Spear & Jackson S1836EH User guide

S1836EH
S1733EH
MEH1735AE
ORIGINAL
INSTRUCTION
MANUAL
Important - Please read these instructions
fully before starting assembly AFTER SALES SUPPORT
Hover
Mower
0345 605 2068
These instructions contain important information that will help
you get the best from your mower, ensuring it is assembled
correctly and safely. If you need help or have damaged or
missing parts, call the Customer Helpline on 0345 605 2068

AFTER SALES HELPLINE 0345 605 2068
2
SPEAR & JACKSON SINCE 1760
For more than 250 years gardeners have enjoyed high quality performance and great results using
Spear & Jackson tools.
Our garden power tools combine continuous innovation and the latest in manufacturing technologies
with a proud heritage.
Each product is carefully designed with performance,comfort and durability rmly in mind,which has
earned Spear & Jackson an enviable reputation as a maker of tools to trust.
As a testament to the quality of our products, we offer a 3 year manufacturers warranty and a
comprehensive after sales service.
The warranty covers manufacturing faults, however in the event that the item has been deliberately
damaged, used in a commercial environment or disassembled then the warranty will be null and void.
Please retain proof of purchase.
We want you to get the best out of your products. Our easy-to-read instruction manual guides you with
best practice use and maintenance tips. Please call 0345 605 2068 for technical support, we can solve
around 80% of questions directly over the phone.
We hope you enjoy your product and we look forward to any feedback, as this allows us to develop
even better products for the future.
3 YEARS GUARANTEE
7 DAYS A WEEK TECHNICAL SUPPORT

AFTER SALES HELPLINE 0345 605 2068
3
Safety Information..................................................................................................................... 4
Intended Purpose............................................................................................................................. 4
Warning Symbols............................................................................................................................... 4
Work Area Safety ............................................................................................................................... 5
Electrical Safety ................................................................................................................................. 6
Power Tool Use and Care .................................................................................................................. 7
Personal Safety.................................................................................................................................. 7
Operating Safety ................................................................................................................................ 9
Maintenance and Storage Safety .................................................................................................... 13
Intended Use.................................................................................................................................... 13
In the Box........................................................................................................................................ 14
Parts ................................................................................................................................................. 14
Assemble................................................................................................................................... 17
Prepare ...................................................................................................................................... 18
Operate...................................................................................................................................... 19
Maintenance ............................................................................................................................. 22
Technical Data .......................................................................................................................... 24
Troubleshooting........................................................................................................................ 25
Warranty .................................................................................................................................... 26
CONTENTS

AFTER SALES HELPLINE 0345 605 2068
4
The following warning symbols appear throughout this
assembly manual and indicate the appropriate safety measures
you should take when assembly and operating the hover.
SAFETY INFORMATION
INTENDED PURPOSE
WARNING SYMBOLS
Before any use, refer
to the corresponding
paragraphin the present
manual.
This symbol, before
a safety comment,
indicates a precaution,
a warning or a danger.
Ignoring this warning
can lead to an accident
for yourself or for others.
To limit the risk of injury,
fire, or electrocution
always apply the
recommendations
indicated.
Wear hearing protection
Wear eye protection
Wear protective gloves
Do not expose and
operate the product to
rain or wet conditions.
Remove the plug from
the mains immediately if
cable is damaged or cut.
There is a risk that some
objects could be thrown
out by the shredder.
Keep bystanders away.
before leaving the
product unattended for
any period.
Double insulation.
Keep supply flexible
cord away form cutting
means.
Guaranteed sound power
level value in 96 dB.
The product complies
with the applicable
European directives and
an evaluation method
of conformity for these
directives was done.
Waste electrical products
should not be disposed
of with household waste.
Please recycle where
facilities exist.

