Sper scientific 850071 User manual

Environmental Quality
SD Card Logger
850071
Instruction Manual

2 3
TABLE OF CONTENTS
Materials Supplied . . . . . . . . . . . . . . . . . . . 6
Power Supply . . . . . . . . . . . . . . . . . . . . . 7
Meter Components . . . . . . . . . . . . . . . . . . 8
Keypad . . . . . . . . . . . . . . . . . . . . . . . . . 8
Setup Mode . . . . . . . . . . . . . . . . . . . . . .10
Measurement Procedures . . . . . . . . . . . . . . .15
Datalogger . . . . . . . . . . . . . . . . . . . . . . .22
Battery Replacement. . . . . . . . . . . . . . . . . .25
Troubleshooting . . . . . . . . . . . . . . . . . . . .25
Specications . . . . . . . . . . . . . . . . . . . . .26
Warranty . . . . . . . . . . . . . . . . . . . . . . . .32
Environmental Quality SD Card Logger 850071
Copyright ©2013 by Sper Scientic
ALL RIGHTS RESERVED
Printed in the USA
The contents of this manual may not be reproduced
or transmitted in any form or by any means electronic,
mechanical, or other means that do not yet exist or
may be developed, including photocopying, recording,
or any information storage and retrieval system
without the express permission from Sper Scientic.

4 5
INTRODUCTION
This Sper Scientic Environmental Meter with SD Card
Datalogger (Model 850071) is an extremely fast and
accurate meter with multiple functions. The meter reads
humidity, air temperature, air velocity, and measures
light in Lux or Ft-cd. Optional Type K/J thermocouple
probes available.
This meter features a real time SD memory card
datalogger. Standard, portable SD memory cards provide
unlimited data storage and upload pre-formatted data
directly to Excel. Each data set includes the measured
value along with the time and date. Sampling time can be
set from 1 second to 3600 seconds. Alternatively, manual
datalogging is available to record 99 readings.
FEATURES
• Functions as a light meter, anemometer, and humidity/
temperature meter. Optional adapter enables Type K/J
thermometer.
• Measures humidity in both %RH and temperature
• Displays air velocity in ve units of measure
• Lux or Foot Candles unit selection
• Zero Adjustment
• Highly accurate microcomputer circuit
• Direct upload of data to Excel
• SD memory card datalogger
• Manual datalogger option
• Internal clock and calendar
• Touch-tone
• Tripod mounting screw
• Built-in tabletop stand
• Maximum and Minimum
• Hold function
• Auto power o󰀨
• Low battery indicator
• Backlight

6 7
MATERIALS SUPPLIED
• Meter
• Sensor
• SD Card
• 6 AA Batteries
• Instruction Manual
• Hard Carrying Case
OPTIONAL ACCESSORIES
840058 USB Power Cable
840097 AC Adapter
840059 SD Card
840093 Field Tripod
840090 Water Resistant Instrument Pouch
POWER SUPPLY
This meter can be powered by six AA (1.5V, UM3)
batteries or an optional 9 Volt DC adapter.
See p. 28 for battery replacement instructions.
Plug the adapter into the power port labeled
“DC 9V,” located on the side of the meter.
Note…
When using the adapter, the meter will remain permanently
on and the POWER button will be disabled.

8 9
METER COMPONENTS
Keypad
1. LCD Display
2. POWER/ESC
3. FUNCTION /HOLD/
NEXT
4. REC/ENTER
5. SET/▼ (TIME
CHECK)
6. LOGGER/▲
(SAMPLING
TIME CHECK)
Side of Meter
7. RESET
8. DC9V Power
Adapter Input Socket
Back of Meter
9. Battery Cover
Screws
10. Tripod Mounting
Screw
11. Battery
Compartment
/ Cover Stand
1
Top of Meter
12. Type K/J
Thermometer
Socket
13. Probe Input
Socket
Bottom of Meter
14. SD Card
Socket
Sensor Probe
15. Anemometer
Vane
16. Humidity/
Temperature
Sensor
17. Light Sensor
7
13
28
14
3
9
15
4
10
16
5
11
17
612

