Sparx Skate Sharpener Installation and operating instructions

OPERATING MANUAL ADDENDUM
11058B.2 - 2/15/2017
Please review this Operating Manual Addendum
and the Operating Manual. You do not need to read
Sections 1, 4, and 6 of the Operating Manual as this
Addendum supersedes those sections.
ATTENTION

SAFETY PRECAUTIONS
1. Before operating the Sparx™ Skate Sharpener, you should
familiarize yourself with the product and read and understand all
applicable instructions and warnings in this manual.
2. Use personal protective equipment. Always wear eye protection
and a dust mask while operating the sharpener.
3. For emergencies: press the nCancel Button two times. This will
stop the Grinding Ring in its place. Do not stop the Grinding Ring
unless it is an emergency, as this may damage the skate blade.
4. We do not recommend that children under 13 years of age be
permitted to use the Sparx™ Skate Sharpener.
5. The Sparx™ Skate Sharpener is not intended for use by persons
(including children 13 years and over) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning
use of the Skate Sharpener by a qualified adult.
6. Children should be supervised to ensure that they do not play
with the Sparx™ Skate Sharpener.
7. The Sparx™ Skate Sharpener may only be used for sharpening skates.
8. Only Sparx™ Grinding Rings may be used with this machine.
9. Set up the product securely on a stable surface and in a protected
location. It must be placed where no one can step on or trip over
the Power Cord and where the Power Cord cannot be damaged.
10. Always use the Sparx™ Skate Sharpener in a dry, well-lit and non-
condensing environment. To avoid the risk of electric shock, do not
use the Sparx™ Skate Sharpener in wet or damp conditions.
11. To avoid injury, always use caution when operating the Sparx™
Skate Sharpener or when changing the Grinding Ring.
12. Do not attempt to touch the Grinding Ring, Carriage, or Skate
Clamp while the Grinding Ring is moving. Wait for the Carriage and
Grinding Ring to come to a complete stop before attempting any
adjustments or Grinding Ring replacement.
13. Make sure that the Thumb Nut is tightened down onto the
Grinding Ring before starting any grinding operation
14. Do not leave the Sparx™ Skate Sharpener running unattended.
15. Never disconnect the Power Cord by pulling the wire to
disconnect it from the socket.
16. Store the Sparx™ Skate Sharpener in a dry place, out of the reach
of children.
17. Maintain the sharpener according to the Maintenance section of
this manual. Emptying the Dust Tray and Replacing the Air Filter, at
specified intervals, are necessary steps for performance and safety.
18. If at any time the product does not operate normally, see the
Troubleshooting section of this manual.
19. There are no user-serviceable parts on the sharpener. The
sharpener should only be repaired by a professional Sparx™ Hockey
technician, using only original spare parts. Unauthorized repairs
could lead to hazardous conditions for the user and/or void the
warranty.
20. For any further questions about the sharpener, please contact
Sparx™ Hockey Support at 1-855-SPARXHQ (1-855-772-7947) or by
email at [e-mail].
Warning: Please see the manual for operating instructions.
Caution: Pinch point hazard. Keep hands, hair and other body parts
clear of the Skate Clamp area.
1
SAFETY

FCC NOTICE
(FOR U.S. CUSTOMERS)
This device complies with Part 15 of the FCC Rules:
Operation is subject to the following conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, Including
interference that may cause undesired operation
Changes and Modifications not expressly approved by Velasa
Sports, Inc. can void your authority to operate this equipment under
Federal Communications Commissions rules.
INDUSTRY CANADA
COMPLIANCE
This device complies with Industry Canada license-exempt RSS
standard(s). Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this device must
accept any interference, including interference that may cause
undesired operation of the device.

