SOUNDMASTER SCD6500USB User manual

DEUTSCH NEDERLANDS
ENGLISH ESPAÑOL
FRANÇAIS
SCD6500USB

SAFETY PRECAUTIONS
1
ENGLISH
To ensure safe, appropriate use of your personal
CD player, please follow the advice below:
Location
• Do not use the product in extremely hot, cold,
dusty or damp conditions.
• Place the product on a smooth, flat surface.
• Ensure that air is free to circulate through the
product. Do not use it in a poorly ventilated
place, cover it with a cloth or place it on carpet.
• Before using the product, check that its rated
voltage is suitable for your mains supply.
Safety precautions
• When you plug in or unplug the power cord,
always hold the plug rather than the cable.
Pulling the cord could damage it and create a
hazard.
• Always unplug the product from the mains if
you do not intend to use it for an extended
period.
• The On/Off button does not disconnect the
product from the mains power supply. To
disconnect the product from the power supply,
you must unplug the power cord.
• This product should only be used in a horizon-
tal position.
Condensation
• Water droplets or condensation may form
inside the CD player if it is left in a warm,
damp atmosphere.
• The product may not operate correctly if
condensation forms inside it.
• Leave the product in a warm, dry room for 1 to
2 hours to allow the condensation to evaporate.
In the event of a problem, unplug the power cord
and contact a qualified repair technician.
Warning: Ventilation
Your personal CD player has ventilation holes,
which should never be obstructed.
Liquid warning:
Never allow liquids to splash or drip onto the
product. Never place a liquid-filled container
(e.g. vase, jar, etc.) above it.
• The apparatus shall not be exposed to dripping
or splashing liquids, no objects filled with
liquids, such as vases, shall be placed on the
apparatus
• The mains plug is used as the disconnect
device and it shall remain readily operable.
To be completely disconnect the power input,
the mains plug of apparatus shall be
disconnected from the mains.
• The apparatus will be use in open area
• The ventilation should not be impeded by
covering the ventilation openings with items
such as newspaper, table-cloths, curtains etc.
• No open flame sources such as lighted candles
should be placed on the apparatus;
• Attention should be drawn to the environmental
aspects of battery disposal;
• Only use the apparatus in moderate climates.

FUNCTION OVERVIEW
2
ENGLISH
18 19
21
20

FUNCTION OVERVIEW
3
FRONT AND REAR
1. SPEAKER
2. FUNCTION switch
selects the function RADIO, TAPE or CD/AUX
3. VOLUME control
adjusts volume level.
5. STEREO EARPHONE JACK
press once to skip to previous track, press &
hold to search backward.
6. CASSETTE:
press once to skip to next track, press & hold
to search forward.
7. AUX-IN JACK
8. USB PORT
BASS BOOST switch
9. TUNING CONTROL
selects AM/FM stations.
10. BAND switch
selects AM/FM/FM STEREO band
PLAY: starts playback
F.FWD/REW: fast winds / rewinds the tape
STOP/EJECT: stopps the tape and opens the
cassette compartment
PAUSE: interrupts playback
11. >>/>>|
12. FOLDER/ +10
Select the ALBUM or skip the tracks in 10
multiple.
13. |<</<<
14. LCD Display
15. PLAY/ PAUSE, USB
Play or pause playback; Press and hold to
switch in CD mode or USB mode.
16. PLAY MODE
(Repeat mode, Random, Program)
17. STOP
stop playback/ erases a program.
18. TELESCOPIC ANTENNA
19. Battery compartment
20. ON/ OFF Switch
to switch ON or OFF the unit.
21. AC MAINS
inlet for power cord.
Whenever convenient, use the power supply if
you want to conserve battery life. Make sure you
remove the plug from the set and wall outlet
before inserting batteries.
Batteries (not included):
Open the battery compartment and insert eight
batteries, type MONO, R-20, UM-1 or D-cells,
(preferably Alkaline) with the correct polarity as
indicated by the „+“ and „-“ symbols inside the
compartment.
Batteries contain chemical substances, so they
should be disposed of properly.
Incorrect use of batteries can cause electrolyte
leakage and will corrode the compartment or
cause the batteries to burst. Therefore:
�Do not mix battery types: e.g. alkaline with
carbon zinc. Only use batteries of the same
type for the set.
�When inserting new batteries, do not try to
mix old batteries with the new ones.
�Remove the batteries if the set is not to be
used for a long time.
Using AC Power
1. Check if the power voltage, as shown on the
type plate located on the bottom of the set
corresponds to your local AC power supply. If
it does not, consult your dealer or service
centre.
2. Connect the power cord to the AC MAINS
inlet and the wall outlet. Slide the ON/OFF
switch to “ -- ” position.
3. To switch off completely, unplug the power
cord from the wall outlet.
Unplug the power cord from the wall outlet to
protect your set during heavy thunderstorms.
4.
HSILGNE

