtodecrease
thevolume.




7
FCCInstructions
Changesormodificationsnotexpresslyapprovedbythepartyresponsibleforcompliancecouldvoidthe
user’sauthoritytooperatetheproduct.
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment .
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.


NOTE:ThisproducthasbeentestedandfoundtocomplywiththelimitsforaClassBdigitaldevice,
pursuanttoPart15oftheFCCRules.Theselimitsaredesignedtoprovidereasonableprotectionagainst
harmfulinterferenceinaresidentialinstallation.Thisproductgenerates,usesandcanradiateradio
frequencyenergyand,ifnotinstalledandusedinaccordancewiththeinstructions,maycauseharmful
interferencetoradiocommunications.However,thereisnoguaranteethatinterferencewillnotoccurin
aparticularinstallation.Iftheproductdoescauseharmfulinterferencetoradioortelevisionreception,
whichcanbedeterminedbyturningtheequipmentoffandon,theuserisencouragedtotrytocorrect
theinterferencebyoneormoreofthefollowingmeasures:
‐  Reorientorrelocatethereceivingantenna.
‐  Increasetheseparationbetweentheproductandreceiver.
‐  Connecttheproductintoanoutletonacircuitdifferentfromthattowhichthereceiverisconnected.
‐  Consultthedealeroranexperiencedradio/TVtechnicianforhelp.

ThedevicecomplieswithPart15oftheFCCRules.Operationissubjecttothefollowingtwoconditions:
(1)thisdevicemaynotcauseharmfulinterference,and(2)thisdevicemustacceptanyinterference
received,includinginterferencethatmaycauseundesiredoperation.

LimitedWarranty
Thismanufacturer'sproductwarrantyextendstotheoriginalconsumerpurchaseroftheproduct.Neitherthe
retailernoranyothercompanyinvolvedinthesaleorpromotionofthisproductisaco‐warrantorofthis
manufacturerwarranty.
WARRANTYDURATION:Allmaterialsandworkmanshiparewarrantedtotheoriginalconsumerpurchaser
foraperiodofninety(90)daysfromtheoriginalpurchasedate.
WARRANTYCOVERAGE:Thisproductiswarrantedagainstdefectivematerialsorworkmanship.Thiswarranty
isvoidiftheproducthasbeendamagedbyaccident,inshipment,unreasonableuse,misuse,neglect,
improperservice,commercialuse,repairsbyunauthorizedpersonnelorothercausesnotarisingoutof
defectsinmaterialsorworkmanship.Thiswarrantydoesn’tcoverthefollowingwhichmaybesupplied
withthisproduct,includingbutnotlimitedto;LCDScreens,glassparts,lenses,bulbsetc.Thiswarrantyis
This equipment should be installed and operated with minimum distance 20cm
between the radiator& your body.

8
effectiveonlyiftheproductispurchasedandoperatedinUSAandCanada,anddoesnotextendtoany
unitswhichhavebeenusedinviolationofwritteninstructionsfurnishedbymanufacturerortounitswhichhave
beenalteredormodifiedor,todamagedproductsorpartsthereofwhichhavehadtheserialnumberremoved,
altered,defacedorrenderedillegible.
WARRANTYDISCLAIMERS:Thiswarrantyisinlieuofallwarrantiesexpressedorimpliedandnorepresentativeor
personisauthorizedtoassumeformanufactureranyotherliabilityinconnectionwiththesaleofourproducts.
Thereshallbenoclaimsfordefectsorfailureunderanytheoryoftort,contractorcommerciallawincludingbut
notlimitedto,negligence,grossnegligence,strictliability,breachofwarrantyandbreachofcontract.Underno
circumstanceswillManufacturer’s/Distributor’smaximumliabilityexceedtheretailvalueoftheproduct.
WARRANTYPERFORMANCE:Duringtheabove90daywarrantyperiod,aproductwithadefectwillbeeither
repairedorreplacedwithareconditionedcomparablemodel(atmanufacturer'soption).Therepairedor
replacementproductwillbeinwarrantyforthebalanceofthe90daywarrantyperiodandanadditional
one‐monthperiod.Nochargewillbeapplicableforsuchrepairorreplacement.
SERVICEANDREPAIR:Ifserviceisrequiredforthisproduct,youshouldfirstcontactMidwestTradingGroup
CustomerServiceatin[email protected]orbycalling1(866)815‐4714,MondaytoFriday10amto6pm
EST.
NOTE:Manufacturercannotassumeresponsibilityforlossordamageduringincomingshipment.Asa
precautionarymeasure,carefullypackagetheproductforshipment,andinsureitwiththecarrier.Besureto
enclosethefollowingdetailswiththeproduct:yourfullname,returnaddressanddaytimephonenumber,a
notedescribingtheproblemyouexperienced,acopyofyoursalesreceiptorotherproofofpurchaseto
determinewarrantystatus.C.O.D.shipmentscannotbeaccepted.