CONSIGNES DE SÉCURITÉ
1. Avant d’utiliser l’aûteuse de patins SparxMC, vous devez vous
familiariser avec le produit et lire et comprendre toutes les
instructions et mises en garde dans ce manuel.
2. Portez un équipement de protection individuelle. Portez toujours
des lunettes de sécurité et un masque anti-poussières lorsque vous
utilisez l’aûteuse de patins.
3. En cas d’urgence : appuyez deux fois de suite sur le bouton
nAnnuler (Cancel). Ceci immobilise immédiatement la meule
d’aûtage. N’arrêtez la meule d’aûtage qu’en cas d’urgence, car
cela pourrait endommager la lame du patin.
4. Il n’est pas recommandé que les enfants de moins de 13 ans soient
autorisés à utiliser l’aûteuse de patins SparxMC.
5. L’aûteuse de patins SparxMC ne doit pas être utilisée par des
personnes (y compris des enfants de 13 ans et plus) ayant des
capacités physiques, sensorielles ou mentales réduites, ou un
manque d’expérience et de connaissances, à moins qu’elles
soient surveillées ou qu’elles aient reçu une bonne formation sur
l’utilisation de l’aûteuse par un adulte compétent.
6. Les enfants doivent être surveillés pour s’assurer qu’ils ne jouent
pas avec l’aûteuse de patins SparxMC.
7. L’aûteuse de patins SparxMC doit être utilisée exclusivement pour
l’aûtage de patins.
8. La machine doit être utilisée exclusivement avec des meules
d’aûtage SparxMC.
9. Pour assurer la sécurité de tout le monde, installez la machine
sur une surface stable et dans un endroit protégé. Elle doit être
placée dans un endroit où il n’y a aucun risque que quelqu’un puisse
marcher ou trébucher sur le cordon d’alimentation ou le cordon
d’alimentation puisse être endommagé.
10. Utilisez l’aûteuse de patins SparxMC toujours dans un
environnement sec, bien éclairé, et sans condensation. Pour éviter
tout risque de décharge électrique, n’utilisez jamais l’aûteuse de
patins SparxMC dans des conditions humides ou mouillées.
11. Pour éviter les blessures, soyez toujours prudent lors
de l’utilisation de l’aûteuse de patins SparxMC, ou lors du
remplacement de la meule d’aûtage.
12. N’essayez pas de toucher la meule d’aûtage, le guide-meule
mobile ou la pince de serrage pendant la rotation et le mouvement
de la meule. Attendez l’arrêt complet du guide-meule et de la meule
d’aûtage avant de tenter un réglage ou le remplacement de la meule.
13. Assurez-vous que l’écrou à ailettes est serré sur la meule
d’aûtage avant de commencer l’aûtage
14. Ne laissez jamais l’aûteuse de patins SparxMC sans surveillance
pendant qu’elle est en marche.
15. Ne débranchez jamais le cordon d’alimentation en tirant sur le
cordon.
16. Rangez l’aûteuse de patins SparxMC dans un endroit sec, hors de
la portée des enfants.
17. Faites l’entretien de l’aûteuse selon les consignes de ce manuel.
Le vidage du bac à poussière et le remplacement du filtre à air, à des
intervalles déterminés, sont des étapes nécessaires à la performance
et à la sécurité.
18. Si, à tout moment, la machine cesse de fonctionner normalement,
consultez la section Diagnostic des pannes de ce manuel.
19. L’aûteuse ne comporte aucune pièce réparable par l’utilisateur.
Elle ne doit être réparée que par un technicien professionnel SparxMC
Hockey, exclusivement avec des pièces de rechange d’origine.
Les réparations non autorisées pourraient créer des conditions
dangereuses pour l’utilisateur ou annuler la garantie.
20. Pour toute question au sujet de l’aûteuse, veuillez communiquer
avec le service technique de SparxMC Hockey au (855-772-7947) ou
par courriel à [e-mail].
Mise en garde : Veuillez consulter les instructions dans le manuel.
Attention : Danger de pincement. Gardez les mains, les cheveux et
d’autres parties du corps à l’écart de la zone de la pince de serrage.
1
SÉCURITÉ

CONFORMITÉ AUX NORMES
D’INDUSTRIE CANADA
Le présent appareil est conforme aux CNR d’Industrie Canada
applicables aux appareils radio exempts de licence. L’exploitation
est autorisée aux deux conditions suivantes : (1) l’appareil ne doit
pas produire de brouillage, et (2) l’utilisateur de l’appareil doit
accepter tout brouillage radioélectrique subi, même si le brouillage
est susceptible d’en compromettre le fonctionnement.

