Spectra MobileMapper 120 User manual

Getting Started Guide
Handheld Platform for
MobileMapper 120,
ProMark 120 & ProMark 220

Copyright Notice
Copyright 2012-2013 Trimble Navigation Limited.
All rights reserved.
Trademarks
All product and brand names mentioned in this pub-
lication are trademarks of their respective holders.
SPECTRA PRECISION LIMITED WARRANTY TERMS
AND CONDITIONS
PRODUCT LIMITED WARRANTY - Subject to the fol-
lowing terms and conditions, Spectra Precision war-
rants that for a period of one (1) year from date of
purchase this Spectra Precision product (the “Prod-
uct”) will substantially conform to Spectra Preci-
sion’s publicly available specifications for the
Product and that the hardware and any storage media
components of the Product will be substantially free
from defects in materials and workmanship.
PRODUCT SOFTWARE - Product software, whether
built into hardware circuitry as firmware, provided as
a standalone computer software product, embedded
in flash memory, or stored on magnetic or other me-
dia, is licensed solely for use with or as an integral
part of the Product and is not sold. If accompanied
by a separate end user license agreement (“EULA”),
use of any such software will be subject to the terms
of such end user license agreement (including any
differing limited warranty terms, exclusions, and lim-
itations), which shall control over the terms and con-
ditions set forth in this limited warranty.
SOFTWARE FIXES - During the limited warranty pe-
riod you will be entitled to receive such Fixes to the
Product software that Spectra Precision releases and
makes commercially available and for which it does
not charge separately, subject to the procedures for
delivery to purchasers of Spectra Precision products
generally. If you have purchased the Product from a
Spectra Precision Authorized Distribution Partner
rather than from Spectra Precision directly, Spectra
Precision may, at its option, forward the software Fix
to the Spectra Precision Authorized Distribution
Partner for final distribution to you. Minor Updates,
Major Upgrades, new products, or substantially new
software releases, as identified by Spectra Precision,
are expressly excluded from this update process and
limited warranty. Receipt of software Fixes or other
enhancements shall not serve to extend the limited
warranty period.
For purposes of this warranty the following defini-
tions shall apply: (1) “Fix(es)” means an error correc-
tion or other update created to fix a previous software
version that does not substantially conform to its
Spectra Precision specifications; (2) “Minor Update”
occurs when enhancements are made to current fea-
tures in a software program; and (3) “Major Upgrade”
occurs when significant new features are added to
software, or when a new product containing new fea-
tures replaces the further development of a current
product line. Spectra Precision reserves the right to
determine, in its sole discretion, what constitutes a
Fix, Minor Update, or Major Upgrade.
WARRANTY REMEDIES - If the Spectra Precision
Product fails during the warranty period for reasons
covered by this limited warranty and you notify Spec-
tra Precision of such failure during the warranty peri-
od, Spectra Precision will repair OR replace the
nonconforming Product with new, equivalent to new,
or reconditioned parts or Product, OR refund the
Product purchase price paid by you, at Spectra Pre-
cision’s option, upon your return of the Product in ac-
cordance with Spectra Precision’s product return
procedures then in effect.
HOW TO OBTAIN WARRANTY SERVICE - To obtain
warranty service for the Product, please contact your
local Spectra Precision Authorized Distribution Part-
ner. Alternatively, you may contact Spectra Precision
to request warranty service at [phone] (24
hours a day) or e-mail your request to support@spec-
traprecision.com. Please be prepared to provide:
• your name, address, and telephone numbers
• proof of purchase
• a copy of this Spectra Precision warranty
• a description of the nonconforming Product in-
cluding the model number
• an explanation of the problem
The customer service representative may need addi-
tional information
from you depending on the nature of the problem.
WARRANTY EXCLUSIONS AND DISCLAIMER - This Prod-
uct limited warranty shall only apply in the event and
to the extent that (a) the Product is properly and cor-
rectly installed, configured, interfaced, maintained,
stored, and operated in accordance with Spectra Pre-
cision’s applicable operator's manual and specifica-
tions, and; (b) the Product is not modified or
misused. This Product limited warranty shall not ap-
ply to, and Spectra Precision shall not be responsible
for, defects or performance problems resulting from
(i) the combination or utilization of the Product with
hardware or software products, information, data,
systems, interfaces, or devices not made, supplied,
or specified by Spectra Precision; (ii) the operation of
the Product under any specification other than, or in
addition to, Spectra Precision standard specifica-
tions for its products; (iii) the unauthorized installa-
tion, modification, or use of the Product; (iv) damage
caused by: accident, lightning or other electrical dis-
charge, fresh or salt water immersion or spray (out-
side of Product specifications); or exposure to
environmental conditions for which the Product is
not intended; (v) normal wear and tear on consum-
able parts (e.g., batteries); or (vi) cosmetic damage.
Spectra Precision does not warrant or guarantee the
results obtained through the use of the Product, or
that software components will operate error free.
NOTICE REGARDING PRODUCTS EQUIPPED WITH
TECHNOLOGY CAPABLE OF TRACKING SATELLITE
SIGNALS FROM SATELLITE BASED AUGMENTA-
TION SYSTEMS (SBAS) (WAAS/EGNOS, AND
MSAS), OMNISTAR, GPS, MODERNIZED GPS OR
GLONASS SATELLITES, OR FROM IALA BEACON
SOURCES: SPECTRA PRECISION IS NOT RESPON-
SIBLE FOR THE OPERATION OR FAILURE OF OP-
ERATION OF ANY SATELLITE BASED POSITIONING
SYSTEM OR THE AVAILABILITY OF ANY SATELLITE
BASED POSITIONING SIGNALS.
THE FOREGOING LIMITED WARRANTY TERMS
STATE SPECTRA PRECISION’S ENTIRE LIABILITY,
AND YOUR EXCLUSIVE REMEDIES, RELATING TO
THE SPECTRA PRECISION PRODUCT. EXCEPT AS
OTHERWISE EXPRESSLY PROVIDED HEREIN, THE
PRODUCT AND ACCOMPANYING DOCUMENTA-
TION AND MATERIALS ARE PROVIDED “AS-IS”
AND WTHOUT EXPRESS OR IMPLIED WARRANTY
OF ANY KIND, BY EITHER SPECTRA PRECISION
OR ANYONE WHO HAS BEEN INVOLVED IN ITS
CREATION, PRODUCTION, INSTALLATION, OR DIS-

