1 Introduction
About This Guide
This guide contains information about BlueScale Encryption for Spectra T950, T120, and T50
libraries. This reviews information on the configuration and use of encryption. Note that the
encryption procedures for the Spectra T950 and T120 libraries cover both library-based and
drive-based encryption; the Spectra T50 library supports drive-based encryption only.
The guide has been divided into the following sections:
BlueScale Encryption Overview on page 10 reviews both encryption best practices and
information on using BlueScale Encryption and key management on your site, and
includes a short glossary.
Spectra T950 and T120 BlueScale Encryption on page 26 reviews using Spectra T950/T120
BlueScale Encryption and key management.
Spectra T50 BlueScale Encryption on page 71 reviews using Spectra T50 BlueScale
Encryption and key management.
EDU and BlueScale Encryption Support on page 123 reviews an optional utility that lets
you recover data without a library; this section also provides support information.
Intended Audience
This guide assumes that you are familiar with data backup and data protection strategies.

1. Introduction
8
Related Publications
This guide outlines the configuration and use of BlueScale Encryption software in your
Spectra library.
For detailed information on the configuration and use of the library itself, see the Spectra
Logic publications specific to your library.
• The library’s user guide describes the configuration and use of the library, including
specifications and troubleshooting information.
•Thelibrary’s release notes provide the most up-to-date information about the library,
drives, and media.
The most up-to-date versions of all library documentation are available on Spectra Logic’s
Web site at www.SpectraLogic.com.
Conventions Used in this Guide
Important information is called out as follows:
Note: Provides additional points or suggestions.
Caution: Provides information about how to avoid damage to equipment.
Warning: Describes ways to avoid personal injury.
A caret (>) describes a series of menu selections. For example:
Select Configuration > Network
means
Select Configuration, then select Network.

1. Introduction
9
Shipped Items
The following items are included with the purchase of BlueScale Encryption:
• One encryption activation key
• One software support agreement
•Thisuserguide
•Onet-shirt
If you ordered the Endura®Decryption Utility (EDU), you also receive one EDU CD.

BlueScale Encryption
Overview

11
2 Encryption Architecture & Strategies
BlueScale Encryption Overview
BlueScale Encryption is tightly integrated into your Spectra library. Encryption can be handled
through the library’s encryption-enabled Quad Interface Processors (QIPs), if any are in use,
and through LTO-4 drives working with LTO-4 media. BlueScale encryption key management is
provided through the library’s graphical interface.
If a single library has encryption-ready QIPs and LTO-4 drives installed, both can be used for
encryption. Set up an encryption-enabled partition for each.
The system is based on two major components:
• The encryption chip on the QIP or LTO-4 drive. By implementing encryption in both types
of hardware, the encryption is extremely fast and places no burden on your network.
• Key management software through the library’s graphical interface. The interface displays
using the library’s touch-screen front panel Library Controller (LC). It also displays from
anywhere through the Web, using a Web browser to display the Remote Library Controller
(RLC). Optionally, you can secure the Web browser using SSL, which is part of the
Telescope suite of management tools.
Together, these components let you easily implement the strongest encryption available, as
recognized by the federal government: AES encryption using a 256-bit key. BlueScale
Encryption incorporates multiple layers of security, some of which are discussed in this
chapter. Others are technically implemented and invisible to the user.
Site-Specific Decisions
To determine a BlueScale Encryption strategy appropriate for your site and your data, decide
on the security level appropriate for your site, and the amount and kinds of data to encrypt.
Then you can make some choices about how best to implement BlueScale Encryption.

2. Encryption Architecture & Strategies
12
BlueScale Encryption: Standard Edition vs. Professional Edition
All data encrypted using BlueScale Encryption and Key Management—Standard and
Professional Editions, and LTO-4 drive-based encryption—is secured by the strongest
available encryption method, AES-256. Through BlueScale Encryption and Key Management,
you have additional choices in defining the level of security you can implement in your data
center. Whether to implement BlueScale Standard Edition or Professional Edition is your first
choice.
Feature Standard Edition Professional Edition
Keys - Single encryption key on a library
at a time
- Easier to manage and track
- Multiple simultaneous encryption keys
(maximum is 30 keys)
- More secure, with a key for each of multiple data
sets
Encryption Login
Passwords
- Single encryption password
- Easier to manage and track
- Choice of either one encryption password or three
- More secure, with the option of requiring multiple
users to export and import keys, etc.
Key Export and
Import
- Import and export functions
require a single password
- Easier to manage
- Choice of single password or M-of-N shares with
multiple passwords to export/import keys
- More secure
Compression a
a. If you are using drive-based encryption, compression is handled through the drive. Further references to compression in this
manual apply to library-based, not drive-based, encryption.
- Not available for QIP-based
encryption
- Available for QIP-based encryption
Compatibility
between
Versions
- Data encrypted using either version can be decrypted by a library running the other
version.
- Data encrypted and compressed by a library using LTO-4 drives, Professional Edition, or
both, can be decrypted and decompressed by a library running Standard Edition.
Summary - Less secure, but less to manage - Fewer tapes through compression
- More secure, but more to manage