AFTER SALES HELPLINE 0345 605 2068
5
SAFETY INFORMATION
WORK AREA SAFETY
GENERAL SAFETY
• Inspect the area where
the machine is to be used
and remove all objects
which can be thrown by
the machine. If objects are
hidden while operating stop
the motor and remove them.
• Do not operate the machine
in explosive atmospheres,
such as in the presence of
flammable liquids, gases
or dust. Power tools create
sparks which may ignite the
dust or fumes.
• Keep children and
bystanders away while
operating a power tool.
Distractions can cause you
to lose control.
IMPORTANT!
• Keep this instruction manual
in a safe place for future
reference.
• Read the instructions
carefully. Be familiar with the
controls and the proper use
of the equipment.
• Never allow children or
people unfamiliar with
these instructions to
use this Hover. Local
regulations can restrict the
age of the operator.
• Never use the machine while
people, especially children,
or pets are nearby. Keep
in mind that the operator
or user is responsible
for accidents or hazards
occurring to other people or
their property.
• This appliance can be
used by children aged
from 8 years and above
and persons with reduced
physical, sensory or
mental capabilities or
lack of experience and
knowledge if they have
been given supervision or
instruction concerning use
of the appliance in a safe
way and understand the
hazards involved. Children
shall not play with the
appliance. Cleaning and
user maintenance shall not
be made by children without
supervision.
• Don’t use the appliance
without reading the
instruction sheet.
• Children should be
supervised to ensure that
they do not play with the
appliance.

AFTER SALES HELPLINE 0345 605 2068
6
tool outdoors, use an
extension cord suitable for
outdoor use. Use of a cord
suitable for outdoor use
reduces the risk of electric
shock.
• If operating a power tool
in a damp location is
unavoidable, use a residual
current device (RCD)
protected supply. Use
of an RCD reduces the
risk of electric shock. The
maximum operating current
of the RCD must be less
than 30mA.
• The voltage indicated
on the rating plate must
correspond to the voltage of
the power source.
• Only use or replace power
supply cables for this unit
which correspond to the
types indicated by the
manufacturer. See the
operating instructions for the
order no. and types.
• Never touch the mains plug
with wet hands.
• Do not run over, crush or
pull the power supply cable
or extension lead, otherwise
it may be damaged. Protect
the cable from heat, oil and
sharp edges.
SAFETY INFORMATION
GENERAL SAFETY
ELECTRICAL SAFETY
• The plug must match the
outlet. Never modify the
plug in any way. Do not
use any adapter plugs
with earthed (grounded)
power shall not play with
the appliance. Cleaning and
user maintenance tools.
Unmodified plugs and
matching outlets will reduce
the risk of electric shock.
• Avoid body contact with
earthed or grounded
surfaces, such as pipes,
radiators, ranges and
refrigerators. There is an
increased risk of electric
shock if your body is
earthed or grounded.
• Do not expose power tools
to rain or wet conditions.
Water entering a power
tool will increase the risk of
electric shock.
• Do not abuse the cord.
Never use the cord
for carrying, pulling or
unplugging the power tool.
Keep the cord away from
heat, oil, sharp edges or
moving parts. Damaged or
entangled cords increase
the risk of electric shock.
• When operating a power

AFTER SALES HELPLINE 0345 605 2068
7
SAFETY INFORMATION
• The extension lead must
have a cross section
in accordance with the
operating instructions
and be protected against
splashed water. The
connection must not be in
water.
POWER TOOL USE AND CARE
• Do not force the power
tool. Use the correct power
tool for your application.
The correct power tool will
do the job better and more
safely when operated at
the rate for which it was
designed.
• Do not use the power tool
if the switch does not turn it
on and off. Any power tool
that cannot be controlled
with the switch is dangerous
and must be repaired.
• Store idle power tools out of
the reach of children and do
not allow persons unfamiliar
with the power tool or these
instructions to operate the
power tool. Power tools are
dangerous in the hands of
untrained users.
• Maintain power tools. Check
for misalignment or binding
of moving parts, breakage
of parts and any other
condition that may affect
the power tool’s operation.
If damaged, have the power
tool repaired before use.
Many accidents are caused
by poorly maintained power
tools.
• Keep cutting tools sharp
and clean. Properly
maintained cutting tools with
sharp cutting edges are less
likely to bind and are easier
to control.
• Use the power tool,
accessories and tool bits
etc. in accordance with
these instructions, taking
into account the working
conditions and the work to
be performed. Use of the
power tool for operations
different from those intended
could result in a hazardous
situation.