TRIBUTION, INCLUDING, BUT NOT LIMITED TO,
THE IMPLIED WARRANTIES OF MERCHANTABILI-
TY AND FITNESS FOR A PARTICULAR PURPOSE,
TITLE, AND NONINFRINGEMENT. THE STATED EX-
PRESS WARRANTIES ARE IN LIEU OF ALL OBLI-
GATIONS OR LIABILITIES ON THE PART OF
SPECTRA PRECISION ARISING OUT OF, OR IN
CONNECTION WITH, ANY PRODUCT. BECAUSE
SOME STATES AND JURISDICTIONS DO NOT AL-
LOW LIMITATIONS ON DURATION OR THE EXCLU-
SION OF AN IMPLIED WARRANTY, THE ABOVE
LIMITATION MAY NOT APPLY OR FULLY APPLY TO
YOU.
LIMITATION OF LIABILITY - SPECTRA PRECI-
SION’S ENTIRE LIABILITY UNDER ANY PROVI-
SION HEREIN SHALL BE LIMITED TO THE
AMOUNT PAID BY YOU FOR THE PRODUCT. TO
THE MAXIMUM EXTENT PERMITTED BY APPLICA-
BLE LAW, IN NO EVENT SHALL SPECTRA PRECI-
SION OR ITS SUPPLIERS BE LIABLE FOR ANY
INDIRECT, SPECIAL, INCIDENTAL, OR CONSE-
QUENTIAL DAMAGE WHATSOEVER UNDER ANY
CIRCUMSTANCE OR LEGAL THEORY RELATING IN
ANYWAY TO THE PRODUCTS, SOFTWARE, AND AC-
COMPANYING DOCUMENTATION AND MATERIALS,
(INCLUDING, WITHOUT LIMITATION, DAMAGES
FOR LOSS OF BUSINESS PROFITS, BUSINESS IN-
TERRUPTION, LOSS OF DATA, OR ANY OTHER PE-
CUNIARY LOSS), REGARDLESS OF WHETHER
SPECTRA PRECISION HAS BEEN ADVISED OF THE
POSSIBILITY OF ANY SUCH LOSS AND REGARD-
LESS OF THE COURSE OF DEALING WHICH DE-
VELOPS OR HAS DEVELOPED BETWEEN YOU AND
SPECTRA PRECISION. BECAUSE SOME STATES
AND JURISDICTIONS DO NOT ALLOW THE EXCLU-
SION OR LIMITATION OF LIABILITY FOR CONSE-
QUENTIAL OR INCIDENTAL DAMAGES, THE
ABOVE LIMITATION MAY NOT APPLY OR FULLY AP-
PLY TO YOU.
PLEASE NOTE: THE ABOVE SPECTRA PRECISION
WARRANTY PROVISIONS WILL NOT APPLY TO
PRODUCTS PURCHASED IN THOSE JURISDIC-
TIONS (E.G., MEMBER STATES OF THE EUROPEAN
ECONOMIC AREA) IN WHICH PRODUCT WARRAN-
TIES ARE THE RESPONSBILITY OF THE LOCAL
SPECTRA PRECISION AUTHORIZED DISTRIBU-
TION PARTNER FROM WHOM THE PRODUCTS ARE
ACQUIRED. IN SUCH A CASE, PLEASE CONTACT
YOUR LOCAL SPECTRA PRECISION AUTHORIZED
DISTRIBUTION PARTNER FOR APPLICABLE WAR-
RANTY INFORMATION.
OFFICIAL LANGUAGE - THE OFFICIAL LANGUAGE
OF THESE TERMS AND CONDITIONS IS ENGLISH.
IN THE EVENT OF A CONFLICT BETWEEN ENG-
LISH AND OTHER LANGUAGE VERSIONS, THE
ENGLISH LANGUAGE SHALL CONTROL.
REGISTRATION - To receive information regarding
updates and new products, please contact your local
Spectra Precision Authorized Distribution Partner or
visit the Spectra Precision website at www.spectra-
precision.com/register. Upon registration you may
select the newsletter, upgrade, or new product infor-
mation you desire.
CE
a. Caution:
•CAUTION: Danger of explosion if battery is in-
correctly replaced. Replace only with the same
or equivalent type recommended by the manu-
facturer.
•Dispose of used batteries according to the man-
ufacturer instructions.
b. Please make sure the temperature for adapter will
not be higher than 40 ˚C.
CE SAR Compliance
This device meets the EU requirements (1999/519/
EC) on the limitation of exposure of the general pub-
lic to electromagnetic fields by way of health protec-
tion.
The limits are part of extensive recommendations for
the protection of the general public. These recom-
mendations have been developed and checked by in-
dependent scientific organizations through regular
and thorough evaluations of scientific studies. The
unit of measurement for the European Council's rec-
ommended limit for mobile devices is the "Specific
Absorption Rate" (SAR), and the SAR limit is 2.0 W/
kg averaged over 10 gram of body tissue. It meets the
requirements of the International Commission on
Non-Ionizing Radiation Protection (ICNIRP).
For body worn operation, this device has been tested
and meets the ICNIRP exposure guidelines and the
European Standard EN 62311 and EN 62209-2, for
use with dedicated accessories. Use of other acces-
sories which contain metals may not ensure compli-
ance with ICNIRP exposure guidelines.
EU Conformance
The following CE compliance information is applica-
ble to this device that carry the following CE mark:
FCC
FCC Regulations:
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
and (2) this device must accept any interference re-
ceived, including interference that may cause unde-
sired operation.
This device has been tested and found to comply
with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are de-
signed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates, uses and can radiate ra-
dio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However,
there is no guarantee that interference will not occur
in a particular installation if this equipment does
cause harmful interference to radio or television re-
ception, which can be determined by turning the
equipment off and on. The user is encouraged to try
to correct the interference by one or more of the fol-
lowing measures:

• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment
and receiver.
• Connect the equipment into an outlet on a cir-
cuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV
technician for help.
Changes or modifications not expressly approved by
the party responsible for compliance could void the
user‘s authority to operate the equipment.
The antenna(s) used for this transmitter must not be
co-located or operating in conjunction with any other
antenna or transmitter.
RF Exposure Information (SAR)
This device meets the government’s requirements for
exposure to radio waves.
This device is designed and manufactured not to ex-
ceed the emission limits for exposure to radio fre-
quency (RF) energy set by the Federal
Communications Commission of the U.S. Govern-
ment.
The exposure standard for wireless devices employs
a unit of measurement known as the Specific Absorp-
tion Rate, or SAR. The SAR limit set by the FCC is
1.6W/kg. Tests for SAR are conducted using standard
operating positions accepted by the FCC with the de-
vice transmitting at its highest certified power level
in all tested frequency bands. Although the SAR is
determined at the highest certified power level, the
actual SAR level of the device while operating can be
well below the maximum value. This is because the
device is designed to operate at multiple power levels
so as to use only the poser required to reach the net-
work. In general, the closer you are to a wireless base
station antenna, the lower the power output.
The highest SAR value for the device as reported to
the FCC when worn on the body, as described in this
user guide, is 0.39 W/kg for GSM850 / 1.23 W/kg for
PCS1900 (Body-worn measurements differ among
device models, depending upon available accesso-
ries and FCC requirements.)
While there may be differences between the SAR lev-
els of various devices and at various positions, they
all meet the government requirement.
The FCC has granted an Equipment Authorization for
this device with all reported SAR levels evaluated as
in compliance with the FCC RF exposure guidelines.
SAR information on this device is on file with the FCC
and can be found under the Display Grant section of
www.fcc.gov/oet/ea/fccid after searching on FCC ID:
NZI802111A.
This device is compliant with SAR for general popu-
lation /uncontrolled exposure limits in ANSI/IEEE
C95.1-1999 and had been tested in accordance with
the measurement methods and procedures specified
in OET Bulletin 65 Supplement C.
For body worn operation, this device has been tested
and meets the FCC RF exposure guidelines for use
with an accessory that contains no metal and the po-
sitions the handset a minimum of 0.5 cm from the
body. Use of other accessories may not ensure com-
pliance with FCC RF exposure guidelines. If you do
not use a body-worn accessory and are not holding
the device at the ear, position the handset a mini-
mum of 0.5 cm from your body when the device is
switched on.
IC
This device complies with Industry Canada licence-
exempt RSS standard(s). Operation is subject to the
following two conditions: (1) this device may not
cause interference, and (2) this device must accept
any interference, including interference that may
cause undesired operation of the device.
Le présent appareil est conforme aux CNR
d’Industrie Canada applicables aux appareils radio
exempts de licence. L’exploitation est autorisée aux
deux conditions suivantes :
(1) l’appareil ne doit pas produire de brouillage , et
(2) l’utilisateur de l’appareil doit accepter tout
brouillage radioélectrique subi, même si le brouillage
est susceptible d’en compromettre le
fonctionnement.
This Class B digital apparatus complies with Canadi-
an ICES-003.
Cet appareil numérique de la classe B est conforme
à la norme NMB-003 du Canada.
This Category II radio communication device com-
plies with Industry Canada Standard RSS-310.
Ce dispositif de radiocommunication de catégorie II
respecte la norme CNR-310 d’Industrie Canada.
IMPORTANT NOTE:
IC Radiation Exposure Statement
This EUT is compliant with SAR for general popula-
tion/uncontrolled exposure limits in IC RSS-102 and
had been tested in accordance with the measure-
ment methods and procedures specified in IEEE
1528. This equipment should be installed and oper-
ated with minimum distance 0.5 cm between the ra-
diator & your body.
This device and its antenna(s) must not be co-locat-
ed or operating in conjunction with any other antenna
or transmitter.
The County Code Selection feature is disabled for
products marketed in the US/Canada.