2. Encryption Architecture & Strategies
13
BlueScale Standard Edition
For sites with a primary goal of securing data while it is transported to a remote site and
stored there, or only for data that will be stored for a long period of time, BlueScale Standard
Edition works well.
For information about configuring and using BlueScale Encryption Standard Edition, see
Chapter 4. Using Standard Edition in Spectra T950 and T120 Libraries on page 30.
BlueScale Professional Edition
For sites that want to implement compression along with greater flexibility and security, to
protect data wherever it’s stored and regardless of the retention period, BlueScale Encryption
Professional Edition works well.
For information about configuring and using BlueScale Professional Edition, see Chapter 5.
Using Professional Edition in Spectra T950 and T120 Libraries on page 45.
Security on Initialization
Both editions of BlueScale Encryption give you security options at library startup. Choose
whether to start the library:
• In standard mode, so that at library startup, data is encrypted with no further action
required.
• In secure initialization mode, so that at startup, drives are not automatically enabled;
encryption is only available and backups only run after a superuser has logged in and the
encryption password is entered.

2. Encryption Architecture & Strategies
14
Multiple Encryption Password Support
The Standard Edition of BlueScale Encryption supports one encryption password.
The Professional Edition of BlueScale Encryption lets you choose whether to support one
encryption password, or three encryption passwords that enforce another level of security. If
you choose to implement the triple-password option, then:
• Three different passwords must be entered when configuring encryption.
• Any one of the three passwords must be entered to enable encryption when the library is
in Secure Initialization mode.
• Any one of the three passwords must be entered to access encryption key management
and configuration options, excluding key import and export.
• Two of the three passwords must be entered to import and export keys.
Data to Encrypt
Decide whether to encrypt all data or a subset; then determine if the encrypted data can be
grouped together or if it must be isolated into sets. For example, your site may store financial
data as one set, separate from consumer identity information.
If all data can be encrypted together, the library requires only a single, encryption-enabled
partition. Otherwise, create multiple encryption-enabled partitions, one for each set of data,
and one or more partitions for data that is not to be encrypted.
Users with Professional Edition typically set up multiple partitions, each with its own key. For
example, if you are encrypting all your data, you only need one partition. If you are encrypting
only some of your data, create a partition dedicated to encryption along with a non-encryption
partition. If you want to keep your encrypted data sets isolated, create an encryption-enabled
partition for each encrypted data set, along with non-encryption partitions as needed.
Note: Implementing encryption after the library has been configured to
handle encryption simply requires creating backup jobs with your
backup software, which sends data to the proper partitions. Data is
automatically encrypted as it is backed up.

2. Encryption Architecture & Strategies
15
Encryption Methods
Choose how to encrypt data. You can use encryption-enabled QIPs, LTO-4 drives, or both to
encrypt data. With QIPs, the library handles encryption, and can encrypt data written to any
tape type (such as LTO-3 and SAIT). With LTO-4 drives, the drive handles encryption, and
encrypts data written to LTO-4 tapes.
Note: If a partition uses LTO-4 drive-based encryption, the library can load
LTO-3 media into that partition. However, attempts to write to LTO-3
media fail. Note that LTO-4 drives can successfully read data on LTO-3
tapes.
Further, if an encryption-enabled QIP and a Fibre Channel LTO-4 drive share a partition, you
can only encrypt data using the LTO-4 drive.
To decrypt data encrypted using a QIP, use a partition with QIP-based encryption. To decrypt
data encrypted using an LTO-4 drive, use a partition with drive-based encryption.
Only one encryption key is allowed per LTO-4 tape. Once you stop using that key, you can no
longer directly encrypt data to any LTO-4 tape that stores data encrypted using the old key. To
write encrypted data using a different key, you must first recycle the tape. Recycling media is
easily managed through BlueScale Encryption Key Management.
LTO-4 Media Recycling
LTO-4 tapes can store only data encrypted using a single key. If you have an LTO-4 tape storing
data encrypted using a different key, or encrypted using a QIP, you have to recycle the tape
before you can re-use it in an encryption-enabled LTO-4 drive.For more information about
recycling media using a T950 or T120 library, refer to Chapter 6. Recycling Encrypted LTO-4
Media in Spectra T950 and T120 Libraries on page 68. For more information about recycling
media using a T50, refer to Chapter 10. Recycling Encrypted Media in Spectra T50 Libraries on
page 119.