4
OPERATION
We recommend inserting the skate into the Skate Clamp
with the toe pointing to the right. For most skate blades, this
orientation allows for the greatest flexibility in Grinding Ring
height adjustment. It is, however, acceptable to insert the
skate with the toe facing in either direction.
LOADING A SKATE
*For loading goalie skates and youth skates,
see the end of this section.
To watch the How-To video, visit sparxhockey.com/loadskate.
1 LOAD THE SKATE
Press and hold down the Clamp Lever to open the Skate Clamp.
With the skate toe pointing right and the laces tucked into the
skate, set the skate into the Skate Clamp slot letting the plastic
blade holder rest on top of the clamps. Center the skate blade
in the Skate Clamps. Release the Clamp Lever.
2 CLOSE THE PROTECTIVE SLOT COVERS
Move each Protective Slot Cover (A) in toward the
skate until they touch the blade holder and the Safety
Lights (B) extinguish.
B B
A

ADJUSTING THE GRINDING
RING HEIGHT
To watch the How-To video, visit sparxhockey.com/ringheight.
For every pair of skates sharpened, you must assess
the height of the Grinding Ring and adjust if necessary.
We will first introduce a few new concepts, and then move into the
actual adjustment. We want to first define an intersection zone,
where the vertical face of the blade (B) meets the nearly horizontal
face of the blade (C).
This zone can be a curved section of blade (A) like that shown in the
figure below or in some cases, it can be a point where surfaces (B)
and (C) meet.
When the intersection zone is a curved surface (A as shown above)
the Grinding Ring can safely initially contact the blade anywhere in
this region (A).
A
B
C
When the intersection zone is a point, which is more common with
skates that have been sharpened multiples times (A as shown above),
the first contact between the Grinding Ring and the blade should be
just below the point.
A
B
C
1 INITIATE MOVE MODE
Press the mMove Button on the Keypad. This will set the
Grinding Ring into Move Mode and allow you to control
its movement.
2 INSPECT THE CONTACT POINT
Use the lLeft and rRight Buttons to touch the Grinding
Ring to the skate blade. Inspect its contact point and be sure it
is in the desired position. In the graphic below you will see an
example of a contact point that is too high (B) and too low (C).
A Grinding Ring contacting in the right zone is shown below as
A. If the Grinding Ring is not in a desired position, follow step 3.
If the Grinding Ring is in a desired position, skip to step 6.
If the skate blade is worn down the graphic below shows a
contact point that is too low (B) and a Grinding Ring contacting
the blade at the proper point (A).
B
A

3 MOVE THE CARRIAGE INTO POSITION
Using the lLeft and rRight Buttons on the Keypad, back
the Grinding Ring o the toe of the skate blade 1/4 inch.
4 ADJUST THE GRINDING RING HEIGHT
Open the Glass Door. Locate the red hHeight Adjustment
Knob (A). Turn the knob left to raise the height or right to
lower the height until the Grinding Ring is at the desired height.
The knob is labeled 1-8, with 8 being the highest setting for the
Grinding Ring and 1 being the lowest setting.
5 INSPECT THE CONTACT POINT
Close the Glass Door. Once the Glass Door has been closed,
using the lLeft and rRight Buttons, touch the Grinding Ring
to the skate blade. Inspect its contact point and be sure it is
in its desired position. Repeat steps 4 and 5 until the Grinding
Ring makes contact at the desired position.
6 END MOVE MODE
Press the mMove Button again to send the Grinding Ring back
to its home position.
A
A
SELECTING THE NUMBER
OF CYCLES
To watch the How-To video, visit sparxhockey.com/cycle.
When the sharpener moves the Grinding Ring out and back over the
skate blade once, it is called a cycle.
The Sparx™ Sharpener comes set automatically to a standard 4
four cycles with all standard Radius Ring™ and FIRE Ring™ Grinding
Rings. We recommend trying four cycles to start and moving higher
or lower as needed. Typically, we have found that four cycles will
handle normal wear and tear (and even small nicks) from one to four
hours of skating between sharpenings. For brand-new steel or when
changing Grinding Ring hollow depths, we recommend using the 1
10-cycle setting to ensure you completely reset the skating surface
of the blade. See Sharpening New Steel at the end of the Operation
section.
1 ADJUST THE CYCLE COUNT
Use the lLeft and rRight Buttons (A) on the Keypad to
adjust the number of cycles desired. The number of cycles
selected will be illuminated on the Cycle Counter (B).
B
A