Table of Contents
First-Time Use ............................................................................. 1
Unpacking .............................................................................. 1
Inserting the Battery Into the Receiver.......................................1
Charging the Battery for the First Time ...................................... 2
Installing the OS Language and Applications.............................. 3
Adjusting Backlight Level ......................................................... 5
Setting Backlight Idle Time ...................................................... 5
Power Management.................................................................. 6
Regional Settings .................................................................... 6
Locking the Screen and the Keypad........................................... 6
How to Hold the Receiver ......................................................... 7
Switching to Suspend Mode...................................................... 7
Turning the Receiver Off .......................................................... 8
System Description....................................................................... 9
Receiver Front View ................................................................. 9
Display Screen..................................................................... 9
Keypad, Scroll and Enter Buttons .......................................... 9
Stylus and Stylus Holder....................................................... 9
Built-in GNSS Antenna......................................................... 9
Microphone ......................................................................... 9
Built-in GSM Antenna ........................................................ 10
Built-in Bluetooth Antenna.................................................. 10
Receiver Rear View ................................................................ 10
Camera Lens...................................................................... 10
Loudspeaker ...................................................................... 10
Battery Compartment ......................................................... 10
Receiver Side View (Left)........................................................ 10
Power Button..................................................................... 10
Power & Battery LED .......................................................... 11
SDIO Interface................................................................... 11
External Antenna Input ....................................................... 11
Receiver Bottom View ............................................................ 11
Power/Data Connector......................................................... 11
Docking Station..................................................................... 12
Top View ........................................................................... 12
Rear View.......................................................................... 13
Advanced Features ..................................................................... 14
Power Modes......................................................................... 14
LED Indicator........................................................................ 15
Internal Battery ..................................................................... 16
Battery Charging Scenarios ................................................. 17
Port Allocation Table.............................................................. 18
Inserting a SIM Card.............................................................. 19
Using the Internal Modem ...................................................... 19
Enabling the Phone Function .............................................. 20

