Before an Authorized Field Service Technician can perform the machine’s final checkout, the following requirements must be met:
The machine must be in position and placed on its rest pads
To move the machine while on the pallet, a 15000 lb. forklift with a 24” load
center & 6’ fork extensions is required. Depending on the load center or rating
of the forklift, a larger fork lift may be required. The center of gravity (CG) of
the machine while on the pallet is 42” from the edge of the pallet. Please see
the manual for more information about lifting the machine.
The machine must be leveled (refer to installation and service manual).
The machine must be wired (refer to the installation and service manual).
The machine must have air hooked up if power drawbar is installed (see the
installation and service manual).
The machine must be cleaned. Remove all grease from the way surfaces.
Space & Weight
•Floor area = 168.5”x 119”
•Height = 87.875”
•Footprint = 42.52 x 63”
•Net (approx.) Weight = 7480 lbs.
•Shipping (approx.) Weight = 7700 lbs.
•Pallet Size = 91 x 84”
•Allow clearance at the rear of the mill to open
and work on the electrical box.
•A solid and level foundation to maintain
approximately 7480 lbs plus the weight of the
workpiece (maximum total 9680 lbs) is
required. Six leveling screws are provided.
Electrical
•Machine is only available in the 208 VAC
configuration (200 to 240V is acceptable). A
separate 208V, 42 amps, 60 Hz, 3 phase
circuit is required. For shops with 440 VAC, a
step-down transformer to 208 VAC must be
used. The transformer must be sized to carry
a load of 42 amps minimum.
•Machine tool must be earth grounded.
Air (for optional Power Drawbar)
•¼” NPT connection
•Air pressure not to exceed 100 psi
•17.5 SCFM or 2.5 CFM at 90 psi
DPMRX7 Machine Footprints
A
Overall Width
168.5”
B
Overall Length
119”
C
Bed width
42.52”
D
Bed width between leveling screws
39.76”
D1
Bed with between leveling screws
26.57”
E
Distance between leveling screws
26.57”
F
Bed length
63”

TRAK Machine Tools
Site Preparation Guide
TRAK DPMRX7
F16467-44 Rev 062518
Page 2 of 3
DPMRX7 Overall Dimensions
G
Height of table from bottom of bed
38.75”
H
Maximum distance from spindle nose to table
24.25”
I
Height from bottom of bed to top of column cover
85.0625”
J
Max. height from bottom of bed to top of Z-axis motor
87.875”
K
Width of machine (including table tray)
110”
L
Length of machine with electrical cabinet closed
94.5”
M
Max. height of machine from bottom of leveling pads to
top of spindle motor with the head all the way up
107.625”
N
Spindle center to column face
24”
O
Bottom of Bed to Top of Electrical Cabinet
87.25”
Note: Removing the z-axis motor, z-axis motor
cover, resistor housing, resistor housing lid, and
unscrewing the top resistor from its bracket and
placing it to the side results in a height of
80.4375” from the bottom of base to the top of
the Z-Axis ball screw. With the head all the way
down, this is the minimum clearance needed to
move the machine through doors.

TRAK Machine Tools
Site Preparation Guide
TRAK DPMRX7
F16467-44 Rev 062518
Page 3 of 3
Lifting the Machine
1. Using the recommended size forklift, lift the pallet
with the machine on thru the fork pocket. ( Note: The
center of gravity (CG) of the machine while on the
pallet is 42” from the edge of the pallet.)
WARNING!
The DPMRX7 machine weighs
approximately 7500 lbs.
The lift truck must have sufficient lifting
capacity (15000 lbs.) with a 24” load
center or equivalent, and be equipped
with 6 ft. extension forks.
2. Using (4) pieces of 4” x 4” x 6” high steel block.
Equally, position the steel blocks to the front, back
and side of the machine base.
3. Gradually lower the lift and let the machine base
rest on the (4) steel blocks. (Note: Machine weight
must be equally distributed and well supported by
the (4) steel blocks) Please make sure that the
position of the blocks does not obstruct the skid.
4. Remove forklift from steel pallet.
5. Remove the (4) bolts securing the machine base to
the pallet and let the steel pallet rest on the floor.
6. Carefully lift the machine thru the fork access cut out
on the side of the machine.
7. Remove steel pallet under the machine.
8. Insert the (6) leveling screws into place.
9. Position and lower the machine to its location (see
floor plan bed/footprint). (Note: Make sure to
position each leveling pads under each leveling
screws.)
