Spectra Powerbox 210 Series User manual

SPECTRAPOWERBOX210‐
SERIES
USERMANUAL
Version1.0–April2019

SpectraGmbH&Co.KG
[email protected]
UserManual
SpectraPowerBox 210Series
Version1.0
April2019 2
Contents
Prefaces
Revision …………………………………………………..……………….………… 04
Copyright Notice ……………………………………………………………………. 04
Acknowledgement …..………………………………………………..................... 04
Disclaimer …………………………………………………………………………… 04
Declaration of Conformity …………………………………………………………. 04
Product Warranty Statement ……………………………………………………… 05
Technical Support and Assistance ……………………………………………….. 06
Conventions Used in this Manual ………………………………………………… 06
Safety Precaution ……...…………………………………………………………… 07
Package Content …..………………………………………………………………. 08
Ordering Information …………………….………………………………………… 08
Optional Modules and Accessories …….…………………………….....................09
Chapter 1 Product Introductions
1.1 Overview ……………………………………………….……………….. 11
1.2 Highlights ………………………………………………………………… 11
1.3 Product Pictures ………………………………………………………… 12
1.4 Key Features …………………………………………………………… 12
1.5 Hardware Specification ………………………………………………… 13
1.6 System I/O .……………………………………………………………… 14
1.7 Mechanical Dimension .………………………………………………… 16
Chapter 2 Switches and Connectors
2.1 Jumper Settings ………………………………………………………… 18
2.2 Location of the Switches and Connectors ……..…………………….. 18
2.2.1 Top View ………………………………………………………… 18
2.2.2 Bottom View …………………………………………………….. 19
2.3 Switch and Connector Definition .......................................................20
2.4 Definition of Switches ..……………………....................................... 21
2.5 Definition of Connectors ……………………….................................. 23
Chapter 3 System Setup
3.1 Removing the Chassis Bottom Cover ……...………………………... 28
3.2 Removing the Chassis …………………….…..…….……………….... 29
3.3 Installing Antennas………………………………………………………. 30
3.4 Installing Full-Size Mini PCIe Cards on Bottom Side …....………... 32
3.5 Installing a SATA Hard Drive…………………………………………… 34
3.6 Installing a SODIMM……….……………………..….……………....... 35
3.7 Installing the Chassis ………….…………..………..….…………….... 36
3.8 Installing the Chassis Bottom Cover …..…………..….……………... 37
3.9 Installing a SIM Card ………………………………..…………………. 38
3.10 Installing Wall Mount Brackets ..……….…………….…………….... 39
3.11 Installing DIN-Rail Mount Clips……………………………………….. 40

SpectraGmbH&Co.KG
[email protected]
UserManual
SpectraPowerBox 210Series
Version1.0
April2019 3
Chapter 4 BIOS Setup
4.1 BIOS Introduction …….……….……….…….…….…..….…………... 42
4.2 Main Setup ……..……….…………….…….…..….………………...... 43
4.3 Advanced Setup ……………………….……….……………………….. 44
4.3.1 ACPI Settings ……..…………….……….………………………. 44
4.3.2 F81866 Super IO Configuration ..…….………………………... 45
4.3.3 Hardware Monitor ………………..…………………………….... 47
4.3.4 S5 RTC Wake Setting …….……..……………..……………..... 47
4.3.5 Serial Port Console Redirection ..……………..….……….….... 48
4.3.6 CPU Configuration ....……………………….……..…………..... 49
4.3.7 Network Stack Configuration ..……………….……………….... 50
4.3.8 CSM Configuration …………………………….………..………. 50
4.3.9 USB Configuration ………………………..…………………….. 52
4.4 Chipset Setup …...……….………………….……….…..……………... 53
4.4.1 North Bridge ………….…………………….…………………….. 53
4.4.2 South Bridge ………….………………………………………….. 54
4.4.3 South Cluster Configuration …………………………………….. 55
4.5 Security Setup …...……….………………….……….…..……………... 58
4.6 Boot Setup …..……….….………………….……….…..….…………... 59
4.7 Save & Exit …...……….….………………….…..….…..…………….... 60
Chapter 5 Product Application (For PB-210-DIO Only)
5.1 Digital I/O (DIO) application……………………….…..….…………….. 62
5.1.1 Digital I/O Programming Guide ………………………………... 62
5.2 Digital I/O (DIO) Hardware Specification………………………..……. 74
5.2.1 DIO Connector Definitions ………………………..……………. 75
Chapter 6 Optional Modules and Accessories
6.1 Location of the Connectors for CMI Modules…………..…………… 79
6.2 Location of the Connector for PB-210-IGN Module……..……….… 81
6.3 Location of the Connector for PB-210-PoE Module ……………….. 82
6.4 PB-210-COM Module Connector Definition and Settings………….. 83
6.5 PB-210-IGN Module Switches Definition and Settings…………….. 85
6.6 Installing a PB-210-DVI Module.…………..………………………… 86
6.7 Installing a PB-210-VGA Module .………..………………………….. 88
6.8 Installing a PB-210-HDMI Module .…………..……………………….. 90
6.9 Installing a PB-210-COM Module .…………..……………………….. 92
6.10 Installing a PB-210-DIO Module .…………..…………………………..94
6.11 Installing a PB-210-IGN Module .…………..…………………………..96
6.12 Installing a PB-210-PoE Module .……..…………………………..….. 97
6.13 Installing a Side Mount Bracket ……………………………………… 99
6.14 Installing a VESA Mount Bracket…………………………………….. 101