10 11
SETUP MODE
The advanced Setup Mode allows you to customize the
following meter preferences and defaults:
• Real Time Clock
• Decimal Type
• Auto Power O󰀨
• Touch-Tone
• Thermometer Type K/J
• Temperature Units
• Sampling Time
• SD Memory Card Format
Note…
The setup functions can be performed under any
parameter, but not while utilizing the datalogger function.
Once selections are saved, the meter will default to the
selected preferences.
Entering Setup Mode
1. Press POWER to turn the meter on.
2. Press and hold SET for at least 2 seconds to enter
Setup Mode.
3. Press NEXT to cycle through the setup functions.
Note…
Press ESC to exit Setup Mode. The meter will return to
Normal Mode.
Real Time Clock
1. Enter the clock function from Setup Mode
(see above). “dAtE” appears on the LCD.
2. Press ENTER. The year will appear on the LCD.
3. Press ▲or ▼ to adjust the value. Press ENTER to
save the value.
4. Repeat Step 3 to adjust the month, date, hour,
minute, and second.
Note…
This procedure adjusts the meter’s internal clock. The
internal clock will function when the meter is turned o󰀨 as
long as the batteries have adequate power.

12 13
Decimal Type
Although the decimal is commonly expressed as the “.”
symbol (i.e., 20.6 or 1000.53), some European countries
use a “,” symbol to represent the decimal (i.e., 20,6 or
1000,53). The meter defaults to the period symbol.
To adjust:
1. Enter the decimal type function from Setup Mode
(see page 11). “dEC” appears on the LCD.
2. Press ▲or ▼ to select Basic (.) or Euro (,).
Press ENTER to save the selection.
Auto Power O󰀨
The meter automatically turns o󰀨 after 10 minutes of
inactivity. To disable this function:
1. Enter the auto power o󰀨 function from Setup Mode
(see page 11). “PoFF” appears on the LCD.
2. Press ▲or ▼ to select yes (auto power o󰀨 enabled)
or no (auto power o󰀨 disabled). Press ENTER to
save the selection.
Touch-Tone
1. Enter the touch-tone function from Setup Mode
(see page 11). “bEEP” appears on the LCD.
2. Press ▲or ▼ to select yes (touch-tone enabled)
or no (touch-tone disabled). Press ENTER to
save the selection.
Thermometer Type K/J
1. Enter the thermometer type function from Setup
Mode (see page 11). “tYPE” appears on the LCD.
2. Press ▲or ▼ to select K or J. Press ENTER to
save the selection.
Temperature Units
1. Enter the temperature units function from Setup
Mode (see page 11). “t-CF” appears on the LCD.
2. Press ▲or ▼ to select C (degrees Celsius) or
F (degrees Fahrenheit). Press ENTER to save
the selection.
Sampling Time
The sampling time is the time allotted between successive
measurements. To adjust the sampling time (in seconds):
1. Enter the sampling time function from Setup Mode
(see page 11). “SP-t” appears on the LCD.
2. Press ▲or ▼ to adjust the value (1, 2, 5, 10,
30, 60, 120, 300, 600, 1800, or 3600 seconds).
Press ENTER to save the value.

14 15
SD Memory Card Format
This function will format the SD memory card to work
specically with your meter. New SD cards should always
be formatted before rst use. Formatting the SD card will
erase any previous memory on the card.
1. Enter the SD memory card format function from Setup
Mode (see page 11). “Sd F” appears on the LCD.
2. Press ▲or ▼ to select yes (format the SD memory
card) or no (do not format the SD memory card).
Press ENTER to conrm the selection.
3. If you selected yes in step 2 the display will show
“yES Ent.” Press ENTER again and the meter will
format the SD card.
MEASUREMENT PROCEDURES
Turning the Unit On/O󰀨
1. Press POWER to turn the meter on.
2. Press and hold POWER for ≥2 seconds to turn
the meter o󰀨.
Selecting the Function
Press and hold FUNC to cycle through the options
listed below. Release FUNC when you reach the
desired function.
Code on Display Function
An Air velocity/temperature
rH Humidity/temperature
tP Type K/J thermometer
LIgHt Light meter
Note…
The meter will default to the last function setting used when
it is turned o󰀨 and on again.

