Assembly InstructionsAssembly Instructions
0192113 Page 1 of 2
Assembly InstructionsAssembly Instructions
Important
Before you begin, read and comply with all safety and operating instructions,
and ensure all parts and correct quantities are included.
Any parts damaged during shipment must be reported within 5 days of receipt.
To report information regarding missing parts or damage, to purchase parts
or accessories, or if you have any questions, please contact us.
www.spectrumfurniture.com
800-235-1262, 715-723-6750
Thank you for purchasing Spectrum products!
CPU Sling - 34342CPU Sling - 34342
For Esports DeskFor Esports Desk
(3) 0107595
Strap / Buckle
Assembly 58”
(10) 038064
#14 x 3/4”
PHSM
(1) 0151796
CPU Sling • Mounts gaming CPU under worksurface on
left or right side of desk
• Max CPU size: 5.56” - 9”W x 18”D x 22.31”H
• Not for use on tilting worksurfaces
(1) 0152736
Sling bracket
(1) 060048
Sling base
(2) 034195
1/4-20 Wing nut
Figure 1
(4) #14 x 3/4”
PHSM
Worksurface
CPU
Sling
Sling
bracket
Sling
base
(6) #14 x 3/4”
PHSM
1/4-20
Wing nut
(2 required)
1. Attach sling to desk1. Attach sling to desk
1. Determine which side of the desk you would like to mount the CPU
sling (left or right).
2. Attach the CPU sling and sling bracket to the worksurface
underside as shown using (10) #14 x 3/4” PHSM screws and the
pre-drilled pilot holes. Figure 1. Tighten screws securely.
3. Attach the sling base to the sling with (2) 1/4-20 wing nuts.
Sling
bracket
0192113 Page 2 of 2
925 FIRST AVENUE, CHIPPEWA FALLS, WI 54729 / 800-235-1262 / 715-723-6750 / WWW.SPECTRUMFURNITURE.COM925 FIRST AVENUE, CHIPPEWA FALLS, WI 54729 / 800-235-1262 / 715-723-6750 / WWW.SPECTRUMFURNITURE.COM
© 2020 Spectrum Industries Inc., All rights reserved.
2. Attach straps2. Attach straps
1. Thread the (3) straps through the slots in the sling bracket
and base as shown in Figure 2 with the tails hanging down.
2. Thread each strap through the buckles as shown.
Figure 2
CPU tower
Strap / buckle
assembly
1. Slide the base to the widest position and carefully place the CPU
tower into the sling. Figure 3.
2. Slide the base tight against the tower and tighten the two wing nuts.
3. Position all (3) buckles at the same height.
4. Tighten the straps by pulling on tails until the CPU tower and base
are level.
3. Install CPU tower3. Install CPU tower
Figure 3
Buckle
Tails
CPU Sling
Sling
base
1/4-20
Wing nut
(2 required)
Sling
base
