SOYO Super 7 SY-5SSM Use and care manual

SY-5SSM
Super 7 TM
Motherboard
************************************************
Pentium® Class CPU supported
SiS530 PCI/AGP Motherboard
Micro-ATX Form Factor
3D AGP & Audio On-board
************************************************
User's Guide
&
Technical Reference

SOYO™SY-5SSM
ii
About This Guide
This User's Guide is for assisting system manufacturers and end users in setting up
and installing the Motherboard. Information in this guide has been carefully checked
for reliability; however, no guarantee is given as to the correctness of the contents.
The information in this document is subject to change without notice.
Copyright Notice
Copyright 1998, Soyo Computer Inc. All rights reserved. This manual is copyrighted
by Soyo Computer Inc. You may not reproduce, transmit, transcribe, store in a
retrieval system, or translate into any language, in any form or by any means,
electronic, mechanical, magnetic, optical, chemical, manual or otherwise, any part of
this publication without express written permission of Soyo Computer Inc.
Trademarks
Soyo is a registered trademark of Soyo Computer Inc. All trademarks are the property
of their owners.
Disclaimer
Soyo Computer Inc. makes no representations or warranties regarding the contents
of this manual. We reserve the right to revise the manual or make changes in the
specifications of the product described within it at any time without notice and without
obligation to notify any person of such revision or change. The information contained
in this manual is provided for general use by our customers. Our customers should be
aware that the personal computer field is the subject of many patents. Our customers
should ensure that their use of our products does not infringe upon any patents. It is
the policy of Soyo Computer Inc. to respect the valid patent rights of third parties and
not to infringe upon or assist others to infringe upon such rights.
Restricted Rights Legend
Use, duplication, or disclosure by the Government is subject to restrictions set forth in
subparagraph (c)(1)(ii) of the Rights in Technical Data and Computer Software clause
at 252.277-7013.
Product Rights
Products mentioned in this manual are mentioned for identification purpose only.
Product names appearing in this manual may or may not be registered trademarks or
copyrights of their respective companies.
If you need any further information, please come to our home page on the Internet.
The address is "http://www.soyo.com.tw".
Edition: December 1998
Version 1.0
5SSM SERIAL
FC
CTested To Comply
With FCC Standards
FOR HOME OR OFFICE USE
POST CONSUMER
RECYCLED PAPER
100%

Table of Contents SY-5SSM
iii
Table of Contents
SY-5SSM MOTHERBOARD LAYOUT ................................................. 1
CHAPTER 1 INTRODUCTION........................................................... 1
1-1 KEY FEATURES ............................................................ 2
1-2 HANDLING THE MOTHERBOARD............................... 5
1-3 ELECTROSTATIC DISCHARGE PRECAUTIONS......... 5
CHAPTER 2 HARDWARE SETUP.................................................... 6
2-1 PREPARATIONS......................................................6
2-2 UNPACKING THE MOTHERBOARD........................7
2-3 INSTALLATION GUIDE.............................................8
CHAPTER 3 BIOS SETUP UTILITY................................................ 36
3-1 STANDARD CMOS SETUP......................................... 38
3-2 BIOS FEATURES SETUP............................................ 41
3-3 CHIPSET FEATURES SETUP..................................... 47
3-4 POWER MANAGEMENT SETUP................................ 51
3-5 PNP/PCI CONFIGURATION SETUP........................... 57
3-6 LOAD SETUP DEFAULTS ........................................... 60
3-7 LOAD BIOS DEFAULTS .............................................. 60
3-8 INTEGRATED PERIPHERALS .................................... 61
3-9 SUPERVISOR PASSWORD........................................ 66
3-10 USER PASSWORD...................................................... 67
3-11 IDE HDD AUTO DETECTION...................................... 68
CHAPTER 4 DRIVERS INSTALLATION.......................................... 69
CHAPTER 5 ONBOARD VGA AND AUDIO.................................... 73
CHAPTER 6 SIS VGA DRIVER INSTALLATION ............................ 79
CHAPTER 7 ESS™AUDIO DRIVER INSTALLATION.................... 81