AFTER SALES HELPLINE 0345 605 2068
8
• Stay alert, watch what
you are doing and use
common sense when
operating the machine. Do
not use the machine while
you are tired or under the
influence of drugs, alcohol
or medication.
• Use personal protective
equipment such as dusk
masks and non-skid safety
shoes. Always wear eye
protection.
• Prevent unintentional
starting. Ensure the switch
is in the off -position before
connecting to power source,
picking up or carrying the
tool.
• Do not carry the machine
with your finger on the
switch .
• Remove any adjusting key
or wrench before turning
the machine on. A wrench
or a key left attached to a
rotating part of the machine
may result in personal injury.
• Do not overreach. Keep
proper footing and balance
at all times.
• Dress properly. Do not wear
loose clothing or jewellery.
Keep your hair, clothing and
gloves away from moving
parts. Loose clothes,
jewellery or long hair can be
caught in moving parts.
• If devices are provided for
the connection of dust
extraction and collection
facilities, ensure these are
connected and properly
used. Use of dust collection
can reduce dust-related
hazards.
• Warning! Switch off, remove
plug from mains before
adjusting, cleaning or if
cable is cut, damaged or
entangled.
• The blades continue to
rotate for a few seconds
after the machine is
switched off.
• The operating voltage is
220-240V~, 50Hz. If you
want to use an extension
cable should not be lighter
than:
- if rubber insulated, or
ordinary tough rubber
sheathed flexible cord
-if polyvinyl chloride
insulated, ordinar polyvinyl
chloride sheathed flexible
cord (code designation H05
VVF) and the following cable
dimensions should be used:
PERSONAL SAFETY
SAFETY INFORMATION

AFTER SALES HELPLINE 0345 605 2068
9
• 1.0mm²: max. length 40m
• 1.5 mm²: max. length 60m
• 2.5 mm²: max. length 100m
Note: If an extension cable
is used it must be earthed
and connected through
the plug to the earth cable
of your supply network in
accordance with prescribed
safety regulations.
• If in doubt contact a
qualified electrician or call
the after sales support.
• WARNING! Inadequate
extension cables can be
dangerous. Extension cable,
plug and socket must be of
watertight construction and
intended for outdoor use.
• It is recommended for
increased electrical safety to
use a Residual Current
Device (RCD) with a tripping
current of not more than
30mA. Always check your
RCD every time you use it.
SAFETY INFORMATION
AFTER SALES HELPLINE 03456 052 068
OPERATING SAFETY
TRAINING
• Read the instructions
carefully. Be familiar with the
controls and the proper use
of the machine.
• Never allow people
unfamiliar with these
instructions or children to
use the product. Local
regulations can restrict the
age of the operator.
• Never use the machine while
people, especially children,
or pets are nearby. Keep
in mind that the operator
or user is responsible
for accidents or hazards
occurring to other people or
their property.
PREPARATION
• While operating the machine
always wear substantial
footwear and long trousers.
Do not operate the machine
when barefoot or wearing
open sandals. Avoid
wearing clothing that is
loose fitting or that has
hanging cords or ties.
• Thoroughly inspect the area
where the machine is to be
used and remove all objects
which can be thrown by the
machine.

