Speed Queen TR3 Operator's manual

Quick Consumer
Manual

Two (2) lter
screen washers
Two (2) plain
rubber washers
Four (4) rubber
feet
Beaded strap
Installation
Parts included:
1. Remove shipping brace and shipping plug.
2. Wipe out inside of washtub.
3. Connect ll hoses – water pressure = 20-120 psi [138-827 kPa].
• Two required, sold separately
• Flush water supply lines
• Use two lter screen washers with screen facing faucet
• Use two rubber washers in end of hose connecting
to the machine
4. Connect drain hose to drain receptacle – 36 in. [91 cm]
recommended height.
• Use beaded strap to secure drain hose to drain receptacle
5. Position and level washer – adjust front two legs. Tilt washer
forward and back to set rear legs.
• Place four rubber feet on leveling legs
6. Connect washer to electrical power – on individual branch
circuit. Refer to serial plate for electrical ratings.
7. Run washer through one complete cycle to make sure it is
operating properly.
Welcome
Thank you for purchasing a Speed Queen®appliance. We value you as a customer.
At Speed Queen, leading performance is our daily reality. We seek to deliver an outstanding
experience in every aspect of laundry. Your machine was built to last 25 years in your home and
Speed Queen support has been built to provide you with the best service in the industry.
1.
2.
5.
7.
4.
1.
3.
6.
8. Check for leaks.

The Normal Eco Cycle
The Normal Eco Cycle is designed for providing
an eco-friendly solution for washing everyday
cottons and linens. You will notice that this cycle
uses less water and less hot water than other
cycles. These functions are unique to the Normal
Eco Cycle. All other cycles and options have no
temperature restriction and use a full tub rinse.
Electronic Control Washers –
Special Cycles Reference
When you select the Special Cycles keypad, pressing the
up and down arrow keypads will allow you to choose from
eight dierent cycles. The display will show P and a number
relating to the cycle.
P1
Eco Heavy Duty
This cycle uses a spray rinse to
reduce water consumption. It also
uses less hot water. It has a longer
wash time than the Normal Eco
cycle. If using fabric softener in this
cycle, select the Extra Rinse option.
P2
Eco Delicate
This cycle uses a spray rinse to
reduce water consumption. It also
uses less hot water. It has a shorter
wash time and a gentler wash
action than the Normal Eco cycle.
If using fabric softener in this cycle,
select the Extra Rinse option.
P3
Waterproof
Wash waterproof items such as rain
coats and bed liners with this cycle.
It includes a gentle agitation, very
low spin, and lower water levels. For
best washing results, add another
item such as a cotton sheet on top
of the waterproof items to make
sure they get fully submersed in
the water and that no air is trapped
under the waterproof items.
P4
Super Soiled
Use for very heavily soiled items. It
includes a 15-minute soak at the
beginning of the cycle, a longer
wash time than Heavy Duty and
Extra Rinse.
P6
Wool
Wash wool items using this cycle.
It includes cold water, a 30-minute
soak, a very short gentle agitation,
a one-minute spin, a cold rinse, and
an extended spin time.
P7
Athletic
This cycle includes a cold wash and
a shorter, gentle agitation.
P8
Denim
This cycle is similar to the Heavy
Duty cycle but with cold wash and a
longer spin time.
Cycle Information
P5
Whites
This cycle is designed to keep white
laundry white. It utilizes a longer
wash time. Use for items such as
sheets and towels.
Auto Fill
Auto Fill will provide the most ecient use of
water and also enhance wash performance by
optimizing the water level for each particular
load size and type.

5.
6. 7. 9.
5.
6. 7. 9.
5.
6.
7.
9.
8.
5. Set cycle
Operating
1. Prepare laundry 2. Add detergent
3. Load laundry 4. Close lid
6. Set temperature
Register
1. Register your product at www.speedqueen.com
to take full advantage of the limited warranty.
2. Download full documentation and view installation and operating
videos for an immersive experience at Speedqueendoc.net or scan
the QR code below.
3. If you wish to receive printed documents at no cost, please complete
the order form and return by mail to the address on the form, or
email your request to [email protected].
Warranty
3, 5 & 7 Year Warranties, depending on your model.
Covers all parts and in-home labor.
Order Form for Printed Documentation Allow 1-2 weeks for delivery. Model No. Serial No. Name Address City State Zip Code Phone No. Email Address
7. Set load size
(Auto ll recommended) 8. Set soil level
9. Press start/pause
Note: This unit includes a limited warranty. Refer to
Speedqueendoc.net to download the full warranty bond.
TR3 control
TR5 control
TR7 control

BUSINESS REPLY MAIL
FIRST CLASS MAIL PERMIT NO. 489 RIPON,WI
POSTAGE WILL BE PAID BY ADDRESSEE
NO POSTAGE
NECESSARY IF
MAILED IN THE
UNITED STATES
SPEED QUEEN TECHNICAL DOCUMENTATION SHEPARD STREET P O BOX 990 RIPON WI 54971-9967
Part No. 204793R1
April 2019
