SOYO SY-V6BE+ User manual

SY-V6BE+
Mainboard
Quick Start Guide
Hardware
Installation
Quick BIOS
Setup
Introduction
The SOYO CD

SOYO™
2
SY-V6BE+ Mainboard
Pentium
®
II processor & Celeron
TM
processors
AGP/PCI Mainboard
66&100MHz Front Side Bus supported
ATX Form Factor
Copyright © 1998 by Soyo Computer Inc.
Trademarks:
Soyo is a registered trademark of Soyo Computer Inc. All trademarks are the property of their
owners.
Product Rights:
Product and corporate names mentioned in this publication are used for identification purposes
only and may be registered trademarks or copyrights of their respective companies.
Copyright Notice:
All rights reserved. This manual is copyrighted by Soyo Computer Inc. You may not reproduce,
transmit, transcribe, store in a retrieval system, or translate into any language, in any form or by
any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, any part of
this publication without express written permission of Soyo Computer Inc.
Disclaimer:
Soyo Computer Inc. makes no representations or warranties regarding the contents of this
manual. We reserve the right to revise the manual or make changes in the specifications of the
product described within it at any time without notice and without obligation to notify any
person of such revision or change. The information contained in this manual is provided for
general use by our customers. Our customers should be aware that the personal computer field is
the subject of many patents. Our customers should ensure that their use of our products does not
infringe upon any patents. It is the policy of Soyo Computer Inc. to respect the valid patent rights
of third parties and not to infringe upon or assist others to infringe upon such rights.
Restricted Rights Legend:
Use, duplication, or disclosure by the Government is subject to restrictions set forth in
subparagraph (c)(1)(ii) of the Rights in Technical Data and Computer Software clause at
252.277-7013.
About This Guide:
This Quick Start Guide is for assisting system manufacturers and end users in setting up and
installing the mainboard. Information in this guide has been carefully checked for reliability;
however, no guarantee is given as to the correctness of the contents. The information in this
document is subject to change without notice.
If you need any further information, please visit our Web Site on the Internet. The address is
"http://www.soyo.com.tw".
SY-V6BE+ Serial - Version 1.0 - Edition: November 1998
*Thesespecificationsaresubjecttochangewithoutnotice

SY-V6BE+ Quick Start Guide
3
Introduction
1 1 Introduction
Congratulationsonyourpurchaseofthe SY-V6BE+ Mainboard.ThisQuickStartGuide
describesthestepsforinstallingandsettingupyournewmainboard.
Thisguideisdesignedforalluserstoprovidethebasicstepsofmainboardsettingand
operation.Forfurtherinformation, pleasereferto SY-V6BE+MainboardUser'sGuide and
TechnicalReferenceonlinemanualincludedontheCD-ROMpackedwithyourmainboard.
Unpacking
*Ifyourboardcomeswithadriverdiscandapapermanual,theQuickStartGuideandtheCD-ROMarenotincludedinthepackage.
Whenunpackingthemainboard,checkforthefollowingitems:
u TheSY-V6BE+AGP/PCIMainboard
u ThisQuickStartGuide
u TheInstallation CD-ROM
u TheCPURetentionSet
u OneIDEDeviceFlatCable
u OneFloppyDiskDriveFlatCable

SY-V6BE+ Quick Start Guide
4
Introduction
SY-V6BE+ Mainboard Layout
Key Features
Ø SupportsIntelPentium
®
II processor (233-
500MHz) & Celeron
TM
processors(266-
400MHz)
Ø Auto-detect CPU voltage
Ø PC98,ACPI, Ultra DMA/33MHz
Ø Power-on by modem, alarm or keyboard
Ø SOYO COMBO Setup
Ø SupportsWake-On-LAN(WOL)
Ø Supports onboard hardware monitoring
and includes Hardware Doctor™utility
(optional)
Ø S1x32-bitAGP slot
Ø 4 x 32-bit bus mastering PCI slots
Ø 2 x USB ports onboard
Ø 1 x IrDA port
Ø Supportsmultiple-bootfunction
Ø DMI utility
COM 1
COM 2
PRT
USB 1USB 2
PS/2 KB
Connector
PS/2 Mouse
Connector JP10
PCI Slot #1
PCI Slot #2
PCI Slot #3
PCI Slot #4
ISA Slot #2
ISA Slot #1
ISA Slot #3
JP5
JP44
1
3
IR1
15
1
CPUFAN
Ultra
I/O Chipset
CHAFAN
1
IDE 1
IDE 2
11
1
FDC
Slot 1 for
Pentium IIProcessor
1
3
AGP Slot
ATX
Power
DIMM 1
DIMM 2
DIMM 3
Speaker
Keylock
Power
LED
Reset
PWRBT
Turbo
LED
HDD LED
_
+
_
+
_
+
_
+
3
1
Wake on
LAN
Hardware
Monitoring
Winbond
W83781D
SW1
3V Lithium
Battery
BIOS Flash

