Spectrum industries Link 55295 User manual

0113608 Page 1 of 7

CAUTION:

Before using this product, read this manual and follow

all safety and operating instructions.

Before you begin, please make sure all parts and

proper quantities are included. Any parts damaged

during shipment must be reported within 15 days of

receipt. To report information regarding damages or if

you have any questions, please call 1-800-235-1262.

To purchase parts or accessories, please contact us at

www.spectrumfurniture.com

1-800-235-1262

Thank you for purchasing Spectrum products!

Spectrum Industries, Inc

Chippewa Falls, WI 54729, USA

Owner’s Manual

55295 36”H LINK Lectern w/ overbridge

55296 42”H LINK Lectern w/ overbridge

LINK Lectern w/ Overbridge Control Console™

Overbridge Insert Panel Removal

Note: The insert panel shown (shaded) is

not included with the lectern or overbridge.

This option needs to be ordered separately

to complete the overbridge.

Note: The overbridge panel is horizontally sym-

metrical and can be easily removed, rotated, and

re-installed if a cutout needs to be relocated to

the opposite side of the overbridge.

0113608 Page 2 of 7

Safety

• Read this owner’s manual before assembly or operation.

• Do not allow children to move lectern.

• Move slowly and carefully when mobile.

• For indoor use only. Do not install or store the unit where it will be exposed to weather. Keep unit dry.

• For added safety, plug the unit into a grounded three-prong receptacle controlled by a GFI

(Ground Fault Interrupter) circuit breaker.

Setup

1. To remove the insert panel, remove the (2) 1/4-20 x 35mm JC bolts with a

4mm hex wrench. Figure 1A.

2. Lift the panel out.

3. The overbridge panel is horizontally symmetrical and can be easily removed,

rotated 180° and re-installed if a cutout needs to be relocated to the opposite

side of the overbridge. Figure 1B.

Figure 1A

Figure 1B

Floor Anchoring (Toe Kick models only)

0113608 Page 3 of 7

Figure 2

1/4-20 x 40mm JC bolt

(access from inside lectern)

4 req’d

Note: 4 fasteners are required

toanchorthetoekicktooor.

(fasteners not included).

LINK Lectern

access panel

toe kick

1/2” mounting holes

forooranchors

1. IfyourLINKisequippedwithatoekick,andyouwishtoattachittotheoor,thetoekickwillneedtobe

detached from the unit. To detach, remove the (4) 1/4-20 x 40mm JC bolts (one on each corner from

inside the lectern) with a 4mm hex wrench.

2. Carefully lift the lectern off the toe kick. This will require several people. Figure 2.

3. Locatethetoe-kickintoitsnalpositionontheoorandmarkthe(4)mountingholelocationsontheoor

(The toe kick mounting holes are 1/2” dia.)

4. Drillholesintoyouroorandanchorthetoekickwithappropriatefasteners.

5. Carefully lift the lectern back onto the anchored toe kick and align the (4) mounting holes.

6. Re-attach the lectern to the toe kick with the (4) previously removed JC bolts.

7. The access panel can be removed to access wiring below lectern.

0113608 Page 4 of 7

Cord reel operation

Operating Instructions:

1. To latch cord - Pull cord out to full length. Allow the cord to retract 1-2 feet back into

the reel. Pull the cord out slowly. When a ‘click’ is heard, the cord will latch in place.

2. Plug into 110-125V (single phase), 3-conductor wall outlet.

3. To release cord - Unplug from wall outlet. Pull cord out slowly until clicking stops.

The latch will release and the cord can be guided back into the reel. Do not allow the

cordtoyunrestrictedbackintothereel.

4. Do not overload or circuit breaker (15-amp maximum) will cut off current. To restore

power, remove overload, wait two minutes, then reset the circuit breaker by pressing

the button on the back of the 3-prong male power plug.

Maintenance:

1. Remove dirt and grime as soon as it accumulates on the reel case by using a soft,

damp cloth (a mild detergent may be used if needed), being careful not to wet

the electrical plug. Never immerse any part of the unit in any solution to clean.

