Spectra Precision ashtech ProFlex 800 CORS User manual

Getting Started Guide
CORS
Reference Station
ProFlex™ 800 CORS

Copyright Notice
Copyright 2012 Ashtech. All rights reserved.
Trademarks
All product and brand names mentioned in this pub-
lication are trademarks of their respective holders.
Ashtech Products - Limited Warranty (North, Central
and South America)
Ashtech warrants their GPS receivers and hardware
accessories to be free of defects in material and
workmanship and will conform to our published
specifications for the product for a period of one year
from the date of original purchase. THIS WARRANTY
APPLIES ONLY TO THE ORIGINAL PURCHASER OF
THIS PRODUCT.
In the event of a defect, Ashtech will, at its option,
repair or replace the hardware product with no charge
to the purchaser for parts or labor. The repaired or re-
placed product will be warranted for 90 days from
the date of return shipment, or for the balance of the
original warranty, whichever is longer. Ashtech war-
rants that software products or software included in
hardware products will be free from defects in the
media for a period of 30 days from the date of ship-
ment and will substantially conform to the then-cur-
rent user documentation provided with the software
(including updates thereto). Ashtech's sole obliga-
tion shall be the correction or replacement of the me-
dia or the software so that it will substantially
conform to the then- current user documentation.
Ashtech does not warrant the software will meet pur-
chaser's requirements or that its operation will be un-
interrupted, error-free or virus-free. Purchaser
assumes the entire risk of using the software.
PURCHASER'S EXCLUSIVE REMEDY UNDER THIS
WRITTEN WARRANTY OR ANY IMPLIED WARRAN-
TY SHALL BE LIMITED TO THE REPAIR OR RE-
PLACEMENT, AT ASHTECH'S OPTION, OF ANY
DEFECTIVE PART OF THE RECEIVER OR ACCESSO-
RIES WHICH ARE COVERED BY THIS WARRANTY.
REPAIRS UNDER THIS WARRANTY SHALL ONLY
BE MADE AT AN AUTHORIZED ASHTECH SERVICE
CENTER. ANY REPAIRS BY A SERVICE CENTER
NOT AUTHORIZED BY ASHTECH WILL VOID THIS
WARRANTY.
To obtain warranty service the purchaser must obtain
a Return Materials Authorization (RMA) number prior
to shipping by calling 1-800-229-2400 (North
America) or 1-408-572-1134 (International) and
leaving a voice mail at option 3, or by submitting a
repair request on-line at: http://ashtech.com (fill out
the RMA request from under the Support tab). The
purchaser must return the product postpaid with a
copy of the original sales receipt to the address pro-
vided by Ashtech with the RMA number. Purchaser’s
return address and the RMA number must be clearly
printed on the outside of the package.
Ashtech reserves the right to refuse to provide service
free-of-charge if the sales receipt is not provided or if
the information contained in it is incomplete or illeg-
ible or if the serial number is altered or removed.
Ashtech will not be responsible for any losses or dam-
age to the product incurred while the product is in
transit or is being shipped for repair. Insurance is
recommended. Ashtech suggests using a trackable
shipping method such as UPS or FedEx when return-
ing a product for service.
EXCEPT AS SET FORTH IN THIS LIMITED WAR-
RANTY, ALL OTHER EXPRESSED OR IMPLIED
WARRANTIES, INCLUDING THOSE OF FITNESS
FOR ANY PARTICULAR PURPOSE, MERCHANT-
ABILITY OR NON-INFRINGEMENT, ARE HEREBY
DISCLAIMED AND IF APPLICABLE, IMPLIED WAR-
RANTIES UNDER ARTICLE 35 OF THE UNITED NA-
TIONS CONVENTION ON CONTRACTS FOR THE
INTERNATIONAL SALE OF GOODS. Some national,
state, or local laws do not allow limitations on im-
plied warranty or how long an implied warranty lasts,
so the above limitation may not apply to you.
The following are excluded from the warranty cover-
age: (1) periodic maintenance and repair or replace-
ment of parts due to normal wear and tear; (2)
batteries and finishes; (3) installations or defects re-
sulting from installation; (4) any damage caused by
(i) shipping, misuse, abuse, negligence, tampering,
or improper use; (ii) disasters such as fire, flood,
wind, and lightning; (iii) unauthorized attachments
or modification; (5) service performed or attempted
by anyone other than an authorized Ashtechs Service
Center; (6) any product, components or parts not
manufactured by Ashtech; (7) that the receiver will
be free from any claim for infringement of any pat-
ent, trademark, copyright or other proprietary right,
including trade secrets; and (8) any damage due to
accident, resulting from inaccurate satellite trans-
missions. Inaccurate transmissions can occur due to
changes in the position, health or geometry of a sat-
ellite or modifications to the receiver that may be re-
quired due to any change in the GPS. (Note: Ashtech
GPS receivers use GPS or GPS+GLONASS to obtain
position, velocity and time information. GPS is oper-
ated by the U.S. Government and GLONASS is the
Global Navigation Satellite System of the Russian
Federation, which are solely responsible for the accu-
racy and maintenance of their systems. Certain con-
ditions can cause inaccuracies which could require
modifications to the receiver. Examples of such con-
ditions include but are not limited to changes in the
GPS or GLONASS transmission.) Opening, disman-
tling or repairing of this product by anyone other than
an authorized Ashtech Service Center will void this
warranty.
ASHTECH SHALL NOT BE LIABLE TO PURCHASER
OR ANY OTHER PERSON FOR ANY INCIDENTAL OR
CONSEQUENTIAL DAMAGES WHATSOEVER, IN-
CLUDING BUT NOT LIMITED TO LOST PROFITS,
DAMAGES RESULTING FROM DELAY OR LOSS OF
USE, LOSS OF OR DAMAGES ARISING OUT OF
BREACH OF THIS WARRANTY OR ANY IMPLIED
WARRANTY EVEN THOUGH CAUSED BY NEGLI-
GENCE OR OTHER FAULT OFASHTECH OR NEGLI-
GENT USAGE OF THE PRODUCT. IN NO EVENT
WILL ASHTECH BE RESPONSIBLE FOR SUCH
DAMAGES, EVEN IF ASHTECH HAS BEEN ADVISED
OF THE POSSIBILITY OF SUCH DAMAGES.
This written warranty is the complete, final and ex-
clusive agreement between Ashtech and the pur-
chaser with respect to the quality of performance of
the goods and any and all warranties and representa-
tions. This warranty sets forth all of Ashtech's respon-
sibilities regarding this product. This limited
warranty is governed by the laws of the State of Cali-
fornia, without reference to its conflict of law provi-
sions or the U.N. Convention on Contracts for the
International Sale of Goods, and shall benefit
Ashtech, its successors and assigns.
This warranty gives the purchaser specific rights. The
purchaser may have other rights which vary from lo-
cality to locality (including Directive 1999/44/EC in
the EC Member States) and certain limitations con-
tained in this warranty, including the exclusion or