Establishing a GPRS Connection..........................................20
Establishing a GSM Connection in CSD Mode .......................21
CDMA Connection Using an External Cell Phone.......................21
Editing the Default Dialup String .........................................22
Pairing Bluetooth Between Receiver and External Cell Phone . 22
Setting Up the Internet Connection......................................24
Using the Camera ..................................................................25
Taking a Picture.................................................................25
Renaming a Picture............................................................25
Rotating a Picture ..............................................................25
Cropping a Picture..............................................................25
Auto-correcting a Picture ....................................................26
Deleting a Picture ..............................................................26
Changing Picture Settings ...................................................26
Making a Video......................................................................26
Setting the Duration of a Video Film.....................................26
Starting a Video .................................................................27
Ending a Video...................................................................27
Playing Back a Video ..........................................................27
Renaming a Video ..............................................................28
Deleting a Video.................................................................28
Voice Setting.........................................................................28
GNSS Toolbox............................................................................29
Options.................................................................................29
GNSS Settings ......................................................................30
Differential Mode...................................................................30
NMEA Output........................................................................32
GNSS Status .........................................................................33
Reset....................................................................................34
Troubleshooting.....................................................................34
About ...................................................................................35
Turn Off GNSS ......................................................................35
Platform Specifications............................................................... 36
GNSS Characteristics.............................................................36
Processor .............................................................................. 36
Operating System ..................................................................36
Communication .....................................................................36
Physical Characteristics..........................................................36
User Interface .......................................................................36
Memory ...............................................................................37
Environmental Characteristics.................................................37
Power Requirements ..............................................................37
Multimedia & Sensors ............................................................37
Standard Accessories .............................................................37

English
1
First-Time Use
Unpacking Open the receiver box and unpack the following items:
• Receiver
• SD card containing required applications (GNSS Toolbox,
GNSS Service, etc.)
• Battery
• Docking station
• Universal AC adapter
•USBcable
Inserting the
Battery Into the
Receiver
Follow the instructions below:
• Turn over the receiver and rotate the finger screw counter-
clockwise a quarter turn and pull the trap door open.
• Insert the battery as shown. The label must be outwards
and the right way up.
• Put the trap door back into place by first inserting the two
clips located at the top of the trap door.
• Then push the door against the case and rotate the finger
screw clockwise by one-quarter turn for a secure and
sealed closure.

English
2
Charging the
Battery for the First
Time
The fastest way to charge the battery before first use is to
keep the receiver off until the battery is charged. In these
conditions, it will take less than 4 hours to fully charge the
battery. Follow the instructions below.
• Prepare the AC adapter:
– Remove the protective cover [1] by pushing the button
then sliding the cover forward.
– Choose the plug that fits your country’s AC outlet
standard (see [2]) and slide it into the AC adapter [3}.
(A “click” must be heard when fully inserted.)
– Connect the AC adapter to an electric outlet.
• Put the docking station [4] on a horizontal plane.
• Connect the output cable [5] of the AC adapter to the back
of the docking station.
• Insert the receiver [6] vertically, into the docking station.
The light indicator [7] turns steady red, meaning the
receiver is properly connected to the station and battery
charging is in progress.
The light indicator [7] will turn green when the battery is
fully charged.
[1]
[2]
[3]
[5]
[4]
[6] [7]

English
3
Installing the OS
Language and
Applications
Important! Please keep the receiver on the docking station.
This is to make sure the battery will not go low during the
installation step.
• Insert the delivered SD card into the receiver’s SDIO card
reader [16] (see also SDIO Interface on page 11).
• Press the Power button [8] until the Power LED (next to
this button) lights up in green. This turns on the receiver.
When first turning on the receiver, screen [1] below is
displayed. Follow the procedure below to install a language
and then let the Microsoft Windows Embedded Handheld 6.5
Professional operating system install automatically
applications from the SD card. These applications are
required to run some Spectra Precision software applications
such as ProMark Field or MobileMapper Field. The complete
sequence takes about 4 minutes.
[8]
[16]
[8]

