Southwestern Bell 2-9193 User manual

2-9193
InLine®Plus
Caller ID on Call Waiting
Speakerphone
Use and Care Guide
Southwestern Bell
1
2
3
4
5
6
7
8
9
10
FLASH
PHONENO.
AREACODE
HOLD SPEAKERPHONEREDIAL
MEMDIAL
VOLUMESTOREMENUDIAL OPTIONS
DELETEREVIEWDIAL
NEWCALL NEWMESSAGE
1 2 3
4 5 6
7 8 9
0 #
*
ABC DEF
GHI JKL MNO
RSTUV YZ
PO WX
TONEOPER

2FCC NUMBER IS LOCATED ON THE CABINET BOTTOM
REN NUMBER IS LOCATED ON THE CABINET BOTTOM
SAFETY INFORMATION
1. Read all instructions in this manual.
2. Observe all warnings and instructions marked on your
product.
3. Do not use your product near water, or when your hands are
wet. If the product comes into contact with any liquids, immediately
unplug the power supply. Do not plug your product back in until you
have thoroughly wiped it dry.
4. Unplug your product from all telephone jacks before cleaning.
Clean exposed areas with a soft, damp cloth. DO NOT USE LIQUID
OR AEROSOL CLEANERS TO CLEAN THIS PRODUCT.
5. Install the product in a secure location, where no one will step
or trip over the phone line or power cord.
6. Do not place objects on the phone or power cords which may
damage them.
7. If the product is not operating normally or if it is damaged,
please refer to the Limited Warranty. In all instances, do not
open the plastic housing. This may expose you to dangerous
electrical shock and other risks. Opening the plastic case will void
your warranty.
8. During thunderstorms, avoid using telephones except cordless
ones. The chances of electric shock from lightening does exist.
9. Never touch uninsulated telephone wires or terminals unless
the telephones lines have been disconnected.
10. Do not overload wall outlets and extension cords as this can
result in electrical shock.
Save these instructions

3
WARNING: TO PREVENT FIRE
OR ELECTRICAL SHOCK HAZARD,
DO NOT EXPOSE THIS PRODUCT
TO RAIN OR MOISTURE.
SEE MARKING ON BOTTOM / BACK OF PRODUCT
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
THE EXCLAMATION
POINT WITHIN THE
TRIANGLE IS A
WARNING SIGN
ALERTING YOU OF
IMPORTANT
INSTRUCTIONS
ACCOMPANYING
THE PRODUCT.
THE LIGHTNING
FLASH AND ARROW-
HEAD WITHIN THE
TRIANGLE IS A
WARNING SIGN
ALERTING YOU OF
"DANGEROUS
VOLTAGE" INSIDE
THE PRODUCT.
CAUTION: TO REDUCE THE
RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER
(OR BACK). NO USER-
SERVICEABLE PARTS IN-
SIDE. REFER SERVICING
TO QUALIFIED SERVICE
PERSONNEL.
TABLE OF CONTENTS
SET UP............................................... 4
INSTALLATION ......................................4
WALL MOUNT INSTRUCTIONS ........... 5
SETTING UPYOUR UNIT .......................6
FACTORY PRESETS .............................6
FEATURES ............................................ 8
USING THE PHONE ............................. 10
PULSE AND TONE DIALING ..................10
RECEIVING APHONE CALL ..................10
PLACING APHONE CALL .....................10
SPEAKERPHONE BUTTON .....................10
DURATION COUNTER ..........................11
TONE BUTTON ..................................11
AUTOMATIC MEMORY ......................... 12
TOSTORE APHONE NUMBER IN
MEMORY: ...................................12
TODIAL APHONE NUMBER IN
MEMORY: ...................................12
VOLUME BUTTON ..............................12
REDIAL BUTTON ................................13
HOLD BUTTON ..................................13
FLASH BUTTON ..................................13
CALL WAITING DISPLAY ......................13
USING THE CALLER ID FUNCTION ........ 14
MESSAGE LIGHT .................................14
MESSAGE WAITING .............................14
IFYOUR SERVICE IS FSK: .................14
RECEIVING CALLS ...............................15
IFYOU ARE IN AN AREA WHERE AN FSK
SIGNAL IS NOT AVAILABLE: ............15
REVIEWING CALLS ..............................16
DELETING CALLS ...............................16
CALLBACK .........................................17
DIAL OPTIONS BUTTON ..................18
MESSAGE ERROR ................................19
FORWARD CALL ..................................19
TOLL CALL .......................................20
NODATA SENT ..................................20
PRIVATE CALLS ..................................20
UNKNOWN CALLS ...............................21
GENERAL PRODUCT CARE .................... 21
QUESTIONS AND TROUBLESHOOTING ..... 22