limitation of incidental or consequential damages
may not apply.
For further information concerning this limited war-
ranty, please call or write:
Ashtech SAS - ZAC La Fleuriaye - BP 433 - 44474
Carquefou Cedex - France Phone: [phone]
38 00, Fax: [phone].
Ashtech Products Limited Warranty (Europe, Middle
East, Africa)
All Ashtech global positioning system (GPS) receiv-
ers are navigation aids, and are not intended to re-
place other methods of navigation. Purchaser is
advised to perform careful position charting and use
good judgment. READ THE USER GUIDE CAREFUL-
LY BEFORE USING THE PRODUCT.
1. ASHTECH WARRANTY
Ashtech warrants their GPS receivers and hardware
accessories to be free of defects in material and
workmanship and will conform to our published
specifications for the product for a period of one year
from the date of original purchase or such longer pe-
riod as required by law. THIS WARRANTY APPLIES
ONLY TO THE ORIGINAL PURCHASER OF THIS
PRODUCT.
In the event of a defect, Ashtech will, at its option,
repair or replace the hardware product with no charge
to the purchaser for parts or labor. The repaired or re-
placed product will be warranted for 90 days from
the date of return shipment, or for the balance of the
original warranty, whichever is longer. Ashtech war-
rants that software products or software included in
hardware products will be free from defects in the
media for a period of 30 days from the date of ship-
ment and will substantially conform to the then-cur-
rent user documentation provided with the software
(including updates thereto). Ashtech's sole obliga-
tion shall be the correction or replacement of the me-
dia or the software so that it will substantially
conform to the then- current user documentation.
Ashtech does not warrant the software will meet pur-
chaser's requirements or that its operation will be un-
interrupted, error-free or virus-free. Purchaser
assumes the entire risk of using the software.
2. PURCHASER'S REMEDY
PURCHASER'S EXCLUSIVE REMEDY UNDER THIS
WRITTEN WARRANTY OR ANY IMPLIED WARRAN-
TY SHALL BE LIMITED TO THE REPAIR OR RE-
PLACEMENT, AT ASHTECH'S OPTION, OF ANY
DEFECTIVE PART OF THE RECEIVER OR ACCESSO-
RIES WHICH ARE COVERED BY THIS WARRANTY.
REPAIRS UNDER THIS WARRANTY SHALL ONLY
BE MADE AT AN AUTHORIZED ASHTECH SERVICE
CENTER. ANY REPAIRS BY A SERVICE CENTER
NOT AUTHORIZED BY ASHTECH WILL VOID THIS
WARRANTY.
3. PURCHASER'S DUTIES
To obtain service, contact and return the product
with a copy of the original sales receipt to the dealer
from whom you purchased the product.
Ashtech reserves the right to refuse to provide service
free-of-charge if the sales receipt is not provided or if
the information contained in it is incomplete or illeg-
ible or if the serial number is altered or removed.
Ashtech will not be responsible for any losses or dam-
age to the product incurred while the product is in
transit or is being shipped for repair. Insurance is
recommended. Ashtech suggests using a trackable
shipping method such as UPS or FedEx when return-
ing a product for service.
4. LIMITATION OF IMPLIED WARRANTIES
EXCEPT AS SET FORTH IN ITEM 1 ABOVE, ALL
OTHER EXPRESSED OR IMPLIED WARRANTIES,
INCLUDING THOSE OF FITNESS FOR ANY PARTIC-
ULAR PURPOSE OR MERCHANTABILITY, ARE
HEREBY DISCLAIMED AND IF APPLICABLE, IM-
PLIED WARRANTIES UNDER ARTICLE 35 OF THE
UNITED NATIONS CONVENTION ON CONTRACTS
FOR THE INTERNATIONAL SALE OF GOODS.
Some national, state, or local laws do not allow limi-
tations on implied warranty or how long an implied
warranty lasts, so the above limitation may not apply
to you.
5. EXCLUSIONS
The following are excluded from the warranty cover-
age:
(1) periodic maintenance and repair or replacement
of parts due to normal wear and tear;
(2) batteries;
(3) finishes;
(4) installations or defects resulting from installa-
tion;
(5) any damage caused by (i) shipping, misuse,
abuse, negligence, tampering, or improper use; (ii)
disasters such as fire, flood, wind, and lightning; (iii)
unauthorized attachments or modification;
(6) service performed or attempted by anyone other
than an authorized Ashtechs Service Center;
(7) any product, components or parts not manufac-
tured by Ashtech,
(8) that the receiver will be free from any claim for
infringement of any patent, trademark, copyright or
other proprietary right, including trade secrets
(9) any damage due to accident, resulting from inac-
curate satellite transmissions. Inaccurate transmis-
sions can occur due to changes in the position,
health or geometry of a satellite or modifications to
the receiver that may be required due to any change
in the GPS. (Note: Ashtech GPS receivers use GPS or
GPS+GLONASS to obtain position, velocity and time
information. GPS is operated by the U.S. Govern-
ment and GLONASS is the Global Navigation Satel-
lite System of the Russian Federation, which are
solely responsible for the accuracy and maintenance
of their systems. Certain conditions can cause inac-
curacies which could require modifications to the re-
ceiver. Examples of such conditions include but are
not limited to changes in the GPS or GLONASS trans-
mission.).
Opening, dismantling or repairing of this product by
anyone other than an authorized Ashtech Service
Center will void this warranty.
6. EXCLUSION OF INCIDENTAL OR CONSEQUEN-
TIAL DAMAGES
ASHTECH SHALL NOT BE LIABLE TO PURCHASER
OR ANY OTHER PERSON FOR ANY INDIRECT, IN-
CIDENTAL OR CONSEQUENTIAL DAMAGES WHAT-
SOEVER, INCLUDING BUT NOT LIMITED TO LOST
PROFITS, DAMAGES RESULTING FROM DELAY OR
LOSS OF USE, LOSS OF OR DAMAGES ARISING
OUT OF BREACH OF THIS WARRANTY OR ANY IM-
PLIED WARRANTY EVEN THOUGH CAUSED BY
NEGLIGENCE OR OTHER FAULT OFASHTECH OR
NEGLIGENT USAGE OF THE PRODUCT. IN NO

