Speco CLT5 User manual

Camera Bracket Mounting
Quick Start Guide
Thank you for purchasing our product. This manual is applicable to the wall mounting bracket and the ceiling
mounting bracket of the fisheye camera. All pictures in this manual are for reference only.
Before installation, please make sure the wall or ceiling is strong enough to withstand three times the weight of
the camera and the bracket. Please install your camera and bracket in a dry environment. Here we will introduce
the installation of the wall mounting bracket and the ceiling mounting bracket of the fisheye camera.
Mounting Examples
Installation
Ceiling Mounting
1
4
2
5
3
6
Attach the drill template to the place where you
want to fix the bracket. Then drill the screw holes
according to the drill template.
Tear off the drill template and insert the plastic
plugs.
Fix the mounting base to the wall with the screws
provided.
Install to the mounting base according to the
screw thread.
Mount the water-proof ring to and then screw
b with the water-proof ring into a .
Install the sponge and the rubber plug respectively
to the mounting base .
Sponge
Water-proof ring
Rubber plug
b
b
a
a
7
4
1
8
5
2
9
6
3
78 9
450043001090 A0
Sponge
Rubber plug
Install the sponge and the rubber plug respectively
to the mounting base .
Remove the fixed ring from the gap of the camera
and then open the cover of the micro SD card
slot. After that, insert a micro SD card.
Remove the fixed ring from the gap of the camera
and then open the cover of the micro SD card
slot. After that, insert a micro SD card.
Install the cover of micro SD card slot and then
fasten the camera onto the bracket with screws.
Install the cover of micro SD card slot and then
fasten the camera onto the bracket with screws.
Install the fixed ring back to the camera and then
fix the bracket with screws.
Install the fixed ring back to the camera and then
fix the bracket with screws.
Install to the mounting base according to the
screw thread.
c
c
d
Attach the drill template to the place where you
want to fix the bracket. Then drill the screw holes
according to the drill template.
Tear off the drill template and insert the plastic
plugs.
Fix the mounting base to the wall with the screws
provided.
Gap
Fixed ring
Fixed ring
Gap
Wall Mounting
Mount the water-proof ring to and then screw
d with the water-proof ring into c .
d
Water-proof ring