SY-5SSM Motherboard Layout SY-5SSM
1
SY-5SSM Motherboard Layout
Back Panel SY-5SSM Platform
COM 1
PRT
USB 1USB 2
PS/2KB
Connector
PS/2 Mouse
Connector
VGA
LINE-IN
LINE-OUT
MIC JACK
JOYSTICK
JP5
13
1
1CPUFAN
CHAFAN
IDE 1
IDE 2
11
FDD
ISA Slot #1
Flash BIOS
PCI Slot #1
PCI Slot #4
PCI Slot #3
PCI Slot #2
3V
Lithium
Battery
SiS 530
Chipset
I/O Chip
®
ITE 8661
ES1938
JP30
JP32
J1
3 5 7 91
2 68104
ATX
Power
COM 2
JP44
31
WOL
Header
1
IR1
LED
Speaker
KEY
LOCK
Power
Reset PWRBT ACPILED HDDLED
_
+
_
+
_ + _
+
SW1
5
6
1
2
3
4
P.B. SRAM
64Kx64
P.B. SRAM
64Kx64
JP9
DIMM 1
DIMM 2
DIMM 3
CD IN1
CD IN2
1
4
1
4
5595
SiS
6
8
4
21
7
5
3

Introduction SY-5SSM
2
Chapter 1
INTRODUCTION
The SY-5SSM AGP/PCI Motherboard is a high-performance
MICRO-ATX form-factor system board. SY-5SSM uses the SiS530
PCI Chipset technology and supports Pentium® class processors.
This Motherboard is fully compatible with industry standards and
adds many technical enhancements.
1-1 KEY FEATURES
ØIntegrated 3D AGP accelerator supports UMA or non-UMA
(option)
Ø3D PnP PCI Audio onboard
Ø1 MB L2 cache on board
ØSupports CPU voltage from 2.0V to 3.5V in 0.1V increment
ØPC98, ACPI, Ultra DMA 33/66
ØPower-on by modem or alarm
ØSupports Wake-On-LAN (WOL)
ØSupports power-off by hot-key
Ø3 x 32-bit bus mastering PCI slots
Ø1 x 32-bit bus slaving PCI slot
Ø2 x USB ports
Ø1 x IrDA port
ØSupports multiple-boot function
ØSupports Pentium® class CPU with host bus clock of 66/100
MHz
ØSupports system memory up to 768MBytes

Introduction SY-5SSM
3
SY-5SSM PLATFORM FEATURES
Board Size 4-layer PCB, 22x24.4cm(8.7”x9.6”), MICRO-ATX
Form Factor
Socket 7 Socket for Pentium® class CPUs
with host bus frequency of 66/100MH; Supports:
ØIntel Pentium® Processors P54C/P55C (100-233MHz)
ØCyrix 6x86™(PR166+-PR200+),
Cyrix 6x86 MX™(PR166-PR266) and Cyrix M II™
(300~350)
ØAMD K5™(PR100-PR166), and AMD K6™(166-300)
and AMD K6™-2 (266~450)
ØIDT WinChip™C6/W2 (200/225MHz)
Chipset SiS530 PCI/AGP Bus Chipset
3D AGP accelerator integrated
ATX Power 20-pin Male Connector
CPUFAN 3-pin CPU Cooling Fan Connector
CHAFAN 3-pin Chassis Cooling Fan Connector
Memory DIMM Bank (DIMM1 & DIMM2 & DIMM3)
Ø168-pin Unbuffered SDRAM DIMM Module
ØSupports 8~256MB DIMM in each Bank
ØSupports ECC configuration
BIOS System BIOS built-in, Award BIOS
ØAPM, ACPI and "Plug-and-Play" function
ØSupports multiple-boot function
PCI Slots 3 x 32-bit Bus Mastering Slots
1 x 32-bit Bus Slaving Slots
ISA Slots 1 x 16-bit ISA Slots
IDE1, IDE2 2 x 40-pin Bus Mastering E-IDE/ATAPI Ports
ØIDE1: Primary IDE Device Connector
ØIDE2: Secondary IDE Device Connector
ØSupports Ultra DMA 33/66
FDC 1 Floppy Disk Drive (FDD) Port
(Supports 1.2MB/1.44MB/2.88MB and LS120/3-mode FDD)
COM2 1 x 9-pin RS-232 Serial Connector
IR1 5-pin Serial Infrared Device Connector
Keylock 5-pin KeyLock Connector
Reset 2-pin Reset Switch Connector
Speaker 4-pin PC Speaker Connector