EVENT WILL ASHTECH BE RESPONSIBLE FOR
SUCH DAMAGES, EVEN IF ASHTECH HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAG-
ES.
Some national, state, or local laws do not allow the
exclusion or limitation of incidental or consequential
damages, so the above limitation or exclusion may
not apply to you.
7. COMPLETE AGREEMENT
This written warranty is the complete, final and ex-
clusive agreement between Ashtech and the pur-
chaser with respect to the quality of performance of
the goods and any and all warranties and representa-
tions. THIS WARRANTY SETS FORTH ALL OF
Ashtech'S RESPONSIBILITIES REGARDING THIS
PRODUCT.
THIS WARRANTY GIVES YOU SPECIFIC RIGHTS.
YOU MAY HAVE OTHER RIGHTS WHICH VARY
FROM LOCALITY TO LOCALITY (including Directive
1999/44/EC in the EC Member States) AND CER-
TAIN LIMITATIONS CONTAINED IN THIS WARRAN-
TY MAY NOT APPLY TO YOU.
8. CHOICE OF LAW.
This limited warranty is governed by the laws of
France, without reference to its conflict of law provi-
sions or the U.N. Convention on Contracts for the In-
ternational Sale of Goods, and shall benefit Ashtech,
its successors and assigns.
THIS WARRANTY DOES NOT AFFECT THE CUS-
TOMER'S STATUTORY RIGHTS UNDER APPLICA-
BLE LAWS IN FORCE IN THEIR LOCALITY, NOR
THE CUSTOMER'S RIGHTS AGAINST THE DEALER
ARISING FROM THEIR SALES/PURCHASE CON-
TRACT (such as the guarantees in France for latent
defects in accordance with Article 1641 et seq of the
French Civil Code).
For further information concerning this limited war-
ranty, please call or write:
Ashtech SAS - ZAC La Fleuriaye - BP 433 - 44474
Carquefou Cedex - France.
Phone: [phone], Fax: [phone]
39 39