AFTER SALES HELPLINE 0345 605 2068
10
SAFETY INFORMATION
• Before using, always
visually inspect to see that
the blade, blade bolt and
the blade assembly are
not worn or damaged.
Replace worn or damaged
components in sets to
preserve balance. Replace
damaged or unreadable
labels.
• Before use check the supply
and extension cord for signs
of damage or aging. If the
cord becomes damaged
during use, disconnect
the cord from the supply
immediately.
OPERATION
• Operate the machine only in
daylight or in good artificial
light. Do not expose the
product to rain or wet
conditions. Avoid using the
product in bad weather
conditions especially when
there is a risk of lightning.
• Never operate the machine
with defective guards or
shields, or without safety
devices, for example
deflectors and/or grass
collector, in place.
• Do not put hands or feet
near or under rotating parts.
Keep clear of the discharge
opening at all times.
• Before use check the
controls and correct
operation of the product.
• Before using the product or
after any impact, check for
signs of wear or damage
and repair as necessary.
• Always disconnect the
product from the power
supply (i.e. remove the plug
from the power supply)
– Whenever leaving the
product unattended;
– Before clearing a
blockage;
– Before checking, cleaning
or working on the product
– After striking a foreign
object;
– Whenever the product
starts vibrating abnormally.
• Always ensure that the
air vents are kept clear of
debris.
• Never use replacement
parts or accessories not
provided or recommended
by the manufacturer.
• Position the cord so that it
will not be caught by the
cutting attachment during
operation.
• Disconnect from the power
supply when the cord

AFTER SALES HELPLINE 0345 605 2068
11
devices, for example
deflectors and/or grass
collector, in place.
• Switch on the motor
carefully according to
instructions and with feet
well away from the blade(s).
• Do not tilt the machine when
switching on the motor,
except if the machine has to
be tilted for starting. In this
case, do not tilt it more than
absolutely necessary and lift
only the part, which is away
from the operator.
• Do not start the machine
when standing in front of the
discharge opening.
• Do not transport the
machine while the cutting
blade is running. Make sure
that all moving parts have
come to a complete stop.
• Whenever you leave the
machine,
• Before clearing blockages
or unclogging chute,
• Before checking, cleaning
or working on the machine,
• After striking a foreign
object. Inspect the machine
for damage and make
repairs before restarting and
operating the machine.
becomes damaged or
tangled.
• Do not use the product if the
cord is damaged or worn.
• Warning! The cutting blade
may continue to move after
the product is switched off.
• Keep the extension cord
away from the blades at all
times.
• Always be sure of your
footing on slopes.
• Walk, never run.
• Mow across the face of
slopes, never up and down.
• Exercise extreme caution
when changing direction on
slopes.
• Do not mow excessively
steep slopes.
• Use extreme caution when
reversing or pulling the
machine towards you.
• Stop the blade(s) if the
machine has to be tilted
for transportation when
crossing surfaces other
than grass, and when
transporting the machine
to and from the area to be
used.
• Never operate the machine
with defective guards or
shields, or without safety
SAFETY INFORMATION

AFTER SALES HELPLINE 0345 605 2068
12
• If the machine starts to
vibrate abnormally (check
immediately),
• inspect for damage,
• replace or repair any
damaged parts,
• check for and tighten any
loose parts.
EMERGENCY
• WARNING! Familiarize
yourself with the use of
this machine by means
of this instruction manual.
Memorise the safety
directions and follow them
to the letter. This will help to
prevent risks and hazards.
• Always be alert when using
the machine, so that you
can recognize and handle
risks early. Fast intervention
can prevent serious injury
and damage to property.
• Switch off and disconnect
from the power supply if
there is any malfunction.
Have the machine checked
by a qualified specialist and
repaired, if necessary before
you put it into operation
again.
RESIDUAL RISKS
• WARNING! Even if you
are operating the machine
in accordance with all
safety requirements,
potential risks of injury
and damage remain. The
following dangers can arise
in connection with the
structure and design of this
machine:
• Health defects resulting
from vibration emission if the
machine is being used over
long periods of time or not
adequately managed and
properly maintained.
• Injuries and damage to
property due to broken
application tools or sudden
impact of hidden objects
during use.
• WARNING! This
machine produces an
electromagnetic field during
operation! This field may
under some circumstances
interfere with active or
passive medical implants!
To reduce the risk of
serious or fatal injury, we
recommend persons with
medical implants to consult
their doctor and medical
implant manufacturer before
operating this product!
SAFETY INFORMATION