BASIC OPERATION
4
ENGLISH
Switching on/off: Save energy
Whether you are using mains or battery supply,
to avoid unnecessary energy consumption
always adjust the ON/OFF switch to OFF.
1. To select your sound source, adjust the
FUNCTION selector to RAIDO, TAPE or
CD/ USB.
2. Adjust the sound with VOLUME.
3. To switch off the power, set the ON/OFF
switch to OFF position.
Radio reception
1. Turn the function selector to RADIO.
2. Turn the BAND selector to a desired setting
(FM ST., FM or AM)
3. Rotate the TUNING control to find the desired
stations, the frequency will show on display.
4. If the BAND selector is set to FM ST. and a
station with stereo broadcast is received
accurately.
When you have finished listening, slide the
ON/OFF switch to the OFF position.
−If FM reception is weak, stereo may be indi-
cated but the sound may not be good. In this
case, set the BAND selector to FM to receive
in mono only.
−For FM, pull out the telescopic antenna.
Incline and turn the antenna. Reduce its
length if the signal is too strong (very close
to a transmitter).
−For AM the set is provided with a built-in
antenna so the telescopic antenna is not
needed. Direct the antenna by turning the set
itself.
PLAYING A CASSETTE
1. Select TAPE source.
2. Press STOP/EJECT to open the cassette door.
3. Insert a cassette and close the cassette door.
4. Press PLAY to start playback.
5. To interrupt playback, press PAUSE. To resume, press PAUSE again.
6. by pressing FF or REW on the set, fast winding of the tape is possible in both directions.
7. To stop the tape, press STOP/EJECT.
The keys are automatically released at the end of the tape, except if PAUSE has been
activated.

CD / MP3 / WMA PLAYBACK
5
ENGLISH
This CD-player can play Audio Discs, MP3,
CD-R and CD-RW. Do not try to play CD-ROM,
CDi, VCD, DVD or Computer CD.
1. Slide the FUNCTION selector to CD/USB,
the display becomes active.
2. To open the CD door, press the CD door
at the edge marked OPEN/CLOSE.
3. Insert a CD/MP3, CD-R or CD-RW with the
label side facing up and gently close the
CD door.
4. Press PLAY/PAUSE on the set to start
playback
5. To pause playback, press PLAY/PAUSE.
To resume, press PLAY/PAUSE again.
6. To stop playback, press STOP
NOTE: playback will also stop when
• you open the CD compatment,
• you select RADIO function,
• the CD has reached the end
Selecting a different track
During playback you can use or to
select a particular track.
• If you have selected a track number in the
stop or pause mode, press PLAY/PAUSE
to start playback.
• Press once briefly to advance forward
to the next track, press repeatedly until the
desired track number appears in the
display.
• Press once briefly to return to the
beginning of the current track.
• Press repeatedly to select a previous track.
Fast finding MP3 track
1. Press and hold the FOLDER/+10 key,
the MP3 track will skip in 10 multiple.
2. Press the FOLDER/ +10 key in once,
to select the desired ALBUM.
.
Different play modes: REPEAT
REPEAT: plays the current track continuously.
REPEAT ALL: plays the entire CD continuously.
Programming track numbers
You may store up to 32 tracks in the desired
sequence. If you like, store any track more
than once.
1. In the progam mode, press or for
your desired track.
2. When your chosen track number appears,
press PROGRAM once to store the track.
The display shows PROG and your selected
track number.
3. Repeat steps 1 and 2 to select and store all
desired tracks this way.
4. To play your program, press PLAY/PAUSE
Erasing a program
You can erase the contents of the memory by
• opening the CD door
• selecting RADIO function
• in STOP mode, press the STOP button
twice
Notice for CD-R/CD-RW users:
Depending on the type of CD writer, disc brand
and writing speed, some reading problems
may occur.

PLAY MODE
6
ENGLISH
• PLAY MODE
Press the PLAY MODE button during play. A single track, single folder (MP3 only) or all the tracks can be repeated. Press the
button for the repeat mode as follows:
FOR CD
REPEAT REPEAT ALL REPEAT OFF
FOR MP3
REPEAT REPEAT ALL REPEAT ALBUM REPEAT OFF
REPEAT MODE REPEAT INDICATOR ON DISPLAY
REPEAT SINGLE TRACK REPEAT
REPEAT ALL TRACKS REPEAT ALL
REPEAT CURRENT ALBUM (MP3 only) REPEAT ALBUM
• RANDOM PLAY
You can listen all the tacks in a random order using this function.
1. Press PLAY MODE button until the RANDOM lights up on the LCD.
2. All tracks will start playback in a random order automatically.
3. Press
STOP button to cancel the random mode.
CD PROGRAMMING
Up to 32 tracks can be programmed for disc play in any sequence. Before using, be sure to press the STOP button first.
1. Set in CD mode.
2. Press the PLAY MODE
button. PROG will appear on the LCD display. The PRO--G, "P" and the digits for track
number are displayed and flash.
3. Select a desired track by pressing >>/>>|or |<</<< buttons.
4. Press the PLAY MODE button to store the track into memory.
5. Repeat steps 3 and 4 to enter additional tracks into the memory if necessary.
6. When all the desired tracks have been programmed, press the PLAY/PAUSE button to play the disc in the order you have
programmed.
7. Press the
STOP button to terminate program playing.
- Press the STOP button in twice to erases the programed tracks.
ENGLISH
1. Select the FUNCTION selector to CD/ USB mode
2. Press and hold the PLAY PAUSE/ USB button for 2 secs until the display show "USB"
3. Plug in USB Memory Stick into USB Port
4. Display will show total track number
5. Press
PLAY/PAUSE to start music playing
6. Press or to select tracks
7. Repeat function can be selected identical to CD/MP3 playback
8. Press
STOP to end playback
Note : Due to fast changing IT technology, this unit may not be compatible with some USB or SD/MMC
flash storage device.
* USB support Specification : USB V1.1/V2.0
USB PLAYBACK