2. Encryption Architecture & Strategies
16
Best Practices
To effectively use BlueScale Encryption and to ensure data security, plan an encryption
strategy and back it up with processes and best practices. Once you’ve implemented
BlueScale Encryption, which always uses the strongest keys (AES-256), build custom
strategies based on your security requirements. As stated in the NIST publication
Recommendation for Key Management1:
“Ultimately, the security of information protected by cryptography directly depends on [...]
the effectiveness of [...] protocols associated with keys, and the protection afforded the
keys.”
Sound key management policies and procedures and appropriate staff are essential to
successful encryption.
People
Identify the people on your site who are responsible for backing up data. They will be
responsible for encrypting data written to tape and to other portable media, such as mobile
RXT®Media packs. Identify:
• The person to have superuser privileges on the Spectra Logic library with BlueScale
Encryption.
• The person to have the library’s encryption password.
Next, identify how many users are to have responsibilities that involve encryption. It may be
wise to have more than a single user familiar with passwords, depending on the size of your
organization, so that if one person is not available, another can take over. Make sure only the
authorized users know the encryption passwords, and that the passwords themselves are
secure. Refer to Passwords and Other Identifiers on page 19 for more information on setting
up passwords and monikers.
1. Barker, Elaine, W. Barker, W. Burr, W. Polk, and M. Smid. Recommendation for Key Management Part 1:
General. NIST Publication 800-57, 2005, p. 25

2. Encryption Architecture & Strategies
17
Processes
On an organizational level, you need to identify the level of security your site requires, and the
data to be encrypted—for example, you may choose to encrypt all data, or any combination of
financial, identity-related information, and strategic data.
Consider the following when establishing your encryption procedure:
• Determine the level of security to use at startup. Both editions of BlueScale encryption
permit a standard mode and a secure initialization mode, described in Security on
Initialization on page 13.
• Identify any data sets that must be isolated from other encrypted data sets, described in
Data to Encrypt on page 14.
• Identify when to make copies of encryption keys. AES-256 encryption, a symmetric
encryption method, is a private key method. Users must track each key, which BlueScale
Encryption identifies only by a nickname, or moniker. The key itself is never displayed,
and is encrypted prior to export. Best practices dictate that you make copies of the key
immediately following the key’s creation.
• Identify the number of copies to make of each key, and note the location of each key copy.
Consider storing multiple copies of keys, that you then track carefully, storing the copies
away from the data encrypted using those keys. It is important to make sure that at least
one copy of each key is secure and readable (that is, uncorrupted), to make sure you can
restore your data. This is important in that keys, once deleted, are not recoverable—and
once the key is gone, the data is inaccessible; this is typically considered deleted for legal
and practical purposes.
• Identify the key rotation plan—how often to create and use new keys. BlueScale
Encryption Standard Edition stores one key on the library at a time. Professional Edition
permits multiple keys per library, with a one key per encryption-enabled partition. In
Standard Edition, you must delete the key currently on the library before you can create
another key.
• Before you delete a key, make sure that at least one copy has been exported and stored
securely.

