SOUNDMASTER MCD 211 User manual

REMOTE
CONTROL
DBBS
SUPER BASS
BOOSTER
soundmaster
®
BEDIENUNGSALEITUNG
Modell: MCD 211
Bitte vor Inbetriebnahme sorgfältig durchlesen !

ENG-2
WARNING: To reduce
the risk of electric shock, do
not remove cover (or back).
No user-serviceable
parts inside. Refer
servicing to qualified
service personnel.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The exclamation
point within the
triangle is a warning
sign alerting you of
important instructions
accompanying the
product.
The lightning flash
and arrowhead
within the triangle
is a warning
sign alerting you of
"dangerous voltage"
inside the product.
CAUTION
DO NOT EXPOSE TO DRIPPING OR SPLASHING LIQUIDS!
NOTE: CAUTION SYMBOLS ARE PRINTED ON BOTTOM OF UNIT.
PLEASE REFER TO INSTRUCTION MANUAL.
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS APPLIANCE TO DRIPPING OR SPLASHING LIQUIDS.
CLASS 1 LASER PRODUCT
KLASSE 1 LASER PRODUKT
LASER DE CLASSE
LASER DI PRIMA CLASSE
KLASSE 1 LASER
LASER PRIMERA CLASE
LASER CLASSE 1
KLASSE 1 LASER PRODUKT
CAUTION: INVISIBLE LASER RADIATION WHEN OPEN AND
INTERLOCKS DEFEATED. AVOID EXPOSURE TO BEAM.
VORSICHT: UNSICHTBARE LASERSTRAHLUNG TRITT AUS,
WENN DECKEL GEÖFFNET UND WENN SICHERHEITSVERRIEGELUNG
ÜBERBRÜCKT IST. NICHT DEM STRAHL AUSSETZENI.
VARNING: OSYNLIG LASERSTRÁLNING NÄR DENNA DEL ÄR ÖPPNAD OCH
SPÄRR ÄR URKOPPLAND. STRÁLEN ÄR FARLIG.
ADVARSEL: USYNLIG LASERSTRÁLING VED ÁBNING. NÁR
SIKKERHEDSAFBRYDERE ER UDE AF FUNKTION. UNDGÁ UDS/ETTELSE FOR
STRÁLING.
ATTNENZIONE: RADIONS LASER INVISIDILE. NON GUARDARE
DIRETTAMENTE NELLA SORGENTE DEL LASER.
ACHTUNG: LASERLINSE NICHT BERÜHREN UNSICHTBARER LASERSTRAHL.
AVISO: A LENTE NUNCA DEVE SER TOCADA.
CAUTION: GROUNDING OR POLARIZATION. THE PRECAUTIONS
SHOULD BE TAKEN SO THAT THE WIDER BLADE OF THE AC PLUG
MUST MATCH THE SLOT IN RECEPTACLE "WALL SOCKET".

1. RADIO BAND SWITCH (AM/ FM/ FM ST.) &
DBBS ON/OFF SWITCH
2. FUNCTION SWITCH (OFF/ CD/ RADIO)
3. VOLUME DOWN KEY
4. VOLUME UP KEY
5. REMOTE CONTROL SENSOR
6. FM-STEREO LED LIGHT
7. DBBS LED LIGHT
8. LCD DISPLAY
9. CD "BACK" KEY
10. CD "PLAY/PAUSE" KEY
11. CD "NEXT" KEY
12. CD "REPEAT" KEY
13. CD "STOP" KEY
14. CD "PROGRAM" KEY
ENG-3
LOCATION OF CONTROLS
15. RADIO TUNING KNOB
16. SPEAKER (LEFT)
17. SPEAKER (RIGHT)
18. FM-ANTENNA WIRE
19. HEADPHONE SOCKET
20. SPEAKER OUTPUT SOCKETS
(LEFT & RIGHT)
21. AC-CORD & PLUG
22. CD DOOR FINGER-GRIP
23. CD DOOR
24. CD "RANDOM" KEY
(ON REMOTE CONTROL)
25. BATTERY COMPARTMENT
(ON REMOTE CONTROL)
18
19
20
21
1
2
3
4
5
9
12
13
14
10
11
15
22
23
16 17
6
7
8
10
25
14
REMOTE CONTROL
9
12
13
11
24