SpectraGmbH&Co.KG
[email protected]
UserManual
SpectraPowerBox 210Series
Version1.0
April2019 4
Prefaces
Revision Description Date
1.00 First Release 2019/04/09
Copyright Notice
© 2019 by Spectra GmbH & Co. KG. All rights are reserved. No parts of this manual may be copied,
modified, or reproduced in any form or by any means for commercial use without the prior written
permission of Spectra GmbH & Co. KG. All information and specification provided in this manual are
for reference only and remain subject to change without prior notice.
Acknowledgement
All registered trademarks and product names mentioned herein are used for identification purposes
only and may be trademarks and/or registered trademarks of their respective owners.
Disclaimer
This manual is intended to be used as a practical and informative guide only and is subject to change
without notice. It does not represent a commitment on the part of Spectra. This product might include
unintentional technical or typographical errors. Changes are periodically made to the information
herein to correct such errors, and these changes are incorporated into new editions of the publication.
Declaration of Conformity
FCC
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the
user will be required to correct the interference at his own expense.
CE
The product(s) described in this manual complies with all application European Union
(CE) directives if it has a CE marking. For computer systems to remain CE compliant,
only CE-compliant parts may be used. Maintaining CE compliance also requires proper
cable and cabling techniques.
Revision

SpectraGmbH&Co.KG
[email protected]
UserManual
SpectraPowerBox 210Series
Version1.0
April2019 5
Product Warranty Statement
Warranty
Spectra products are warranted by Spectra GmbH & Co. KG. to be free from defect in materials and
workmanship for 2 years from the date of purchase by the original purchaser.
During the warranty period, we shall, at our option, either repair or replace any product that proves to
be defective under normal operation.
Defects, malfunctions, or failures of the warranted product caused by damage resulting from natural
disasters (such as by lightening, flood, earthquake, etc.), environmental and atmospheric disturbances,
other external forces such as power line disturbances, plugging the board in under power, or incorrect
cabling, and damage caused by misuse, abuse, and unauthorized alteration or repair, and the product
in question is either software, or an expendable item (such as a fuse, battery, etc.), are not warranted.
RMA
Before sending your product in, you will need to fill in a Spectra RMA Request Form and obtain a RMA
number from us. Please go to www.spectra.de/RMA to fill in this form. Our staff is available at any
time to provide you with the most friendly and immediate service.
RMA Instruction
Customers must fill in Spectra Return Merchandise Authorization (RMA) Request Form and
obtain a RMA number prior to returning a defective product to Spectra for service.
Customers must collect all the information about the problems encountered and note anything
abnormal and describe the problems on the “Spectra Service Form” for the RMA number apply
process.
Charges may be incurred for certain repairs. Spectra will charge for repairs to products whose
warranty period has expired. Spectra will also charge for repairs to products if the damage
resulted from acts of God, environmental or atmospheric disturbances, or other external forces
through misuse, abuse, or unauthorized alteration or repair. If charges will be incurred for a
repair, Spectra lists all charges, and will wait for customer’s approval before performing the
repair.
Customers agree to insure the product or assume the risk of loss or damage during transit, to
prepay shipping charges, and to use the original shipping container or equivalent.
Customers can be send back the faulty products with or without accessories (manuals, cable,
etc.) and any components from the system. If the components were suspected as part of the
problems, please note clearly which components are included. Otherwise, Spectra is not
responsible for the devices/parts.
Repaired items will be shipped along with a "Repair Report" detailing the findings and actions
taken.

