Spectrum Industries 55114 User manual

Assembly Instructions
Tools
Required
0120377 Page 1 of 3
Assembly Instructions
Important
Before you begin, read and comply with all safety and operating instructions,
and ensure all parts and correct quantities are included.
Any parts damaged during shipment must be reported within 5 days of receipt. To
report information regarding missing parts or damage, to purchase parts or acces-
sories, or if you have any questions, please contact us.
www.spectrumfurniture.com
800-235-1262, 715-723-6750
Thank you for purchasing Spectrum products!
Instructor-Side Door
55114 - 41”H
55387 - 36”H
4mm Hex
Wrench
(included)
(2) 0107139
Door Stop
(2) 0100195
3/8” Bushing
(2) 0102297
7mm x 30mm
JCWS
(1) 025039
4mm Hex
Wrench
(1) Door Assembly
1. Determine if the door will be hinged from the left or right-side of
the lectern when installed.
2. Install the (2) 3/8” bushings into the base panel holes. Figure 1.
3. Install the (2) door stops opposite the chosen hinge-side.
(One in upper, and one in lower position.)
1. Install Bushings and Door Stops
Note: The door comes from the
factory left-hinged. To switch the
hinge-side, see Step 4.
Figure 1
7mm x 30mm
JCWS
Door stop
7mm x 30mm
JCWS
Door stop
3/8” Bushing
3/8” Bushing
Base Panel
(1) 052311
3/8” Snap-in
grommet

Figure 3
Door stop
JC screw
0120377 Page 2 of 3
1. Install (1) 3/8” Snap-in grommet into the upper corner of the door
bay if one is not already installed. This will be the upper hinge point.
Figure 2A.
2. Set the lower hinge point of the door into the lower bushing.
3. Push down the quick-release lever, align the upper hinge point, then
release the lever. Figure 2B.
4. Close door.
2. Install Door
Figure 2B
Quick-release
lever
The offset door stops can be rotated slightly
to adjust the closed position of the door.
3. Adjust Door Stop
1. To rotate, loosen the JC screw slightly with a 4mm hex wrench.
Figure 3.
2. Rotate each door stop until the door contacts both bumpers at the
same time when closed. Also be sure the lock rods on the door will
align and engage with the lock holes.
3. Re-tighten the JC bolt securely.
Figure 2A
3/8” Snap-in
grommet

0120377 Page 3 of 3
925 FIRST AVENUE, CHIPPEWA FALLS, WI 54729 / 800-235-1262 / 715-723-6750 / WWW.SPECTRUMFURNITURE.COM
© 2016 Spectrum Industries Inc., All rights reserved.
4. Switch Hinge-Side of Door - Optional
The door can easily be removed for easier access using the quick-release
hinge lever located on the upper hinge pin of each door. Figure 4A. To
remove, push down the lever while lifting out the door.
Figure 4A
Quick-release
lever
The door can be installed to be hinged from the left or right-side.
To switch the hinge side:
1. Remove the door using the quick-release lever. Figure 4B.
2. Rotate the door 180°. Figure 4C.
3. The vented panel should be located on the bottom of the door.
Switch the lower vented metal panel with the upper acrylic panel
(requires removing or loosening 8-32 nuts.) Figure 4D.
4. Switch the corner hinge components as shown and tighten securely.
5. Re-install the door.
Figure 4B
Hinged on left
Hinged on right
3 4
1 2
Figure 4C
Figure 4D
180°
Tools Required
11/32” and
3/8” or
adjustable
wrench
Phillips
screwdriver