SY-V6BE+ Quick Start Guide
5
Hardware
Installation
2 2 Installation
Toavoiddamagetoyourmainboard,followthesesimpleruleswhile
handlingthisequipment:
l Beforehandlingthemainboard,groundyourselfbygraspinganunpaintedportionof
thesystem'smetalchassis.
l Removethemainboardfromitsanti-staticpackaging.Holditbytheedgesandavoid
touchingitscomponents.
l Checkthemainboardfordamage.Ifanychipappearsloose,presscarefullytoseatit
firmlyinitssocket.
Followthedirectionsinthissectiondesignedtoguideyouthroughaquickandcorrect
installationofyournew SY-V6BE+ Mainboard.Fordetailedinformation,pleasereferto SY-
V6BE+MainboardUser'sguideandTechnicalReferenceonlinemanualincludedonthe
CD-ROMpackedwithyourmainboard.
PREPARATIONS
Gatherandprepareallthenecessaryhardwareequipmenttocompletetheinstallation
successfully:
u Pentium
®
II processorwithbuilt-inCPUcoolingfan(boxedtype)
u SDRAMmodule
u Computercaseandchassiswithadequatepowersupplyunit
u Monitor
u PS/2Keyboard
u PointingDevice(PS/2mouse)
u VGACard
u SoundCard(optional)
u Speaker(s)(optional)
u DiskDrives:HDD,CD-ROM,Floppydrive…
u ExternalPeripherals:Printer,Plotter,andModem-(optional)
u InternalPeripherals:ModemandLANcards(optional)

SY-V6BE+ Quick Start Guide
6
Hardware
Installation
Install the Mainboard
Followthestepsbelowinordertoperformtheinstallationofyournew SY-V6BE+
Mainboard.
Step 1. Install the CPU
Mark your CPU Frequency: RecordtheworkingfrequencyofyourCPU
thatshouldbeclearlymarkedontheCPUcover.
233MHz(66 x3.5) 300MHz(66 x4.5) 350MHz (100 x3.5) 450MHz (100 x4.5)
266MHz(66 x4.0) 333MHz(66 x5.0) 400MHz (100 x4.0) 500MHz (100 x5.0)
CPU Mount Procedure: TomountthePentium
®
IIprocessorthatyouhave
purchasedseparately,followtheseinstructions.
1
Unpack the Retention Kit 2
Position the Mainboard 3
Insert the Screws
4
Install the Supporting Base
5
Install the Retention Clip 6
Install the CPU
7
Install the Support Clip 8
Insert the Latches 9
Remember to connect the CPU
Cooling Fan to the CPUFAN
power connector on the
mainboard.
Supporting Base
Support Clip
Screws (x2)
Retention Clip
Latches (x2)
ATX Power
Heat Sink
Slot 1
CPUFAN Power Larger Pinhole