MAINTENANCE
ENGLISH
Precautions & General Maintenance
• Place the set on a hard and flat surface so
that the system does not tilt.
• Do not expose the set, batteries or CDs to
humidity, rain, sand or excessive heat
caused by heating equipment or direct
sunlight.
• Do not cover the set. Adequate ventilation
with a minimum gap of 6 inches between
the ventilation holes and surrounding
surfaces is necessary to prevent heat
build-up.
• The mechanical parts of the set contain
self-lubricating bearings and must not be
oiled or lubricated.
• To clean the set, use a soft dry cloth. Do not
use any cleaning agents containing alcohol,
ammonia, benzine or abrasives as these
may harm the housing.
CD AND PLAYER HANDLING
• The Lens of the CD player should never be touched!
• Sudden changes in the surrounding temperature can cause condensation to form and
the lens of your CD player to cloud over. Playing a CD in this condition is impossible.
Do not attempt to clean the lens. Leave the set in a warm environment until the
moisture evaporates.
• Always close the CD door to keep the CD compartment dust-free. To clean, dust the
compartment with a soft dry cloth.
• To clean the CD, wipe in a straight line from the centre towards the edge using a soft,
lint-free cloth. Do not use cleaning agents as they may damage the disc.
• Never write on a CD or attach any stickers to it.
X
7

TROUBLESHOOTING
8
ENGLISH
If a fault occurs, first check the points listed below before taking the set for repair.
Do not open the set as there is a risk of electric shock.
If you are unable to remedy the problem by following these hints, call service and support at the
phone number shown below.
Warning :
Under no circumstances should you try to repair the set yourself, as this will invalidate the
warranty
Problem Cause Solution
No sound / power
Volume not adjusted Adjust the Volume
Power cord not securely connected Connect the AC cord properly
Batteries dead / incorrectly inserted Insert (fresh) batteries correctly
Display does not function properly /
No reaction to operation of any of the
controls
Electrostatic discharge Switch off and unplug the cord. Reconnect
after a few seconds
Dust and dirt on the head, etc. Clean deck parts , etc.
The CD skips tracks CD damaged or dirty Replace or clean CD
Program is active Quit program mode
No disc indication
No CD inserted Insert a CD, CD-R or CD-RW
CD badly scratched or dirty Replace or clean CD
Laser lens has steamed up Wait until lens has cleared
CD-R is blank or the disc is not finalized Use a finalized CD-R
CD Playback does not work
CD badly scratched or dirty Replace or clean CD
Laser lens steamed up Wait until lens has adjusted to room
temperature
Poor cassette sound quality

SPECIFICATIONS
9
ENGLISH
GENERAL
Power Supply: AC 230V~50Hz
Battery Operation: 12V DC (8x 1,5V Type UM-1 / R-20 / D-CELL / MONO)
Power consumption: 25 W
Dimensions of unit: 380(w) x 17 (h) x 2 (d) mm
Weight: ,80 kg
Frequency range: AM 5 - 16 0kHz
FM 87.5 - 108 MHz
AUDIO
Output power: 2x 3WRMS
Speaker: 8 Ohms
COMPACT DISC
Frequency range: 125 Hz - 20.000 Hz
CASSETTE RECORDER
Frequency range: 125 Hz - 6.300 Hz
MP3 PLAYER
Format: ISO9660
Bitrate: 8 - 320 kBit/s
MP3 and WMA compatible
SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE
Disposal of old electrical appliances
The European Directive 2002/96/EC on Waste Electrical and
Electronic Equipment (WEEE), requires that old household electrical
appliances must not be disposed of in the normal unsorted municipal
waste stream. Old appliances must be collected separately in order
to optimise the recovery and recycling of the materials they contain
and reduce the impact on human health and the environment.
The crossed out ‘wheeled bin’ symbol on the product reminds you
of your obligation, that when you dispose of the appliance it must
be separately collected.
Consumers should contact their local authority or retailer for
information concerning the correct disposal of their old appliance.
638
2
2
22.5
