Spot-on NovaGear NG-54 User manual

NG-54
12V RECIPROCATING SAW
INSTRUCTION MANUAL
PRODUCT CODE: 40044
CAUTION: Read the operating
instructions to reduce the risk of inquiry
Battery and charger sold separately

2
ELECTRICAL SAFETY
This manual contains important
safety and operating instructions
for your battery charger (sold
separately).
› Before using the charger, read all
instructions and cautionary markings
on charger, battery pack and product
using the battery pack.
› This charger is not intended
for any uses other than charging
rechargeable batteries. Any other
use may result in risk of fire, electric
shock or electrocution.
› Do not place any object on top of the
charger or place the charger on a soft
surface that may result in excessive
internal heat. Place the charger in a
position away from any heat source.
› To reduce risk of damage to the
electric plug and cord, pull by the
plug rather than the cord when
disconnecting the charger.
› Make sure cord is located so that it
will not be stepped on, tripped over, or
otherwise subjected to damage or
stress.
› An extension cord should not be used
unless absolutely necessary. Use of an
improper extension cord could result
in the risk of fire, electric shock or
electrocution.
› Do not operate charger if it has
received a sharp blow, been dropped
or otherwise damaged in any way. Have
it checked by an electrician or power
tool repairer.
› Do not disassemble charger. Take it to
an electrician or power tool repairer
when service or repair is required.
Incorrect reassembling may result in
a risk of electric shock, electrocution
or fire.
› To reduce risk of electric shock,
unplug charger from the outlet before
attempting any cleaning. Removing the
battery pack will not reduce this risk.
› Never attempt to connect 2 chargers
together.
SAFETY
CAUTION: Read the operating
instructions to reduce the risk
of inquiry.
DOUBLE INSULATED
This tool is double insulated
in accordance with AS/NZS
60335-1; therefore no earth wire
is required.
DANGER! If the battery pack case is
cracked or damaged, do not insert
into charger. There is a danger of
electric shock or electrocution.
Warning: Do not allow any liquid to
get inside charger. Electric shock
may result. To facilitate cooling of
the battery pack after use, avoid
placing the charger or battery pack
in a warm environment such as in
a metal shed, or an uninsulated
trailer.
!
!

3
GENERAL SAFETY
› DO NOT store or use the tool and
battery pack in locations where the
temperature may reach or exceed
40ºC (such as outside sheds or metal
buildings in summer).
› The charger is designed to operate
on standard household electrical
power (240 volts). Do not attempt
to use it on any other voltage! The
battery pack is not fully charged out
of the carton. First read the safety
instructions and then follow the
charging notes and procedures.
› The longest life and best
performance can be obtained if the
battery pack is charged when the air
temperature is between 18 - 24ºC.
Do not charge the battery pack in
an air temperature below 10ºC or
above 40ºC. This is important and will
prevent damage to the battery pack.
› Do not incinerate the battery pack
even if it is seriously damaged or is
completely worn out. The battery can
explode in a fire.
› Never attempt to open the battery
pack for any reason. If the plastic
housing of the battery pack breaks or
cracks, immediately discontinue use
and do not recharge.
Save these instructions and other
documents supplied with this tool for
future reference.
1) WORK AREA SAFETY
a) Keep work area clean and well
lit. Cluttered or dark areas invite
accidents.
b) Do not operate power tools in
explosive atmospheres, such as in
the presence of flammable liquids,
gases or dust. Power tools create
sparks which may ignite the dust or
fumes.
c) Keep children and bystanders
away while operating a power tool.
Distractions can cause you to lose
control.
2) ELECTRICAL SAFETY
a) Power tool plugs must match
the outlet. Never modify the plug
in any way. Do not use any adapter
plugs with earthed (grounded)
power tools. Unmodified plugs and
matching outlets will reduce risk of
electric shock.
b) Avoid body contact with earthed
or grounded surfaces, such as
pipes, radiators ,ranges and
refrigerators. There is an increased
risk of electric shock if your body is
earthed or grounded.
c) Do not expose power tools to rain
or wet conditions. Water entering a
power tool will increase the risk of
Warning: Read all safety warnings
and all instructions. Failure to
follow the warnings and
instructions may result in electric
shock, fire and/or serious injury.
!