SpectraGmbH&Co.KG
[email protected]
UserManual
SpectraPowerBox 210Series
Version1.0
April2019 6
This indication alerts operators to an operation that, if not strictly
observed, may result in severe injury.
WARNING
This indication alerts operators to an operation that, if not strictly
observed, may result in safety hazards to personnel or damage to
equipment.
CAUTION
This indication provides additional information to complete a task easily.
NOTE
Technical Support and Assistance
1. Visit our website at www.spectra.de where you can find the latest information about the product.
2. Contact our technical support team or sales representative for technical support if you need
additional assistance. Please have following information ready before you call:
Product name and serial number
Description of your peripheral attachments
Description of your software (operating system, version, application software, etc.)
A complete description of the problem
The exact wording of any error messages
Conventions Used in this Manual

SpectraGmbH&Co.KG
[email protected]
UserManual
SpectraPowerBox 210Series
Version1.0
April2019 7
Safety Precautions
Before installing and using this device, please note the following precautions:
1. Read these safety instructions carefully.
2. Keep this User’s Manual for future reference.
3. Disconnected this equipment from any AC outlet before cleaning.
4. For plug-in equipment, the power outlet socket must be located near the equipment and must be
easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation. Dropping it or letting it fall may cause
damage.
7. Make sure the voltage of the power source is correct before connecting the equipment to the
power outlet.
8. Use a power cord that has been approved for using with the product and that it matches the
voltage and current marked on the product’s electrical range label. The voltage and current rating
of the cord must be greater than the voltage and current rating marked on the product.
9. Position the power cord so that people cannot step on it. Do not place anything over the power
cord.
10.All cautions and warnings on the equipment should be noted.
11.If the equipment is not used for a long time, disconnect it from the power source to avoid damage
by transient overvoltage.
12.Never pour any liquid into an opening. This may cause fire or electrical shock.
13.Never open the equipment. For safety reasons, the equipment should be opened only by qualified
service personnel.
If one of the following situations arises, get the equipment checked by service personnel:
The power cord or plug is damaged.
Liquid has penetrated into the equipment.
The equipment has been exposed to moisture.
The equipment does not work well, or you cannot get it work according to the user's manual.
The equipment has been dropped and damaged.
The equipment has obvious signs of breakage.
14. CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or
equivalent type recommended by the manufacturer.

SpectraGmbH&Co.KG
[email protected]
UserManual
SpectraPowerBox 210Series
Version1.0
April2019 8
Package Contents
Before installation, please ensure all the items listed in the following table are included in the
package.
Item Description Q’ty
1 Spectra PowerBox 210 1
2 Utility DVD Driver 1
3 Thermal Pad (for CPU Thermal Block) 1
4 Power Terminal Block Connector 1
5 Screw Pack 1
6 Remote Power On/Off Terminal Block Connector 1
7 Wall Mounting Kit 1
8 DIN Rail Mounting Kit 1
Note: Notify your sales representative if any of the above items are missing or damaged.
Ordering Information
Model Name Product Description
Spectra PowerBox
210-N42 Intel® Pentium® Processor N4200 Compact Size Fanless Computer

SpectraGmbH&Co.KG
[email protected]
UserManual
SpectraPowerBox 210Series
Version1.0
April2019 9
Model No. Description
PB-210-DVI CMI Module with 1x DVI-D Connector ,1x Universal Bracket with 1x DVI-D
Cutout for Spectra PowerBox 210
PB-210-VGA CMI Module with 1x VGA Port, 1x Universal Bracket with 1x VGA Cutout for
Spectra PowerBox 210
PB-210-HDMI CMI Module with 1x HDMI Port,1x Universal Bracket with 1x HDMI Cutout
for Spectra PowerBox 210
PB-210-COM CMI Module with 2x RS232/422/485 (Support 5V/12V),1x Universal Bracket
with 2x DB9 Cutout for Spectra PowerBox 210
PB-210-DIO CMI Module with 8x Optical Isolated DIO (4 in/4 out), 1x Universal Bracket
with DIO Cutout for Spectra PowerBox 210
PB-210-IGN CFM Module with Power Ignition Sensing Control Function, Select 12V/24V
PB-210-PoE
Daughterboard CFM Module with PoE Control Function, Individual Port 25.5W
PB-210-MEC-COM-
M212
Mini-PCIe Module with 2x COM Ports,1x Universal Bracket with 2x DB9
Cutout for Spectra PowerBox 210
PB-210-MEC-LAN-
M002
Mini-PCIe Module with 2x LAN Ports,1x Universal Bracket with 2x RJ45
Cutout for Spectra PowerBox 210
PB-210-SIDE-KIT Side Mount Kit for Spectra PowerBox 210 Series, with KMRH-K175 for DIN-
Rail option
Netzteil, 60W/12, 3pin Adapter AC/DC 12V 5A 60W, wide temp(-30°C ~ +70°C)
Netzteil, 120W/24 V.2 Adapter AC/DC 24V 5A 120W, wide temp(-30°C ~ +70°C), level VI
Optional Modules and Accessories

