Sportline Syncdistance User manual

MODE/RESET BUTTON
• OperatingMode:Scrollsthroughdisplaymodes.
• Press&Hold:ResetsActivityTrackerdata.
• ProgrammingMode:Decreasescurrentvalue.
SET BUTTON
• OperatingMode:Press&HoldtoentertheProgrammingSequence.
• ProgrammingMode:Acceptstheinformationbeingadjustedand
 advancestothenextsetting.
+ BUTTON
• ProgrammingMode:Increasescurrentvalue
2-REMOVINGBATTERYINSULATORTAB 3-BUTTONSANDTHEIRFUNCTIONS
1-GETTINGSTARTED
Back cover
Congratulations on your purchase of a SYNC™ Activity Tracker. The
SYNC™Activity Tracker features highly advanced sensor technologies
thataccuratelymeasureyourbodymovementswhenwornfrommultiple
locationsonthebodyandinmultipleorientations.Inaddition,thebuilt-
in audio jack technology allows youto easily upload your data to any
compatiblesmartphoneortabletthroughtheMapMyWalk™smartphone
application. Please visit www.syncactive.com/compatibilityfor a
completelistofcompatibledevices.
Downloading the MapMyWalk™Application:
InadditiontotheActivityTrackeryouhavepurchased,youwillalsoneed
todownloadtheMapMyWalk™applicationforFREEontoyourcompatible
smartphoneortabletandcreateauseraccount.
Foracompletetutorialregardingdownloading,installing,andusingthe
MapMyWalk™application,pleasevisit:www.syncactive.com/tutorial
CUSTOMER SUPPORT
If you have questions, comments or need assistance with your device
pleasefeelfreetocontactCustomerSupportbycalling 1-866-694-4575.
To activate your Activity Tracker after purchase, you must remove the
batteryinsulatortabinsidethebatterycompartment.
1.LocatethetabonoftheActivityTracker.
2.FirmlygraspthetabandpullawayfromtheActivityTrackeruntilcom-
pletelyremovedfromtheunit.
3.Theunitwillnowbeactivatedandthescreenwillbeon.
Fold 1
Fold 2Fold 3 Fold 3
Fold 4
4-PROGRAMMINGTHEACTIVITYTRACKER 5-OPERATINGTHEACTIVITYTRACKER
The Activity Tracker automatically begins capturing data once
movementoccurs.TherearenoStartorStopbuttonstopush.
ScrollthroughdisplaymodesbyPRESSINGtheMODE/RESET
buttononthefrontoftheunit.
TO CLEAR ALL CURRENT ACTIVITY TRACKER DATA:
1.PRESS & HOLDtheMODE/RESETbuttononthefrontoftheunit.
2. Continueholdingasthedisplayreads“RESET”.
3.WhenActivityTrackerdatareadszeros(O),RELEASE the MODE/
RESETbutton.Theunitisnowreadyforanewworkout.
NOTE: Yourpersonalprolesettingswillbesaved.
WWW.SYNCACTIVE.COM
SPORTLINE®ANDSYNC™ARETRADEMARKSOFSPORTLINE,
ADIVISIONOFEBSPORTGROUP,HAZLETON,PA18202
MAPMYWALK®ISAREGISTEREDTRADEMARKOFMAPMYFITNESS,INC.
DISTRIBUTEDINTHEUKBY
EBBRANDS(UK),WORCESTER,WR49FA
ALLRIGHTSRESERVED.©2013
WV3728IS01SYN
1. Enter the Programming Sequence by PRESSING & HOLDING the SET
buttononthebackoftheunitforapproximately3seconds.
2. AdjustthevalueofeachofthesettingsshownbyPRESSINGthe+button
toincreaseorMODEbuttontodecrease.PressSETtoconrm.
3.When promptedforstridelength,this activitytrackerhasan automatic
stridelengthcalculatorthatsetsyourlengthbasedonyourheight.PRESS
theSET buttontoacceptthisvalueoryoucanadjustyourStrideLength
(see“DeterminingStrideLength”onthebackpage)byPRESSING the+
orMODEbuttons.
4.SAVED willbedisplayedonthenalpressofthe SET button.Theunitis
nowprogrammedandreadyforuse!