4
electric shock.
d) Do not abuse the cord. Never
use the cord for carrying, pulling
or unplugging the power tool. Keep
cord away from heat, oil, sharp
edges or moving parts. Damaged or
entangled cords increase the risk of
electric shock.
e) When operating a power tool
outdoors, use an extension cord
suitable for outdoor use. Use of a
cord suitable for outdoor use reduces
the risk of electric shock.
f) If operating a power tool in a
damp location is unavoidable, use
a residual current device (RCD)
protected supply. Use of an RCD
reduces the risk of electric shock.
3) PERSONAL SAFETY
a) Stay alert, watch what you are
doing and use common sense when
operating a power tool. Do not use
a power tool while you are tired
or under the influence of drugs,
alcohol or medication. A moment
of inattention while operating power
tools may result in serious personal
injury.
b) Use personal protective
equipment. Always wear eye
protection. Protective equipment
such as dust mask, non-skid safety
shoes, hard hat, or hearing protection
used for appropriate conditions will
reduce personal injuries.
Prevent unintentional starting.
Ensure the switch is in the off-
position before connecting to power
source and/or battery pack, picking
up or carrying the tool. Carrying
power tools with your finger on the
switch or energising power tools that
have the switch on invites accidents.
d) Remove any adjusting key or
wrench before turning the power
tool on. A wrench or a key left
attached to a rotating part of the
power tool may result in personal
injury.
e) Do not overreach. Keep proper
footing and balance at all times. This
enables better control of the power
tool in unexpected situations.
f) Dress properly. Do not wear
loose clothing or jewellery. Keep
your hair, clothing and gloves away
from moving parts. Loose clothes,
jewellery or long hair can be caught in
moving parts.
g) If devices are provided for the
connection of dust extraction and
collection facilities, ensure these
are connected and properly used.
Use of dust collection can reduce
dust-related hazards.
4) POWER TOOL USE AND CARE
a) Do not force the power tool. Use
the correct power tool for your
application. The correct power tool
will do the job better and safer at the

5
rate for which it was designed.
b) Do not use the power tool if
the switch does not turn it on
and off. Any power tool that cannot
be controlled with the switch is
dangerous and must be repaired.
c) Disconnect the plug from the
power source and/or the battery
pack from the power tool before
making any adjustments, changing
accessories, or storing power tools.
Such preventive safety measures
reduce the risk of starting the power
tool accidentally.
d) Store idle power tools out of the
reach of children and do not allow
persons unfamiliar with the power
tool or these instructions to operate
the power tool. Power tools are
dangerous in the hands of untrained
users.
e) Maintain power tools. Check for
misalignment or binding of moving
parts, breakage of parts and any
other condition that may affect the
power tool’s operation. If damaged,
have the power tool repaired before
use. Many accidents are caused by
poorly maintained power tools.
f) Keep cutting tools sharp and
clean. Properly maintained cutting
tools with sharp cutting edges are
less likely to bind and are easier to
control.
g) Use the power tool, accessories
and tool bits etc. in accordance with
these instructions, taking into
account the working conditions and
the work to be performed. Use of the
power tool for operations different
from those intended could result in a
hazardous situation.
5) SERVICE
a) Have your power tool serviced by
a qualified repair person using only
identical replacement parts. This will
ensure that the safety of the power
tool is maintained.
b) If the supply cord is damaged,
it must be replaced by the
manufacturer, its service agent or
similarly qualified persons in order to
avoid a hazard.
5) BATTERY TOOL USE AND CARE
a) Recharge only with the charger
specified by the manufacturer. A
charger that is suitable for one type of
battery pack may create a risk of fire
when used with another battery pack.
b) Use power tools only with
specifically designated battery. Use
of any other battery packs may create
a risk of injury and fire.
c) When the battery is not in use,
keep it away from other metal
objects, like paper clips, coins, keys,
nails, screws or other small metal
objects, that can make a connection
from one terminal to another.
Shorting the battery terminals