4
SET UP
1. Connect the adapter. Plug the large part of the adapter into the wall
outlet and the adapter tip to the jack at the rear side of unit. (Use only
9V DC, 300mA, Center negative Class 2 adapter.)
2. Connect the telephone line cord.
A. To connect without an answering machine.
• Take the new line cord supplied to connect the PHONE jack of
your new caller ID phone to the modular wall jack.
1
2
B. To connect with an existing answering machine.
• Use the existing line cord supplied to connect the LINE jack of
your answering machine to the wall modular line jack.
• Take the new line cord supplied to connect the telephone’s
jack of your new caller ID phone to the PHONE jack of your
answering machine.
• Set your answering machine to answer the phone after 2 or
more rings.

5
3. Follow the procedure "Setting Up Your Unit ” to set up your unit.
4. Place the unit on a flat table or mount it onto a wall. If you desire to
place it onto a wall, please use the wall mount bracket and short line
cord supplied to accomplish the wall mounting.
3
Speaker Volume Low Med Hi Ringer Off Hi Low Pulse Tone
2
1
H
O
VOLUM
DE
L
NEW
C
*
GH
RS
PO
TO
N
Handset
Hook
4
WALL MOUNT INSTRUCTIONS
1. Remove wall mount bracket and route cords as shown in diagram
below.
2. Connect the adapter and the line cord. See Steps 2 & 3 on preceding
page for specific instructions.
3. Rotate the handset hook, plug the coiled cord into the handset, and
then plug the other end of the cord into the base.
4. Place the handset on the base.

6
SETTING UPYOUR UNIT
FACTORY PRESETS
The following table shows you the factory settings for your unit:
Display Setting
Language English
LCD Contrast 1
Area Code no setting
LDS Code 1
After the adapter is connected, the display will show as indicated below
for setting.
1. “
SET LANGUAGE ” appears on the display. Press the REVIEW UP ( )
button to select the language, E - English, F - French, S - Spanish, and
then press the DIAL button to confirm the selection.
12:00 1/01
E
AM
SET LANGUAGE
2. When “ LCD CONTRAST ” appears, press REVIEW UP ( ) to set the
contrast darker, and then you can press REVIEW DOWN ( ) to set the
contrast back to the preset. The preset value is “1” and “2” is darker.
When you are finished with this setting, press DIAL. The display will
indicate as shown below and is ready to let you set the area code.
12:00 1/01
2
AM
LCD CONTRAST

7
3. When “ SET AREA CODE ” appears, use REVIEW UP ( ) and REVIEW
DOWN () to set your local area code.
12:00 1/01
– – –
AM
SET AREA CODE
REVIEW UP ( ) button - to change the digit from -,0,1,2~9.
REVIEW DOWN ( ) button - to move to the next digit.
When you are finished setting the local area code, press DIAL. The
display will indicate as shown below and will be ready to let you set
the LDS (long distance) code.
4. When “
SET LDS CODE ” appears, press REVIEW UP ( ) to change the
long distance code from -,0,1,2~9. When you are finished, press DIAL.
The display will indicate as shown (Stand-By Screen) and be ready to
receive incoming calls. You have to set the LDS code as “1” when you
are in the USA or Canada.
12:00 1/01
1
AM
SET LDS CODE
5. The time and date are automatically set when a caller ID (CID) number
is received. The unit will keep the current time accurately, and is
updated each time a CID number is received. After the time is initially
set, at the Stand-By Screen, you can press the MENU button to check
or reprogram the language, area code, and LDS code.
TOTAL CALLS 00
After you have set up the unit completely for the first time, use the MENU
button to review or reprogram the Language, Area Code or LDS Code.