UNLOADING A SKATE
To watch the How-To video, visit sparxhockey.com/unloadskate.
1 DISENGAGE PROTECTIVE SLOT COVERS
Move both Protective Slot Covers (A) away from the skate. The
safety light on each cover (B) will illuminate.
2 REMOVE THE SKATE
Press and hold down the Clamp Lever to open the Skate
Clamp. Remove the skate from the Skate Clamp and release the
Clamp Lever.
B B
A
SHARPENING SKATES
To watch the How-To video, visit sparxhockey.com/sharpening.
Once you have loaded the skate, closed the Protective Slot Covers,
and adjusted the height of the Grinding Ring, you are ready to begin
sharpening.
To cancel the cycles at any point during the sharpening, press the
nCancel Button once. This will send the Carriage back to its home
position at the end of its current pass.
1 BEGIN SHARPENING
Press the pPlay Button. Once the button has been pressed, it
will change from white to blue and the sharpening process will
begin.
Upon pressing the pPlay Button, the Air Filter fan and grinding
motor will turn on. The Cycle Counter will flash with the current
cycle number until that cycle (out and in) is completed. The
sharpener will continue to run until all cycles have been performed.
At the completion of the final cycle, the end of sharpening is marked
by a “cycle complete” tone and the case LEDs will turn green. The
fan will continue to run for an additional 30 seconds after the final
cycle completes.
ADDITIONAL CYCLES
If additional cycles are desired, you can reset the cycle count and
press the pPlay Button again.
If the Grinding Ring skips when it first makes contact
with the blade, the Grinding Ring’s height is too high.
When properly set, the Grinding Ring should make a
smooth transition onto the skate blade.

EDGE DEBURRING
To watch the How-To video, visit sparxhockey.com/deburr.
We recommend using protective gloves when
deburring the skate blade.
1 DEBURR THE BLADE WITH THE STONE
Press the Honing Stone (A) against the face of the skate blade
(B). Do not put pressure on the side of the stone closest to the
blade edge. With light pressure, press down on the lower side
of the stone (C) and slowly run the stone back and forth along
the length of the blade for four full passes.
2 REPEAT ON THE OPPOSITE SIDE
Turn the skate over. Repeat step 1 on the opposite side of
the blade.
3 DEBURR THE BLADE WITH THE STROP
Press the Leather Strop (A) against the edge of the skate blade
(B) at a 45 degree angle. With light pressure, slowly run the
strop back and forth along the length of the edge for four full
passes
B
C
A
A
B
4 REPEAT ON THE OPPOSITE SIDE
Turn the skate over. Repeat step 3 on the opposite edge of
the blade.
POWERING OFF
1 LOCATE THE POWER INPUT PORT
On the back of the sharpener, locate the Power Input Port.
2 TURN OFF THE SHARPENER
Toggle the Power Input Port switch to the o position (I=on,
0=o).
GOALIE SKATES
To watch the How-To video, visit sparxhockey.com/loadgoalie.
Before loading a goalie skate, you must first install the Goalie
Risers onto the Skate Clamp (one Goalie Riser on each side of the
Skate Clamp). Each Goalie Riser has two Anchor Pins (A) as shown
below.
A