Introduction SY-5SSM
4
ACPI_LED 2-pin ACPI LED Connector
HDD_LED 2-pin IDE Device LED Connector
PWRBT ATX Power On/Off Switch 2-pin Connector
J1 CPU Burst Mode Jumper
JP5 CMOS Clear Jumper
JP9 Enable/Disable Onboard Sound Function Jumpers
CD IN1,CD IN2 2 x CD Line-in 4-pin Connectors
JP30 CPU Voltage Selection Jumper
JP32 CPU Host Bus Frequency Jumpers
SW1 CPU Multiplier Jumpers
JP44 WOL (Wake-On-LAN) 3-pin Connector
BACK-PANEL FEATURES
PRT 1 x Onboard 25-pin Female Parallel Printer Port
COM1 1 x Onboard RS-232 Serial Port
PS/2 KB 1 x Onboard PS/2 Keyboard Connector
PS/2 Mouse 1 x Onboard PS/2 Mouse Connector
USB1, USB2 2 x Onboard USB (Universal Serial Bus) Connectors
VGA 1 x Onboard 15-pin VGA Port
JOYSTICK 1 x Onboard 15-pin Joystick Port
LINE-OUT 1 x Onboard Line-out Audio Stereo Jack
LINE-IN 1 x Onboard Line-in Audio Stereo Jack
MIC JACK 1 x Onboard Microphone Stereo Jack

Introduction SY-5SSM
5
1-2 HANDLING THE MOTHERBOARD
To avoid damage to your Motherboard, follow these simple rules
while unpacking:
ØBefore handling the Motherboard, ground yourself by grasping
an unpainted portion of the system's metal chassis.
ØRemove the Motherboard from its anti-static packaging. Hold
the Motherboard by the edges and avoid touching its
components.
ØCheck the Motherboard for damage. If any chip appears loose,
press carefully to seat it firmly in its socket.
Warning: Do not apply power if the Motherboard appears
damaged. If there is damage to the board, contact your
dealer immediately.
1-3 ELECTROSTATIC DISCHARGE PRECAUTIONS
Make sure to ground yourself before handling the Motherboard or
other system components. Electrostatic discharge can easily
damage the components. Note that you must take special
precautions when handling the Motherboard in dry or air-conditioned
environment.
To protect your equipment from electrostatic discharge, take the
following precautions:
ØDo not remove the anti-static packaging until you are ready to
install.
ØGround yourself before removing any system component from
its protective anti-static packaging. (To ground yourself, grasp
the expansion slot covers or other unpainted portions of the
computer chassis.)
ØFrequently ground yourself while working or use a grounding
strap.

Hardware Setup SY-5SSM
6
Chapter 2
HARDWARE SETUP
Congratulations on your purchase of SY-5SSM Super 7 TM
Motherboard. You are about to install and connect your new
Motherboard.
Note: Do not unpack the Motherboard from its protective
anti-static packaging until you have made the following
preparations.
2-1 Preparations
Gather and prepare all the following hardware equipment to
complete the installation successfully:
1. Pentium processor with CPU cooling fan.
2. DIMM memory module
3. Computer case and chassis with adequate power supply unit
4. Monitor
5. Keyboard
6. Pointing Device (PS/2 mouse)
7. Speaker(s) (optional)
8. Disk Drives: HDD, CD-ROM, Floppy drive…
9. External Peripherals: Printer, Plotter, and Modem (optional)
10. Internal Peripherals: Modem and LAN cards (optional)
Frequently Asked Questions:
lDo I need to install a VGA card?
lDo I also need to install a sound card?
The answer is NO to both questions above, since, for your
convenience, the SY-5SSM Motherboard already features one built-
in VGA port and three built-in audio-stereo ports (Line-out, Line-in,
Microphone).
Notice: If you plan on using the onboard VGA and intend to install
only one DRAM memory module, then this single DRAM must be
installed in bank DIMM1.
lWhat kind of speaker can connect to "Line-out" port?
This Motherboard requires a speaker with built-in amplifier to
generate proper output sound volume.

