Spedal MC01 User manual

008C1728-EN
USB
CONDENSER
MICROPHONE
MC01

- 1 -
SPECIFICATION01
Sensitivity: -36±3dB(1.5V, 680KΩ; 0dB = 1V/Pa, 1KHz)
Output impedance: Low impedance(<680Ω)
Polar Pattern: Cardioid
Frequency range: 100Hz-18000Hz
SPL: 125dB
Signal to noise ratio: >58dB
Input sampling rate: 192KHz/24bit
Output sampling rate: 48KHz/16bit
20
10
0
-10
-20
-30
dB re 1V/Pa
● Typical Frequency Response Curve
20Hz 100 1000 10000 20000
0°
180°
● Polar Response 0°
-2.0
-10.0
-20.0
180°
270°90°
+5.0
0.0
-2.0
-4.0
-6.0
-8.0
-10.0
-12.0
-14.0
-16.0
-18.0
-20.0
-22.0
-24.0 -25.0
Frequency：
500 Hz：
1000 Hz：
4000 Hz：

- 2 -
FEATURES02
Volume up
Volume down
Volume off
Insert headphones
Volume adjustment
POWER REQUIREMENTS03
1. The microphone is powered through your device’s
USB port, which means that in most instances you
can just plug in and get started right away. For
non-standard USB ports, a powered USB hub may be
required.
2. This “Plug & Play” USB device is compatible with
both Windows and Mac computers.
● Typical Frequency Response Curve
Plug one end of the USB cable
into the power socket in the
microphone, and connect the
other end to a computer. The
power indicator light will turn
blue if it is working properly.
Power socket

- 3 -
GENERAL OPERATION04
The ideal positioning of the microphone and
distance to the user may be influenced by several
factors including room acoustics, vocal perfor-
mance, the user’s tone etc.
It is suggested that the microphone be directly
placed 15 cm (6") away in front of the lead singer.
● Microphone placement
● Positioning the microphone for users
15cm (6”)
The microphone has already been set in an ideal
internal gain mode, so there is no need for horizon-
tal adjustments. Necessary horizontal adjustments
can be made from your recording program, or via
your computer’s system preferences. (To adjust
your input level in your recording software, please
refer to the manual provided by the software devel-
oper.)
● Setting your input level
Moving closer will make a more intimate and full
sound, while moving further will contribute to a
sound with room echo effect and avoid increased
bass or low frequency response resulting from a too
close sound source.
Testing should be conducted from the angle at
which microphone is pointing, as different results
can be obtained when the vocalist is ‘offaxis’ to the
microphone.

- 4 -
1. Click on the Apple symbol at the top left of your
screen, and select ‘System Preferences’.
● Adjusting the input level on a Mac
OS computer
To manually adjust your input level via your
computer’s system preferences, please use the
following instructions relevant to your device
platform/operating system. Connect the other end
of the USB cable to a computer. The power indica-
tor light will turn blue if it is working properly.
2. Click on ‘Sound’ to view the sound options.
3. Open the ‘Input tab’.
4. From here, select the ‘USB LCS Audio’ from the
list of devices, and adjust the input level using the
slider.

- 5 -
1. Click on ‘Start’ menu and then ‘Control Panel’.
● Adjusting the input level on a
Windows computer
USB LCS Audio
3. Open the ‘Recording’ tab and double click on
‘USB LCS AUDIO’ from the device list.
2. Click on ‘Sound’ preferences in the ‘Control
Panel folder’.
USB LCS AUDIO

- 6 -
4. Adjust the input level with the slider.

For any questions please contact [email protected]
Scan the QR Code
www.spedal.cc
EN
DE
FR
ES
IT
PL
SV
JP
Download manuals of other languages from our homepage.