6
ADDITIONAL SAFETY FOR
RECIPROCATING SAWS
a) Hold power tool by insulated
gripping surfaces, when performing
an operation where the cutting
accessory may contact hidden
wiring. Cutting accessory contacting
a “live” wire may make exposed metal
parts of the power tool “live” and
could give the operator an electric
shock
This appliance is not intended for
use by persons (including children)
with reduced physical, sensory
or mental capabilities, or lack of
experience and knowledge, unless
they have been given supervision or
instruction concerning use of the
appliance by a person responsible for
their safety.
Recommendations for the use of a
residual current device with a rated
residual current of 30mA or less:
› Wear a hard hat (safety helmet),
safety glasses and/or face shield. It
together may cause burns or a fire.
d) Under abusive conditions,
liquid may be ejected from the
battery; avoid contact. If contact
accidentally occurs, flush with
water. If liquid contacts eyes,
additionally seek medical help.
Liquid ejected from the battery may
cause irritation or burns.
is also highly recommended that you
wear a dust mask, ear protection and
padded gloves.
› Hold the power tool with a firm grip.
› Secure the work piece. A work piece
clamped with clamping devices or
in a vice, is held more secure than
by hand.
› One-handed operation can be
hazardous. It is recommended you
hold the unit firmly with both hands
when operating the tool.
› After installing a blade, pull lightly on
it to make sure that it does not come
loose. If the blade is not installed
properly, it can come loose during
use, which can be dangerous.
› Use a blade that is appropriate for the
application.
› Check that any blade to be used
is not cracked or broken. Broken or
cracked blades are dangerous.
› If the screw securing the blade is
damaged, the blade may come off
during use causing personal injury.
› The torque delivered by the
reciprocating saw depends on how
long it is applied and other factors
such as the state of the battery charge.
› Stop the reciprocating saw before
changing the direction. Always
release the trigger and wait for the
reciprocating saw to stop before
switching the direction of rotation.
› Never touch the blade whilst it is in
use. Do not let the blade get near your
hands or any other part of your body

7
LITHIUM-ION BATTERY &
CHARGER SAFETY
OVER CHARGING PROTECTION
This feature ensures that the battery is
never overcharged. When the battery
has reached its full charge capacity
the charger will shut off protecting the
internal components of the battery
from being damaged.
OVER DISCHARGE PROTECTION
An internal component of the
battery pack is an over discharge
protector. This feature will stop the
battery from discharging beyond the
recommended lowest safety voltage.
OVER HEAT PROTECTION
The battery has an internal Thermister
cut off sensor which will cease the
charging cycle if the battery becomes
hot during the charging process. This
Thermister sensor will also stop the
battery from operating should the
battery become too hot during the
operation of the tool. This can happen
when the tool is overloaded or being
used for extended periods of time.
Up to 30min in cooling time may
be required depending on ambient
temperature and operation being
performed.
OVER CURRENT PROTECTION
Should the battery be overloaded
and the maximum current draw be
exceeded the battery will temporarily
stop working to protect the internal
components. The battery will resume
to normal operation once the
excessive current draw has returned
to normal safe level. This may take a
few seconds.
SHORT CIRCUIT PROTECTION
If the battery pack was to short circuit
the short circuit protector would
immediately stop the battery pack
from operating. This will ensure that
no further internal components of the
battery or the tools are damaged.
as you could be cut.
› Do not touch the blade after it has
been in use for an extended period. It
could be hot and burn you.

8
INTENDED USE
The cordless reciprocating saw
is designed to cut through steel,
aluminium, wood and conduit in
conjunction with the appropriate blade.
The equipment may only be used for
the tasks it is designed to handle. Any
other use is deemed to be a case of
misuse. The user / operator and not
the manufacturer will be liable for any
damage or injuries of any kind caused
as a result of this.
TECHNICAL SPECIFICATIONS
SPECIFICATIONS NG-54 Reciprocating Saw
Product code 40044
Warranty 3 years
Voltage 12V
Stroke length 1/2” (13mm)
No-load speed 0-2300 RPM
Battery type Li-ion 2000mAh
Battery charge time 30 mins

9
PRODUCT OVERVIEW
IDENTIFICATION
BATTERY AND CHARGER
This tool is compatible with the
NG-6020 battery and NG-61 charger.
1
2
6
3
5
4
1. LED light
2. Stationary shoe
3. On / off trigger
4. Lock-off button
5. Battery level indicator
6. Battery release button
(battery not included)
ACCESSORIES INCLUDED
› 1x cutting blade

10
INSTALLING AND REMOVING
THE BATTERY
Always switch off the reciprocating
saw before insertion or removal of the
battery.
INSTALLING THE BATTERY
› Hold the reciprocating saw upright and
pick up the battery in your opposite hand.
Place two fingers over the battery release
buttons and insert the battery until it
clicks into place (Fig. 1).
› Do not use excessive force when
inserting the battery. If the battery does
not slide in easily, it is not being inserted
correctly. It is also possible that there
could be damage to the battery, battery
terminals or the reciprocating saw.
REMOVING THE BATTERY
Press both the battery release buttons on
either side and gently pull the battery out
of the reciprocating saw.
BATTERY LIFE
The length of service from each charging
cycle will depend on the type of work you
are doing. To obtain the longest possible
battery life, we suggest the following:
› Store and charge your battery in a cool
area. Temperatures above or below normal
room temperature will shorten battery life.
› Store and charge your battery in a cool
area. Temperatures above or below
Fig.1

