Source WXP LP Manual

3
Contents
Did you know? ..................................................................4
Filling the reservoir ..........................................................6
Drinking with HELIX-Valve™ ............................................8
Drinking with STORM-Valve .......................................... 10
Rinsing before first time use ........................................ 12
Care: Drying system ...................................................... 14
Care: Cleaning the Reservoir ........................................ 16
Care: Cleaning Helix Tube and Valve ........................... 18
HELIX- Valve™ Secondary Disassembly ....................... 20
Care: Cleaning STORM Tube and Valve ........................ 22
STORM- Valve™ Secondary Disassembly ..................... 24
Replacing the Drinking System .................................... 26
Tips ................................................................................. 28
Connectivity and accessories ........................................ 30
Contents

4
Did you know?
(a short course on Hydration and Dehydration)
Water is essential:
Water is essential even if you are just breathing. But
when exercising, it is especially vital.
During prolonged or strenuous exercise you can easily
sweat away over 1 liter of water an hour.
(The amount also depends on local climate and
conditions.)
Drinking replenishes that sweat loss!
You are what you drink:
Even slight dehydration can cause fatigue, dizziness,
reduced muscle endurance, headaches, and cramps.
In fact, prolonged dehydration is downright
dangerous to your health!
The cooler, the better:
Fluid replacement in your body works better if the
liquid you drink is cooler (15-22ºC or 59-72F).
The faster, the better:
Reducing the gap between the time you lose water
and replenish water loss ensures that your body
has all the water it needs to function at peak level.
Quick, easy access to a reliable, refreshing source of
H2O is the key.
As a rule:
Your body needs 1 liter (33 oz) of water for every hour
of intensive outdoor activity.

5
Why your drinking water should be
obtained from a highly reliable Source?
Bacteria, molds, yeasts and algae are facts of life.
Bacteria and grunge grow by clinging to a surface
and creating a bio-film that allows them to flourish.
A liquid container with a smooth contact surface
such as glass reduces the ability of bio-film to
form. There are no irregularities on the surface for
bacteria to cling to and the regular flow of water
self-cleans the container.
Source has developed a unique plastic
film that has a Glass-Like™ surface and
features Grunge-Guard™ technology
Glass-Like™ is a unique property of the surface
of the inner walls of the reservoir. The surface is
nearly as smooth as glass and prevents build up of
Bio Film in the reservoir.
On top of that, source was the first to initiate
Grunge-Guard™ technology. Utilizing an FDA-
approved and EPA-registered anti microbial agent
embedded into all films and tube liners, Grunge
Guard™ eliminates bacteria growth on the tube and
reservoir surfaces.
The synergy of Glass-Like™ and Grunge-Guard™
gives double protection against bacteria growth and
will assure the freshness of the water for the entire
life of the system.
Your drinking water stays fresh,
odor and taste-free for days,
even weeks!
Did you know?

6
Filling the reservoir
FIRST USE: Before drinking it is strongly recommended
to rinse the reservoir with water and drain it through
the tube and valve. Follow the instructions for filling
and operating the valve BUT DON'T DRINK YET.
Before drinking you will be instructed how to drain the
water you filled in the resrevoir.
1. To fill: Open Filler-Cap.
2. Grasp integrated Refill-Handle and fill reservoir
(drawing 1).
The reservoir is designed to store cold as well as
warm drinks (up to 60ºC or 140ºF). You may add ice
for cold drinks, or even freeze water in the reservoir
overnight (only 3/4 full).
3. Close Filler-Cap and tighten for airtight seal.
4. In our integrated hydration systems, the reservoir
is stored inside the pack. Filling in these models is
done without taking the reservoir out of the pack:
just open the Filler-Cap, grasp the handle as shown
in drawing 2 and fill.
CAUTION Do not fill with boiling water.
NOTE Turn pack upside down and suck out
excess air from the reservoir to silence
your pack (stealth mode) and increase
the period for which water remains
fresh and taste-free.