Product Introductions
Chapter 1

SpectraGmbH&Co.KG
[email protected]
UserManual
SpectraPowerBox 210Series
Version1.0
April2019 11
1.1 Overview
Based on Intel® Pentium® N4200 quad-core processor, the Spectra PowerBox
210 is a fanless embedded computer offering an incredible size-performance ratio
for the most challenging environments. Despite its compact size, the Spectra
PowerBox 210 incorporates extensive connectivities including serial ports, USB
3.0, GbE LAN, full-size Mini-PCIe slot, dual SIM sockets, DVI-D, and DisplayPort.
The system also provides 2.5" SATA drive bay and mSATA socket for extensive
storage requirements.
Furthermore, it is much easier to utilize ready-to-use CMI & CFM modules for
extension of digital I/O, serial ports, power ignition sensing, Power over Ethernet
(PoE) even the third output of video for a variety of applications.
Featuring with rigorous industrial protections, wide temperature range, and wide
range DC power input, the Spectra PowerBox 210 offers a powerful, expandable
computing platform to ensure long-lasting performance and reduce maintenance
costs.
1.2 Highlights
In-Vehicle Computer
Capable of 12V/24V DC power input,
wide operating temperature,
shock/vibration resistant, power
ignition sensing, and E-mark
certified, this robust fanless computer
is specifically designed for
demanding in-vehicle applications.
Highly Efficient & Compact Flexible & Modular Design
Based on exclusive CMI (Combined
Multiple I/O) and CFM (Control
Function Module) technologies, the
Spectra PowerBox 210 can be easily
configured to increase specified
functions and a variety of I/O
modules.
The Spectra PowerBox 210 is
powered by Intel® Pentium®
N4200 (4 core, 2.5 GHz) and
constructed with a compact size
aluminum housing. It can be easily
installed into a control cabinet or
any other space-limited
environments.

SpectraGmbH&Co.KG
[email protected]
UserManual
SpectraPowerBox 210Series
Version1.0
April2019 12
1.3 Product Pictures
• Onboard Intel®Pentium®N4200 Processor
• Supports Triple Independent Display
• Supports CMI Interface for I/O Expandability
• Supports PoE+ and Power Ignition Function (with optional CFM modules)
• 1 x 2.5’’ SATA Drive Bay, 1x mSATA Socket
• 2 x Full Size Mini-PCIe Socket, 2 x SIM Card Socket
• Compact Size (185 x 131 x 56.5 mm)
• Wide Operating Temperature -40°C to 70°C
• E-mark (E13,), LVD EN60950-1
1.4 Key Features

