Splitvolt L2 Setup guide

Splitvolt™ L2 Portable Fast EV Charger
QuickStart User Guide
Models: CGB J1-016, CGB J2-016, CGB J3-016, CGB J1-026, CGB J2-026
The Splitvolt Level 2 Portable EV Charger can charge any electric vehicle
(EV) that is equipped with a standard SAE J1772 interface. This includes
the vast majority of EVs sold in North America. The charger can also
charge any Tesla EV using the adapter that Tesla supplies with their
vehicle.
●The CGB J1-016/026 and CGB J2-016/026 models (with 24-amp
capacity) provide the fastest possible safe charging rate from
common household 30-amp dryer circuits.
●The CGB J3-016 model (with 40-amp capacity) provides the
fastest possible safe charging rate from a standard 50-amp
circuit.
IMPORTANT: Please read this manual and the rear sticker on charger
before use for important safety information.

Contact information
Splitvolt, Inc. [email protected]
3250 Victor Street, Unit B www.splitvolt.com
Santa Clara, CA 95054
Splitvolt L2 Portable Fast EV Charger
QuickStart User Guide
Models covered in this guide
Model
SKU
UPC
Wall Socket
Connection
(Male)
Benefits
Splitvolt
CGB J1-016
CGB-J1-016-
24A
850019012507
NEMA 10-30
Zero cost
installation: Uses the
traditional 240v
dryer plug found in
most homes
Splitvolt
CGB J1-026
CGB-J1-026-
24A
850019012057
NEMA 10-30
Splitvolt
CGB J2-016
CGB-J2-016-
24A
850019012521
NEMA 14-30
Splitvolt
CGB J2-026
CGB-J2-026-
24A
850019012040
NEMA 14-30
Splitvolt
CGB J3-016
CGB-J3-016-
40A
850019012514
NEMA 14-50
Maximum possible
charging rate on a
50-amp circuit
If you’re using a standard dryer
plug, choose the CGB J1 or J2
model that corresponds to your
plug type (NEMA 10-30 or 14-30). If
your electrician has installed
50-amp service, choose the CBG J3
model (NEMA 14-50).
Features and capabilities
●Super fast: Fastest possible safe charging on 30- or 50-amp circuits
●Easy to use: just plug it into your NEMA 10-30, 14-30, or 14-50 wall
socket or your Splitvolt Splitter Switch and connect it to your EV
●See the charging state at a glance via 4 LEDs (see table below)
●Charge any standard EV: compatible with all common electric
vehicles (BEVs and PHIVs) available in North America
Splitvolt, Inc. 2

●Lightweight: highly portable at only 6.4lb (2.9 kg), so you can use it
at home or pop it in the trunk for a road trip
●Convenient: comes with a carry case, compact and simple to store
●Safety certifications: In process
●Warranty: full one-year warranty included for peace of mind
Warnings
●This device contains no user-serviceable parts—do not open
●Do not submerge this device in water
●Do not use this product if the cable or any other part is damaged
●Intended for Electric Vehicle charging use only
●For use with standard U.S. household 30-amp or 50-amp circuits
●Rated for NEC maximum safe continuous charging of 24 or 40 amps
Product Diagram
How to start charging
1. Take out the charger and fully insert the 240-volt plug into the
wall socket outlet
2. Remove the cover and a) for non-Tesla vehicles, plug the J1772
vehicle connector into your vehicle inlet; or b) for Tesla vehicles
attach the standard J1772 adapter and insert into vehicle inlet
3. The device will start charging automatically while the
READY/CHARGE, POWER indicators are all green
How to stop charging
1. Press the button and disconnect the J1772 vehicle connector
from the vehicle inlet
2. Close protective cap of vehicle inlet
3. If necessary, disconnect the plug from the socket outlet
Splitvolt, Inc. 3

LED indications
The charger is equipped with an LED panel that indicates the various
states of the product, including fault and charging status.
No
.
Condition
Power
Charge
Fault 1
Fault 2
1
Initialization
Flash
once
Flash
once
Flash
once
Flash once
2
EV Connection Ready
On
Off
Off
Off
3
Charging
On
Flashing
Off
Off
4
Charging Completed
On
On
Off
Off
5
Power Self-Test Failure
On
Off
On
On
6
Communication
Failure
On
Off
Off
On
7
Overvoltage or
Undervoltage
On
Off
On
Off
8
Grounding Failure
On
Off
Off
Flashing
9
Overcurrent
On
Off
Flashing
Off
10
Power Leakage
On
Off
Flashing
Flashing
11
Overheated
On
On
On
On
Troubleshooting
If you are having trouble, note the LEDs on your unit and consult the
table above to determine the status of your system. Then follow the
steps in the table below to resolve the problem. Check our website
(www.splitvolt.com) and contact us if you are still unable to resolve.
No.
Condition
Resolution
1
Initialization
Normal initialization upon plug-in
2
EV Connection Ready
Plug handle into EV to start charging
3
Charging
Charging normally
4
Charging Completed
Completed charging
5
Power Self-Test Failure
Unplug from wall power and EV, then plug both
back in
6
Communication
Failure
Unplug from wall power and EV, then plug both
back in
7
Overvoltage or
Undervoltage
Unplug from wall power and EV, then plug both
back in. If fault returns, test power source,
contact electrician.
Splitvolt, Inc. 4