DO NOT use solvents such as gasoline, turpentine, etc. to clean unit.

2. Keep cord clean to assure smoothest automatic retraction. Simply pull cord to its

full length and allow to retract through a dampened rag. Pull out full length again

and sprinkle cord with talcum powder.

Specications:

15’ retractable, 15-amp, 125V, 12 AWG with breaker, UL listed

WARNING

• This cord reel is intended for general indoor use only. It is not intended to be used

inpotentiallydangerouslocationssuchasammableorexplosiveatmospheres.

The reel is not waterproof and not intended for use in potentially wet locations.

• Do not overload (15-amp maximum).

reset button

power plug

Moving the lectern

1. Before moving the unit, unplug all power cords and retract power cord into the reel.

2. Be sure the casters are in the unlocked position and the doors closed.

3. Move the lectern slowly and carefully.

4. Lock the casters after moving.

0113608 Page 5 of 7

Options

Flip-up Shelf

adjustable-height

223⁄4”W x 261⁄4”D

(50 lbs max load)

55140

Steel Handle

271⁄2”W

55132

Note:Theip-upshelfandsteelhandleareinter-

changeable and can be mounted on either side.

LINK Lectern Rear Rack Rail Kit

55139 - 42” 19RU (15RU full-depth)

55134 - 36” 15RU (12RU full-depth)

Note: Power & communication wiring for document cameras, laptop comput-

ers,and/orprojectorsplacedontheip-upshelfshouldberoutedontopof

the audience-side of the shelf. Use of the shelf grommet hole for wiring will

result in pinching of the cords when the shelf is folded.

Overbridge Insert Panel

required for overbridge version-contact

Spectrum to specify cutout size(s) & position(s)

overbridge not available separately

96504 - blank panel

96504mod - panel with cutout(s)

Replacement Key Set

55142

TouchLink™350CV cutout cover plate

71⁄2”W x 61⁄4”D (16-gauge steel)

55350

Cable Cubby™300S cutout cover plate

(overbridge models only)

511⁄16”W x 7”D (20-gauge steel)

96500

TouchLink™700MV cutout cover plate

(TouchLink™700MV overbridge models only)

93⁄8”W x 67⁄16”D (16-gauge steel)

55351

Flat Panel Monitor Arms & Tablet Mounts

(See the Spectrum website or catalog for the latest

available monitor arm & tablet mounting options)

7-Outlet Power Strip, insured

w/ surge protector, and 12’ cord

10”W x 2”D x 11⁄8”H

99024

6-Outlet Power Strip

w/ 12’ cord

115⁄16”W x 11⁄16”D x 13⁄16”H

99023

Non-Slip CPU Pad

11”W x 23”D

95518

Extron®Controller Adapter Kit

55239

Note: This kit is for use with a 5-gang

overbridge cutout measuring 97⁄16”W x

315⁄16”D.Thekitcanbeconguredfor

2, 3, or 4-gang controllers.

4-gang

3-gang

2-gang

0113608 Page 6 of 7

Rack-mount accessories

Cantilever Shelf (2RU)

171⁄2”W x 18”D x 31⁄2”H

(50 lbs max load)

97504

Cantilever Shelf (3RU)

171⁄2”W x 18”D x 51⁄4”H

(80 lbs max load)

97502

Pull-Out Shelf (2RU)

161⁄2”W x 173⁄4”D

(50 lbs max load)

97505

Locking Drawer (2RU)

interior dims:

153⁄4”W x 1311⁄16”D x 27⁄8”H

(25 lbs max load)

97514

Drawer (3RU)

interior dims:

1515⁄16”W x 141⁄2”D x 51⁄4”H

(50 lbs max load)

97518

Drawer (4RU)

interior dims:

1515⁄16”W x 141⁄2”D x 7”H

(50 lbs max load)

97519

Cooling Fans (3RU)

19”W x 2”D x 51⁄4”H

Single Fan - 97507

Double Fan - 97506

Wire Lace Kit

3 lace straps included

95517

Flexible Halogen Light

(1RU)

