Spring wfp Link User manual

Your fob will indicate when it needs charging by lighting
two LEDs.
Step 2. Fob Charging
DO NOT IMMERSE FOB IN WATERr. Doing
so will result in damage to the unit.
DO NOT LEAVE IN DIRECT SUNLIGHT. Doing
so will result in damage to the unit.
!
wfp Link - Quick Start
* Charge only with micro USB phone chargers or similar micro USB adaptors.
Specification Value
Supply Voltage*
Enclosure Material
Water Resistance
Dimensions
Working Temperature
5 VDC
ABS
IP61
75 x 16mm
0 to 40 Deg C
DISCLAIMER
THE MANUFACTURER RESERVES THE RIGHT TO MAKE CHANGES TO ANY PRODUCT HEREIN TO IMPROVE
RELIABILITY, FUNCTION OR DESIGN. THE MANUFACTURER DOES NOT ASSUME ANY LIABILITY ARISING OUT OF THE
APPLICATION OR USE OF ANY PRODUCT OR CIRCUIT DESCRIBED HEREIN.
v11
To Charge
Plug in micro USB
phone charger or similar
to the charging connector.
Charging LED is red
when charging.
Charging LED is green
when charged.
Step 1. Fob Overview
Pump Decrease
Each press will
reduce pump flow
by 10.
LED segments
indicate this.
Pump Increase
Each press will
increase pump flow
by 10.
LED segments
indicate this.
Auto-Calibrate
Press and hold
until whole LED
segment lights.
One LED lights to indicate
calibration has finished.
Start/Stop
Press once to stop
pump. Whole LED
segment lights to
indicate STP.
Controller will
show 'StP'.
Press once to
start pump.
One LED lights
to indicate pump
has started.
Before you can use your fob it must be paired with its
controller. Please see step 3 for details.
Charging
LED

WFP Link Fob Quick Start Guide v11
Step 3. Pairing your fob Step 4. Use Cont'd
If the fob is charged and working, the LED segments will
appear to circle around the fob. The controller will respond
by displaying 'FOb'.
To begin using your fob you must first pair it with your
controller. Ensure your controller is turned on. Press and
hold two opposite buttons on the fob:
+ +
or
Now press ALL three buttons on the controller at the same
time.
++
If the pairing is successful the fob LED segments will stop
circling and the 'FOb' will disappear from the controller display.
Your fob should now operate the controller as described
in 1. Fob Overview.
If the pairing is unsuccessful turn the controller offfor 30
seconds then on again and repeat the steps above.
Step 4. Use
Pressing this button reduces the flow setting by 10.
The controller will indicate this reduction:
Pressing this button increases the flow setting by 10.
The controller will indicate this increase:
Pressing and holding this button will start an auto
calibration on your controller. (Ensure flow is set to
your desired value e.g. 50).
All LEDs on the segment light to show auto calibration
has started, the controller will indicate 'AUt'.
When the controller has calibrated one LED on the
segment will light to show this. 'CAL' will disappear
from the controller display.
Pressing this button starts and stops the pump. If
the pump is running press the button once to stop.
All LEDs on the segment will light, the pump will stop
and controller indicates 'StP'.
If the pump is stopped press the button once to start.
A single LED on the segment will light, the pump will
start and controller indicates the current flow. e.g. '30'.