SpectraGmbH&Co.KG
[email protected]
UserManual
SpectraPowerBox 210Series
Version1.0
April2019 13
Processor
• Onboard Intel®Pentium®N4200 Quad Core Processor,
up to 2.50 GHz
BIOS
• AMI BIOS, 8MB SPI Flash ROM built on board
Memory
• 1x DDR3L 1333/1600/1866 MHz 204-Pin SO-DIMM Socket
• Support up to 8GB (un-buffered and non-ECC)
Graphics
• Integrated Intel® HD Graphics 505
• Supports Triple Independent Display
(DVI-D, DisplayPort and one output from optional CMI
module)
Audio Codec
• Realtek ALC888-GR
External I/O Interface
• 1x DVI-I (1920 x 1080 @ 60 Hz)
• 1x DisplayPort (4K x 2K @60Hz)
• 2x GbE LAN (Support WoL, Teaming, Jumbo Frame & PXE),
RJ45
- GbE1: Intel ®I210IT
- GbE2: Intel ®I210IT
• 4x USB 3.0 (Type A)
• 2x RS232/422/485 with Auto Flow Control (Supports 5V/12V),
DB9
• 1x Line-out and 1x Mic-in, Phone Jack 3.5mm
• 1x ATX Power On/Off Button
• 1x Reset Button
• 1x AT/ATX Mode Switch
• 1x Clear CMOS Switch
• 1x Remote Power On/Off Connector, 2-pin Terminal Block
• 1x Ignition DIP Switch
(12V/24V, need to work with CFM module)
Storage
• 1x mSATA Socket (SATA 3.0, Shared by Mini-PCIe Socket)
• 1x 2.5" HDD/SSD Drive Bay (SATA 3.0)
Expansion
• 2x Full-size Mini-PCIe Socket
• 2x Control Function Module (CFM) Interface
• 2x Combined Multiple I/O (CMI) Interface
• 2x SIM Card Socket
• 2x Antenna Hole
Other Functions
• Watchdog Timer: Software Programmable Supports
256 Levels System Reset
• SuperCap Integrated for CMOS Battery Maintenance-free
Operation
• Supports Instant Reboot Technology (0.2 sec)
Power Requirement
• Supports AT/ATX Power Type
• Power Input Voltage 9~48VDC
• 1x 3-pin Terminal Block
• Power Adapter AC/DC 12V/5A 60W or 24V/5A 120W (Optional)
Physical
• Dimensions (WxDxH, mm): 185 x 131 x 56.5 mm
• Weight: 1.42 kg
• Construction: Extruded Aluminum with Heavy Duty Metal
• Mounting: Wall / VESA (Optional Side + DIN-Rail Mounting)
• Unibody Chassis
• Fanless Design
• Jumper-less Design
• Cable-less Design
Protection
•Reverse Power Input Protection
• Over Voltage Protection: 58V
• Over Current Protection: 15A
• ESD Protection: +/- 5kV (air), +/- 8kV (contact)
• Surge Protection: 3.84kV
(impedance 12 ohm 1.2/50us waveform)
Operating System
• Windows® 10
• Linux: Supports by project
Environment
• Operating Temperature: -40°C to 70°C
* With extended temperature peripherals; Ambient with air flow
* According to IEC60068-2-1, IEC60068-2-2, IEC60068-2-14
• Storage Temperature: -40°C to 85°C
• Relative Humidity: 95% RH @ 70˚C (non-Condensing)
• Shock: Operating, 50 Grms, Half-sine 11 ms Duration
* w/ SSD, according to IEC 60068-2-27
• Vibration: Operating, 5 Grms, 5-500 Hz, 3 Axes
* w/ SSD according to IEC 60068-2-64
• MTBF: 479,119 Hours
Certification
• EMC: CE, FCC Class A
• Safety: LVD (EN60950-1)
• Vehicle: E-mark (E13) Certified
1.5 Hardware Specification

SpectraGmbH&Co.KG
[email protected]
UserManual
SpectraPowerBox 210Series
Version1.0
April2019 14
ATX Power On/Off Switch
Press to power-on or power-off the system
Power LED
Indicates the power status of the system
HDD LED
Indicates the status of the hard drive
Line-Out
Used to connect a speaker
Mic-In
Used to connect a microphone
USB 3.0 Port
Used to connect USB 3.0/2.0/1.1 device
LAN Port 1 & 2
Used to connect the system to a local area network
DisplayPort Port
Used to connect the system with DisplayPort monitor
Universal I/O Bracket
Used for customized I/O output with optional modules
Reset Button
Used to reset the system
AT/ATX Switch
Used to select AT or ATX power mode
SIM Card Slot
Used to insert a SIM Card
IGN Setting Switch
Used to set up IGN function
Clear CMOS
Used to clear CMOS to reset BIOS
1.6 System I/O
1
1.6.1 Front Panel