16 17
Air Velocity and Air Temperature
1. Plug the anemometer probe plug into the probe
input socket.
2. Press POWER to turn the meter on.
3. Press and hold FUNC to cycle through the
options until “An” appears on the LCD. Release
the FUNC button.
4. Hold the probe handle and point the probe head
toward the air ow. The air velocity value appears
on the upper display and the air temperature value
appears on the lower display.
Selecting the Air Velocity Unit
1. Press and hold UNIT. The meter will cycle through
m/s, Km/h, mph, Knot, and FPM.
2. Release UNIT when the desired unit appears
on the LCD.
Note…
To change the temperature unit, see page 13.
Humidity and Temperature
1. Plug the probe plug into the probe input socket.
2. Press POWER to turn the meter on.
3. Press and hold FUNC to cycle through the
options until “rH” appears on the LCD. Release
the FUNC button.
4. The humidity value appears on the upper display
and the air temperature value appears on the
lower display.
Note…
To change the temperature unit, see page 13.
Type K/J Thermometer
Note…
The anemometer probe must be disconnected from the
meter to obtain accurate Type K/J readings.
1. Press POWER to turn the meter on.
2. Press and hold FUNC to cycle through the
options until “tP” appears on the LCD. Release
the FUNC button.
3. Plug a thermocouple temperature probe (type K or J,
optional) into the type K/J thermometer socket. The
LCD will display the measurement value from the
temperature probe.

18 19
4. “K” or “J” appears on the LCD to indicate the type of
thermometer.
Notes…
When using the meter for the rst time, the meter
will default to K type thermocouple. See page 13 for
instructions on selecting the thermocouple type.
To change the temperature unit, see page 13.
Light Meter
1. Press POWER to turn the meter on.
2. Press and hold FUNC to cycle through the options
until “LIgHt” appears on the LCD. Release the
FUNC button.
3. Plug the probe plug into the probe input socket.
4. While holding the sensor handle, point the light
sensor directly toward (facing) the light source.
The light measurement will appear on the LCD.
Note…
This meter measures light in LUX or Foot Candles (Ft-cd).
To change the light unit, press and hold REC ENTER.
Release REC ENTER when the desired unit appears on
the LCD.
Zero Adjustment
During light measurement, if the display does not show
a value of 0 when the light sensor is completely covered,
zero adjustment is needed.
1. With the sensor covered, press LOGGER for
>3 seconds. “0” appears on the LCD.
2. Uncover the sensor to resume normal measurement.
Hold Function
1. When measuring any parameter, press HOLD to
freeze the reading on the display. “HOLD” will appear
on the LCD.
2. Press HOLD again to release the hold function.
“Hold” will disappear from the LCD.

20 21
Maximum and Minimum
To record maximum and minimum readings:
1. When measuring any parameter, press REC to
begin recording the maximum and minimum values.
“REC” appears on the LCD.
2. Press REC. The maximum value and “REC MAX”
appears on the LCD.
3. Press REC. The minimum value and “REC MIN”
appears on the LCD.
4. When you are viewing the maximum or minimum
value, you may press HOLD to delete the value.
“REC” appears on the LCD and the meter will begin
recording maximum and minimum values again.
5. To exit the max/min function, press and hold REC for
2 seconds. The meter will return to Normal Mode.
Note…
The meter cannot be turned o󰀨 from the memory record
function. Exit the function, then press and hold POWER to
turn the meter o󰀨.
Backlight
The backlight turns on automatically when the meter is
turned on.
1. Press POWER once to turn the backlight o󰀨.
2. Press POWER again to turn the backlight on.
View Real Time Clock
To view the time function during normal measurement
(not during datalogging):
1. Press TIME CHECK. The time information (Year,
Month/Date, Hour/Minute) will appear on the LCD.
View Sampling Time
To view the sampling time function during normal
measurement (not during datalogging):
1. Press SAMPLING CHECK. The sampling time
(in seconds) will appear on the LCD.