SY-V6BE+ Quick Start Guide
7
Hardware
Installation
Step 2. Make Connections to the Mainboard
Thissectiontellshowtoconnectinternalperipheralsandpowersupplytothemainboard.
InternalperipheralsincludeIDEdevices(HDD,CD-ROM),FloppyDiskDrive,ChassisFan,
FrontPanelDevices(TurboLED,InternalSpeaker,ResetButton,IDELED,and KeyLock
Switch.),Wake-On-LANcard,VGAcard,SoundCard,andotherdevices.
FormoredetailsonhowtoconnectinternalandexternalperipheralstoyournewSY-V6BE+
Mainboard,pleasereferto SY-V6BE+MainboardUser'sGuideandTechnicalReference
onlinemanualonCD-ROM.
Connectors and Plug-ins
IrDA (Infrared Device Header): IR1 Wake-On-LAN Header: JP44
Pin1 Pin2 Pin3 Pin4 Pin5 Pin1 Pin2 Pin3
VCC None IRRX GND IRTX 5VSB GND MP-Wakeup
CPU Cooling Fan: CPUFAN Chassis Fan: CHAFAN
Pin1 Pin2 Pin3 Pin1 Pin2 Pin3
GND 12V SENSOR GND 12V SENSOR
Power LED Keylock
Pin1 Pin2 Pin3
Pin1 Pin2
5V NC GND
ControlPin GND
Speaker
Pin1 Pin2 Pin3 Pin4
5V NC NC Speakerout
HDD LED Turbo LED PWRBT RESET
Pine1 Pin2 Pin1 Pin2 Pin1 Pin2 Pin1 Pin2
LEDAnode LED
Cathode LED Cathode GND PowerGood GND Power On/Off GND
ATX Power On/Off: PWRBT ATX Power Supply: ATX PW
Connect your power switch to this
header (momentary switch type).
To turn off the system, please
press this switch and hold down
for longer than 4 seconds.
Attach the ATX Power cable to this connector.
When using the Power-On by PS/2 Keyboard
function, please make sure the ATX power
supply can take at least 720mA load on the
5V Standby lead (5VSB) to meet the standard
ATX specifications.
1
1
1
11
1
1
Power LED
Key Lock
Speaker
Reset
PWRBT
Turbo LED
HDD LED

SY-V6BE+ Quick Start Guide
8
Hardware
Installation
Step 3. Configure Memory
YourboardcomeswiththreeDIMMsockets,providingsupportforupto768MBofmain
memoryusingDIMMmodulesfrom8MBto256MB.For66MHzfrontsidebusCPUsuse
12nsorfastermemory;for100MHzfrontsidebusCPUsuse8ns(100MHz,PC100
compliant)memory.
Memory Configuration Table
Number of Memory Modules DIMM 1 DIMM 2 DIMM 3
11st
22nd 1st
33rd 2nd 1st
RAM Type SDRAM
Memory Module Size (MB) 8/16/32/64/128/256 Mbytes
Note:(1) 256 MB memory modules only available on PC registered DIMM.
(2) Always install memory modules in the order prescribed in this table.
(3) Do not install unbuffered and registered memory modules together.
Important: ItisofprimeimportancethatyouinstallDIMMmodulesasoutlinedinthetable
aboveinordertopreservesignalintegrityon100MHzfrontsidebussystems.
Step 4. Set SW1 for power up FSB clock and AGP bus clock.
SW1isusedtoadjustAGPbusclockfrequencydependingonthevalueofthefrontsidebus
(FSB)clock,alsothesettingoftheSW1determinesthepowerupFSBclockwhichwill
remaineffectiveuntiltheBIOSsettheFSBclocktotheCMOSsetting.
SW1 Setting Power up FSB Clock AGP Clock
66MHz AGP Clock
= FSB Clock ÷1
100MHz AGP Clock
= FSB Clock ÷1.5
Note: The specification of maximum AGP bus Clock frequency
is 66.6MHz.
∗ SetSW1toopenwhenyouuseaFSB100MHzCPUsuchas350MHz,400MHz,
450MHz,or500MHz.
∗ SetSW1toclosewhenyouuseaFSB66MHzCPUsuchas233MHz,266MHz,
300MHz,333MHz,or366Mhzonlyfor Celeron.
∗ SetSW1toopenwhenyouuseaFSB66MHzbutwanttooverclocktheFSBclockto
100MHzviatheBIOSsetting.