Table of Contents
What is ProFlex 800 CORS? .................................................................1
Hardware Description..........................................................................3
System Components Overview .................................................3
Basic Supply .....................................................................3
Optional Accessories ..........................................................4
Equipment Description & Basic Functions................................5
Front View .........................................................................5
Rear View ..........................................................................7
Buzzer ..............................................................................9
Battery Model & Battery Compartment .................................9
Special Button Combinations ............................................10
Charging Batteries Before Use ..............................................10
Removing the Battery from the ProFlex 800........................11
Charging the Battery.........................................................11
Inserting the Battery in the ProFlex 800.............................12
Display Screens ...................................................................12
Power-On Screen .............................................................13
General Status Screen ......................................................13
Memory Screens ..............................................................15
Receiver Identification Screen...........................................16
Position Computation Screen ............................................16
ATL Recording Screen ......................................................17
Screen Backlight..............................................................18
Data Transfer Screen ........................................................18
How to Safely Power the ProFlex 800 CORS...........................18
Introduction to ProFlex 800 CORS Configuration .................................20
Introductory Notes ...............................................................20
Creating Sessions ................................................................21
Raw Data Types and Files Collected During Sessions...............23
Storing G-Files Collected During Sessions ..............................23
Converting/Deleting G-Files Collected During Sessions ............24
Moving Files Originating from Sessions ..................................24
Pushing Files Originating from Sessions to an External
FTP Server - Backup FTP Server............................................25
Recording Raw Data Outside of Any Sessions .........................27
Embedded NTRIP Caster......................................................28
Introduction.....................................................................28
NTRIP Caster Control & Monitoring ....................................30
Map................................................................................32
Protecting Mount Points ...................................................32
E-mail Notifications .............................................................32
Embedded FTP Server..........................................................33
External Sensors..................................................................34
First Steps With the Web Server.........................................................36
Home Tab...........................................................................36
Status Bar and Units Used ...................................................37
Distance Units .................................................................39