English
4
• Browse the list of available languages using the Up or
Down key, until the desired language is selected.
•PresstheEnter key to pre-select this language. Screen [2]
is now displayed (see above).
• Press the Up key to access the check button setting on the
screen.
•PressEnter again to activate the check button.
• Press the Down key then the Right key to select the Next
button on the screen.
Warning! You are now ready to install the selected
language. Once the installation is started, you will no
longer be given the opportunity to install another
language.
(So if you realize at this point that you selected the wrong language, you may
still revert to the language selection screen by pressing the Left key, then the
Enter key. This will take you back to screen [1] from which you can resume
the language installation step from the beginning.)
• Press the Enter key again to start the language
installation. Screen [3] is now displayed.
Let the receiver complete the language installation. The
operating system will then automatically start installing
the applications from the SD card (in the same language
as the one you selected for the operating system).
Once the applications are installed, the receiver will be re-
booted (blank screen for a few seconds). Then the
operating system will ask you to initialize the receiver
(screen calibration, time zone, date and time). Follow the
instructions on the screen to complete this step.
NOTE: The receiver will also re-boot after language
installation so it’s better to wait for the second re-boot
before you start initializing the receiver.
[1] [2] [3]
Up
Down
Left Enter Right

English
5
• Once the receiver has been initialized, you can remove the
SD card and put that card away in a safe place.
Warning! For some reason, you may need to use > Settings
> System > Reset to factory default to reset the receiver to its
default settings. Be aware this will delete the applications
you installed from the SD card. So please insert the SD card
before you reset to factory settings, This will automatically re-
start the installation of the applications once the reset
sequence is complete.
Adjusting
Backlight Level
The screen backlight may be adjusted to match the ambient
light for optimized visibility. You don’t need the same level of
screen backlight in dark areas than in hot sun.
• On the Home screen, tap successively , Settings, System
and Brightness.
• Drag the cursor to the right or left to set the screen
backlight to the desired level (between 0 and 10). The
resulting brightness is obtained when you release the
cursor.
• Tap OK to save your setting.
• Tap to return to the Home screen.
Setting Backlight
Idle Time
One way of saving the battery is to avoid those periods of time
during which the screen backlight is unnecessarily on.
As the receiver automatically counts the time during which
neither the keypad nor the touch screen is active, you can set
the receiver to turn off the backlight automatically after a
certain idle time.
• On the Home screen, tap successively , Settings, System
and Backlight.
• Choose the idle time before the backlight is turned off
(10 seconds, 30 seconds or 1 to 5 minutes). For
maximum power saving, you may clear the option that re-
activates the screen backlight on touching the screen or
pressing a key.
Different settings may be made for these two parameters
depending on the power source used (battery or external).
• Tap OK to save the settings.
• Tap to return to the Home screen

English
6
Power
Management
A better way of saving the battery is to allow the receiver to
switch to Suspend mode automatically after a certain period
of inactivity.
• On the Home screen, tap successively , Settings and
Power.
• Tap on the Advanced tab. This tab allows you to ask for the
receiver to switch automatically to Suspend mode if it
stays idle for the period of time you choose. You may
choose a different setting depending on whether the
receiver is powered from the internal battery or from an
external power source.
• Tap OK to save the settings.
• Tap to return to the Home screen
Regional Settings
It’s a good idea to customize your receiver so that it complies
with a number of local preferences, such as country’s
currency, decimal point representation, time and date
formats, etc.
• On the Home screen, tap successively , Settings, System
and Regional Settings.
•OntheRegion tab, select your country.
• Use the other tabs to set your local settings:
– Number format
– Currency choice
– Time and date formats
• Tap OK to save the settings.
• Tap to return to the Home screen
Locking the
Screen and the
Keypad
At some stage in your work, you may need to lock the receiver
to make sure no user intervention from the screen or keypad
can affect the work in progress.
• From the Home screen, tap .
• At the bottom of the screen, tap . As a result, the touch
screen and keypad are made inactive.

English
7
• To unlock the touch screen and keypad, just drag the on-
screen slide button either to the left or right. This will take
you back to the Home screen.
How to Hold the
Receiver
Tracking satellites with your receiver requires that you use the
receiver outdoor and hold it in an appropriate manner.
The receiver will have the best view of the sky when you hold
it at an angle of 30 to 45 degrees (38° ideally) from
horizontal and not too close to your body.
You can check that your receiver is tracking enough satellites
by running the GNSS Toolbox, and more particularly the
GNSS Status function (see GNSS Status on page 33). When
enough satellites are tracked, you can start using your
receiver and run your application software.
Switching to
Suspend Mode
Switching the receiver to Suspend mode is the right thing to
do when you need to make a short pause in your work and you
want to save the operating time of your battery. You should
not however switch the receiver to Suspend mode when it is
collecting raw data.
In Suspend mode, GNSS reception and the modem are off.
The receiver is idle, using the minimum of energy required to
save the use context. The Power & Battery LED flashes green
every 5 seconds or so.
To switch to Suspend mode, just press briefly on the Power
button [8].
[8]
[16]

English
8
To wake up the receiver, hold the same button pressed until
the screen wakes up. This will instantly restore the use
context in which the receiver was before entering the
Suspend mode.
Turning the
Receiver Off
After you have finished your field work, turn off your receiver
by holding the Power button [8] pressed until the message
“Saving Parameters” is displayed on the screen. The power
shutdown will be effective after about 10 seconds.