Hardware Setup SY-5SSM
7
2-2 Unpacking the Motherboard
When unpacking the Motherboard, check for the following items:
ØThe SY-5SSM SiS530 PCI/AGP Motherboard
ØThis Quick Start Guide *
ØThe Installation CD-ROM *
ØOne IDE Device Flat Cable
ØOne Floppy Disk Drive Flat Cable
ØOne serial port flat cable with a 9-pin connector
* If your board comes with a driver disc and a paper manual, the Quick Start Guide
and the CD-ROM are not included in the package.
Warning: Do not unpack the Motherboard from its anti-
static packaging until you are ready to install it.
Like most electronic equipment, your Motherboard may be damaged
by electrostatic discharge. To avoid permanent damage to
components ground yourself while working by using a grounding
strap. Otherwise, ground yourself frequently by touching the
unpainted portion of the computer chassis to drain the static
charges.
Handle the Motherboard carefully, holding it by the edges.
You are now ready to start the installation.

Hardware Setup SY-5SSM
8
2-3 Installation Guide
We will now begin the installation of the Motherboard. Please follow
the step-by-step procedure designed to lead you to a complete and
correct installation.
Step 1. CPU Installation
Follow these instructions to install your Pentium® class processor
correctly.
Locate the CPU socket labeled Socket 7 on your Motherboard and
note the distinctive pinhole arrangement.
Note the corresponding pinhole arrangement on the processor.
CPU
Socket 7
Blunt Edge Blunt Edge

Hardware Setup SY-5SSM
9
Follow these steps to install the CPU in the Socket 7:
1. Lift the socket handle up to a vertical position.
2. Align the blunt edge of the CPU with the matching pinhole
distinctive edge on the socket.
3. Seat the processor in the socket completely and without forcing.
4. Then close the socket handle to secure the CPU in place.
Step 2. CPU Fan Installation
Your Pentium® processor kit comes with a cooling fan. Mount the fan
on the processor according to the instructions provided by the
manufacturer. The fan is a key component that will ensure system
stability. The fan prevents overheating, therefore prolonging the life
of your CPU.
Note: Remember to connect the fan to the appropriate power
source.
1 2
34

Hardware Setup SY-5SSM
10
Step 3. CPU Voltage Setting (JP30)
Please verify the correct voltage with your dealer before installation.
Use the following tables to set JP30 to the proper "Voltage Value",
according to the specifications marked on your CPU: This
Motherboard comes with pre-configured setting of CPU voltage.
However the voltage of your CPU maybe different with the default
setting.
lCPU VOLTAGE SETTING (JP30)
JP30 are the only jumpers that you need t4o set for your CPU
voltage on this Motherboard.
There are two kinds of CPU voltages currently on the market
depending on the CPU manufacturer:
ØSingle Voltage (CPU: P54C, AMD-K5, Cyrix 6x86, IDT
WinChip C6/W2)
ØDual Voltage (CPU: P55C, AMD-K6, AMD-K6-2 Cyrix
6x86L,Cyrix 6x86MX, Cyrix M II)
®
1
3
5
7
10
6 84
9
2
CPU Voltage