YOUTH SKATES
To watch the How-To video, visit sparxhockey.com/loadyouth.
Before loading a youth skate of size 12 or smaller, Youth Skate
Adapters must be installed onto each Protective Slot Cover. On the
adapter, locate the Upper Anchor Tab (A) on the top of the adapter
and then the Lower Anchor Tab (B) on the bottom.
Below is a cross-sectioned Protective Slot Cover. Locate the
recessed slot (C) and the tab cut out (D) on the Protective Slot
Cover Switch (E).
1 INSTALL YOUTH SKATE ADAPTERS
Press the Upper Anchor Tab (A in figure above) into the tab
cut out (C in figure above). Once it is in, rotate and press down
firmly on the bottom of the Youth Skate Adapter until the
Lower Anchor Tab clicks in place.
B
D
E
A
C
2
1
1INSTALL THE GOALIE RISERS
Align the Anchor Pins of the Goalie Risers to the Anchor Slots
of the Skate Clamp. Once aligned, press down firmly until you
feel the Goalie Risers snap into place.
2 CONTINUE THE SHARPENING PROCESS
Refer to “Loading a Skate” in the Operation section of the
manual. When adjusting the Grinding Ring Height, refer the
graphic in step 3.
3 ADJUST THE GRINDING RING HEIGHT
Refer to “Adjusting the Grinding Ring Height” in the Operation
section of the manual using the figure below as your guide
where the desired contact point is A, contact point B is too
high and contact point C is too low.
5CONTINUE THE SHARPENING PROCESS
Refer to “Sharpening Skates” in the Operation section
of the manual.
6REMOVE THE GOALIE RISERS
Pull up on each end of the Goalie Risers to remove from the
Skate Clamp.
A
B
C
A

SHARPENING NEW STEEL
To watch the How-To video, visit sparxhockey.com/newsteel.
Before loading new steel, try taking a dark colored
marker and running it down the bottom surface of the
skate blade. To ensure you have sharpened the entire
blade, inspect the blade after running the cycles and
if the sharpening is complete, all of the marker on the
skating surface will be removed.
1 LOAD THE SKATE
Follow the instructions in “Loading a Skate” in the Operation
section of this manual.
2 ADJUST GRINDING RING HEIGHT
Follow the instructions in “Adjust the Grinding Ring Height” in
the Operation section of this manual.
3 SELECT 1CYCLES
Using the lLeft and rRight Buttons, select 1on the
Cycle Counter.
4CONTINUE THE SHARPENING PROCESS
Refer to the Operation section of the manual.
Below is how an installed Youth Skate Adapter will look.
2CONTINUE THE SHARPENING PROCESS
Refer to ”Load the Skate” in the Operation section of
the manual.
3 REMOVE YOUTH SKATE ADAPTERS
Press up on the lip (A) of the Youth Skate Adapter until it clicks
out from the Protective Slot Cover Switch (B).
A
B

There are no user-repairable parts in the Sparx™
Sharpener. Refer to “Exclusions” in the Warranty
section for more information. Maintenance of the
Sparx™ Sharpener is limited to the procedures outlined
in this section.
REMOVING AND EMPTYING
THE DUST TRAY
To watch the How-To video, visit sparxhockey.com/dusttray.
Maintenance Frequency: Perform the following steps after every ½
Grinding Ring of sharpener use (160 cycles on any of the following:
Radius Ring™, FIRE Ring™, or X-Grind Ring) and before moving and/
or traveling with the sharpener.
1 REMOVE AND EMPTY THE DUST TRAY
Open the Glass Door and remove the Dust Tray. To empty Dust
Tray—wipe completely clean with a damp cloth (water).
Do not use any solvents or cleaning chemicals in and
around the Skate Sharpener.
2VACUUM SHARPENER
Without removing the Air Filter, thoroughly vacuum the top, sides,
and around the Air Filter Housing. We recommend using a HEPA
certified vacuum.
3REPLACE THE DUST TRAY
Slide the Dust Tray back into the machine. Close the
Glass Door.
REPLACING THE AIR FILTER
To order a replacement Air Filter, visit sparxhockey.com/filter.
To watch the How-To video, visit sparxhockey.com/airfilter.
Standard Grinding Ring Use (Radius Rings™ and FIRE Rings™):The
Air Filter should be replaced every 4 Grinding Rings (1, 280 cycles).
Sparx X-Grind Ring Use: the Air Filter should be replaced every 2
Grinding Rings (640 cycles).
Maintenance Frequency: The Air Filter replacement limits listed
above are related to the type of Grinding Rings being used and refer
to the maximum amount of usage that an Air Filter should have
when using a specific type of Grinding Ring.
The fAir Filter Button will light up to remind you to replace the
Air Filter at the Standard Grinding Ring Use interval ONLY (X-Grind
Ring Must be Accounted for Separately by the User).
1REMOVE AND EMPTY THE DUST TRAY
Open the Glass Door and remove the Dust Tray. To empty Dust
Tray—wipe completely clean with a damp cloth (water).
Do not use any solvents or cleaning chemicals in and
around the Skate Sharpener.
2VACUUM SHARPENER
Before removing the Air Filter, thoroughly vacuum the top, sides,
and around the Air Filter Housing. We recommend using a HEPA
certified vacuum.
6
MAINTENANCE