English
9
System Description
Receiver Front
View
Display Screen
The display screen [1] is a 3.5-inch, QVGA, 256k-color (18-
bit RGB) touch screen (240 x 320 pixels).
Keypad, Scroll and Enter Buttons
The keypad [2] consists of the following buttons:
The Enter button [3] is used to accept highlighted input and
initiate various functions.
The Scroll button [4] is the ring around the Enter button. It
is used to move the cursor on the screen, from one data field
to the next on a parameter screen, from one option to another
in a menu, from one geographical location to another on a
map screen.
Stylus and Stylus Holder
The stylus [5] can be used to work directly from the touch
screen. When not used, the stylus can conveniently be stored
in the receiver by inserting it into the dedicated holder [5].
Built-in GNSS Antenna
The receiver incorporates a built-in antenna [6]. The receiver
should be held properly to optimize satellite reception.
Microphone
A microphone is used by the voice recorder. Keep the small
aperture [7] clear when recording a vocal comment.
[6]
[7]
[2]
[1]
[8]
[5]
[3] [4]
[9]
Button Function
The keypad includes two of these buttons, one on the right,
the other on the left.
Each of them is a convenient alternative to tapping on the
functions appearing just above in the task bar at the bottom
of the screen (e.g. Notifications, Contacts, Menu, Log, etc.).
Use this button to enlarge the map displayed on the screen
(zoom in).
Use this button to reduce the map displayed on the screen
(zoom out).
In some software applications, use this button to cancel the
last action performed or return to the previous screen.
Equivalent to the OK button.
This is the default function assigned to this button but you
are however allowed to define another function for this but-
ton through Start>Settings>Personal>Buttons.

English
10
Built-in GSM Antenna
[8]: Location of the built-in GSM antenna used for mobile
communications.
Built-in Bluetooth Antenna
[9]: Location of the built-in Bluetooth antenna for wireless
communication with nearby Bluetooth-fitted equipment.
Receiver Rear
View
Camera Lens
Keep the camera lens [10] clear when taking pictures or
recording videos.
Loudspeaker
As a multi-media device, the receiver includes a high-quality
loudspeaker [11], which can be used by any voice-based
software application.
Battery Compartment
The receiver makes use of a rechargeable battery pack.
Loosen the quarter-turn finger screw [12] to access the
battery compartment [13],
Receiver Side
View (Left)
Power Button
• With the receiver off, pressing the Power button [14] until
the screen wakes up will turn on the receiver.
• After the receiver has completed the boot sequence,
another short press on the Power button will put the
receiver in Suspend mode. Please refer to Power Modes on
page 14 for more information on the Suspend mode.
• To quit the Suspend mode, hold the Power button pressed
for a few seconds until the screen wakes up. The receiver
will then restore the context in which it was before being
switched to Suspend mode.
• With the receiver on, holding the Power button pressed for
about 3 seconds will result in a receiver being turned off
after about 10 seconds. In the sequence before effective
receiver shutdown, the screen will display the message:
“Saving Parameters...”.
[10]
[12] [13]
[11]
[17]
[14]
[16]
[15]

English
11
Power & Battery LED
This LED [15] gives indications on the receiver power status,
battery charging and Windows Mobile notifications. Please
refer to LED Indicator on page 15 for more information on the
LED indications.
SDIO Interface
The SDIO interface [16] is used to insert an SD card.
To open the flap, use a finger nail or the tip of a pen.
Inserting an SD card: Push the SD card in until you hear a
“click”.
Removing an SD card: Push a bit further in and let go.
While using the receiver in the field, make sure the flap is
always close, whether an SD card is used or not. This will
efficiently protect the receiver from rain.
The SDIO interface can also be used to connect a WiFi
device.
External Antenna Input
Use the external antenna input [17] to connect an external
antenna to the receiver. When an external antenna is
connected, the built-in antenna is automatically
disconnected from the receiver input.
The antenna input connector is protected by a rubber flap.
Although a waterproof coaxial connector is used, Spectra
Precision recommends you keep the flap close when no
external antenna is used.
Receiver Bottom
View
Power/Data Connector
This connector ([18]) is used to plug the receiver to the
docking station. This is achieved by simply inserting the
receiver in an almost vertical position into the docking
station. A secure connection is obtained once the receiver
naturally rests on the docking station.
[17]
[14]
[16]
[15]
LED color Meaning
Steady Green Occurs at receiver power-up for a few seconds
Green flashes every 5 sec Receiver used in Suspend mode
Red flashes every 5 sec Windows Mobile Notification
Steady red Internal battery being charged on docking station
[18]