8
Grounding Failure
Unplug from wall power and EV, then plug both
back in. If fault returns, test power source,
contact electrician.
9
Overcurrent
Unplug from wall power and EV, then plug both
back in. If fault returns, test power source,
contact electrician.
10
Power Leakage /
reduction
Unplug from wall power and EV, then plug both
back in. If fault returns, test power source, try
shorter extension, contact electrician.
11
Overheated
Unplug from wall power and EV, contact an
electrician
Need more help?
Please visit www.splitvolt.com,email [e-mail], or call (650)
209-0091 and leave a message with your contact information, product
model number and the issue you are experiencing.
Specifications
Description
CGB J1-016
CGB J2-016
CGB J3-016
Maximum load
240V ~60Hz 24A AC
240V ~60Hz 40A AC
Maximum current
24A
40A
Rated power
5.8Kw
9.6Kw
Input voltage AC
88-288V 50/60Hz
Dust & water rating
IP55
Warranty
1 year
Safety certifications
In process
LEDs
Power, Charge, Fault 1, Fault 2
Unit weight
7.7 lbs (3.5 kg)
9.2 lbs (4.2 kg)
Output detection
protections
Short circuit
Leakage current
Overvoltage and
undervoltage
Over and under frequency
Over current
Over and under temperature
Ground
Lightning
Operating temperature
–25°C ~ +55°C
Storage temperature
–40°C ~ +80°C
Operating humidity
20%–85%
Splitvolt, Inc. 5

Cable length
16’5” (5 meters)
Package dimensions
17.7 x 4.7 x 13.4 in
(45x12x34 cm)
17.7 x 5.1 x 15.7 in
(45x13x40 cm)
Package weight
6.4 lb (2.9 kg)
Interface standards
SAE J1772
NEMA 10-30
SAE J1772
NEMA 14-30
SAE J1772
NEMA 14-50
Description
CGB J1-026
CGB J2-026
Maximum load
240V ~60Hz 24A AC
Maximum current
24A
Rated power
5.8Kw
Input voltage AC
88-288V 50/60Hz
Dust & water rating
IP55
Warranty
1 year
Safety certifications
In process
LEDs
Power, Charge, Fault 1, Fault 2
Unit weight
7.7 lbs (3.5 kg)
Output detection
protections
Short circuit
Leakage current
Overvoltage and undervoltage
Over and under frequency
Operating temperature
–25°C ~ +55°C
Storage temperature
–40°C ~ +80°C
Operating humidity
20%–85%
Cable length
26’ (8 meters)
Package dimensions
17.7 x 4.7 x 13.4 in
(45x12x34 cm)
Package weight
6.4 lb (2.9 kg)
Splitvolt, Inc. 6

Interface standards
SAE J1772
NEMA 10-30
SAE J1772
NEMA 14-30
Disclaimers
This product should not be submerged in water and must be treated in a manner
consistent with its IP55 enclosure rating.
The CGB J1-016/026 and CGB J2-016/026 models of this product are designed to
operate at a maximum continuous charging rate of 24 amps on a standard
household 30-amp circuit, according to the National Electrical Code (NEC).
Exceeding this rate can trip your household breaker, or lead to damage or risk of fire.
The CGB J3-016 model is designed to operate at a maximum continuous charging
rate of 40 amps on a standard household 50-amp circuit, according to the National
Electrical Code (NEC). Exceeding this rate can trip your household breaker, or lead to
damage or risk of fire.
These products are for use with standard home wiring that is built and maintained to
the latest National Electrical Code (NEC) safety standards. If you suspect that your
home wiring does not meet code, or is worn-out or damaged in some fashion,
contact an electrician for a safety inspection prior to using this product.
1-year limited warranty
Splitvolt, Inc warrants that this product shall be free from defects in material,
workmanship and assembly, under normal use, in accordance with the specifications
and warnings, for a period of one year from the date of purchase. This warranty
does not cover damages as a result of an accident; resulting from the use or misuse
of parts not manufactured or sold by Splitvolt, Inc; or resulting from modification of
the Splitvolt Charger.
These warranties extend only to the original purchaser of the product and are not
transferable. To exercise your rights under this warranty, you must provide proof of
purchase in the form of an original sales receipt that shows the product name and
the date of purchase. These warranties apply only to natural purchasers of the
Splitvolt Charger for personal, family, or household use, not to commercial,
institutional, or industrial purchasers. These warranties are valid only in the United
States. In no event shall Splitvolt, Inc. be liable for any direct, indirect, incidental,
special, consequential, or multiple damages arising out of the use of the Splitvolt
Charger devices.