SY-V6BE+ Quick Start Guide
9
Hardware
Installation
Step 5. Set the CPU Frequency
ThismainboarddoesnotuseanyjumperstosettheCPUfrequency,CPUsettingare
changedthroughtheBIOS[SOYOCOMBOSETUP].RefertoChapter3 “QuickBIOS
Setup”fordetailsonhowtosetthePentium

IIprocessorfrequency.
Step 6. Enable/Disable Power-On by Keyboard (JP10)
YoucanchoosetoenablethePower-OnbyKeyboardfunctionbyshortingpin1-2onjumper
JP10,otherwise,shortpin2-3todisablethisfunction.
Power-On by
Keyboard Enable Disable
JP10 Setting Short pin 1-2 to enable the
Power-On by Keyboard function. Short pin 2-3 to disable the Power-On by Keyboard function.
Important: When using the Power-On by Keyboard function, please make sure the
ATX power supply can take at least take 720mA load on the 5V standby lead (5VSB) to
meet the standard ATX specification. Apart from the jumper setting, you have to enter
the CMOS setup and set the “Power-On by Keyboard”item in the SOYO COMBO
Setupto“Password”or function key.
Step 7. Clear CMOS Data (JP5)
CleartheCMOSmemorybymomentarilyshortingpin2-3onjumperJP5foratleast5
seconds,andthenbyshortingpin1-2toretainnewsettings. Thisjumpercanbeeasily
identifiedbyitswhitecoloredcap.
CMOS Clearing Clear CMOS Data Retain CMOS Data
JP5 Setting Short pin 2-3 for at least 5 seconds
to clear the CMOS.
Short pin 1-2
to retain the
new settings.
Note: You must unplug the ATX power cable from the ATX power connector when
performing the CMOS Clear operation.
You MUST enter the CMOS SETUP and SAVE CMOS
setting twice after clearing CMOS data. If you fail to do this
your new setting would NOT be Saved.
3
2
1
3
2
1
3
2
1
3
2
1

SY-V6BE+ Quick Start Guide
10
Hardware
Installation
Note on Over-clocking Capability
TheSY-V6BE+mainboardprovidesover-clockingcapability.Duetotheover-clocking
settingyoursystemmayfailtobootuporhangduringruntime.Ifthisoccurs,pleaseperform
thefollowingstepstorecoveryoursystemfromtheabnormalsituation:
1. Turnoffsystempower(IfyouuseaATXpowersupply,sometimesyouhavetopress
thepowerbuttonformorethen4secondstoshutdownthesystem)
2. SettheSW1toshortifyouuseaFSB66MHzCPU,SettheSW1toopenifyouusea
FSB100MHzCPU
3. Pressandholddownthe<Insert>keywhileturningonthesystempower.Keep
holdingdownthe<Insert>keyuntilyouseethemessageoftheCPUtypeand
frequency(133MHzor200MHz)appearonscreen
4. Pressthe<Del>keyduringthesystemdiagnosticcheckstoentertheAwardBIOS
Setupprogram
5. FromtheBIOSmainmenu,select[SOYOCOMBO]andmovethecursortothe[CPU
Frequency]fieldtosettheproperworkingfrequency
6. Select[Save&ExitSETUP]andpress<Enter>tosavetheconfigurationtothe
CMOSmemory,andcontinuethebootsequence
Note: SOYOdoesnotguaranteesystemstabilityiftheuseroverclocksthesystem.
Anymalfunctions dueto over-clocking arenot coveredbythewarranty.

SY-V6BE+ Quick Start Guide
11
Hardware
Installation
3 3 Quick BIOS Setup
ThismainboarddoesnotuseanyhardwarejumperstosettheCPUfrequency.Instead,
CPUsettingsaresoftwareconfigurablewiththeBIOS [SOYO COMBO SETUP]. The
[SOYOCOMBOSETUP]menucombinesthemainparametersthatyouneedtoconfigure,
allinonemenu,foraquicksetupinBIOS.
Afterthehardwareinstallationis complete,turnthepowerswitch on,thenpressthe <DEL> key
duringthesystemdiagnosticcheckstoentertheAwardBIOSSetupprogram.TheCMOS
SETUPUTILITYwill displayonscreen.Then,followthesestepstoconfiguretheCPUsettings.
Step 1. Select [STANDARD CMOS SETUP]
Set[Date/Time]and[Floppydrivetype],thenset[HardDiskType]to “Auto”.
Step 2. Select [LOAD SETUP DEFAULT]
Selectthe“LOADSETUPDEFAULT”menuandtype “Y”attheprompttoloadtheBIOS
optimalsetup.
Step 3. Select [SOYO COMBO SETUP]
Movethecursortothe [CPUFrequency] fieldtosetthe CPUfrequency.
Available[CPUFrequency]settingsonyourSY-V6BE+ Mainboardaredetailedinthe
followingtable.Ifyousetthisfieldto[Manual],youarethenrequiredtofillinthenexttwo
consecutivefields:(1)theCPUHost/PCIClock,and(2)theCPURatio.
CPU Frequency
233MHz (66 x 3.5) 400MHz (100 x 4.0)
266MHz (66 x 4.0) 450MHz (100 x 4.5)
300MHz (66 x 4.5) 500MHz (100 x 5.0)
333MHz (66 x 5.0)
350MHz (100 x 3.5)
Select the working frequency of
your Pentium® II processor among
these preset values.
Note: Mark the checkbox that
corresponds to the working
frequency of your Pentium® II
processor in case the CMOS
configuration should be lost.
Note: ifyouuseBusFrequenciesof75MHz,makesurethatyourPCIcardscancopewith
thehigherPCIclock.
Step 4. Select [SAVE & EXIT SETUP]
Press <Enter> tosavethenewconfigurationtotheCMOSmemory,andcontinuetheboot
sequence.

