Speed Queen SCN080GF Installation instructions

©Copyright 2011 Alliance Laundry Systems LLC AO11-0682
FEATURES & BENEFITS
• Advancedwaterprotection
alertsownersifthewasher
hasastuckdrainorslow
draincondition,whichhelps
conservewater.
• Ruggeddoorhandleand
newlockmechanismensure
easyopeningandclosing
andreliablelocking—no
moredoorlockerrorcodes.
• Newtriple-lipsealanda
stainlesssteelsleevearound
thetrunnion,deliverthe
strongestlineofdefense
inprotectingthebearings
againstthedamagingeffects
ofmoisture.
• Newfour-compartment
chemicaldispenseradds
chemicalsattherighttime,automaticallysavingstafftime.Thenewdispenser
designeliminatesover-sudsingconditions.
AVAILABLE CONTROLS
Control Description
Quantum Standard Washer Extractor OPL For laundry managers requiring basic manage-
ment options, Quantum Standard comes with four
cycle selections, two water levels and manual
programming. It also offers a maximum extraction
speed of 100 G-force.
Forthemostaccurateinformation,theinstallationguideshouldbeusedforalldesignandconstructionpurposes.
Duetocontinuousproductimprovements,designandspecificationssubjecttochangewithoutnotice.Thequal-
itymanagementsystemofAllianceLaundrySystems’RiponfacilityhasbeenregisteredtoISO#9001:2000.
PRODUCT SPECIFICATIONS
Cabinet Dimensions
Capacity 80 lb
Width 41 1/2”
Depth 51 1/2”
Height 56 3/16”
Cylinder Diameter 36”
Cylinder Depth 22”
Cylinder Volume 12.4 cu. ft.
Door Opening Size 18 1/2”
Door Bottom to Floor 17 3/4”
Speed
Wash Speeds 40 RPM
Extract Speed 408 RPM
Distribution Speed 70 RPM
Extract G-Force 100
Connections
Water Inlet 2 @ 3/4”
Drain Diameter 1 @ 3”
Drain Height To Floor 5 3/4”
Motor
Motor Size 5 HP
Electrical Specifications
N 440-480/50/60/3
Voltage/Hz/Phase
Q 200-240/50/60/3
Voltage/Hz/Phase
X 200-240/50/60/1-3
Voltage/Hz/Phase
Shipping
Net Weight 1374 lb
Shipping Weight 1461 lb
Shipping Width 48”
Shipping Depth 56”
Shipping Height 65 3/4”
Agency Approvals
Agency Approvals cETLus, CE
ON-PREMISES LAUNDRY HARDMOUNT SCN080GF