19”W x 2”D x 13⁄4”H

99033

Locking File Drawer (8RU)

w/leholder

interior dims:

153⁄4”W x 139⁄16”D x 135⁄16”H

(50 lbs max load)

97515

Rack-Mount Blanks

(llsrackspaceswhere

components are not needed)

97516 - (1⁄2RU)

97510 - (1RU)

97511 - (2RU)

97512 - (3RU)

97513 - (4RU)

9-Outlet Power Strip

(1RU)

19”W x 9”D x 13⁄4”H

99021

Pull-Out Shelf (3RU)

161⁄2”W x 213⁄4”D

(80 lbs max load)

97503

LT-4 Laptop Storage Unit (7RU)

(stores 4 laptops horizontally)

laptop tray dims:

161⁄4”W x 201⁄2”D x 23⁄16”H

97517

925 First Avenue, PO Box 400, Chippewa Falls, WI 54729 Ph: 1-800-235-1262 Fax: 1-800-335-0473

E-mail: [email protected] web: www.spectrumfurniture.com

0113608 Page 7 of 7

Warranty

WE WILL MAKE IT RIGHT FOR YOU!

Spectrum is committed to provide complete customer satisfaction. Each of our products are manufactured from the best materials available and each

product is stringently monitored throughout the production process through our P.A.C.E. program (Product Assurance to meet Customer Expectations).

Our Customer Service Help Line 1-800-235-1262 is ready to provide immediate attention to any questions, comments or concerns. We are available

to answer your calls Monday through Friday from 7 am to 5 pm CST, excluding observed holidays. In addition your product comments or concerns are

welcome via e-mail at: [email protected].

Warranty Statement

We guarantee all Spectrum products to be free of all defects in materials and workmanship, for the original owner, for a period of ten years. Any item

deemed defective by Spectrum or the original manufacturer, under normal use conditions, will be repaired or replaced at Spectrum’s discretion. This

warranty applies to all products manufactured and distributed by Spectrum except the products

listed below.

Items that have a varying warranty include, but are not limited to, the following:

• Adjustable Crank/Electric Desk Legs (1 yr)

• Flat Panel Desk Gas Cylinders (1 yr)

• Upholstered Soft-Goods (5 yrs)

• Adjustable Height & Stacking Chair Parts – including frames, gas cylinders, wood and plastic parts, and control handles (7 yrs)

• Adjustable Height & Stacking Chair Casters (2 yrs)

• Chair Upholstery & Textiles (2 yrs of normal use of Soft Goods, Adjustable Height, Stacking, Wood and Metal Chairs)

• Chair Upholstery - Graded-In Fabrics and C.O.M (no warranty)

• Height Adjustable Columns and Lifts (1 yr)

• General Use Casters (1 yr)

• Electrical – Electri-Pak, Power Communication Modules, and special order ECA electrical items (1 yr)

• Electrical - Power Strips & Electrical Timers (1 yr)

• Electrical Surge Suppressors (lifetime)

• Electrical - Retractable Power Cords (1 yr)

• Keyboard/Mouse Trays (1 yr)

• Flat Panel Monitor Arm – General Parts (5 yrs)

• Flat Panel Monitor Arm – Gas Cylinders (2 yrs)

• CRT Monitor Arm (1 yr)

Warranty is void if product is not used for its intended purpose or subjected to an unusual application, multiple-shift use, alteration, accident, abuse or

abnormal wear and tear. Representations of colors on-line and in printed materials are meant to be a close reference to the actual colors but not an

exact match. Slight variations in color and texture of wood stains, powder coating, laminates, fabrics and other materials are normal in different manu-

facturing lots; as such these variations are not considered defects.

DESIGNED FOR INDOOR USE ONLY – Unless speciﬁcally stated in the product speciﬁcations, Spectrum’s products have been designed and con-

structed for indoor use only. Moving or using outdoors, or on excessively rough surfaces, may cause damage to the products and will void the warranty.
