Springtree DMX1200 User manual

USER MANUAL AND
INSTALLATION GUIDE
DMX1200

2(615) 599-1505 www.springtree.net
Product Information
Description.................................................................................................................................3
Features....................................................................................................................................3
Safety Precautions....................................................................................................................3
Installation
Installation...............................................................................................................................4-6
Operation
Operation...............................................................................................................................7-9
Menu.........................................................................................................................................7
Zones.........................................................................................................................................8
DMX..........................................................................................................................................9
Technical Specications
Dimensions..............................................................................................................................10
Weights....................................................................................................................................10
Troubleshooting.......................................................................................................................10
Warranty...................................................................................................................................11
Contact us...............................................................................................................................11
Table of Contents

3
[phone] www.springtree.net
Product Information
Features:
Description:
The DMX1200 is a
game-changing 24 volt, DMX-
controlled power supply for Springtree
Lo-Vo lighting modules. It can power up to
(32) 30watt Spatial Flats, (16) 50watt Spatial Flats
or (80) LEDBoard12 LED Modules, all on a single 20 AMP
circuit.
Safety precautions
• To reduce the risk of electrical shock or re, do not expose this unit to moisture.
• Be sure that the local power outlet matches that of the required voltage for your unit.
• Disconnect from main power before making any type of connection.
• Do not remove the cover under any conditions. There are no user serviceable parts inside.
• Never plug this unit into a dimmer pack.
• This power supply is intended for indoor use ONLY.
• Always mount this unit in a safe and stable manner.
• Keep this manual for as long as you own this product!
• Low voltage (24V) LED module control
• 8 Zones, 150w each (120w reccomended)
• White and RGBW modes
• DMX
• Local control
• Color macros

4(615) 599-1505 www.springtree.net
Installation
1. The electrical connection to the DMX1200 is made via Powercon connector on
the rear. There is also a Powercon output provided to daisy-chain to other gear.
(reminder, if at max only one DMX1200 can be powered on a single 20amp circut.
Two could be used if neither of them are at max load. 1800 watts is max reccomened per
20amp circuit)
2. DMX connection is also made on the rear via 3 pin xlr connection. DMX comes
in from your lighting console and can be daisy-chained out to more DMX1200’s or
lighting xtures.
3. Connection to the Lo-Vo lights is made via pheonix connector. See connections
page for instruction on wireing each type of xture.
To install the DMX1200 you will need 2 rack spaces in a standard 19” rack. There
are 4 screw holes for mounting in the rack. Be sure to leave room in back for the electri-
cal and dmx wires and connectors. Do not block any vent holes on the top and sides.
12
3

5
[phone] www.springtree.net
Installation cont.
The DMX1200 can power up to (32) 30watt Spatial Flats, (16) 50watt Spatial Flats or (80)
LEDBoard12 LED Modules, all on a single 20 AMP circuit. The image below shows the DMX1200
used with various combinations of each light per port. Each of the 8 ports must not exceed 150
watts (120w reccomended).

6(615) 599-1505 www.springtree.net
Installation - connections
Connect wires to pheonix connectors as shown here:
Warm White (50watt and 120watt) and all RGBW
For 50watt and 120 watt Warm White and all RGBW connect all 5 wires in this order:
Connector 1 Connector 2 Connector 3 Connector 4
+ = Black + = Black + = Black + = Black
R = Red R = Red R = Red R = Red
G = Green G = Green G = Green G = Green
B = Blue B = Blue B = Blue B = Blue
W = White W = White W = White W = White
Connector 5 Connector 6 Connector 7 Connector 8
+ = Black + = Black + = Black + = Black
R = Red R = Red R = Red R = Red
G = Green G = Green G = Green G = Green
B = Blue B = Blue B = Blue B = Blue
W = White W = White W = White W = White
Warm White (12watt and 30watt)
For 12watt and 30watt Lo-Vo lights connect the Brown and Blue wires in this order:
Connector 1 Connector 2 Connector 3 Connector 4
+ = Brown + = Brown + = Brown + = Brown
R = Blue G = Blue B = Blue W = Blue
Connector 5 Connector 6 Connector 7 Connector 8
+ = Brown + = Brown + = Brown + = Brown
R = Blue G = Blue B = Blue W = Blue

7
[phone] www.springtree.net
Operation - Menu
There are four buttons on the front of this unit: MENU, ENTER, UP and DOWN.
*Press MENU to choose your output mode, DMX address, color macro, user color as well as
PWM (pulse width modulation) mode.

8(615) 599-1505 www.springtree.net
Operation continued - Zones
Splitting Zones:
When the DMX1200 is being controlled by DMX there are 4 options to split zones. See the
images below showing the zone breakout.
4 channels (white) / 20 channels (rgbw) four
zones - outputs 1-2 combined, outputs 3-4
combined, outputs 5-6 combined, outputs
7-8 combined.
1 channel (white) / 5 channel (rgbw) one
zone - all 8 outputs combined
2 channels (white) / 10 channels (rgbw) two
zones - outputs 1-4 combined, outputs 5-8
combined
8 channels (white) / 40 channels (rgbw)
eight zones - all 8 outputs are separate

9
[phone] www.springtree.net
Operation continued - DMX Channels
DMX Channels:

10 [phone] www.springtree.net
Technical Specications
Weight: 20 lbs
• AC input: 120V
• DC output: 150w per connector, 1200w total
• Environmental Temp: -4 deg F - 140 deg F
• Weight: 20 lbs
• Dimensions: 19” x 14.5” x 3.5”
Troubleshooting:
Listed below are a few common problems that you may encounter
when using this product:
Unit not responding to DMX:
1. Check that the DMX cables are
connected properly and are
wired correctly. DMX output DMX input
2. Check that all cables are connected to the right connectors; it does matter
which way the inputs and outputs are connected.
19” 14.5”
3.5”
Troubleshooting/ Technical Specications

11
[phone] www.springtree.net
Oce hours:
Monday-Friday, 8:30
AM to 5:00 PM CT
Telephone:
[phone]
E-mail:
[email protected]
Website:
www.springtree.net
Contact us
Springtree Media Group would like to thank you for choosing our company for
your lighting needs! If you have any questions or concerns, please contact us.
Warranty:
1st YEAR - Parts and labor. Advanced replacement - First 90 days with shipping
covered by Springtree Media.
2nd YEAR - Repair/ Replace Springtree discretion. Return shipping covered by
customer.
Warranty/ Contact us