HOLD SET FOR
3 SECONDS
SAVE
12/24 HOUR FORMAT
STRIDE LENGTH
HOUR
HEIGHT
MINUTE
PREFERRED UNIT OF
MEASURE
MONTH
WEIGHT
DAY
YEAR
PRESS +OR MODE TO ADJUST VALUE, PRESS SET TO ADVANCE TO CONFIRM
USERGUIDE
/INSTRUCTION MANUAL
ALL DAY ACTIVITY TRACKER
SYNC
DISTANCE CALORIES
INCREASEVALUEOF
CURRENTSETTING
HOLDTOENTERSETTINGS
PRESSTOCONFIRM
CURRENTSETTING&
ADVANCETOTHENEXTSCREEN
DECREASEVALUEOF
CURRENTSETTING
PRESS MODE BUTTON TO
CHANGE SCREENS
MODE/RESET SET
+

9-CARE&MAINTENANCE
WARNING: Beforeyou start any exerciseprogramor performany vigorousphysical
activity, we strongly suggest you visit your doctor for a complete physical and
discussyourplans.
CAUTION: TheActivityTrackerisnotwaterresistant.
AvoidexposingtheActivityTrackertoextremeconditions.
AvoidroughusesorsevereimpactstotheActivityTracker.
NevergettheActivityTrackerwet.Thisunitisnotwaterresistant.
NeverattempttoserviceyourActivityTrackerortakeitapart.
Do not expose the unit to extreme heat, shocks, magnetic elds, electrical noise,
strongvibrationorlong-termexposuretodirectsunlight.
DonotdroporstepontheActivityTracker.
CleantheActivityTrackeroccasionallywithasoft,drycloth.
Storetheunitin adryplacewhenyouarenotusingit.
12-BATTERYSAFETYINFORMATION
CAUTION – BATTERY SAFETY INFORMATION
• Non-rechargeablebatteriesarenottoberecharged
• Rechargeablebatteriesmustberemovedbeforerecharging
• Rechargeablebatteriesshouldonlyberechargedunderadultsupervision
• Donotmixalkaline,standard(carbon-zinc),orrechargeable(nickel-cadmium)
batteries
• Exhaustedbatteriesaretoberemoved
• Donotmixoldandnewbatteries
• Donotdisposeofbatteriesinre;batteriesmayexplodeorleak
• Donotdisposeofproductinre;batteriesmayexplodeorleak
• If this product will not be used for an extended period of time, remove the
batteriesfromtheproduct
• Thesupplyterminalsarenottobeshort-circuited
• Batteriesaretobeinsertedwithcorrectpolarity
• Clean the battery contacts and also those of the product prior to battery
installation
• Asalways,disposeofbatteriesinaneco-friendlymanner
Thepurposeofthecrossed-outwheeliebinsymbolisto remindusthatmostelectricalproducts,
andbatteries,containtraceelements(includingMercury–Hg,Cadmium–CdandLead–Pb)which
couldbeharmful toour environmentandthereforeourhealth.We mustall becarefulto dispose
of them responsiblyin a specically designated way – either using a collection scheme or into
thecorrectlylabeledcivicamenity(NOTintogeneralwaste)– thiswillhelp yourlocalauthorityto
arrangetorecycleordisposeofthemintheappropriatemanner.
13-WARRANTY
GUARANTEE CERTIFICATE – FOR PURCHASES MADE IN THE U.S.
Ifatanytimewithinone(1)yearfromthepurchasedateofthisproduct,itfailsto
performproperlybecauseofdefectsinmaterialormanufacturing,returnitprepaidto:
EB SPORT GROUP, 585 OAK RIDGE ROAD, HAZLETON, PA 18202
CompletethisGuaranteeCertificateandencloseit(oracopyofit)withtheproduct.
(PLEASEPRINTCLEARLY)
NAME PHONE
ADDRESS
STORE PURCHASED FROM
DATE OF PURCHASE PURCHASE PRICE
STATE ZIP
PROBLEM WITH PRODUCT
REPLACEMENT
Thisproducthasbeencarefully designed,manufacturedandpackaged.Ifanypartsaremissingordamaged,please
contactusattheaddressaboveandwewillreplacetheunitatnocharge.(Guaranteedoesnotcovercrystalorbattery.)
©2013 Distributed by Sportline®, Hazleton, PA 18202
FOR PURCHASES MADE IN THE UK:
Shouldyouexperienceproblemswiththisitem,pleasereturnittothepointofpurchase.
Thiswillnotaffectyourstatutoryrights.Alternativelyreturnittotheaddressshown
belowforarepair/replacement.
EB Brands UK, Berkeley Business Park, Wainwright Road,
Worcester WR4 9FA
www.sportline.com
Distributed in the UK by EB Brands UK, Worcester WR4 9FA
8-HOWTOWEARTHEACTIVITYTRACKER
ThisActivityTrackerwillbemostaccuratewhenwornclosetothebody,ideallyonyour
beltorwaistlineorinsertingtheunitintoatight,securepocket.
10-FCCCOMPLIANCE
The device complies with Part 15 of the FCC Rules. Operation is subject to the
followingtwoconditions:(1) this devicemaynotcauseharmful interference,and (2)
this device must accept any interference received, including interference that may
causeundesiredoperation.