SpectraGmbH&Co.KG
[email protected]
UserManual
SpectraPowerBox 210Series
Version1.0
April2019
Antenna Hole
Used to connect an antenna for optional Mini-PCIe
WiFi module
DC IN Terminal Block
Used to plug a DC power input with terminal block
COM Port
COM 1 ~ COM 2 support RS232/422/485 serial
device
DVI-D Port
Used to connect a DVI monitor or connect optional
split cable for dual display mode
Remote Power On/Off Terminal Block
Used to plug a remote power on/off terminal block
Universal I/O Bracket
Used for customized I/O output with optional modules
15
1.6.2 Rear Panel
Universal I/O Brackets
These expansion areas are reserved for Mini-PCIe expansion or own pin-defined
interfaces (CMI interfaces). CMI interfaces support various type of I/O modules such
as COM / DIO / DVI / VGA / HDMI modules.
Do not change the CMI module by yourself, it may cause damage to your Spectra
PowerBox 210. Please contact with your regional dealer for more information about it.
Universal I/O Brackets
These expansion areas are reserved for Mini-PCIe expansion or own pin-defined
interfaces (CMI interfaces). CMI interfaces support various type of I/O modules such
as COM / DIO / DVI / VGA / HDMI modules.
Do not change the CMI module by yourself, it may cause damage to your Spectra
PowerBox 210. Please contact with your regional dealer for more information about it.
2 3
1.6.3 Optional Module Configuration
ModelNo.Description Bracket1Bracket2Bracket3
PB‐210‐DVI CMIModulewith1xDVI‐DConnector,1xUniversalBracketwith
1xDVI‐DCutoutforSpectraPowerBox 210 －－Ｖ
PB‐210‐VGA CMIModulewith1xVGAPort,1*UniversalBracketwith1xVGA
CutoutforSpectraPowerBox 210 －－Ｖ
PB‐210‐HDMI CMIModulewith1xHDMIPort,1xUniversalBracketwith1x
HDMICutoutforSpectraPowerBox 210 －－Ｖ
PB‐210‐COM CMIModulewith2xRS232/422/485(Support5V/12V),1x
UniversalBracketwith2xDB9CutoutforSpectraPowerBox 210 －ＶＶ
PB‐210‐DIO CMIModulewith8xOpticalIsolatedDIO(4in/4out),1x
UniversalBracketwithDIOCutoutforSpectraPowerBox 210 －ＶＶ
PB‐210‐MEC‐COM‐
M212
Mini‐PCIeModulewith2xCOMPorts,1xUniversalBracketwith
2xDB9CutoutforSpectraPowerBox 210 Ｖ－－
PB‐210‐MEC‐LAN‐
M002
Mini‐PCIeModulewith2xLANPorts,1xUniversalBracketwith2x
RJ45CutoutforSpectraPowerBox 210 Ｖ－－

SpectraGmbH&Co.KG
[email protected]
UserManual
SpectraPowerBox 210Series
Version1.0
April2019 16
1.7 Mechanical Dimensions
Unit: mm

Switches and Connectors
Chapter 2

SpectraGmbH&Co.KG
[email protected]
UserManual
SpectraPowerBox 210Series
Version1.0
April2019 18
2.1 Jumpers Settings
The Spectra PowerBox 210 is featured with jumper-free design.
2.2 Location of the Switches and Connectors
2.2.1 Top View

SpectraGmbH&Co.KG
[email protected]
UserManual
SpectraPowerBox 210Series
Version1.0
April2019 19
2.2.2 Bottom View

SpectraGmbH&Co.KG
[email protected]
UserManual
SpectraPowerBox 210Series
Version1.0
April2019 20
2.3 Switches and Connectors Definition
List of Switches
Location Definition
POWER_SW3 ATX Power on/off Button
SW1 Super CAP Switch and COM1~2 Power Select Switch
Reset1 Reset Button
AT_ATX AT/ ATX Power Mode Switch
CLR_CMOS1 Clear BIOS Switch
SW2 IGN Module Timing Setting Switch
24V_12V_1 IGN Module Voltage Mode Setting Switch
List of Connectors
Location Definition
POWER_SW2 Remote Power On/Off Connector
DC_IN1 3-pin DC 9~48V Power Input with Power Ignition Connector
DVI_I1 DVI-D Connector
COM1_1, COM1_2 COM1~COM2 RS232 / RS422 / RS485 Connectors
DP1 DisplayPort Connector
USB3_1, USB3_2 USB 3.0 Ports
USB3_34 USB 3.0 Ports
LAN1, LAN2 RJ45 with LED Connector
MIC_IN1 Audio Jack MIC IN
LINE_OUT1 Audio Jack LINE OUT
SODIMM1 204-pin DDR3L SO-DIMM Sockets
Power1, Power2 +5V / +12V Power Output Connectors
SATA2 22-pin SATA Connector
MINIPCIE1 Mini PCIE+SIM/USB3 Socket
MINIPCIE2 Mini PCIE/mSATA Socket
SIMA01, SIMB01 SIM Card Sockets (apply with MINIPCIE1)
BTB_FH1 CMI BTB 50-pin header connector
(Support DVI-D/VGA/HDMI/DIO/COM Ports)
BTB_FH2 CMI BTB 44-pin header connector
(Support DIO/COM Ports)
IGN_PH1 IGN Board to Board Connector
POE_PH2 20-pin POE Board to Board Connector
