Sportsman GEN2000DF User manual

Read and understand instruction manual
before using generator.
3Add Gasoline
Add Oil
Engine
Switch
Recoil
Start
GENERATOR SPECIFICATIONS:
• 3.5 HP Engine, 4 Stroke OHV
• Recoil Start
• 1.2 Gallon Fuel Tank
• Low Oil Shut Off
• UL Listed Electrical Components
• Engine Shut Off Switch
• Circuit Breaker & Power Outlets
• 1-12V DC Outlet
• 2 -120V AC Outlets
• Complies with EPA emissions
• Runs 9 hours @ 50% load (GAS)
• Runs 12 hours @ 50% Load on 20 lbs of
LPG Fuel
• Decibel Rating < 68 db @ 0% Load
• Propane fuel hose / regulator included
• Warranty: 2 YEAR Limited Emissions
• Warranty: 1 YEAR Limited
* SURGE WATTS / RUNNING WATTS
MAY BE REDUCED BY 10% WHEN USING
PROPANE FUEL VS USING GASOLINE.
GEN2000DF
1
2
3
Remove Generator From Package
Add Oil
Add Fuel
2,000 Surge / 1,400 Running Watts
POWERED BY UNLEADED
GASOLINE OR PROPANE FUEL
Oil Type: SAE10W-30 Oil (Must add BEFORE first use)
Oil Capacity: 13.5 fluid oz
Because this generator includes Low Oil Shut Off, the
generator will not start with low oil. Start out with 13.5 oz,
then fill until almost overflowing.)
If using Gasoline, add Unleaded gasoline only
octane rating of 87 or higher. Maximum Capacity:
1.2 Gallon gasoline fuel tank
If using Propane, connect Regulator Hose to
Propane Tank and the LP Gas Inlet on Generator.
Then turn the Tank valve to the “on” position.
www.sportsmanseriesbrand.com/generators
4Start The Generator
Use the generator OUTDOORS in a WELL VENTILATED AREA.
DO NOT CONNECT electrical devices until AFTER the generator
is started.
Turn Engine Switch to ON
A. If using GASOLINE, Turn FUEL PETCOCK to ON (Figure A)
B. If using PROPANE, connect Turn Tank Valve to ON (Figure B)
Adjust the CHOKE to “Closed/Choke” position (Figure C)
Start the generator manually with the Recoil (Pull) Start.
Once the engine has started, GRADUALLY move the choke lever
to the “RUN/OPEN” position until the engine levels off. Then let
the engine run approximately 5 minutes BEFORE adding
appliances or tools.
You can now connect electrical devices.
Visit our website for Troubleshooting & Frequently Asked Questions
Need Help? Do Not Return This Generator To The Store! Call Us First!
Monday-Friday 8:00-4:30 Central Time
TOLL-FREE NATIONWIDE HELP LINE! 866-460-9436
O
On
Run/Open
Closed/Choke
4
2
4
SPORTSMANSPORTSMAN
OIL IS NOT INCLUDED WITH THIS
GENERATOR. IT IS SOLD SEPARATELY.
Step-By-Step Quick Start
Guide To Using Your Generator
Fuel Petcock (Figure A)
LP Gas Inlet
(Figure B)
Choke (Figure C)

GEN2000DF
WARNING
Always follow Warning labels placed on the
generator, and read and follow all Warning
labels included inside the Product Manual.
WARNING: NEVER use a generator inside
a home or a garage, EVEN IF the doors
and windows are open.
ONLY USE OUTSIDE and far way from
windows, doors and vents leading into an
enclosed area.
Using a generator indoors can kill you in
minutes. The generator produces an
exhaust that contains carbon monoxide.
This is a poison you cannot see or smell.
Do not attach a chain or rope to secure the
generator to a post as this can be difficult to
remove in the event of an emergency.
2,000 Surge / 1,400 Running Watts
IF THERE IS ANY QUESTION ABOUT A
CONDITION BEING SAFE OR UNSAFE,
DO NOT OPERATE THIS PRODUCT!
DO NOT CONNECT electrical devices until AFTER the generator is started.
Outlets available on this
generator, from left to right:
One 12V DC outlet
Two 120V AC outlets
NOTES
www.sportsmanseriesbrand.com/generators
Visit our website for Troubleshooting & Frequently Asked Questions
Need Help? Do Not Return This Generator To The Store! Call Us First!
Monday-Friday 8:00-4:30 Central Time
TOLL-FREE NATIONWIDE HELP LINE! 866-460-9436
SPORTSMANSPORTSMAN
12V DC
Engine
Switch
DC Reset
120V AC AC Reset
POWERED BY UNLEADED
GASOLINE OR PROPANE FUEL