1. Changes or modications not expressly approved by the party responsible for
compliancecouldvoidtheuser’sauthoritytooperatetheproduct.
2. NOTE:ThisproducthasbeentestedandfoundtocomplywiththelimitsforaClass
Bdigital device,pursuanttoPart15 of theFCCRules.These limits aredesigned
to provide reasonable protection against harmful interference in a residential
installation.Thisproductgenerates,usesandcan radiateradiofrequencyenergy
and, if not installed and used in accordance with the instructions, may cause
harmfulinterferencetoradiocommunications.However,thereisnoguaranteethat
interferencewill notoccur in aparticular installation.If the productdoes cause
harmful interference to radio or television reception, which can be determined
byturning the equipment offandon,theuserisencouragedto try to correctthe
interferencebyoneormoreofthefollowingmeasures:
•Reorientorrelocatethereceivingantenna.
•Increasetheseparationbetweentheproductandreceiver.
•Connectthe productintoan outletonacircuitdifferentfromthat towhichthe
receiverisconnected.
•Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
7-MEASURINGSTRIDELENGTH
HOW TO MEASURE YOUR STRIDE LENGTH
TheActivityTrackerautomaticallysetsyourstridelengthbaseduponyourheightinput
duringtheSetUpsequence.You maychoosetoadjustthisstridelength.Toobtain
yourpersonalizedmeasurement,seebelow.
1. Tondoutwhatyourstrideis,walkorrun10stepsandthenmeasurethedistance
withatapemeasurefromtherststep’stoetothe10thstep’stoe.
2. Divideyourtotaldistanceby10togetyouraveragestridelength.
3. For a quick estimate,walk 3steps, measurethedistance, and divide by 3.The
morestepsyoutake,themoreaccurateandrealisticyourstridewillbe.Anaverage
walkingstrideforafemaleis2feet(24in.),amaleis2.5feet(30in.).
START WALKING/RUNNING
BASE LINE DIVIDE TOTAL
DISTANCE BY 10
1357 9
24 6 810
START WALKING/
RUNNING
BASE LINE DIVIDE TOTAL
DISTANCE BY 3
13 2
CLiCK!!
6-UPLOADING
UPLOADING ACTIVITY TRACKER DATA TO MAP MY FITNESS
1.Openthe MapMyWalk™applicationonyoursmartphoneortabletandnavigateto
theSYNCsection.
2. Adjust your smartphone/tablet volumeto its maximum level to ensure optimum
uploadingconditions.
3.FlipouttheaudiojackfromtheActivityTrackerandinsertitfullyintotheaudioport
ofyoursmartphoneortabletuntilitclicks.
4. Pressthe MODE buttononyourActivity Trackeruntilthe SYNCscreenisshown.
Aashinglinewillbeshownonthescreentoindicatethatitisreadytouploaddata.
5. Press the SYNC button on the MapMyWalk™ application and your data will be
uploaded. If the Activity Tracker does not successfully upload after a short period,
it will time out, and default back to the STEPS screen. At this point, you will need
tonavigate back to theSYNCscreenontheActivityTrackerandtryuploadingagain
throughtheapplication.
(See www.syncactive.com/tutorial forafulltutorial)
NOTES:
•TheActivityTrackermustbeontheSYNCscreenfor
uploadingtooccur.
•Volumeofsmartphone/tabletshouldbesettohigh
•Itisrecommendedthatyouuploadyourdataoncea
weektoensureactivityisrecorded.
•Whentheunit’smemoryis80%full,aMEMORYLOW
warningwill asheveryminuteuntilthedataisup-
loaded
• When the unit’s memory is 100% full, a MEMORY
FULL warning will ash every 30 seconds until the
dataisuploaded.Noadditionaldatacanbesavedat
thistime.
11-REPLACINGTHEBATTERY
ThisunitusesoneCR20323Vlithiumbattery.
Batteryreplacementwillberequiredfromtimetotime,andshouldoccurwhen:
1. Thedisplayfadesinpartorcompletely.
2. Theunitisnotfunctioningproperly.
TO REPLACE THE BATTERY:
1. Removethe spring-loadedbeltclipon thebackoftheunit toexposethebattery
compartmentdoor. Unscrewthe battery compartment door withasmallPhillips
screwdriver.
2. Removetheexhaustedbatteryfromtheunit,andinsertanewbattery(besureto
placethepositive(+)sideofthebatteryfacingup).
3. Replacethebatterycompartmentcoverandfastenwiththescrew.
4. Replacethespringclipbackintoposition.
1 2
3 4
WV3728IS01SYN
16” × 8”
4.4.13
arlene