8
FEATURES
1. HANDSET - Used for speaking and private listening during a telephone
conversation.
2. DELETE BUTTON - Erases the displayed caller ID records or erases all
records.
3. DISPLAY WINDOW - Displays the current time, the telephone numbers
you dialed, and information of the caller ID.
4. REVIEW UP AND REVIEW DOWN BUTTONS - Review the stored caller
ID records.
5 DIAL BUTTON - Dials the displayed telephone number.
6. MENU BUTTON - Use to review or change Language, LCD Contrast,
Area Code, LDS Code, or Time & Date settings.
7. DIAL OPTIONS BUTTON - Allows you to arrange the format of a
displayed telephone number before pressing the DIAL button.
8. FLASH BUTTON - Used for special services, including call waiting.
9. MEM DIAL BUTTON - Speed Dial any 10 phone numbers stored in the
keypad buttons.
10. 10 AUTO MEMORY BUTTONS - Speed Dial any 10 phone numbers at
the touch of a button.
11. REDIAL BUTTON - Redials the last telephone number you dialed.
12. SPEAKERPHONE INDICATOR - Lights during speakerphone operation.
13. SPEAKERPHONE BUTTON - Used to activate speakerphone.
14. HOLD BUTTON - Allows you to temporarily place a call on hold.
15. HOLD DICATOR- Indicates when a call has been placed on hold.
16. TONE BUTTON - Allows you to switch from pulse dialing to tone
dialing while PULSE/TONE switch is set to pulse position.
17. STORE BUTTON - Stores up to 10 important telephone numbers and
10 keypad memory locations.
18. VOLUME BUTTON - A built-in amplifier feature which allows you to
have a louder listening level from the receiver of the handset.
19. VOLUME CONTROL - Adjusts speakerphone volume level.
20. RINGER SWITCH - Selects ringer volume HI-LOW-OFF.
21. PULSE/TONE SWITCH - Allows you to select either pulse (rotary) or
tone dialing.

9
Speaker Volume Low Med Hi Ringer Off Hi Low Pulse Tone
1
2
3
4
5
6
7
8
9
10
FLASH
PHONE NO.
AREA CODE
HOLD SPEAKERPHONE REDIAL
MEM DIAL
VOLUME STORE MENU DIAL OPTIONS
DELETE REVIEW DIAL
NEW CALL NEW MESSAGE
1 2 3
4 5 6
7 8 9
0 #
*
ABC DEF
GHI JKL MNO
RS TUV YZ
PO WX
TONE OPER
4
2
135
8
9
10
7
6
11
12
13
14
15
16
17
18
21
20
19

10
USING THE PHONE
PULSE AND TONE DIALING
1. If your home is equipped with a touch tone dialing system, set the
PULSE/TONE switch to the TONE position.
2. If your home is equipped with a rotary(pulse) dialing system, set the
PULSE/TONE switch to the PULSE position.
3. If you are unsure which system you have, set the switch to the TONE
position. Lift the handset. When you get a dial tone, dial a telephone
number. If the dial tone continues, move the switch to PULSE, and
then dial the telephone number again.
NOTE: In order for the Caller ID callback feature to work (see Using the Caller
ID Function), you must set the PULSE/TONE switch to the TONE position.
RECEIVING APHONE CALL
1. Be sure the RINGER switch is set to the HI or LOW position.
2. When the phone rings and the caller’s information shows on the
display window (refer to
Using the Caller ID Function ), lift the handset
or press the SPEAKERPHONE button and begin your conversation.
3. Set the RINGER switch to the OFF position when you do not want to
be interrupted by the phone ringing.
PLACING APHONE CALL
1. Lift the handset or press the SPEAKERPHONE button and wait for a
dial tone.
2. Dial the telephone number you wish to call. The number will appear
on the display window.
SPEAKERPHONE BUTTON
1. Receiving Incoming Calls
A . When the phone rings and the caller’s information shows on the
display window (refer to
Using the Caller ID Function ), press and
release the SPEAKERPHONE button and talk normally into the
built-in microphone from a distance of 5-6 inches.