AFTER SALES HELPLINE 0345 605 2068
13
SAFETY INFORMATION
MAINTENANCE AND STORAGE SAFETY
INTENDED USE
• Keep all nuts, bolts and
screws tight to be sure the
machine is in safe working
condition.
• Check the grass collector
frequently for wear or
deterioration.
• On machines with multi
blades, take care as rotating
one blade can cause other
blades to rotate.
• Be careful during
adjustment of the machine
to prevent entrapment
of the fingers between
moving blades and fixed
parts of the machine.
• Always allow the machine to
cool down before storing.
• When servicing the blades
be aware that, even
though the power source
is switched off, the blades
can still be moved.
• Replace worn or damaged
parts for safety. Use only
genuine replacement parts
and accessories.
SERVICE
•
Have your machine repaired
by an authorized service
agent. This
machine
is manufactured in
accordance with the
This Hover is designed for
domestic use only:
• This electric Hover is intended
for mowing lawns in domestic
and hobby gardens.
• This product is not to be used
in wet weather conditions and
may not be used to mow wet
or unusually high grass, e. g.
pasture grass or for shredding
leaves.
• This product is intended for
private domestic use only,
not for any commercial trade
use. It must not be used for
any purposes other than
those described. Any use of
the machine that deviates
from its intended use and is
not included in these.
relevant safety regulations.
To avoid danger,
equipment must only
be repaired by qualified
technicians.
• Only use parts and ccessories
made for this machine by the
manufacturer. Failure to do
so can result in personal
injury.

AFTER SALES HELPLINE 0345 605 2068
14
IN THE BOX
9
10
11
16
1
7
8
3
4
2
5
12
13
14
6
PARTS 7367416 (S1836EH )
1Switch box
2on/off switch lever
3Upper handle
4Quick release lever
5Lower handle
6Grass box
7Safety lock-off
button
8Cable strain relief
hook
9 Cable clamp
10 Spanner
11 Grassbox lid
12 Deck
13 Screw*2
14 Mulch mode
selection
switch(on the box)
15 Spacer*3
(one piece is
pre-assembled)
16 Wheel
15

AFTER SALES HELPLINE 0345 605 2068
15
IN THE BOX
9
10
16
15
11
1
7
8
3
4
2
5
13
12
6
PARTS 7454154 (S1733EH)
1Switch box
2On/off switch lever
3Upper handle
4Quick release lever
5Lower handle
6Grass box
7Safety lock-off
button
8Cable strain relief
hook
9Cable clamp
10 Spanner
11 Grassbox lid
12 Deck
13 Screw*2
14 Spacer*3 (one
piece is pre-
assembled)
15 Mulch plug
16 Wheel
14

AFTER SALES HELPLINE 0345 605 2068
16
IN THE BOX
9
10
11
1
7
8
3
4
2
5
12
6
PARTS 7498103 (MEH1735AE)
1Switch box
2on/off switch lever
3Upper handle
4Quick release lever
5Lower handle
6Grass box
7Safety lock-off
button
8Cable strain relief
hook
9Cable clamp
10 Spanner
11 Grassbox lid
12 Deck
13 Screw*2
14 mulch mode
exchange
switch(on the box)
15 switchSpacer*3
(one piece is pre-
assembled)
16 Detachable cable
17 Wheel
13
16
14
15
17

AFTER SALES HELPLINE 0345 605 2068
17
1
ASSEMBLY
2
3
4
Unpacking
i. Unpack all parts and lay them on a flat, stable surface.
ii. Remove all packing materials and shipping devices if
applicable.
iii. Make sure the delivery contents are complete and free of
any damage. If you find that parts are missing or show
damage do not use the product but contact the aftersales
helpline within 28 days of purchase. Using an incomplete
or damaged product represents a hazard to people and
property.
iv. Ensure that you have all the accessories and tools needed
for assembly and operation. This also includes suitable
personal protective equipment.
Fix the Lower handle
Fully insert the lower handle into the slot on the deck.
Fasten in position with the 2 screws provided.
Fix the upper handle
Attach the upper handle to the lower handle tubes using
bolts and wingknobs.
Once fitted correctly the upper handles should still move
up and down. this freedom of movement allows the hover
mower to float correctly on the uneven surfaces of a lawn.
Do not over tighten these wingknobs.
The spanner could be easily fixed on the machine like below
way
Fix the cable
Ensure that the cables clied are used to fix the cable to the
handle.