SY-V6BE+ Quick Start Guide
12
The SOYO CD
4 4 The SOYO CD
YourSY-V6BE+MainboardcomeswithaCD-ROMlabeled"SOYOCD."TheSOYOCD
containstheuser'smanualfileforyournewmainboard,the driverssoftwareavailablefor
installation,andadatabaseinHTMLformatwithinformationonSOYO mainboardsand
otherproducts.
Step 1. Insert the SOYO CD into the CD-ROM drive
TheSOYOCDwillauto-run,andtheSOYOCDStartUpMenuwilldisplayasshownbelow.
(SOYOCD Start UpProgramMenu)
TheSOYOCDStartUpProgramautomaticallydetectswhichSOYOmainboardyouown
anddisplaysthecorrespondingmodelname.
Step 2. Read SOYO [model name] Manual
Clickthe Read Manual buttontoopentheuser'smanualfileofyourmainboard.

SY-V6BE+ Quick Start Guide
13
The SOYO CD
PleasenotethatiftheStartUpprogramwasunabletodeterminewhichSOYOmainboard
youown,themanualselectionmenuwillpopup,asshownbelow.Thenselecttheuser's
manualfilethatcorrespondstoyourmainboardmodelnameandclick OK.
(ManualSelection Menu)
Theuser'smanualfilesincludedontheSOYOCDcanbereadinPDF(Postscript
Document)format.InordertoreadaPDFfile,theappropriateAcrobatReadersoftware
mustbeinstalledinyoursystem.
Note: TheStartUpprogramautomaticallydetectsiftheAcrobatReaderutilityisalready
presentinyoursystem,andotherwisepromptsyouonwhetherornotyouwanttoinstallit.
YoumustinstalltheAcrobatReaderutilitytobeabletoreadtheuser'smanualfile.Follow
theinstructionsonyourscreenduringinstallation,thenoncetheinstallationiscompleted,
restartyoursystemandre-runtheSOYOCD.
Step 3. Install Drivers
Thefollowing describesthebest wayof installingWindows95 orWindows98onyour SY-V6BE+
mainboard:
ØThefollowingBIOSdefaultsettingsshouldnotbechanged:
1. The‘OnChipUSBController’itemunder‘BIOSfeaturesSetup’issettoenabled.
2. The‘USBAssignedIRQ’itemunder‘PnP/PCIConfigurationissettoenabled.
YouMUSThavethesetwoitemsenabledforWindows95/98torunproperlyonyoursystem.
ØInstallWindows95/98
ØAfterinstallationofwindows,youwillneedtoinstalltheVIAdrivers.Followtheinstructionbelow.
Please select your manual In the box below
and click OK.
SOYO CD Manuals
SY-V6BE+OK Back