Angle Units .....................................................................39
Time Units ......................................................................40
Setting a CORS Reference Station...................................................... 41
How to Start........................................................................41
General Parameters..............................................................41
Defining the Raw Data Generated by the CORS Station ...........43
Programming Sessions .........................................................44
Starting Sessions & Managing Raw Data Files.........................45
Programming Email Notifications .........................................47
Activating the Embedded FTP Server & Creating New Users.....48
Setting the External Sensors .................................................49
Adding Delivery of Real-Time RTK Corrections........................50
NTRIP Server Via Ethernet....................................................51
Setting the Embedded NTRIP Caster .....................................51
Monitoring ProFlex 800 CORS .............................................54

1
What is ProFlex 800 CORS?
ProFlex 800 CORS is a rugged and high-performance CORS
reference station. Designed as an extension of the ProFlex
800 receiver, ProFlex 800 CORS integrates the best of
today’s technologies, including the exclusive Z-Blade™
algorithms and multi-constellation (GPS+GLONASS+
GALILEO+SBAS) capabilities.
The main features of ProFlex 800 CORS are the following:
• Embedded Z-Blade technology guarantees outstanding
quality, availability and reliability of raw data acquisition,
providing the best possible measurements from four
GNSS constellations: GPS (including L5), GLONASS,
SBAS and GALILEO.
• Extended internal memory (8 Gbytes) for data storage.
• Embedded and password-protected Web Server giving the
owner full remote control of the reference station via an
Internet connection. The Web Server returns web pages on
the owner’s computer that give the owner the capability to
monitor the operation of the reference station, or change
partially or completely its settings.
• Generation of raw data files entirely manageable through
the Web Server. Data recording is organized as sessions,
with preset duration, ensuring round-the-clock data
recording, day after day and year after year.
• Raw data files can be converted to Rinex 2.11, Rinex
3.01, Hatanaka or TarZ before being made available to
users. RINEX conversion is performed on the fly (RINEX
file is available immediately after a session is finished to
meet rapid and ultra-rapid IGS services requirements). Up
to two RINEX files with two different periods can be
generated simultaneously.
• Embedded Ring File memory function offering unlimited
use of the storage medium. Enabling this function will
allow the oldest files in memory to be automatically
deleted if necessary to provide storage space for current
files being recorded.
• Raw data files can be pushed automatically to an external
FTP server. A backup FTP server can also be planned,
either as a fallback FTP server in case the primary FTP
fails, or as a second repository for data files.
•Embedded NTRIP caster (firmware option) offering the
possibility of implementing a complete network service
according to the NTRIP protocol. Using this protocol

2
makes it possible to access various sources of data from
different base stations through a single Internet
connection, as well as efficiently protect these sources of
corrections from unauthorized users.
The embedded NTRIP caster allows you to organize a
network of up to 10 different mount points (each of them
receiving corrections from an NTRIP server) and up to 100
users given the ability to receiver corrections through
these mount points.
• Smooth integration of meteorological and tilt data. Meteo
and tiltmeter sensors fully controlled by the receiver.
•Embedded FTP server allowing the administrator to
perform maintenance steps remotely or allow authorized
users to download raw data files directly from the receiver.
• Automatic email notifications informing the administrator
of possible malfunctions in real time.
• High degree of flexibility inherited from the ProFlex 800
receiver. In addition to delivering raw data files in ATOM
or Rinex format, the ProFlex 800 CORS can deliver
simultaneously real-time RTK corrections in ATOM
(configurable), RTCM2.3, RTCM 3.0 & 3.1 or CMR format
through various means:
– As an IP server or client delivering different streams of
raw data through up to nine virtual IP ports (Ethernet
data streaming).
–Asan“NTRIP Server”, delivering its corrections to the
embedded NTRIP caster (firmware option) or to an
external or third-party NTRIP caster. Up to two
independent NTRIP servers can be set up in the
ProFlex 800 CORS.
– Through Direct IP
– Through a UHF radio link
– Through its built-in GSM modem.