Hardware Setup SY-5SSM
11
Those processors may come in various voltages on different
markets. Therefore, always make sure you know the type of the
CPU you are installing and adjust the settings on JP30 accordingly.
This Motherboard supports CPU voltages from 2.0 to 3.52V in 0.1V
increments. Use the following tables to set the CPU voltage jumpers
JP30 to match the voltage value of your CPU:
CPU Voltage Setting: JP30
Voltage Value 1-2 3-4 5-6 7-8 9-10
single3.5V* open short short short short
single 3.3V open short short open short
dual 3.2V open short short open open
dual 3.1V open short open short short
dual 3.0V open short open short open
dual 2.9V open short open open short
dual 2.8V open short open open open
dual 2.7V open open short short short
dual 2.6V open open short short open
dual 2.5V open open short open short
dual 2.4V open open short open open
dual 2.3V open open open short short
dual 2.2V open open open short open
dual 2.1V open open open open short
dual 2.0V short short short short open

Hardware Setup SY-5SSM
12
Voltage Settings for Various Processors
Processor
Voltage Setting Voltage Value: JP30
Intel P54C - 100
Intel P54C - 133 Vcore:3.3V
VI/O:3.3V
Intel P54C - 166
Intel P54C - 200 Vcore:3.5V VI/O:3.5V
Intel P55C - 166
Intel P55C - 200
Intel P55C - 233
Vcore:2.8V
VI/O:3.3V
AMD K5 - PR100
AMD K5 - PR133
AMD K5 - PR166 Vcore:3.5V VI/O:3.5V
AMD K6 166
AMD K6 200 Vcore:2.9V VI/O:3.3V
AMD K6 233 Vcore:3.2V
VI/O:3.3V
AMD K6 266
AMD K6 300
AMD K6-2 266
AMD K6-2 300
AMD K6-2 333
AMD K6-2 350
AMD K6-2 366
AMD K6-2 380
AMD K6-2 400
Vcore:2.2V
VI/O:3.3V
AMD K6-2 450 Vcore:2.3V
VI/O:3.3V
1
3
5
7
9
2
4
6
8
10
1
3
5
7
9
2
4
6
8
10
1
3
5
7
9
2
4
6
8
10
1
3
5
7
9
2
4
6
8
10
1
3
5
7
9
2
4
6
8
10
1
3
5
7
9
2
4
6
8
10
1
3
5
7
9
2
4
6
8
10
1
3
5
7
9
2
4
6
8
10

Hardware Setup SY-5SSM
13
Voltage Settings for Various Processors (continued)
Processor
Voltage Setting Voltage Value: JP30
Cyrix 6x86(L) PR166+
Cyrix 6x86(L) PR200+ The Cyrix 6x86(L) come in several versions with different voltages. Please ask your
dealer for the correct voltage.
Cyrix 6x86MX-PR166*
Cyrix 6x86MX-PR200*
Cyrix 6x86MX-PR233*
Cyrix 6x86MX-PR266*
Cyrix M II 300*
Cyrix M II 333*
Cyrix M II 350*
Vcore:2.9V
VI/O:3.3V
IDT WinChip C6/W2-
200
IDT WinChip C6/W2-
225
Vcore:3.5V
VI/O:3.5V
* Set the proper CPU voltage according to the marking on the CPU.
1
3
5
7
9
24
6
8
10
1
3
5
7
9
24
6
8
10

Hardware Setup SY-5SSM
14
Step 4. CPU Frequency Setting (SW1,JP32)
The SY-5SSM Motherboard is designed to support most Pentium®
class processors currently on the market. Jumpers SW1 and JP32
are used to configure the Motherboard frequency parameters to
match the working frequency of your CPU.
®
1
3
5
2
4
6
1
3
5
8
7
2
4
6
SW1
Frequency Multiplier
JP32
Host Bus Frequency

