Soundstream REFERENCE R3.8 User manual

2013
REFERENCE
SUBWOOFERS
R3.8 R3.10 R3.12 R3.15

Thank you for choosing SOUNDSTREAM woofers. Designed and engi-
neered in the USA, this product combines innovative technology with
the finest materials to consistently deliver Absolutely State of the Art
performance, sound quality, reliability, and value. This SOUNDSTREAM
product reflects our commitment to offer you unparalleled perfor-
mance and quality for years of dependable service and listening en-
joyment.
Pressed Paper Pulp Cone
High Roll Foam Surround
2.5” 4-layer VC on Aluminum Former
Nickel Plated 8ga. Compression Terminals
Poly-Cotton Suspension Spider
Vented T-Yoke Back-plate
Woven Fiber Dust Cap
Textured Basket with Voice Coil Cooling
Features, Parameters, & Dimensions
www.SOUNDSTREAM.com
Impedance dual 2ohm dual 2ohm dual 2ohm dual 2ohm
Re2.2122 2.1802 2.1672 2.2146
Fs(hz) 39.0485 34.58 33.72 31.38
Qes 1.3713 1.2530 1.1741 1.3086
Qms 7.1915 7.3411 6.2245 5.3272
Qts 1.1517 1.0703 0.9878 1.0505
le(mh) 0.9283 1.0274 0.9794 1.0310
dIam 8Inch 10Inch 12Inch 15Inch
sd50.2655 In^2 78.5398 In^2 113.097 In^2 176.7146 In^2
Vas 18.3920 33.3893 59.8989 296.8294
Bl7.3081 9.3526 10.4883 7.3069
mms 134.9398 231.3417 281.2842 160.0019
sen 80.77 82.17 84.66 90.20
Rms/max 700/1000 1000/1200 1200/2500 1400/3000
cutout d. 7.8Inch 9.6Inch 11.6Inch 14.5Inch
mount d. 5.25Inch 6Inch 6 7/8 Inch 7 5/8 Inch
R3-8 R3-10 R3-12 R3-15

Enclosure Construction
Enclosure Dimensions
Enclosure Recommendations
www.SOUNDSTREAM.com
Included in this manual are a number of different enclosure sugges-
tions. These are by no means the only enclosures to use, but they
provide a starting point to determine the correct enclosure for your
needs many factors must be addressed (amount of power, vehicle,
placement, crossovers, etc) Therefore, as always, SOUNDSTREAM
recommends that your subwoofer be installed by an authorized
SOUNDSTREAM dealer.
All enclosures should be made of .75” (3/4”) material only. When pos-
sible, make the baffle 1.5” (1 ½) thick and add .75” (3/4”) to the depth
of the enclosure to compensate. All volumes INCLUDE vent/port and
subwoofer displacements. DO NOT change the volume unless you
plan on adding a substantial amount of bracing. For added per-
formance, applying a coat of fiberglass resin to the interior walls will
greatly improve sealing the enclosure. Adding a thin layer of poly-fill
will improve response by smoothing out reflections within the enclo-
sure.
sealed R3-8 R3-10 R3-12 R3-15
mIn .50 cu Ft. .75 cu Ft. 1.0 cu Ft. 1.5 cu Ft.
optImum .75 cu Ft. 1.0 cu Ft. 1.5 cu Ft. 2.75 cu Ft.
poRted
mIn 1.0 cu Ft. 1.0 cu Ft. 1.5 cu Ft. 2.0 cu Ft.
poRt Wxl 3” x7” 3”x5.5” 4”x5” 5”x7.8”
F3 (hz) 35 34 38 30
optImum 1.25 cu Ft. 1.5 cu Ft. 2.25 cu Ft. 2.75 cu Ft.
poRt Wxl 4” x6.7” 4” x6” 6” x7” 6” x7”
F3 (hz) 33 32 34 28
