Sports Art Industrial E845 User manual

E845 15” TFT LCD
Elliptical Trainer
Owner’s Manual
Sports Art Industrial Co., Ltd. ISO 9001/14001 Certied 2014.11
No. 11, Gong Huan Rd. Tainan City, Taiwan R.O.C. www.gosportsart.com

E845-15 OWNER’S MANUAL CONTENTS
1. INTRODUCTION .............................................................................. 2
2. SAFETY PRECAUTIONS ................................................................ 3
3. LIST OF PARTS ............................................................................... 7
4. ASSEMBLE THE PRODUCT .......................................................... 9
STEP 1 Install the Frame .................................................................... 9
STEP 2 Install the Glide Rail ............................................................... 14
STEP 3 Install the Pedestal Covers .................................................... 15
STEP 4 Install the Foot Pedals .......................................................... 16
STEP 5 Move the Product into Place ................................................. 18
STEP 6 Level the Product ................................................................... 19
STEP 7 Install the Power Cord ........................................................... 20
STEP 8 TV Terminal and Netwotk ...................................................... 21
STEP 9 Install the TV Cable ............................................................... 22
STEP 10 Beware of Moving Parts ...................................................... 23
5. UNDERSTAND THE E845-15 DISPLAY .......................................... 24
DISPLAY Overview .............................................................................. 24
DISPLAY Home Page Display Sequence ............................................ 24
DISPLAY Keys ..................................................................................... 25
DISPLAY Windows .............................................................................. 25
Home Page ........................................................................................ 26
6. OPERATE THE PRODUCT ............................................................. 27
OPERATION Quick Start ..................................................................... 27
OPERATION Program Selection.......................................................... 29
OPERATION Media Selection ............................................................. 35
OPERATION User Prole .................................................................... 36
OPERATION Default Setting ............................................................... 36
OPERATION Switching Program ......................................................... 37
OPERATION Idle Mode ....................................................................... 37
OPERATION Energy Smart Function .................................................. 37
7. ABOUT HEART RATE DETECTION ................................................ 38
HEART RATE Telemetry ...................................................................... 38
HEART RATE Contact ......................................................................... 38
8. GUIDELINES FOR EXERCISE ....................................................... 39
9. ACCESSORIES ............................................................................... 40
ACCESSORIES Entertainment Cap .................................................... 41
10. MAINTENANCE ............................................................................. 42
MAINTENANCE Messages .................................................................. 42
MAINTENANCE How to Replace a Fuse ............................................ 43
MAINTENANCE Lubrication Procedure............................................... 44
MAINTENANCE Cleaning the Glide Rails ........................................... 46
MAINTENANCE Schedule ................................................................... 47
MAINTENANCE Task List (Elliptical Trainers) ..................................... 48
MAINTENANCE One-Year Maintenance Log ...................................... 49
MAINTENANCE Electronics Block Diagram ........................................ 50

2
1. INTRODUCTION
Congratulations on your purchase of one of the nest exercise products on the
market today, the SportsArt E845 15” touch screen Elliptical trainer. Constructed
of high quality materials and designed for years of reliable usage, this product was
made to become an integral part of your commercial tness venue.
Before this product is assembled or operated, we recommend that you familiarize
yourself with this manual. Understanding the correct assembly and operation of
this product will help ensure that exercisers obtain their tness goals safely and
successfully.
LR

3
2. SAFETY PRECAUTIONS
Your SportsArt elliptical trainer was designed and built for optimum safety. However
certain precautions apply whenever you use your elliptical trainer.
Please read the entire manual before assembly and operation. Also, please note the
following safety precautions:
●Please read the instructions carefully and install the elliptical trainer as instructed.
●Assemble and operate the elliptical trainer on a solid, level surface. DO NOT use
outdoors or near water.
●Never allow children on or near the elliptical trainer.
●Check the elliptical trainer before every use. Make sure all parts are assembled,
and all fasteners are tightened. DO NOT use the elliptical trainer if the unit is
disassembled in any way.
●Keep your hands away from moving parts.
●Wear proper workout clothing; DO NOT wear loose clothing. DO NOT wear
shoes with leather soles or high heels. Tie all long hair back. DO NOT go barefoot
on this product.
●Be careful when mounting and dismounting the unit.
●The elliptical trainer may or may not stop immediately if an object becomes caught
or impedes normal motion.
●DO NOT use any accessories that are not specically recommended by the
manufacturer. Such parts might cause injuries or cause the unit to fail.
●Close supervision is necessary when this elliptical trainer is used by, on, or near
children, invalids, or disabled persons.
●Use this elliptical trainer only for its intended use as described in this manual.
●Never operate this elliptical trainer if it has been damaged in any way. If it is not
working properly, or has been dropped or damaged, contact your dealer.
●Keep all air ventilation areas free of blockage.
●Never drop or insert any object into any opening.
●DO NOT operate where aerosol (spray) products are being used or where oxygen
is being administered.
●The general user weight limit for this elliptical trainer is 205kg (450lb). Note that
at resistance level 40 this product meets standards for users of up to 150kg (330lb).
●This elliptical trainer is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or instruction
concerning use of this bike by a person responsible for their safety.
●Children should be supervised to ensure that they do not play with the
elliptical trainer.

4
2. SAFETY PRECAUTIONS (CONTINUED)
Caution
If you feel any pain or abnormal sensation, STOP YOUR WORKOUT and
consult your physician immediately. Work within your recommended exer-
cise level. DO NOT work to exhaustion.
Before beginning any exercise program, you should consult with your doc-
tor. It is recommended that you undergo a complete physical examination.
Note: This equipment has been tested and found to comply with the limits
for a digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particu-
lar installation. If the user desires to correct such interference, it is at the
user’s own expense.
Warning
Heart rate monitoring systems may be inaccurate. Over exercise may
result in serious injury or death. If you feel faint, stop exercise immediately
and consult a medical physician.