3
Hardware Description
System
Components
Overview
The tables below provide an overview of the different key
items composing the ProFlex 800 CORS.
Depending on your purchase, you may only have some of the
listed items. Please refer to the packing list for an accurate
description of the equipment that has been delivered to you.
Ashtech reserves the right to make changes to the items
listed below without prior notice.
Basic Supply
Item Part Number Picture
ProFlex 800 CORS receiver with all the acces-
sories listed below. 990627
Cellular antenna (quad-band) 111397
Bluetooth antenna 111403
7.4 V-4.4 Ah Li-ion Battery Pack (rechargeable) 111374
USB Host-to-Device Cable, 0.2 m
Makes ProFlex 800 a USB device. 702104
Ethernet adaptor cable 702426
Serial data cable 700461
Multi-function cable, 7C circular connector, bare
wires, length: 3 m approx. 702450
Soft transport bag 206410

4
Optional Accessories
AC/DC Power Supply Kit (includes external AC
adapter, battery charger and cable extension for
powering ProFlex 800 directly from the AC
adapter)
802064
ProFlex 800 User Documentation CD 501510
Item Part Number Picture
L1/L2 GNSS Antenna 111406
Choke ring installation kit for GNSS antenna
P/N 111406 802093
Choke ring GNSS antenna,
38 dB, 4.2-15 V DC,
includes “antibird” radome
111584
Choke ring antenna bundle, includes the fol-
lowing part numbers:
• 111584 (choke ring)
• 702455 (coaxial cable)
• + N-male / TNC-female adaptor
802120
Low-loss LMR-240GPS/GNSS cable, 30
meters, TNC male / TNC male 702455
TNC/TNC coaxial cable, 10 meters 700439
Item Part Number Picture

5
Equipment Description & Basic Functions
Front View
From left to right:
Bluetooth Antenna. A coaxial female connector (reverse SMA
type) allowing you to connect a Bluetooth antenna for
wireless communication with a field terminal or other device.
Cellular Antenna. A coaxial female connector (SMA type)
allowing you to connect a cellular antenna. A cellular antenna
is required when the ProFlex 800 sends or receives RTK or
differential corrections data via its internal cellular modem
(GSM).
Take care not to swap the Bluetooth antenna and the cellular
antenna. The picture below shows where the shorter and
longer antennas should be connected.

6
USB Host & Device. A nine-contact female connector (Fischer
type). Depending on how it is configured, the USB port can
be used in two different ways:
1. For a USB host, such as a mass storage device using
optional device cable P/N 702104.
2. For a USB device allowing ProFlex 800 to be seen as a
disk from the computer connected to this port. In this
configuration, files can be transferred between the
ProFlex 800’s internal memory and the computer using
the USB cable provided (P/N 702103).
Display Screen. The display consists of a 128 x 64-pixel, 1.5-
inch monochrome yellow screen using organic LED
technology (OLED).
Used in conjunction with the Scroll button, the display screen
allows you to view different pages of information. See Display
Screens on page 1for a detailed description of the
information available from this screen.
After a few seconds of inactivity (i.e. Scroll button idle),
screen luminosity turns from high to low level.
Power button. To turn on the ProFlex 800, hold the Power
button pressed until the power LED lights up.
To turn off the ProFlex 800, hold the Power button pressed
until the “Ashtech” screen is displayed. Then release the
button and wait until the ProFlex 800 shuts down.
Power LED. •This indicator light is off when the ProFlex 800
is off and no external power source is connected to the DC
power input.
• It is on and red when an external power source is present
at the DC power input and the ProFlex 800 is off.
• It is on and green when the ProFlex 800 is on, regardless
of whether it is powered from the internal battery or an
external power source.
• It is blinking red when the sleep mode has been enabled
and the receiver is currently running a session. With the
sleep mode enabled, the receiver is idle between any two
sessions, as if it were virtually turned off, and the power
LED is also turned off during this time.

7
Log Button. Press this button briefly to start recording raw
data on the selected storage medium.
Another short press on this button will immediately stop raw
data recording.
Scroll button. Press this button briefly to scroll through the
different pages of information viewed on the screen.
If an alarm is reported on the display screen, a short press on
the Scroll button will acknowledge the alarm. The Scroll
button will recover its display scrolling function only after all
the alarms have been acknowledged this way.
Another function of the Scroll button is to re-activate the
screen backlight after the latter has automatically been
turned off. The Scroll button is also used in the firmware
update procedure.
Rear View
DC Power Input. A Fischer, three-contact, female connector
[1] allowing the ProFlex 800 to be powered from either the
provided AC adapter (connect the cable extension between
ProFlex 800 and the end of the AC adapter output cable), or
an external 9- to 36-V DC power source through cable P/N
730477 (cf. base setup using an external radio transmitter).
GNSS Input #1 . A TNC coaxial female connector [2] allowing
you to connect a GNSS antenna to the receiver via a coaxial
cable.
[9] [3] [4] [5] [7] [1]
[6] [8] [2] [10]