7
Filling the reservoir
1
2

8
Operating HELIX-Valve™
If your system is equipped with STORM-Valve™, see p. 10
1. First time use: Remove hygienic shrink-wrap from
Helix-Valve™.
2. Unlock valve from shut-off position by turning
mouthpiece 180º counter-clockwise until it locks in
OPEN position (drawings 3 and 4).
3. Now you know how to operate the valve, it's
time to drain the first water you have filled in the
reservoir. Go to page 12 to see how it's done and
continue from here:
4. Drinking: To drink, bite lightly on the Helix-Valve™
groove and sip (drawing 5).
5. To close the valve,turn mpiyjpiece 180º clockwise
until it locks in CLOSED position.
6. When not in use, cover Helix-Valve™ with the
DIrt-Shield™ (available in most of the models)
Notes
To get maximum flow, bite only slightly on the
biting zone. Strong biting will result in blocking
the valve orifice and no liquid will flow.
Tips To avoid the first warm sip in hot weather:
after drinking, bite lightly on Helix-Valve™
for a couple of seconds while keeping
your lips apart to let air into the tube.
Liquid remaining in the tube returns to the
reservoir.

9
Dirt-Shield
biting
groove
angled
valve-tube
fitting
valve in CLOSE position
valve in OPEN position
Drinking with HELIX-Valve™
4
3
5
Dirt-Shield

10
Operating STORM-Valve
1. Remove hygienic shrink-wrap from STORM-Valve™
2. Unlock valve from LOCKED position by turning
mouthpiece 90º counter-clockwise (drawing 6).
3. Open the valve (drawing 7) by pulling the rubber
mouthpiece.
4. Now you know how to operate the valve, its
time to drain the first water you have filled in the
reservoir. Go to page 12 to see how it's done and
continue from here:
5. Drinking: To drink, sip as with a straw.
6. To close the valve, push in the mouthpiece.
7. To lock the valve when closed, turn mouthpiece 90º
clockwise (drawing 6)
8. When not in use, cover STORM-Valve™ with the
DIrt-Shield™ (drawing 8) (available in most of the
models)
Note In the lock/shut-off position, the grooves
on the rubber mouthpiece are aligned
with the dots on the valve’s housing. In
the dark, use your fingers to verify that
the valve is in the secure lock position.
Tip Pull/Push Valve can be operated by hand
or by mouth.

11
Dirt-Shield
UNLOCKED
LOCKED
CLOSE
OPEN
Drinking with STORM-Valve™
6
7
8

12
Rinsing before first time use
HELIX Valve™:
1. To rinse the the resevoir before first time use:
Turn the valve to OPEN position (drawing 4)
2. Roll the reservoir from the closure downto creatre
pressure in the reservoir.
3. Pinch the drinking groove between your index and
thumb and let the water flow through the valve.
(drawing 8a)
4. Drain at least a third of the capacity of the reservoir
(if you have a 3L reservoir, drain at least 1L).
You can drink now. See drinking in page 8, parag. 4.
STORM Valve™:
1. To rinse the the resrevoir before first time use:
Turn the valve to OPEN position (drawing 7)
2. Roll the reservoir from the closure down and let the
water flow through the valve. (drawing 8b)
3. Drain at least a third of the capacity of the reservoir
(if you have a 3L reservoir, drain at least 1L).
You can drink now. See drinking page 10, parag. 5.
Tip If your resevoir is inside a pack, instead
of rolling, you can inflate the reservoir by
blowing air through the valve in addition
to the water, then apply your weight on
the pack and let the water flow and rinse
the system.