11
B. You can adjust the volume of the caller’s voice by sliding the
VOLUME control on the right side of the phone.
C. After the conversation has finished, press the SPEAKERPHONE
button to hang up.
2. To Make A Call
A. Press and release the SPEAKERPHONE button.
B. When you hear a dial tone, dial the number or press the auto
memory button just as you would on any other push-button
telephone. The number appears on the display window.
C. When your party answers, adjust the sound level of his or her
voice by sliding the VOLUME control located on the right side of
the phone.
D. After the conversation has finished, press SPEAKERPHONE to
hang up.
NOTES:
1. If you wish to switch from speakerphone to handset, simply lift the
handset.
2. If you wish to switch from handset to speakerphone, press and release
SPEAKERPHONE and then hang up the handset.
DURATION COUNTER
A built-in counter will start counting for your reference 6 seconds after
you lift the handset or 6 seconds after you dial a telephone number.
TONE BUTTON
If the PULSE/TONE switch is set to the PULSE position, and you want to
make a tone dialing call after pulse dialing, press the TONE button once, A
built-in amplifier feature allows you to increase the listening volume in
the receiver of the handset when speaking with your party. When needed,
press the VOLUME button.

12
AUTOMATIC MEMORY
This telephone can store up to 20 telephone numbers (10 auto memory
buttons and 10 keypad memory locations ). Each of the memory number
locations can store up to a maximum of 15 digits. Numbers can be stored
in either pulse or tone mode.
TOSTORE APHONE NUMBER IN MEMORY:
1. Lift the handset and then press the STORE button.
“
MEMORY STORING ” appears on the display window.
2. Dial the number you want to store in memory.
3. Press STORE again.
4. Press the desired memory location.
• To store in an auto memory button (located on left-hand side of
base) - Press 1, 2, 3...or l0.
• To store in a keypad memory location - Press one of the keypad
buttons (1,2,3...9, or 0).
5. Hang up.
6. Use pull out memory index to write in name and location where it is
stored.
TODIAL APHONE NUMBER IN MEMORY:
1. Lift the handset and wait for a dial tone.
2. Press any memory location.
• To dial an auto memory button (located on left-hand side of
base) - Press the desired auto memory button (1, 2, 3...or l0 ).
• To dial a keypad memory location - Press the MEM DIAL button
first, and then the desired keypad button (1,2,3...9, or 0).
3. The number will be displayed and dial automatically.
VOLUME BUTTON
A built-in amplifier feature allows you to increase the listening volume in
the receiver of the handset when speaking with your party. When needed,
press the VOLUME button.
The volume will go back to normal after you hang up the handset.

13
REDIAL BUTTON
1. If the number you dialed is busy, or you want to call the last number
dialed again, press and release the hook switch for a new dial tone.
2. Press REDIAL. The number will appear on the display window.
3. The last number called will automatically be redialed.
HOLD BUTTON
1. To place a call on hold, press the HOLD button and hang up the
handset. The HOLD INDICATOR will light up and remain lighted until
you resume your conversation.
2. To resume your conversation, lift the handset or that of any extension
phone on the same line or press and release HOLD. The HOLD
indicator will go out and your call can continue.
FLASH BUTTON
This telephone provides a break signal for a PABX service of Call Waiting
from your local telephone company. If you have Call Waiting service, you
can operate the Call Waiting function per the following instructions.
1. While having a conversation, another party calls and you hear a tone.
2. Press the FLASH button once and release. The first conversation is
placed on hold and the second call can be answered.
3. Press FLASH again and release. The first caller can be spoken to again
and the second call is placed on hold.
NOTE: If you also have subscribed to Call Waiting Caller ID service, please see
Call Waiting Display below.
CALL WAITING DISPLAY
In the past, if you had call waiting service, a tone alerted you there was a
new call coming while you were on an existing call.
Now our Call Waiting Caller ID not only tells you there is another call
waiting, but lets you know who the caller is before you answer it. The call
waiting information will be shown on the unit’s display.

14
Call Waiting symbol
JACK SMITH
10 : 59 9/24
PM
CALL #
NEW
36
655-5666
CW
The Call Waiting (CW) symbol will flash for
16 seconds along with the telephone
number and name of the person who is on
call waiting. Press the FLASH button to put
the existing call on hold and answer the new
call.
No matter whether you answer the call or
not, the Call Waiting Caller ID will store the
call information for future reference.
NOTE: Make sure you have subscribed to
both Call Waiting Caller ID and Caller ID
service from your local telephone company.
If you only have Caller ID service, the unit works for caller ID only.
USING THE CALLER ID FUNCTION
MESSAGE LIGHT
An indicator marked NEW CALL will light up to let you know when there
are new calls received.
If you have a voice mailbox service with your telephone company, another
indicator marked NEW MESSAGE will flash to alert you to dial your
telephone company to check your new messages.
The NEW MESSAGE indicator also monitors the unit’s situation. When the
phone is in use, the NEW MESSAGE indicator will be on continuously. If
the indicator is flashing quickly, it means the phone is ringing. If it is not
ringing and the light is flashing, the unit has experienced a power outage.
MESSAGE WAITING
This unit’s Message Waiting Detection is for both FSK and Stutter Tone
Systems.
IFYOUR SERVICE IS FSK:
1. If you have a voice mailbox service from the phone company, the
NEW MESSAGE indicator will flash and “
MESSAGE WAITING” will