ENG-4
THE BUILT IN "SUPER BASS BOOSTER" CIRCUIT PROVIDES A POWERFUL
ENHANCEMENT TO LOW FREQUENCY MUSIC, GIVING A STRONGER BASS
SOUND WHICH IS IDEAL FOR "ROCK" OR "JAZZ" MUSIC.
SUPER BASS (DBBS) FUNCTION
CONNECTION OF SPEAKER BOXES
- UNWRAP THE SPEAKER-CORDS OF BOTH SPEAKER-BOXES AND INSERT THE
LEFT/RIGHT PLUGS INTO SOCKETS IN THE REAR OF MAIN UNIT.
- PLACE THE SPEAKER BOXES AS FAR APART AS POSSIBLE FOR BEST SOUND
EFFECT.
POWER SUPPLY
- THIS SET WORKS ON NORMAL HOUSEHOLD AC-POWER.
- MAKE SURE THE SET VOLTAGE OF THE UNIT MATCHES YOUR LOCAL VOLTAGE.
- INSERT THE PLUG OF THE AC-CORD INTO A WALL OUTLET WITH AC-POWER.
TO SWITCH ON THE POWER TO THE SET, SLIDE THE FUNCTION
SWITCH TO "CD" OR "RADIO".
- IMPORTANT- HOW TO SWITCH POWER "ON"
- SET THE FUNCTION SWITCH TO "RADIO".
- SET THE RADIO BAND SELECTOR SWITCH TO THE DESIRED BAND.
- ROTATE TUNING KNOB TO TUNE-IN THE DESIRED STATION, AS DISPLAYED
IN THE LCD DIGITAL DISPLAY.
- ADJUST THE VOLUME TO THE DESIRED LEVEL.
- TO IMPROVE FM-RADIO RECEPTION, FULLY EXTEND THE FM-ANTENNA WIRE
AND ADJUST IT'S POSITION.
- TO IMPROVE AM (MW) RADIO RECEPTION, ROTATE OR RE-POSITION THE
MAIN UNIT.
OPERATION OF RADIO

NORMAL CD OPERATION
- INSERT A CD AS DESCRIBED. SET THE FUNCTION SWITCH TO "CD".
- ONCE THE CD-DOOR IS CLOSED (WITH A DISC INSIDE) THE SET WILL
IMMEDIATELY READ THE DISC AND DISPLAY THE NUMBER OF SONGS
(TRACKS) ON THE CD.
- THE DISK WILL START SPINNING AND THE FIRST SONG (TRACK) WILL START
PLAYING. THE DISPLAY WILL INDICATE THE CURRENT TRACK NUMBER.
("001" IF IT IS THE FIRST TRACK).
- AT ANYTIME DURING PLAYBACK, PRESS THE "STOP" KEY TO STOP
OPERATION OF THE SET. THIS WILL RESET THE SET TO THE FIRST TRACK
(IF YOU PRESS PLAY AFTER STOP, THE FIRST TRACK WILL ALWAYS START
PLAYING).
- AT ANYTIME DURING PLAYBACK, "PRESS AND RELEASE" THE BACK/NEXT
KEYS : OR TO SKIP BACKWARDS OR FORWARDS BY ONE
TRACK, AS DESIRED.
- AT ANYTIME DURING PLAYBACK, PRESS THE "CD REPEAT KEY" AS FOLLOWS:
PRESS ONCE = TO REPEAT THE CURRENT TRACK
(REPEAT SYMBOL LIGHT WILL "FLASH")
PRESS TWICE = TO REPEAT ALL TRACKS (FULL CD)
(REPEAT SYMBOL LIGHT WILL STAY "ON")
- AT ANYTIME DURING PLAYBACK, PRESS THE "PLAY/PAUSE" KEY TO
PAUSE OPERATION OF THE UNIT. PRESS PLAY/PAUSE KEY TO RESUME
OPERATION AT THE SAME TRACK AND POSITION.
ENG-5
INSERTION & REMOVAL OF DISCS
- WHEN OPENING THE CD-DOOR, ALWAYS ENSURE THE DISC IS NOT IN
MOTION (NOT SPINNING) WHEN YOU OPEN THE CD-DOOR.
ALWAYS PRESS "STOP" BUTTON TO STOP THE DISC SPINNING FIRST.
- PLACE A CD INTO THE COMPARTMENT WITH THE LABEL-SIDE (PRINTED
SIDE OF DISC) FACING UPWARDS. PRESS DOWN IN THE CENTER PART OF
DISC UNTIL THE DISC "LOCKS" ONTO THE CENTER SPINDLE.
- WHEN THE CD HAS BEEN PLACED ONTO THE CENTER SPINDLE, GENTLY
LOWER THE CD-DOOR DOWNWARDS UNTIL IT LOCKS SHUT.
- THE CD IS NOW READY TO BE PLAYED.
- TO REMOVE A DISC, FOLLOW THE SAME PROCEDURE AS DESCRIBED
ABOVE, EXCEPT TO REMOVE THE CD INSTEAD OF INSERTING IT INTO THE
COMPARTMENT, BY PLACING ONE FINGER AT THE MIDDLE OF DISC
(CENTER SPINDLE) & THE OTHER AT THE EDGE OF THE DISC & GENTLY
PULLING UPWARDS.
- IMPORTANT : ALWAYS HOLD A CD BY ITS EDGES. AVOID GETTING ANY
FINGER PRINTS, SMUDGES OR DIRT ONTO THE SURFACE OF A DISC.
IN CASE THIS HAPPENS, USE A SPECIAL CD-CLEANING CLOTH OR
CLEANING KIT TO REMOVE THE DIRT OR SMUDGES.