AFTER SALES HELPLINE 0345 605 2068
18
5
PREPARE
Connection to the power supply
i. Hook the mains cable through the cable strain-release to
reduce the strain on the cable fitting as you mow.
ii. Connect the plug to the main socket.
Setting the cutting height
Remove the blade bolt, add the spacer to your suitable cut-
ting height.
Cutting position Cutting height
1 (Non-spacer) 33mm
2 (1 spacer, pre-assemble) 26mm
3 (2 Spacers) 19mm
4 (3 spacers) 12mm

AFTER SALES HELPLINE 0345 605 2068
19
OPERATE
Mowing tips
i. Verify that the lawn is free of stones, sticks, wires ,and other
objects that could damage the hover.
ii. When cutting thick grass, reduce walking speed in order to
allow for a more effective cut and a proper discharge of the
clippings.
iii. Never cut off more than one-third of the total length of the
grass for a healthy lawn. If it is roughly 6cm long, the grass
should not be shorter than 4cm once mowed. If the grass
is higher, you should gradually cut it down to the desired
length so as not to damage the grass.
iv. Do not cut wet grass because it tends to stick to the un-
derbody of the hover, preventing the proper discharge of
grass clippings.
Blade Maintenance
Always switch the product off, disconnect it from power sup-
ply and let the product cool
down before performing inspection, maintenance and clean-
ing work!
Removing the blade and fan. USE GLOVES.
• To remove the blade bolt 18 , hold the blade 19 firmly and
with the spanner 10 provided loosen the blade bolt 18 .
• Remove the blade bolt 18 , blade 19 , spacer 20 and
impeller 21 .
• Inspect for damage and clean as necessary.
Renew your metal blade after 50 hours mowing or 2 years
whichever is the sooner-regardless of condition. If the blade is
cracked or damaged replace it with a new one. Never use a
blade bolt if the insulated head is damaged cracked or missing.
Fitting the blade and impeller. USE GLOVES.
• Ensure the impeller 21 is located correctly.
• Place the spacers 20 onto the fan ensuring the pegs have
located into the holes
• Ensure the pegs have located into the holes on the blade
and that the blade is positioned as illustrated in figure 6.
• Place the blade bolt 18 through the centre hole of the
blade.
• Tighten down clockwise by hand.
• Hold the blade 19 firmly and tighten the blade bolt with
the spanner provided.
33 mm
12 mm
19 mm
26 mm
21
19
18
20

AFTER SALES HELPLINE 0345 605 2068
20
OPERATE
When removing a spacer from its storage location on the
spanner, gently twist it as you remove it. When you replace a
spacer back to this location just push it firmly into position.
IMPORTANT! Ensure the power cord is disconnected
from the mains supply and wait until the cutting head has
stopped rotating before adjusting the cutting height.
• There are 4 different cutting heights. Figure 7 shows
the lowest cutting height, 3 spacers. Figure 8 shows
the highest cutting height, no spacers. Adding spacers
reduces the cutting height, removing spacers increases
cutting height
• Disconnect from the main electricity supply and wait
until impeller 21 and the blade bolt 18 have stopped
rotating.
• Turn your product upside down.
• To remove the blade 19 and adjust the number of spac-
ers 20 , use the spanner 10 to remove blade bolt 18 . The
spacers 20 and blade 19 can now be removed and the
number of spacers adjusted.
• Spacers that are not being used can be stored on the
spanner to prevent loss.
• Refit the blade as described in Blade Maintenance.
21
21
19
19
18
18
20
20