English
12
Using this connector, the receiver can also be powered via the
POGO cable (see picture) or a cigarette lighter adapter.
However, none of these connections will allow the internal
battery to be charged from the external power source then
used.
Docking Station The docking station basically is a holder for the receiver. It
may be used at the office for various and combined purposes:
• As a safe and convenient tool for temporary receiver
storage. The receiver is held firmly minimizing the risk of
fall or scratches.
• As a battery charger once powered by the AC adapter. The
docking station can charge the battery inserted in the
receiver as well as an additional battery placed at the back
of the docking station.
When two batteries are charged simultaneously, fast
charging (< 4 hours) is always for the battery in the
turned-off receiver and slow charging (about 11 hours) for
the spare battery located at the back of the docking
station.
Charging for the spare battery switches to fast charging
once the receiver battery is fully charged or the receiver is
removed from the docking station.
• As an interface with a computer for office work, using a
serial data line (USB or RS232 port), possibly through
Microsoft ActiveSync.
Top View
[19]
[20]

English
13
The top view of the docking station shows the slot [19] in
which to insert the receiver from above the docking station.
At the bottom of the slot is the 16-contact connector [20].
When resting on the docking station, the receiver is
automatically powered from the AC adapter (if connected)
and the charging status of its internal battery tested.
Rear View
The following elements can be found at the rear of the
docking station:
• Back slot [21] for charging a second battery
• Charging indicator [22] for back slot:
– Steady red: Battery charging in progress
– Steady green: Battery fully charged
– Off: No battery connected
– Blinking red, every second: Temperature inside battery
exceeds upper limit. Charging suspended until
temperature is back to normal. If persisting, remove
the battery and resume charging later. If this occurs
several times with the same battery, consider changing
the battery. Dispose of the battery according to
regulations.
• Mini USB connector [23]: Use this connector only to let
the receiver communicate with your computer through
Microsoft ActiveSync (USB “Device”).
• USB connector [24], Use this connector to plug a USB
key (USB “Host”, mass storage only).
• RS232 SubD 9-C connector [25]: Use this port to connect
the receiver to a computer or external device.
• Power input [26]. Connect the output of the AC adapter to
this input.
[21] [22]
[23] [24] [25] [26]

English
14
Advanced Features
Power Modes The receiver can be powered from one of three different
sources:
• Its internal battery (typically for field operations)
• The power line, through the AC adapter and the docking
station (typically for office work). These two items are part
of the basic supply.
• An external DC source using the POGO cable or the
cigarette lighter adapter connected to the bottom of the
receiver through its 16-pin connector. The POGO cable
and cigarette lighter adapter are optional accessories.
The receiver can be switched to Suspend mode. This is a
power saving mode typically used in the field to allow a quick
restart after a pause. In this mode, only some parts of the
receiver are powered for the sole purpose of restoring the
context of use in which the receiver was when it was switched
to Suspend mode. GNSS reception is not however maintained
in this mode. That is why the receiver should NOT be used in
that mode while collecting raw data or/and operating in RTK
mode.
The receiver can also enter the Suspend mode automatically
in case of a very low battery after dismissing successively the
two “low battery” alerts, or after an idle time that you can set
through Start, Settings, Power (Advanced tab) (See also Power
Management on page 6). When collecting raw data and/or
operating in RTK mode, please clear this option so that the
receiver can never enter this mode.
Please note the following points whenever the receiver is
connected to a docking station powered by the AC adapter:
• The receiver won’t start if you try to power it up from the
docking station without having an internal battery
previously inserted in the receiver.
• If the receiver is currently on, the power input is switched
automatically from the internal battery to the AC adapter.
• Whether the receiver is on or off, the internal battery is
tested for its charging status. If it is discharged, a
charging sequence is started automatically. The end of
charging is also automatically detected, meaning you are
allowed to keep the battery and/or the receiver on the
docking station without any risk of overcharging.
• The AC adapter and docking station are designed to
provide power to the receiver while ensuring the charging