22 23
DATALOGGER
Preparing the Datalogger
1. Insert the SD card into the SD card socket on the
bottom of the meter, ensuring that the front of the
SD card faces the back of the meter.
2. Format the SD card as needed (see page 14).
3. Set the clock if using the meter for the rst time
(see page 11).
4. Set the decimal type if using the meter for the rst
time (see page 12).
Auto Datalogging
1. Set the sampling time to ≥ 1 second (see page 13).
2. Press REC. “REC” will appear on the LCD.
3. Press LOGGER. “REC” will ash on the LCD. The
tone will sound as the measurement data and time
information are saved to memory.
4. To pause datalogging, press LOGGER. The meter
will temporarily stop recording and “REC” will stop
ashing on the LCD. Press LOGGER again to
resume datalogging.
5. To nish datalogging, pause the datalogger.
Press REC for ≥ 2 seconds. “REC” will disappear
from the LCD to indicate that datalogging has ended.
Note…
To enable/disable the touch-tone feature, see page 12.
Manual Datalogging
1. Set the sampling time to 0 seconds (see page 13).
2. Press REC. “REC” will appear on the LCD.
3. Press LOGGER. “REC” will ash on the LCD. The
tone will sound as the measurement data and time
information are saved to memory. The position
(location) number will appear on the bottom of the
LCD and will also be recorded on the SD card.
4. To change the position number, press ▼.
The position number will ash on the LCD.
5. Press ▲or ▼ to set the position number
(from 1 to 99).
6. To indicate the position location, P x (x= 1 to 99)
will appear on the LCD.
7. Select the position number and press ENTER
to conrm.
8. To nish datalogging, press REC for ≥ 2 seconds.
“REC” will disappear from the LCD to indicate that
datalogging has ended.
Note…
To enable/disable the touch-tone feature, see page 12.

24 25
SD Card Data Structure
• The rst time a SD card is used in this meter, a folder
EMA01 will be generated.
• If the datalogger is being used for the rst time, a new
le EMA01001.XLS will be generated under the route
EMA01\.
• After exiting the datalogger and executing the function
again, the data is saved to the EMA01001.XLS le until
the data reach 30,000 data columns. A new le will then
be generated (i.e. EMA01002.XLS).
• The folder EMA01\ will hold 99 les. A new route will be
generated when exceeding 99 les (i.e. EMA02\).
The le’s route structure:
EMA01\
EMA01001.XLS
EMA01002.XLS
………………….
EMA010099.XLS
EMA02\
EMA02001.XLS
EMA02002.XLS
………………….
EMA020099.XLS
EMAXX\
………………….
BATTERY REPLACEMENT
This meter uses six AA (1.5V, UM3) batteries. When
the low battery indicator appears on the LCD, battery
replacement is needed. After the icon appears on the LCD,
in-spec measurement can still be made for several hours
before becoming inaccurate.
1. Press and hold POWER for 2 seconds to turn the
meter o󰀨.
2. Unscrew the battery cover and remove from the meter.
3. Remove the old batteries and replace with six
new AA batteries, ensuring correct polarity.
4. Replace the battery cover. Tighten the screws
on the battery cover to secure to the meter.
TROUBLESHOOTING
If the meter is not functioning properly during use (i.e.
the system is frozen and the keypad is non-operational),
reset the meter:
1. Use a small tool (such as a disassembled paperclip or
a pin) to press the RESET button (located on the right
side of the meter under the protective black cover).
2. Press POWER to turn the meter on.
Note…
XX: Maximum value is 10.

26 27
SPECIFICATIONS
Circuit Custom one-chip of microprocessor LSI
circuit
Display LCD size: 52 mm x 38 mm
LCD with green backlight (ON/OFF)
Measurement Unit • Type K/J thermometer
• Humidity/Temp. meter
• Anemometer with Temp.
• Light Meter
• Sound level meter (optional adaptor)
Datalogger
Sampling Time
Setting Range
Auto 1 second to 3600 seconds
@ For anemometer mea-
surement, the sampling time
setting value should be ≥ 2
seconds.
@ Sampling time can set to 1
second, but memory data may
loss.
Manual Push the data logger button
once will save data one time.
@ Set the sampling time to 0
second
@ Manual mode, can also
select the 1 to 99 position
(Location) no.
Memory Card SD memory card. 1 GB to 16 GB.
Advanced setting • Set clock time (Year/Month/Date/Hour/
Minute/Second)
• Decimal point of SD card setting
• Auto power OFF management
• Set beep Sound ON/OFF
• Set thermometer type to Type K or
Type J
• Set temperature unit to C or F
• Set sampling time
• SD memory card Format
Temperature
Compensation
Automatic Temp. Compensation for the
Anemometer function and the type K/J
thermometer
Data Hold Freeze the display reading
Memory Recall Maximum & Minimum value
Sampling Time of
Display
Approx. 1 second
Operating
Temperature
0 to 50 C
Operating Humidity Less than 85% RH