15
SMITH JOHN
8:59 8/24
AM CALL #
NEW
06
9 14-656-5666
RPT
TOTAL CALLS 06
8:59 8/24
PM NEW
05
Repeat symbol New Call symbol
appear on the display for 20 seconds when a message waiting signal
(on) from the Central Office is received.
2. The NEW MESSAGE indicator will go off and “
MSG WAITING OFF”
will appear for 20 seconds if the message waiting off signal is sent
from the Central office.
IFYOU ARE IN AN AREA WHERE AN FSK
SIGNAL IS NOT AVAILABLE:
1. This unit will check your line for a
stutter dial tone every time you hang up
or each time a call goes unanswered.
The NEW MESSAGE indicator will flash
when there is a message waiting.
2. You may experience some delay in
seeing the NEW MESSAGE indicator
light up even though there are
messages in your mail box. This delay
is due to regulatory matters and does
not indicate a problem with the unit.
This unit may not be activated or
deactivated under certain conditions. For
example, when you retrieve your message
from an outside phone (not your own
telephone number), the NEW MESSAGE
indicator may not be canceled when you
return home. If you experience this
situation, pick up the receiver and hang up.
The NEW MESSAGE indicator will cancel
3. The number will be displayed and dial
automatically.
RECEIVING CALLS
1. When the telephone is not in use and a
new call is received, the display will
show the NEW symbol, the phone
number, thc caller’s name, and time and
date of the call for 20 seconds. The RPT
(Repeat) symbol will appear if the call
has come in more than once.

16
- END OF LIST -
CALL#
00
2. After 20 seconds with no activity, the
display will default to the Stand-By
screen and remain on until another call
is received or a button is pressed. This
will show you the total number of calls
stored and how many new calls that
have not been reviewed.
REVIEWING CALLS
1. When the NEW symbol is flashing on
the Stand-By screen, you have new
incoming calls. Next to the NEW symbol
is the total number of new calls. Press
the REVIEW UP ( ) and REVIEW DOWN
() buttons to review the incoming
stored calls.
2. The NEW symbol attached to each call
will be removed after you review the
call.
3. If the NEW symbol is still flashing when
the display goes back to the Stand-By
screen, there are new calls that you
have not yet reviewed.
4. The reviewed number can be stored
into any of the auto memory buttons or
keypad memory locations by pressing
the STORE button first, then one of the
memory buttons.
5. When you have reached the end of the
call records, the display will indicate
“-END OF LIST-”, confirming there are
no more calls stored.
NOTE: If the telephone number received is
more than 10 digits, the unit will only store
the last 10 digits into memory.
TOTAL CALLS 06
8:59 8/24
PM NEW
05
New symbol
Total
New Calls

17
DELETE ALL?
9:27 9/21
PM
CALL #
10
PICKUP PHONE . .
8:59 8/24
PM
CALL #
NEW
06
9 14-656-5666
RPT
BROWN JOHN
Handset symbol
DELETING CALLS
1. To delete an individual call:
When reviewing calls, you can delete an
individual call by pressing the DELETE
button once. The display will be erased
line by line and the rest of the records
will be renumbered.
2. To delete all calls:
When reviewing calls, you can delete all
calls by pressing and holdling DELETE
for more than 3 seconds. Then “DELETE
ALL?” will appear. Press DELETE to
confirm you really want to erase all
records. “
-NO CALLS -” appears on the
display to show there are no calls stored
in memory.
CALLBACK
When reviewing received calls, there are
two ways to dial the telephone numbers
shown on the display by pressing DIAL.
1. To review calls with the handset in its
cradle (on-hook), press DIAL. “
PICKUP
PHONE”
will appear in the LCD display
to ask you to pick up the handset. The
number will be dialed after you pick up
the handset.
2. If you pick up the handset, review the
calls, and press DIAL, the displayed
number will be dialed immediately.
NOTE: The HANDSET symbol will light up
in the upper left hand corner of the LCD
display when the handset is picked up.