Hardware Setup SY-5SSM
15
lCPU FREQUENCY & SDRAM frequency SETTING (SW1,JP32)
Configure the SW1 jumpers to the settings that match your CPU
speed. Refer to the following tables to set the Frequency Multiplier
and Host Bus Frequency of your CPU:
Frequency Multiplier: SW1
Multiplier 1-2 3-4 5-6
1.5/3.5x open open open
2.0x short open open
2.5x short short open
3.0x open short open
4.0x short open short
4.5x short short short
5.0x open short short
5.5x open open short
Host Bus Frequency & SDRAM frequency: JP32
Host Bus
Frequency PCI SDRAM 1-2 3-4 5-6 7-8
66MHz 33MHz 66MHz open short short short
75MHz 30MHz 75MHz open short short open
55MHz short short short open
83MHz 33MHz 83MHz open short open short
90MHz 30MHz 90MHz short short short short
63.4MHz short short open short
95MHz 31.7MHz 95MHz open short open open
100MHz 33MHz 100MHz open open short short
105MHz 35MHz 70MHz short open short short
75MHz short open short open
112MHz 37.5MHz 112MHz open open short open
82.6MHz short open open short
124MHz 31MHz 124MHz open open open short
88.9MHz short open open open
133MHz 33MHz 133MHz open open open open
Example: If the working frequency of your CPU is 133MHz, then
select Multiplier=2.0x and Host Bus Frequency=66Mhz accordingly.

Hardware Setup SY-5SSM
16
Please refer to the following table that gives you the correct
frequency settings for the specific brand and model of CPU you are
installing on this Motherboard.
Frequency Settings for Intel®Processors
Processor
Frequency Setting Ratio Bus
Clock PCI Clock
CPU Host
Bus Setting:
JP32
Frequency
Multiplier:
SW1
Intel P54C - P100 1.5 x66MHz 33MHz
Intel P54C - P133 2.0 x66MHz 33MHz
Intel P54C - P166 2.5 x66MHz 33MHz
Intel P54C - P200 3.0 x66MHz 33MHz
Intel P55C - P166 2.5 x66MHz 33MHz
Intel P55C - P200 3.0 x66MHz 33MHz
Intel P55C - P233 3.5 x66MHz 33MHz
** Set the proper CPU frequency according to the marking on the CPU.
1
3
5
8
7
2
4
6
1
3
5
2
4
6
1
3
5
8
7
2
4
6
1
3
5
8
7
2
4
6
1
3
5
8
7
2
4
6
1
3
5
8
7
2
4
6
1
3
5
8
7
2
4
6
1
3
5
8
7
2
4
6
1
3
5
2
4
6
1
3
5
2
4
6
1
3
5
2
4
6
1
3
5
2
4
6
1
3
5
2
4
6
1
3
5
2
4
6

Hardware Setup SY-5SSM
17
Frequency Settings for AMD™Processors
Processor
Frequency Setting Ratio Bus
Clock PCI Clock CPU Host Bus
Setting: JP32
Frequency
Multiplier:
SW1
AMD K5 - PR100 1.5 x 66MHz 33MHz
AMD K5 - PR133 2.0 x 66MHz 33MHz
AMD K5 - PR166 2.5 x 66MHz 33MHz
AMD K6 - 166 2.5 x 66MHz 33MHz
AMD K6 - 200 3.0 x 66MHz 33MHz
AMD K6 - 233 3.5 x 66MHz 33MHz
AMD K6 - 266 4.0 x 66MHz 33MHz
AMD K6 - 300 4.5 x 66MHz 33MHz
AMD K6-2 266 4.0 x 66MHz 33MHz
AMD K6-2 300 4.5 x 66MHz 33MHz
AMD K6-2 300 3.0 x 100MHz 33MHz
AMD K6-2 333 5.0 x 66MHz 33MHz
** Set the proper CPU frequency according to the marking on the CPU.
1
3
5
8
7
2
4
6
1
3
5
8
7
2
4
6
1
3
5
8
7
2
4
6
1
3
5
8
7
2
4
6
1
3
5
8
7
2
4
6
1
3
5
8
7
2
4
6
1
3
5
8
7
2
4
6
1
3
5
8
7
2
4
6
1
3
5
8
7
2
4
6
1
3
5
8
7
2
4
6
1
3
5
2
4
6
1
3
5
2
4
6
1
3
5
2
4
6
1
3
5
2
4
6
1
3
5
2
4
6
1
3
5
2
4
6
1
3
5
8
7
2
4
6
1
3
5
2
4
6
1
3
5
2
4
6
1
3
5
2
4
6
1
3
5
2
4
6
1
3
5
2
4
6
1
3
5
2
4
6
1
3
5
8
7
2
4
6