TRAVELING WITH THE
SHARPENER
To watch the How-To video, visit sparxhockey.com/travel.
1REMOVE AND EMPTY THE DUST TRAY
Open the Glass Door and remove the Dust Tray. To empty Dust
Tray—wipe completely clean with a damp cloth (water).
Do not use any solvents or cleaning chemicals in and
around the Skate Sharpener.
2VACUUM SHARPENER
Without removing the Air Filter, vacuum the top of and around
the Air Filter Housing. We recommend using a HEPA certified
vacuum.
3 REPLACE THE DUST TRAY
Slide the Dust Tray back into the machine. Close
the Glass Door.
4 INSTALL THE TRAVEL GUARD
Open the Skate Clamp by pressing and holding down the
Clamp Lever. Install the Travel Guard by placing the claw of the
Travel Guard behind the Grinding Ring Shaft’s impeller as
3 REMOVE THE AIR FILTER
Open the top lid of the Air Filter Housing until it clicks into the
open position. Keeping it horizontal, carefully remove the Air
Filter. Vacuum remaining dust from the Filter Housing area.
On removal do not tip the Filter and let dust
particles fall into the empty Filter Housing.
Take care not to damage the Filter Seal inside the
Filter Housing when cleaning or vacuuming.
4INSTALL NEW AIR FILTER
Insert the new Air Filter into the filter housing. The Air Filter
label will indicate installation direction which side to install up.
5 RESET THE AIR FILTER BUTTON
Once your filter has been replaced, hold down the fAir Filter
Button for two seconds until an audible tone is heard to reset
the system and extinguish the fAir Filter Button.

shown below. Release the Clamp Lever. Ensure that the
middle section of the Travel Guard (A) is held securely in
the Skate Clamp.
5 REMOVE THE CLAMP LEVER
Slide the Clamp Lever (A) o of the Lever Dock.
When setting up the Sparx Sharpener after travel,
wipe down the Grinding Ring Shaft’s face and
threaded arbor to remove any unwanted steel
shavings that may have gathered during transit. This
will ensure a proper fit between the Grinding Ring
Shaft and the Grinding Ring.
A
A

OPERATING MANUAL

SAFETY 1
Safety Precautions 1
FCC Notice (for U.S. Customers) 2
Industry Canada Compliance 2
SÉCURITÉ 3
Consignes de sécurité 3
Conformité aux normes d’Industrie Canada 4
INTRODUCTION 5
Technical Specifications 5
Getting to Know Your Sparx Sharpener 6
What’s In the Box? 7
Grinding Ring Life Indicator Behavior 9
SETUP 11
Assembling the Sharpener 11
Alignment 12
OPERATION 15
Loading a Skate 15
Adjusting the Grinding Ring Height 16
Selecting the Number of Cycles 17
Sharpening Skates 18
Unloading a Skate 18
Edge Deburring 19
Powering O 19
Goalie Skates 19
Yout h S kate s 20
Sharpening New Steel 21
TROUBLESHOOTING 23
Error Types 23
User Interface prompts 24
Error Codes 25
MAINTENANCE 27
Emptying the Dust Tray 27
Changing the Air Filter 27
Traveling with the Sharpener 28
WARRANTY 29

