QUANTUM STANDARD OPL CONTROL
For laundry managers requiring basic management options,Quantum
Standard comes with four cycle selections, two water levels and manual
programming. It also offers a maximum extraction speed of 100 G-force.
For the most accurate information, the installation guide should be used for all design and construction purposes. Due to continuous product improvements,design and specifications subject to change without notice.The
quality management system of Alliance Laundry Systems’Ripon facility has been registered to ISO#9001:2000.
Printed in the U.S.A.
speedqueen.com
© 2012 Alliance Laundry Systems LLC AO11-0673R1
ON-PREMISES LAUNDRY HARDMOUNT SCN030GF
FEATURES & BENEFITS
• Advancedwaterprotectionalertsownersifthewasher
hasastuckdrain,slowdrainconditionorleakinginlet
valve,whichhelpsconservewater.
• Ruggeddoorhandleandnewlockmechanismensure
easyopeningandclosingandreliablelocking—no
moredoorlockerrorcodes.
• Newdualtriple-lipsealsandastainlesssteelsleeve
aroundthetrunnion,deliverthestrongestlineof
defenseinprotectingthebearingsagainstthe
damagingeffectsofmoisture.
• Four-compartmentchemicaldispenseradds
chemicalsattherighttime,automaticallysavingstaff
time.Thenewdispenserdesigneliminatesover-
sudsingconditions.
PRODUCT SPECIFICATIONS
SCN030GF
Capacity 30 lb
Width 29”
Depth 34 9/16”
Height 45”
Cylinder Diameter 24”
Cylinder Depth 16”
Cylinder Volume 4.19 cu. ft.
Door Opening Size 14 5/16”
Door Bottom to Floor 14”
Wash Speeds 48 RPM
Extract Speed 542 RPM
Distribution Speed 86 RPM
Extract G-Force 100
Water Inlet 2 @ 3/4”
Drain Diameter 1 @ 2”
Drain Height To Floor 4 1/2”
Motor Size 1.0 HP
Electrical Specs
Voltage/Hz/Phase
X 200-208/208-240/50/60/1/3
Q 200-208/220-240/50/60/3 (electric heat)
P 380-415/50/60-3
N 440-480/50/60/3
Net Weight 491 lb
Shipping Weight 516 lb
Shipping Width 32 1/2”
Shipping Depth 39 13/16”
Shipping Height 54 1/2”
Agency Approvals cETLus, CE