2. Encryption Architecture & Strategies
18
• Identify methods of tracking user passwords, key passwords and monikers. If the data is
stored on a computer, make sure it is stored on a computer that enforces encryption and is
not available on a network.
• Optionally, identify a primary and secondary team, so that you have redundancy in your
encryption strategy. Although that means the information required to decrypt data is
spread across more people, it also means that restoration of encrypted data may be much
easier, and you may ultimately have more data protection given the extra layer of
coverage; for example, if a user leaves, you aren’t in a position to lose data. This returns to
your initial decisions on how tightly and in what manner to enforce security for your site.
• Run drills confirming that your data is being encrypted properly, that keys are stored
properly, and that you can recover your data efficiently. Make sure that these drills are
included with your overall organizational security strategy.
• Create procedures to handle encrypted data that has been, or may have been,
compromised. For example, you may want to take all data and decrypt it, then re-encrypt it
and store it in an alternate location. You will also need to investigate the incident
involving compromised data, and take appropriate actions if identity-related data may
have been exposed.
• Archive the Endura Decryption Utility (EDU) for emergency use, such as to recover from a
disaster. Use this utility if you have no Spectra Logic libraries on hand but need to decrypt
and write data, which you can then restore using backup software.
• If you are using Professional Edition and multiple keys, make sure that data stored to one
tape shares a common expiration date or period (e.g., fourth quarter), regardless of the
number of keys used to encrypt data written to the tape. This simplifies tape management
and re-use.
• If you are using Professional Edition, make sure that critically important data is stored
using a single key on its own tape, to simplify restoration in case of disaster recovery and
to achieve business continuity goals.
• If you are using Professional Edition, you may want to take advantage of the M-of-N
shares option. This lets you select the M-of-N (such as 2 of 3) option to split a single file of
encrypted key data into multiple parts, or shares (N, which in this example is 3), and then
requires some specified subset (M, which in this example is 2) to import the file containing
key data. This further protects data from unauthorized use.

2. Encryption Architecture & Strategies
19
Passwords and Other Identifiers
BlueScale Encryption requires that you supply passwords and monikers (key names). Your
site may want to consider whether specific rules govern these.
Superuser Login/Encryption Passwords Passwords are standard user security that restrict
access. Spectra Logic BlueScale Encryption requires that a superuser is logged in, then an
encryption password is supplied. A Professional Edition feature lets you optionally require
two of three different encryption passwords to be entered. The passwords involved with all
editions of BlueScale Encryption are:
• Superuser Password: Lets you access all administrative privileges except encryption
privileges. To access encryption features, the superuser must be logged in prior to
entering the encryption password.
• Encryption Password: Lets you access encryption features. This password must be
entered after the superuser login; then you can select Security --> Encryption to display
the encryption password screen.
• Import/Export Key Password: Lets you import and export encryption keys. This feature is
only available after the superuser has logged in and the encryption password has been
entered. Optionally, in Professional Edition, you can require two different passwords prior
to importing and exporting keys.
Password(s) for Key Import and Export Passwords are also used to encrypt keys for export.
Your site may consider whether to create different rules for these passwords, such as
requiring that these passwords are longer than the encryption access password(s), and
therefore more secure.
Monikers Your site may want to create rules governing naming conventions for key
monikers, an alphanumeric identifier used to refer to the never-revealed true key value, which
is a 256-bit key.
Password and Naming Standards Examples Create password and naming standards, in part
again depending on your site’s security requirements. For example, your site may require a
high level of security for access to encryption partitions, in which case you need to require
some combination of the following:
• A long password
• A combination that requires alphabetic and numeric characters
• No password that corresponds to a dictionary entry
• Passwords to be reset at predefined schedules

2. Encryption Architecture & Strategies
20
Site Security Example: Low Security Site
Description of organization: Small company with 75 employees.
Security
Considerations
Security goals Protecting company from legal liability associated with unauthorized access to data
stored on tape, both onsite and offsite, including transport to the offsite location.
Encryption principals IT administrator, company president, corporate legal counsel.
Data to encrypt Financial and consumer identity data.
Level of security to
implement
BlueScale Standard Edition: single key per library is sufficient.
Standard initialization mode: encryption partitions are enabled at all times.
Data sets requiring
isolation
None. A single partition for encrypted data is sufficient.
Key escrow method Staff at company will escrow keys at a site remote from the data storage location.
Copies of each key to
store and their locations
Keep three copies of each key: one with the senior IT administrator, one with the
company president, one in a corporate safety deposit box.
Key rotation plan Create a new key every six months.
Tracking key monikers
and passwords
On a non-networked computer that supports encryption, create one or more charts
or lists with this data, including key moniker, dates used, encryption and superuser
passwords, and password used to encrypt exported key. (Because BlueScale
prompts for the required encryption key moniker when restoring encrypted data,
this company chose not to track monikers and their relationship to media.)
Multiple encryption
teams (optional)
Deemed unnecessary given the users already identified as those responsible for
encryption.
Schedule and run drills Formalized approach deemed unnecessary. Instead, incorporate review of data
decryption into standard six-month check to make sure that backups and restores
are working properly. This now includes a test involving data decryption.
Passwords • Password to access encryption features: minimum of 12 characters,
including at least one number and one letter
• Password to export and import encryption keys: minimum of 30 characters,
including at least one number and one letter