SY-V6BE+ Quick Start Guide
14
The SOYO CD
ClicktheInstallDriversbuttontodisplaythelistofdriversthatcanbeinstalledonyourmainboard.The
start-upprogramdisplaysthedriversavailablefortheSY-V6BE+andtheWindowsversionyouuse.For
Windows95fourdriverswillbelisted(see‘DriverInstallationMenu’below),forWindows98threedriverswill
belisted(theACPIdriverswillbeleftout).
IfyouwanttoseeallthedriversavailableontheSOYO–CD,clicktheDisplayall drivers onthe SOYO
CDbutton.DoNOTinstalldriversthatarenotsuitableforyou board,otherwiseyour systemmaycrash.
(DriverInstallation Menu)
Selectwhichdriveryouwanttoinstallandclick OK, orclick Cancel toreturntothemain
menu.WhentheinstallationprogramofadriverstartsrunningtheSOYO-CDwillexit.After
finishingtheinstallation,restarttheSOYO-CDandinstallthenextdriver.Werecommend
youtoinstallalldrivers,andtodosointherightsequence(toptobottom).
Note: Onceyouhaveselectedadriver,thesystemwillautomaticallyexittheSOYOCDto
beginthedriverinstallationprogram.Whentheinstallationiscomplete,mostdriversrequire
torestartyoursystembeforetheycanbecomeactive.
Installthedriversinsequence, starting withtheVIAIRQ remappingutility.
Afterinstallingalldriversabove,ifyouuseWindows95,firstinstallthe
USBsupplementbeforeinstallingtheAGPdriverthatcamewithyour
AGPcard.
Please select the driver you want to install and click OK, You will have to
restart your system after installation. Only the drivers that are relevant
to your board are displayed initially.
VIA ACPI Driver
SOYO SpeedPro BusMaster Driver
VIA IRQ remapping utility
VIA VxD Driver
CancelDisplay all drivers
on the SOYO CDOK
Driver Installation

SY-V6BE+ Quick Start Guide
15
The SOYO CD
TheUSB supplement isavailableon theWindowsOSR 2orabove CDinthe
followingdirectory:\OSR2\usbsupp.exe
Italsocanbedownloadedfrom www.microsoft.com
Step 4. Enter the SOYO CD
Clickthe EnterSOYO CD buttontoentertheSOYOHTMLdatabase.TheStartUpprogram
willactivatethedefaultHTMLbrowserinstalledonyoursystem(forexample,Internet
ExplorerorNetscape)tovisualizethecontentsoftheSOYOCD.
TheSOYOCDcontainsusefulinformationaboutyour MainboardandotherSOYOproducts
availableinasmanyaselevendifferentlanguages.Foryourconvenience,thisinformationis
availableinHTMLformat,similartotheformatwidelyusedontheInternet.
(SOYOCD HTMLDatabase inEnglish*)
(*Thelistofmenuoptionsmayvarybetweenlanguages)
Note: IfnoHTMLbrowserisinstalledonyoursystem,theStartUpprogramwillpromptyou
onwhetherornotyouwouldliketoinstalltheInternetExplorer*browser.ClickYEStoinstall
theHTMLbrowser.Aftertheinstallationiscomplete,pleaserestartyoursystem.Thenre-run
theSOYOCDandyouwillbeabletobrowsetheSOYOHTMLdatabase.
(*InternetExplorerisaMicrosoftTrademark)

Edition: November 1998
Version 1.0
SY-V6BE+ SERIAL
International Headquarters
SoyoComputerInc.,(Taiwan)
Tel:[phone]
Fax:[phone]
WebSite:http://www.soyo.com.tw
E-mail:[email protected]
USA Branch Office
SoyoTekInc.,(USA)
Tel:[phone]
Fax:[phone]
WebSite:http://www.soyousa.com
E-mail:[email protected]
SOYO Europe
SoyoEuropeB.V.,(Holland)
Tel:[phone]
Fax:[phone]
WebSite:http://www.soyo-europe.com
http://www.soyo.nl
E-mail:[email protected]
Germany Branch Office
SAATTechnologyGmbH,(Germany)
Tel:[phone]
Fax:[phone]
WebSites:http://www.saat.de
http://www.soyo-saat.de
http://www.soyo-saat.com
Email:[email protected]
UK Branch Office
Soyo(U.K.) Ltd.
Tel:[phone]
Fax:[phone]
WebSite:http://www.soyo.nl
E-mail:[email protected]
Japan Branch Office
SoyoComputer(Japan)
Tel:[phone]
Fax:[phone]
WebSite:http://www.soyo.co.jp
E-mail:[email protected]
Hong Kong Branch Office
SoyoHongKongLtd.(H.K.)
Tel:[phone]
Fax:[phone]
WebSite:http://www.soyo.com.hk
E-mail:[email protected]