SAfETy 1
SAfETy PRECAUTIONS
1. Before operating the Sparx™ Skate Sharpener, you should
familiarize yourself with the product and read and understand all
applicable instructions and warnings in this manual.
2. Use personal protective equipment. Always wear eye protection
and a dust mask while operating the sharpener.
3. For emergencies: press the nCancel Button two times. This will
stop the Grinding Ring in its place. Do not stop the Grinding Ring
unless it is an emergency, as this may damage the skate blade.
4. We do not recommend that children under 13 years of age be
permitted to use the Sparx™ Skate Sharpener.
5. The Sparx™ Skate Sharpener is not intended for use by persons
(including children 13 years and over) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning
use of the Skate Sharpener by a qualified adult.
6. Children should be supervised to ensure that they do not play
with the Sparx™ Skate Sharpener.
7. The Sparx™ Skate Sharpener may only be used for sharpening skates.
8. Only Sparx™ Grinding Rings may be used with this machine.
9. Set up the product securely on a stable surface and in a protected
location. It must be placed where no one can step on or trip over
the Power Cord and where the Power Cord cannot be damaged.
10. Always use the Sparx™ Skate Sharpener in a dry, well-lit and non-
condensing environment. To avoid the risk of electric shock, do not
use the Sparx™ Skate Sharpener in wet or damp conditions.
11. To avoid injury, always use caution when operating the Sparx™
Skate Sharpener or when changing the Grinding Ring.
12. Do not attempt to touch the Grinding Ring, Carriage, or Skate
Clamp while the Grinding Ring is moving. Wait for the Carriage and
Grinding Ring to come to a complete stop before attempting any
adjustments or Grinding Ring replacement.
13. Make sure that the Thumb Nut is tightened down onto the
Grinding Ring before starting any grinding operation
14. Do not leave the Sparx™ Skate Sharpener running unattended.
15. Never disconnect the Power Cord by pulling the wire to
disconnect it from the socket.
16. Store the Sparx™ Skate Sharpener in a dry place, out of the reach
of children.
17. Maintain the sharpener according to the Maintenance section of
this manual.
18. If at any time the product does not operate normally, see the
Troubleshooting section of this manual.
19. There are no user-serviceable parts on the sharpener. The
sharpener should only be repaired by a professional Sparx™ Hockey
technician, using only original spare parts. Unauthorized repairs
could lead to hazardous conditions for the user and/or void the
warranty.
20. For any further questions about the sharpener, please contact
Sparx™ Hockey Support at 1-855-SPARXHQ (1-855-772-7947) or by
email at [e-mail].
Warning: Please see the manual for operating instructions.
Caution: Pinch point hazard. Keep hands, hair and other body parts
clear of the Skate Clamp area.
1
SAfETy