- THE CD PLAYER CAN BE PROGRAMMED TO PLAY ANY SEQUENCE OF UPTO 20 TRACKS,
AS DESIRED.
- ALWAYS PRESS THE STOP KNOB BEFORE STARTING THE PROGRAMMING.
- PRESS THE PROGRAM KNOB, THE DISPLAY WILL SHOW A FLASHING SYMBOL
AND THE DISPLAY WILL SHOW “ ” (FLASHING), TO INDICATE THAT THE SET IS
NOW IN "MEMORY PROGRAMMING MODE", AT MEMORY POSITION NO. 1.
- PRESS THE NEXT/BACK KNOBS OR TO SELECT THE TRACK (SONG) NUMBER
YOU WISH TO BE STORED IN THE FIRST MEMORY (PROGRAM) POSITION, AND PRESS
THE PROGRAM KNOB TO CONFIRM YOUR SELECTION.
- WHEN YOU PRESS PROGRAM KNOB THE DISPLAY WILL ADVANCE TO THE NEXT
MEMORY POSITION NUMBER (EG. “ ” FOR 2ND POSITION).
- REPEAT THE PREVIOUS 2 STEPS, EACH TIME SELECTING ANY TRACK NUMBER OF
YOUR CHOICE TO BE STORED IN THE SUCCESSIVE MEMORY (PROGRAM) POSITIONS.
- AFTER EACH TRACK NUMBER, REMEMBER TO PRESS THE PROGRAM KNOB.
- AFTER A MAXIMUM OF 20 SONGS (OR LESS) HAVE BEEN SELECTED AS DESCRIBED
ABOVE, PRESS THE PROGRAM KNOB.
- ALSO, THE SYMBOL WILL REMAIN "ON" TO INDICATE THAT YOU
HAVE SAVED A PROGRAM-MEMORY (SEQUENCE).
- PRESSING PLAY WILL NOW PLAY BACK THE "SAVED SEQUENCE" IN
THE PROGRAM MEMORY.
- PRESSING NEXT/ BLACK WILL MOVE TO THE NEXT OR PREVIOUS SONG
IN THE SAVED SEQUENCE.
- TO CLEAR (CANCEL) THE ENTIRE PROGRAM WHICH IS STORED IN THE MEMORY,
SIMPLY PRESS "STOP" , OR SWITCH "OFF" THE SET.
PROGRAMMING THE CD-PLAYER
P
P01
P02
P
ENG-6
SPECIFICATIONS
POWER SUPPLY : ......................................... AC 230V ~ , 50 Hz
POWER CONSUMPTION : ............................. 15W
SPEAKER : ..................................................... 3" x 2
FREQUENCY : ............................................... AM 522 - 1600 kHz
FM 87.5 - 108 MHz
THE APPARATUS SHOULD NOT BE EXPOSED TO DRIPPING OR SPLASHING
AND NO OBJECTS FILLED WITH LIQUIDS SHOULD BE PLACED ON THE
APPARATUS.