8
Serial Data Ports. These are all Fischer, seven-contact, female
connectors, each allowing a serial connection to an external
device.
• Ports F [3] and B [4] are both RS232-only ports
• RS232/422 Port A [5] is a switchable RS232/RS422 port
(Default is RS232).
As an option (installed at the factory), port A also delivers
a regulated DC power voltage between pin 1 (+12 V DC)
and pin 2 (GND) that can be used to power a connected
device. The DC current available is 0.5 A steady state, and
1.0 A peak.
UHF Input. A TNC coaxial female connector [6] allowing you to
connect a radio whip antenna. This connector is available
only if the ProFlex 800 has been fitted with a radio module.
(Connector [6] is missing from the rear view above.)
Warning! Do not confuse this coaxial input with the GNSS
input [2] below. Connecting a GNSS antenna to the UHF
input might damage it if the embedded UHF transmitter is
used (although the transmitter is not supposed to transmit
until there are enough GNSS satellites received).
Ethernet Port. A Fischer, seven-contact female connector [7]
allowing you to connect the ProFlex 800 to a local network
(LAN). Through this connector, you may remotely control and
monitor the ProFlex 800 from any computer connected to the
Internet. Data may also flow through this port, in the same
way as through a serial port.
GNSS Input #2. A TNC coaxial female connector [8] for
applying an external reference clock. (Connector [8] is
missing on the rear view above.)

9
CAN 2.0 Bus. A Fischer, five-contact, female connector [9]
allowing you to connect the ProFlex 800 to external,
NMEA2000-compatible equipment via CAN bus. (For future
use.)
Earth Terminal. A screw terminal [10] for connecting the
receiver chassis to Earth.
Electric Isolation. All signals available on the following
connectors are optically isolated from the receiver’s internal
circuitry and chassis ground, as well as from each other:
• Serial ports A, B and F (including DC power output voltage
on port A)
• Ethernet port
•CANbus
Buzzer
The internal buzzer will sound whenever an error is detected.
The buzzer will sound six times and then stop. The error icon
will however continue to blink. To acknowledge the error
notification, first press the Scroll key to view the error and
associated code and then press the same button again.
Battery Model & Battery Compartment
The battery used is a 7.4-V DC - 4600 mAh rechargeable
battery. It is a standard model used in many camcorders.

10
The battery is housed in a battery compartment accessible
from above the ProFlex 800. The compartment door can be
opened by lifting and then turning the quarter-turn finger
screw counter-clockwise.
The battery will automatically operate as a backup power
source for the receiver if for some reason the external DC
source used is removed from the DC power input.
A slide switch is available at the bottom of the battery
compartment to set the behavior of the receiver after removal
or failure of the DC power source while the receiver is on:
• Slide switch pushed to the right: Automatic re-start. The
receiver will automatically be switched on when DC power
is restored. This is the typically the setting that should be
used with ProFlex 800 CORS.
• Slide switch pushed to the left: Manual re-start. After
power is restored, the receiver will stay off. Operator
intervention is needed to switch the receiver back on.
Use for example the tip of a pen to slide the switch to the left
or right.
Special Button Combinations
• With the ProFlex 800 OFF, pressing the Power, Log and
Scroll buttons simultaneously for a few seconds will
restore all the factory settings.
• With the ProFlex 800 OFF and a USB key connected,
pressing the Power and Scroll buttons simultaneously for
a few seconds will cause the ProFlex 800 to start a
firmware upload process. If there is no USB key
connected or the key does not contain a firmware upgrade,
then the process will abort after a few seconds.
Because data has to be decompressed on the USB key
during upgrades, the USB key must be unlocked, with at
least 100 MBytes of free memory, before starting the
upgrade.
These button combinations are summarized in the table
below:
Charging Batteries
Before Use
For a ProFlex 800 CORS, inserting a fully charged battery into
the receiver will guarantee that the station can keep operating
Button
Combination
ProFlex 800
State Function
Power+Log+Scroll OFF Restores Factory Settings.
Power+Scroll OFF Initiates firmware update from USB key.