SÉCURITÉ 3SAfETy2
fCC NOTICE
(fOR U.S. CUSTOMERS)
This device complies with Part 15 of the FCC Rules:
Operation is subject to the following conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, Including
interference that may cause undesired operation
Changes and Modifications not expressly approved by Velasa
Sports, Inc. can void your authority to operate this equipment under
Federal Communications Commissions rules.
INDUSTRy CANADA
COMPLIANCE
This device complies with Industry Canada license-exempt RSS
standard(s). Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this device must
accept any interference, including interference that may cause
undesired operation of the device.
CONSIGNES DE SÉCURITÉ
1. Avant d’utiliser l’aûteuse de patins SparxMC, vous devez vous
familiariser avec le produit et lire et comprendre toutes les
instructions et mises en garde dans ce manuel.
2. Portez un équipement de protection individuelle. Portez toujours
des lunettes de sécurité et un masque anti-poussières lorsque vous
utilisez l’aûteuse de patins.
3. En cas d’urgence : appuyez deux fois de suite sur le bouton
nAnnuler (Cancel). Ceci immobilise immédiatement la meule
d’aûtage. N’arrêtez la meule d’aûtage qu’en cas d’urgence, car
cela pourrait endommager la lame du patin.
4. Il n’est pas recommandé que les enfants de moins de 13 ans soient
autorisés à utiliser l’aûteuse de patins SparxMC.
5. L’aûteuse de patins SparxMC ne doit pas être utilisée par des
personnes (y compris des enfants de 13 ans et plus) ayant des
capacités physiques, sensorielles ou mentales réduites, ou un
manque d’expérience et de connaissances, à moins qu’elles
soient surveillées ou qu’elles aient reçu une bonne formation sur
l’utilisation de l’aûteuse par un adulte compétent.
6. Les enfants doivent être surveillés pour s’assurer qu’ils ne jouent
pas avec l’aûteuse de patins SparxMC.
7. L’aûteuse de patins SparxMC doit être utilisée exclusivement pour
l’aûtage de patins.
8. La machine doit être utilisée exclusivement avec des meules
d’aûtage SparxMC.
9. Pour assurer la sécurité de tout le monde, installez la machine
sur une surface stable et dans un endroit protégé. Elle doit être
placée dans un endroit où il n’y a aucun risque que quelqu’un puisse
marcher ou trébucher sur le cordon d’alimentation ou le cordon
d’alimentation puisse être endommagé.
10. Utilisez l’aûteuse de patins SparxMC toujours dans un
environnement sec, bien éclairé, et sans condensation. Pour éviter
tout risque de décharge électrique, n’utilisez jamais l’aûteuse de
patins SparxMC dans des conditions humides ou mouillées.
11. Pour éviter les blessures, soyez toujours prudent lors
de l’utilisation de l’aûteuse de patins SparxMC, ou lors du
remplacement de la meule d’aûtage.
12. N’essayez pas de toucher la meule d’aûtage, le guide-meule
mobile ou la pince de serrage pendant la rotation et le mouvement
de la meule. Attendez l’arrêt complet du guide-meule et de la meule
d’aûtage avant de tenter un réglage ou le remplacement de la
meule.
13. Assurez-vous que l’écrou à ailettes est serré sur la meule
d’aûtage avant de commencer l’aûtage
14. Ne laissez jamais l’aûteuse de patins SparxMC sans surveillance
pendant qu’elle est en marche.
15. Ne débranchez jamais le cordon d’alimentation en tirant sur le
cordon.
16. Rangez l’aûteuse de patins SparxMC dans un endroit sec, hors de
la portée des enfants.
17. Faites l’entretien de l’aûteuse selon les consignes de ce manuel.
18. Si, à tout moment, la machine cesse de fonctionner normalement,
consultez la section Diagnostic des pannes de ce manuel.
19. L’aûteuse ne comporte aucune pièce réparable par l’utilisateur.
Elle ne doit être réparée que par un technicien professionnel SparxMC
Hockey, exclusivement avec des pièces de rechange d’origine.
Les réparations non autorisées pourraient créer des conditions
dangereuses pour l’utilisateur ou annuler la garantie.
20. Pour toute question au sujet de l’aûteuse, veuillez communiquer
avec le service technique de SparxMC Hockey au (855-772-7947) ou
par courriel à [e-mail].
Mise en garde : Veuillez consulter les instructions dans le manuel.
Attention : Danger de pincement. Gardez les mains, les cheveux et
d’autres parties du corps à l’écart de la zone de la pince de serrage.
1
SÉCURITÉ

INTRODUCTION 5SÉCURITÉ4
CONfORMITÉ AUX NORMES
D’INDUSTRIE CANADA
Le présent appareil est conforme aux CNR d’Industrie Canada
applicables aux appareils radio exempts de licence. L’exploitation
est autorisée aux deux conditions suivantes : (1) l’appareil ne doit
pas produire de brouillage, et (2) l’utilisateur de l’appareil doit
accepter tout brouillage radioélectrique subi, même si le brouillage
est susceptible d’en compromettre le fonctionnement.
S K ATE C OM PAT IB I LI T Y
Hockey Skates
Goalie Skates
Figure Skates*
*Requires an additional adapter, which is sold separately.
DIMENSIONS AND WEIGHT
Width: 26.8 Inches / 680 mm
Height: 7.6 Inches / 194 mm
Depth: 15.5 Inches / 390 mm
Weight: 38.5 Pounds / 17.5 kg
ELECTRICAL
Line Voltage: 100–240 Volts AC (50–60 Hz single phase)
Maximum Power Consumption: 200 W
INTRODUCTION
2
TECHNICAL SPECIfICATIONS
