Space MOD-HDMI-Q User manual

TECHNICAL SPECIFICATIONS
Input
Type 4 x HDMI
Connector 4 x HDMI Type A
Video coding MPEG-4 AVC / H.264
Prole High prole 4.0
Resolution 1920 x 1080 - 30p
HDCP support Yes
Audio HDMI
Audio encoding MPEG2, ACC, AC3
Standard MPEG-1 Layer II
Audio bit rate 64, 96, 128, 192, 256, 320 Kbps
H.264 Encoder
Standard MPEG-4 AVC / H.264
Bit rate 1 – 19 Mbps adjustable
Congurable parameters Service Name, Service ID, Video PID, Audio PID, PMT PID, PCR PID
Transport Stream Processing
Automatic regeneration: NIT,PAT,CAT,SDT, PMTs,EITs tables
Congurable parameters: TS ID, Original Network ID, Network ID, Provider Name
LCN support: Yes
LCN Providers: Nordig, ITC/UK, EICTA/Europe, New Zealand
DVB-T Output
Standard: EN 300 744
Bandwidth: 5,6,7,8 MHz
Mode: 2K,8K
Constellation: QPSK,16QAM, 64QAM
Guard interval: 1/4, 1/8, 1/16, 1/32
Code rate: 1/2, 2/3, 3/4, 5/6, 7/8
RF Output
Type: 4 x RF DVB-T (COFDM)
Output frequencies: 174…862MHz
Output level: 4 x 90dbμV max.
Connector: 75Ω - F, female
Output attenuator: 0…25dB
MER: 35dB (Typical)
Shoulder attenuation: >45dBc
Connectors: 1 x F - female
Programming interface Seven Segment Display + keypad USB interface
General
Power supply: +12VDC
Power supply consumption: 1.3A max.
Operating temperature: 0 ºC to 50 ºC
Storage temperature: -10 ºC to +70 ºC
Humidity: Up to 90%
Dimensions: 206 x 179 x 30mm
Weight: 0.55Kg
QUICK START GUIDE
Quad Full HD
DVB-T Modulator
4x HDMI to 4x DVB-T (COFDM)
“Home” modulator
MOD-HDMI-Q
HELPLINE 0861 40 41 42 • www.spacetv.co.zaHELPLINE 0861 40 41 42 • www.spacetv.co.za
MOD-HDMI-Q Quick Start 1v0 MOD-HDMI-Q Quick Start 1v0

MORE INFORMATION
• You can download MOD-HDMI-Q’s full manual from product’s page at www.spacetv.co.za
• After 5 min the MOD-HDMI-Q’s keypad will be locked. To unlock, keep the “Up/Down”
buttons (No.3) pressed simultaneously for 5sec. approximately
INSTALLATION
The MOD-HDMI-Q can be programmed with one of the following ways:
• Fromthefrontpaneldisplay
• FromtheUSBinterface
STEP 1:
Power up the MOD-HDMI-Q by plugging in the external power supply.
The MOD-HDMI-Q will need 40-50secs to initialize itself.
The SSD (Seven Segment Display – No 2) depicts the initialization status.
STEP 2:
Select a modulator by pressing the MOD Select button (No 5). A LED indicator will
indicate which modulator is selected.
Step 3:
Choose “Channel” mode by pressing the Channel/Prole button (No 1) and select
the output RF channel using the Up/Downs buttons.
Step 4:
Choose “Attenuation mode” by pressing the Channel/Prole button (No 1) and
select output attenuation ( 0dB, -10dB, -25 dB) using the Up/Downs buttons.
Step 5:
Choose “Prole mode” by pressing the Channel/Prole button (No 1) and select
Prole number using the Up/Downs buttons. Each modulator must have its unique
prole number in the same CATV installation.
For example, select:
Prole No 1 for the rst modulator
Prole No2 for the second modulator
…
Prole No10 for the 10th modulator etc…
* The MOD-HDMI-Q offers advanced programming features from a PC software via a USB interface.
Step 6:
Repeat the procedure from step Νο 2 up to step Νο 5 for the rest of the modulators
of the MOD-HDMI-Q .
1. Channel or Prole selection
button
2. Seven Segment Display
3. UP / DOWN buttons
4. LED indicators
a. Lock:
ON when HDMI
communication has been
established
b. Channel:
ON when “Channel” mode is
selected
c. Attenuation:
ON when “Attenuator” mode
is selected
d. Channel:
ON when “Prole” mode is
selected
5. Modulator selection button
6. HDMI input for modulator Νο 1
7. HDMI input for modulator Νο 2
8. USB port for advanced
programming
9. HDMI input for modulator Νο 3
10. HDMI input for modulator Νο 4
11. +12VDC / 2A PSU input
12. Choice indication LED for
modulator Νο 3
13. Choice indication LED for
modulator Νο 4
14. Choice indication LED for
modulator Νο 1
15. Choice indication LED for
modulator Νο 2
FRONT PANEL