13
8a
8b
Rinsing before first time use

14
Care: Drying system
During regular use with drinking water, there is no
need to drain, dry, or clean your hydration system.
Simply refill and drink again and again without special
care.
As long as your drinking water is not exposed to direct
sunlight, the same water in your drinking system will
remain fresh for days and even weeks. If you are using
energy drinks or sweetened liquids, we recommend
that you follow the cleaning instructions after every
usage.
To Dry Drinking System:
1. Turn the valve to OPEN position (this will allow air
circulation through the tube).
Open reservoir by sliding Widepac™-Closure off
sideways and unfold the top. (drawing 9)
2. Drain reservoir completely and hang it upside down.
(drawing 10)
3. To speed drying time: fold the tube and tuck it into
the reservoir. (drawing 11)
You may also use paper towels to dry reservoir.
4. When dry, fold top and close reservoir’s wide
opening and slide back Widepac™ Closure.
5. Storing Drinking System:
6. Dry drinking system as described above.
7. Store in a clean and dry place.

15
Note Before prolonged storage, we recommend
that you also follow the cleaning
instructions on page 16.
Tips After prolonged storage, rinse reservoir
with water and a few drops of lemon juice.
Care: Drying system
9
11
10

16
Care: Cleaning the Reservoir
It is recommended to wash the reservoir if it was filed
with liquids other than water (such as sweetened
beverages) or before prolonged storing.
To clean the reservoir:
1. Disconnect the tube: push the release button of the
QMT connector. (drawing 12). OR: If your system is
not equipped with QMT connector, firmly pull and
twist it away from its connector (drawing 13).
2. Slide off Widepac™ closure for wide opening access.
(drawing 1)
3. Wash reservoir with soapy water (drawing 14).
If necessary scrub with a soft brush. Rinse well.
CAUTION Never use boiling water.
Do not scrub reservoir with
abrasive materials.
4. Dry reservoir completely as detailed in page 14:
(drawing 10), slide the wideslide back (drawing 11).
5. Reconnect the tube and store the system in a dry
place.
6. If necessary, proceed to clean the tube and valve:
• page 13: HELIX™ valve
• page 15: STORM™ valve

17
Care: Cleaning the Reservoir
12
13
14
SQC™ connector

18
Care: Cleaning Helix Tube and Valve
Leave the valve connected to the tube and the tube
connected to the reservoir, even if your model allows
quick disconnection with QMT connectors.
To disassemble and clean the HELIX valve™:
1. To disassemble helix-valve™: turn the valve counter
clockwise 90º halfway opened: align the central notch
on the the rim of the mouthpiece with the arrow on the
valve's neck and pull apart (drawing 15).
2. Wash with mild soapy water and rinse several times.
3. To clean the tube, Proceed with #4 below.
If you don't clean the tube, proceed with #6 below.
To clean the tube:
4. Leave the tube connected to the reservoir and the
valve disassembled. Hold your thumb on the open
extremity of the tube, fill the reservoir with water
and close with the wideslide closure.
5. Fold the reservoir from the top down and let the
water flow through the tube (drawing 16).
6. Re-assemble the two parts of the HELIX-Valve™:
Align the central notch with the arrow, push the
mouthpiece slightly on its track and turn 90º clockwise
to CLOSED position.

19
drawing 10
1. Turn 90º counter clockwise
3. Pull apart
Care: Cleaning Helix Tube and Valve
2. Align
central notch
and arrow
15
16

20
HELIX- Valve™ Secondary Disassembly
This should be performed only if Helix-Valve™
is severly soiled.
To disassemble the HELIX-Valve™:
1. Set Helix-valve™ to OPEN position
2. Operate carefully: Pull the silicone tip firmly away
from the valve, (drawing 17).
Attention! make sure you do not loose the
springed pin (A)
To Re-assemble the Helix-Valve™:
1. Insert the springed pin (A) in its base (B)
2. Adjust the rim of the silicon tip on the base
3. Push the tip firmly in its place. Make sure it goes all
the way until the rim of the silicon tip is against the
rim of the base (C). (drawing 18).

21
AB
C
RIGHT WRONG
HELIX-Valve™ Secondary Disassembly
17
18