28 29
Power Supply • Alkaline or heavy duty DC 1.5 V battery
(UM3, AA) x 6 PCs, or equivalent
• DC 9V adapter input (AC/DC power
adapter is optional)
Power Current Normal operation (w/o SD card save data
and LCD Backlight if OFF): Appox. DC
15 mA.
When SD card save the data and LCD
Backlight is OFF: Appox. DC 36mA.
Weight 1 lb. (0.45 kg)
Anemometer
A. Air Velocity
Meas. Range Resolution Accuracy
m/S 0.4 ~ 25.0 m/S 0.1 m/S ± (2% + 0.2 m/S)
km/h 1.4 ~ 90.0 km/h 0.4 kn/h ± (2% + 0.8 km/h)
mph 0.9 ~ 55.9 mile/h 0.1 mile/h ± (2% + 0.4 mile/h)
knot 0.8 ~ 48.6 knots 0.1 knots ± (2% + 0.2 m/S)
FPM 80 ~ 4930 ft/min 1 ft/min ± (2% + 40 ft/min)
Note: m/S - meters per second
km/h - kilometers per hour
mph - miles per hour
knot - nautical miles per hour (international knot)
FPM - feet per minute
B. Temperature
Measuring Range 32 ~ 122 F (0 ~ 50 C)
Resolution 0.1 C / 0.1 F
Accuracy ± 0.8 C / 1.5 F

30 31
Humidity/Temp. Meter
A. Humidity
Measuring Range 0% to 95% RH
Resolution 0.1 %R.H.
Accuracy ≥ 70% RH: ± (3% reading + 1% RH)
< 70% RH: ± 3% RH
B. Temperature
Measuring Range 32 ~ 122 F (0 ~ 50 C)
Resolution 0.1 C / 0.1 F
Accuracy ± 0.8 C / 1.5 F
Light Meter
Measuring
Range
LUX
Ft-cd
0 to 20,000 LUX
0 to 1, 860 ft-cd
Resolution LUX
Ft-cd
1 LUX
0.1 Ft-cd
Accuracy ± (5% rdg ± 8 dgt)
Type K/J Thermometer
Sensor Type Res Range Accuracy
Type K 0.1 C -50.0 ~ 1300.0 C ± (0.4% + 0.8 C)
-50.1 ~ 100.0 C ± (0.4% + 1 C)
0.1 F -58.0 ~ 2372.0 F ± (0.4% + 1.5 F)
-58.1 ~ 148.0 F ± (0.4% + 1.8 F)
Type J 0.1 C -50.0 ~ 1200.0 C ± (0.4% + 0.8 C)
-50.1 ~ 100.0 C ± (0.4% + 1 C)
0.1 F -58.1 ~ 2192.0 F ± (0.4% + 1.5 F)
-58.1 ~ 148.0 F ± (0.4% + 1.8 C)
• Accuracy value is specied for the meter only.
• Type K probes are optional accessories.
• Above specication tests under the environment RF Field
Strength less than 3 V/M & frequency less than 30 MHz only.

32
WARRANTY
Sper Scientic warrants this product against defects in
materials and workmanship for a period of ve (5) years
from the date of purchase, and agrees to repair or replace
any defective unit without charge. If your model has since
been discontinued, an equivalent Sper Scientic product
will be substituted if available. This warranty does not cover
probes, batteries, battery leakage, or damage resulting
from accident, tampering, misuse, or abuse of the product.
Opening the meter to expose its electronics will break the
waterproof seal and void the warranty. To obtain warranty
service, ship the unit postage prepaid to:
SPER SCIENTIFIC LTD.
8281 E. Evans Rd., Suite #103
Scottsdale, AZ 85260
[phone]
The defective unit must be accompanied by a description
of the problem and your return address. Register your
product online at www.sperwarranty.com within 10 days
of purchase.
Please note: The most current version of the manual can
always be found at www.sperdirect.com
rev. 10/1/2019