18
If “SET AREA CODE” appears prior to
“PICKUP PHONE...” or dialing, it means you
have not programmed the local area code.
Please hang up the telephone and program
the area code.
1. If a local call (a telephone number with
the same area code as you set) is
reviewed and its 7-digit number
displayed, press DIAL to dial the
number displayed.
2. If a long distance call (a telephone
number with a different area code than
you set) is reviewed and its l0-digit
number (3-digit area code + 7-digit
telephone number) is displayed, press
DIAL to dial the number displayed.
DIAL OPTIONS BUTTON
The DIAL OPTIONS button allows you to
change the format of the displayed number.
The available format follows.
7-digit 7-digit telephone number.
10-digit 3-digit area code + 7-digit
telephone number.
11-digit long distance code 1 + 3-
digit area code + 7-digit
telephone number.
If a local call, and its 7-digit number is
displayed:
• Pressing DIAL OPTIONS once will
change it to a 10-digit format (your area
code + 7-digit number).
• Pressing DIAL OPTIONS twice will
change it to an 11 digit number (1 +
your area code + 7-digit telephone
number).
DANIEL WHITE
9:27 9/21
PM
CALL #
08
785-2883
The original number.

19
• Pressing DIAL OPTIONS three times will
go back to the original 7-digit telephone
number.
For example: your area code is 205 and you
are reviewing telephone number 785-2883.
When the desired format of the telephone
number is reached, press DIAL to dial the
displayed number.
NOTE: Since the LCD can only display 10
digit telephone numbers, when you change
the format to 11-digits, only the first 10 digits
can be seen, but it will dial 11-digits after you
press DIAL.
If a long distance call, and its 10-digit
number is displayed,
1. Pressing DIAL OPTIONS once will change
it to an 11-digit number (1 + 3-digit area
code + 7-digit telephone number).
2. Pressing DIAL OPTIONS twice will
remove the 3-digit area code and change
to display only the 7-digit telephone
number.
3. Pressing DIAL OPTIONS three times will
go back to the original 10-digit number.
4. For example: your own area code is 205,
and you are reviewing telephone number
914-656-5756.
When the desired format of the telephone
number is reached, press DIAL to dial the
displayed number.
SMITH JOHN
8:59 8/24
AM CALL #
06
191-465-6575
Press DIAL OPTIONS once to see
an 11-digit display.
SMITH JOHN
8:59 8/24
AM CALL #
06
914-656-5756
The original number.
Press DIAL OPTIONS twice to see
an 11-digit display.
DANIEL WHITE
9:27 9/21
PM
CALL #
08
120-578-5288
DANIEL WHITE
9:27 9/21
PM
CALL #
08
205-785-2883
Press DIAL OPTIONS once to see a
10-digit display.
SMITH JOHN
8:59 8/24
AM CALL #
06
656-5756
Press DIAL OPTIONS twice to see a
7-digit display.

20
PRIVATE NUMBER
9:27 9/27
PM
CALL #
13
- - - - - - - - - - - - - - - - - - - -
JOHN SMITH
PRIVATE NAME
8:59 8/24
AM CALL #
06
656-5666
PRIVATE CALLER
7:59 9/24
AM CALL #
NEW
05
MESSAGE ERROR
• The display indicates “ -MESSAGE
ERROR
-” if your unit receives a call that
has an error in the transmission or
reception.
NODATA SENT
1. “NO DATA SENT” will be displayed if
there is no caller ID (CID) number sent
from the telephone company while
ringing.
2.
“NO DATA SENT” will also be
displayed if there is no CID number sent
when the call waiting tone sounds.
PRIVATE CALLS
• If the caller has exercised the option to
block his number from being sent
,
“PRIVATE NUMBER”
and his name will
alternately display on the screen when
this information is received.
• If the caller has exercised the option to
block his name from being sent,
“PRIVATE NAME” and his telephone
number will be displayed on the screen.
• If the caller has exercised the option to
block his name and number from being
sent, then
“PRIVATE CALLER” will be
displayed on the screen.
- MESSAGE ERROR -
9:27 9/21
PM
CALL #
10
- NO DATA SENT -
9:27 9/28
PM