11
normal room temperature will shorten
battery life.
› Never store batteries in a
uncharged condition. Recharge them
immediately after they are uncharged.
› All batteries gradually lose their
charge. The higher the temperature
the quicker they lose their charge. If
you store your reciprocating saw for
long periods of time without using it,
recharge the batteries every month or
two. This practice will prolong battery
life.
ASSEMBLY
INSTALLING A BLADE
1. Depending on the job, the blade may
be inserted with the teeth facing up or
down. To install a blade, twist the collar
in the direction of the arrow (fig. 2) while
inserting the blade into the clamp (fig.3)
until the tang butts against the collar.
2. Release collar and the spring loaded
Warning: Always remove the
battery from the tool before
inserting or removing a blade or
when making any adjustments to
your tool.
Warning: Ensure the spindle and
blade clamp areas are clean. Metal
chips and sawdust may prevent the
blade clamp from clamping
securely
!
!
Fig.2
Direction arrow
Fig.3
Blade clamp

12
mechanism will clamp the blade firmly in
place (Fig. 4).
3. Twist collar in the opposite direction
of the arrow to ensure that the blade is
locked into the clamp.
4. Tug on blade to make sure it is securely
locked in place.
REMOVING A BLADE
To remove a blade, twist collar in the
direction of the arrow while pulling on
the blade. Be careful when handling hot
blades.
REMOVING BROKEN BLADES
Broken blades can be removed by the
following:
› Remove battery pack before removing
blades.
› Point the tool downward, twist the collar,
and shake the tool up and down (DO NOT
turn the tool on while your fingers are
holding the blade clamp open). The shank
of the broken blade should drop out of
the clamp.
› If shaking the tool does not work: in most
cases, a corner of the broken blade will
extend beyond the blade clamp. Twist the
collar and pull the broken blade out of the
clamp by this corner.
› If the broken stub does not extend far
enough to be grabbed by its corner, use
a thin blade with small teeth (such as a
metal cutting blade) to hook the blade that
is jammed in the clamp while twisting the
collar and pull it out.
Fig.4

13
OPERATION
LOCK OFF BUTTON
The lock-off button is a safety device
designed to reduce the possibility of a
user accidentally starting the saw. This
button must be pressed before the on /
off trigger can be squeezed (Fig. 5).
NOTE: The lock-off button can be pressed
from either the left or right side of the
handle.
ON / OFF TRIGGER
1. Turn the reciprocating saw ON by
pressing the on / off trigger (Fig. 6) whilst
pressing the lock-off button.
2. To turn the reciprocating saw OFF
release the on / off trigger and the lock-
off button.
VARIABLE SPEED
You can vary the speed of the
reciprocating saw by controlling the
amount of pressure applied to the on
/ off trigger. The tool reaches its max
speed when the on / off trigger is fully
pressed.
Fig.6
Lock off button
On / off trigger
Fig.5

14
MATERIALS SUITABLE FOR CUTTING
This reciprocating saw is a versatile tool
that allows you to cut many different
types of materials. Some of these
materials include:
› Wood products such as lumber,
hardwood, plywood, composite board,
and panelling
› Drywall
› Fibre board and plastic
› Metals, such as pipe, steel rods, sheet
steel, aluminum, brass, and copper.
NOTE: There are many different types of
blades available. Generally, there are
metal cutting blades (fine teeth) and
wood cutting blades (coarse teeth). Use
the correct blade for your application. The
packaging on the blade will indicate the
type of materials each blade is designed
to cut.
LED LIGHT
› The saw has one LED Light built into the
unit (Fig. 7).
› The LED light turns on automatically
when you press the on / off trigger.
› The LED light illuminates dark areas in
tight corners to assist with cutting. This
helps achieve a more accurate result in
your work piece.
Fig.7
LED light