11
for several hours after a power shutdown, giving you the time
to take the necessary maintenance steps.
Follow the instructions below to charge a battery.
Removing the Battery from the ProFlex 800
Unless the battery has already been taken out, do the
following:
• Open the battery trapdoor, accessible from above the
ProFlex 800, by lifting and then turning the quarter-turn
finger screw anticlockwise. This releases the two springs
located under the battery, pushing the battery slightly
upward (see picture).
• Grab the battery and take it out of the compartment.
Charging the Battery
The battery charger comes with a separate universal AC
adapter fitted with a 1.5-m output cable. The AC adapter
includes a choice of four different, detachable plug types.
Follow the instructions below to operate the charger.
• Choose the plug type that is suitable for your country.
• Secure that plug on the AC adapter.
• Connect the cable from the AC adapter to the battery
charger.
• Give the battery the right orientation with respect to the
charger [1] (the battery terminals should come into
contact with the two sets of connectors on the charger),
then push the battery against the plate and slide it forward
[2] until it locks into place.

12
• Plug the adapter into an AC outlet. Battery charging starts
immediately.
For a low battery that’s being charged, you will first see the
three LEDs switch on and off, one after the other, followed
by a short period of time when none of the LEDs is on (see
[3]).
After about two hours of charging, the MED LED will stay
on [4]. A few minutes later, the HI LED [5], and then the
MAX LED [6] will also stay on.
• When the three LEDs are on, this means the battery is
fully charged and can be disconnected from the charger.
Inserting the Battery in the ProFlex 800
• Insert the battery into the compartment making sure the
battery has the right orientation (the battery terminals
should come into contact with the two sets of connectors
located at the bottom of the compartment).
• Close the trapdoor, push the finger screw in tight, and turn
it fully clockwise.
Note that once it is properly secured, the trapdoor pushes
the battery against the bottom of the compartment to
ensure electrical connection of the battery to the ProFlex
800.
Display Screens
If you press the Scroll button several times, you will see the
following displays successively.
[1] [2]
11
2
MED MAXHI
MED MAXHI
[3]
[6]
MED MAXHI
[5]
MED MAXHI
[4]

13
Power-On Screen
When you power on the receiver, the Ashtech logo appears on
the screen. It is displayed until the receiver has completed its
auto-test (this takes about 30 seconds).
Then the General Status screen is displayed.
General Status Screen
An example of General Status screen is shown below.
This screen displays the following information:
• : Satellite icon [1] (always displayed).
• Number of satellites tracked [2].
• BASE [3]: A label indicating that the receiver is used as a
base.
• Number of satellites used [4]: Number of satellites
processed by the reference station and for which
corrections are made available to users. These satellites
are also used to compute an SDGPS solution of the base
position. This solution is permanently available on the
position computation screen (see Position Computation
Screen on page 16).
[1]
[7] [8] [9] [10] [11]
[2] [3] [4]
[6]
[5]

14
• Raw data logging icon [5]:
• Percentage of free memory in the storage medium used
[6].
• : Battery icon [7] with visual indication of remaining
charge. If an external power source is used (AC adapter or
external battery), the battery icon will be animated to
indicate battery charging in progress.
is displayed when there is no battery in the
compartment and the receiver is operated from an
external power source.
• Power status [8].
•Alarmstatus[9].
• GSM module (modem) status [10]. This may be one of the
following icons:
Data recording through front panel Log button or using Recording
submenu in the Web Server:
– Blinking: Raw data logging in progress
– Fixed: No raw data logging in progress.
Data recording through sessions:
– Blinking: Raw data logging in progress
– Fixed: No raw data logging in progress.
ATL data recording for advanced diagnosis.
Icon Definition
Percent
value
Percentage of remaining battery. This indication will flash when
the remaining energy drops below 5%. When an internal battery is
used with external power applied, this icon alternates between the
plug and the percentage of charge on the battery.
Replaces percentage when an external power source is used.
Icon Definition
Alarm detected. Press the Scroll button to view the alarm type.
Press it again to acknowledge the alarm, which then disappears
from the list. Unless there is another alarm in the queue, in which
case you will have to resume the acknowledge sequence, the
screen then displays the memory screens.
None No alarm detected
Icon Definition
Blank Modem turned off.