15
GENERAL CUTTING
1. Clearly mark the work piece to locate
the position of the cut.
2. Hold smaller workpieces with a vice.
Clamp larger work pieces to a workbench
or table.
3. Make sure there are no nails, screws,
clamps or foreign materials in the path
of the saw blade.
4. Hold the saw away from your body
and in front of you.
5. With both hands firmly gripping the
saw, and with the blade NOT in contact
with the surface to be cut, start the saw
by pressing the lock-off button and
squeezing the trigger.
6. Once the saw has reached the
desired speed, place the adjustable
pivoting shoe against the work piece
and gradually bring the moving blade
into contact with the work piece at the
appropriate location.
PLUNGE CUTTING
1. Clearly mark the work piece to locate
the position of the cut.
2. Clamp the work piece to a workbench
or table.
NOTE: Make sure the area to be cut is
clear under the work piece so that the
blade will not come into contact with
anything other than the work piece.
3. Select a convenient starting point in
the area to be cut out. Place the tip of
the blade over that point.
4. Rest the lower edge of the adjustable
pivoting shoe on the work piece and
hold it firmly in that position, maintaining
a shallow cutting angle.
5. Press the lock-off button and squeeze
the trigger to start the saw.
6. With the saw running at full speed,
slowly tilt the saw until the tip of the blade
contacts the work piece and begins to
cut. After the blade cuts through the work
piece, tilt the saw upward until the blade
is perpendicular to the work piece.
Caution: Verify the following every
time the reciprocating saw is used:
1. The blade is sharp and in good
condition.
2. The blade is firmly clamped in
the blade holder.
3. The work piece is properly
secured.
4. Safety glasses and hearing
protection are being worn. Failure
to observe these safety rules will
significantly increase the risk of
injury.
Caution: Make sure the blade does
not touch the work piece until the
saw reaches full speed. Loss of
control and possible injury could
result.
!
!

16
WASTE DISPOSAL
& RECYCLING
SERVICING
Do not dispose of this product
in household waste!
Please recycle this product
responsibly in accordance with
local and national law.
For information on servicing
and repairs please contact
Spot-on on 1300 658 338 or
visit www.spoton.com.au.
NOTE: Nova Gear will not be
responsible for any damage or
injuries caused by repair of the
reciprocating saw by an unauthorised
person or by mishandling of the
reciprocating saw.
MAINTENANCE
› When not in use, the reciprocating
saw should be stored in a dry, frost free
location, out of reach of children.
› Keep ventilation slots of the
reciprocating saw clean at all times and
prevent any foreign matter from entering.
› If the housing of the reciprocating saw
requires cleaning, do not use solvents
but a moist soft cloth only.
› Blow out the ventilation slots with
compressed air periodically.
› Periodically clean dust and debris from
the blade clamp with dry compressed air.
› If the collar resists twisting, twist the
collar back and forth to shake debris
loose.
› Periodically lubricate the blade clamp
with a dry lubricant such as graphite.
METAL CUTTING
Metals such as pipe, steel rods, sheet
steel, aluminum, brass and copper can
be cut with your reciprocating saw.
› To cut thin sheet material, “sandwich”
the material between hardboard or
plywood and clamp the layers to limit
vibration and material tearing.
› Always use a fine toothed metal
cutting blade and run the saw at
medium speeds when cutting metal.
› Use cutting oil to keep the blade cool,
increase cutting action, and prolong
the life of the blade.
› Do not twist or bend the saw blade. Let
it cut at its own speed.
Warning: Always clamp the work
piece in a vise, or to a workbench
or table. Do not hold work piece in
your hand.
Warning: Never use gasoline as a
lubricant or as a cleaning agent. A
spark from the motor may cause
an explosion. Gasoline will also
damage the plastic components of
the saw.
!
!

17
WARRANTY
The NG-54 Reciprocating Saw comes
with a 3 year manufacturers warranty.
Our goods come with guarantees that
cannot be excluded under the Australian
Consumer Law. You are entitled to a
replacement or refund for a major
failure and for compensation for any
other reasonably foreseeable loss or
damage. You are also entitled to have
the goods repaired or replaced if the
goods fail to be of acceptable quality
and the failure does not amount to a
major failure.
Separate to the above Australia
Consumer Law, Spot-on offers a global
warranty.
The warranty period commences on
the date of purchase, which can be
verified on your receipt or invoice. We
cannot offer a warranty for damages
and defects on appliances or their
parts caused by improper use or
treatment. Damage caused by failure
to comply with the operating manual
will be excluded from the warranty.
In the event that an unauthorised
persons has modified the appliance,
the warranty will be rendered void.
Damages that are caused by improper
handling are excluded from the
guarantee.
If you have any concerns or wish to
make a warranty claim please contact
your retailer or Spot-on Laser and Tool
Company on 1300 658 338.
Spot-on Laser and Tool Company PTY LTD
10-12 Dowsett Street,
South Geelong, VIC 3220
Australia

18
NOTES

19

Spot-on Laser and Tool Company | 1300 658 338 | www.spoton.com.au
