DPS5005
Programmable power supply
1. GENERAL INFORMATIONS
Dear customer,
thank you for purchasing our product. In the following, we will show you
how to use your product.
Should you encounter any unexpected problems during use, please do not
hesitate to contact us.
This power supply unit is characterized by its outstanding precision and
accuracy and combines analog and digital technologies in an advanced de-
sign. The adjustable output reaches up to 50V or 5A and can be precisely
configured in 0.001A steps. The power supply is additionally equipped with a
switch-o parameter memory and ten programmable data memories. The
operation of the device has been optimized for particularly easy operation
and the colour display oers particularly detailed and comprehensive infor-
mation. Among other things, the current voltage and current values, preset-
tings and output powers can be displayed here. Dynamic notification sym-
bols also facilitate clarity. The additional settings menu oers maximum
control of overcurrent and overvoltage values as well as other parameters.
The DPS5005 oers modern design and advanced technology in a compact
package, making it the ideal power supply.

www.joy-it.net
Pascalstr. 8 47506 Neukirchen-Vluyn
2. TECHNICAL DETAILS
Attention! Make sure that the input voltage is always at least 1.1
times the output voltage. In addition, always ensure suicient ven-
tilation of the device for heat dissipation.
Input voltage 6—55 V
Output voltage
Output current
Output power
Weight
Display size
Case cutout
Dimensions
Accuracy of output voltage
Accuracy of output current
0—50 V
0—5 A
0—250 W
88 g
1,44“
39 x 71
42 x 45 x 80 mm
± 0,5 %
± 0,5 %
3. CONNECTION DETAILS
IN+ IN- OUT+ OUT-
IN+
IN-
OUT+
OUT-
Positive input
Negative input
Positive output
Negative output
The permissible range of the input voltage is 6—55 V (DC). Always
ensure a suicient safety distance and never exceed the maximum
permissible input voltage. The non-observance can cause substan-
tial damage at your device.
Operate the device exclusively with direct current! Operating the
device with alternating current can lead to fatal electric shocks and
irreparable damage to the device.

www.joy-it.net
Pascalstr. 8 47506 Neukirchen-Vluyn
4. PANEL AND DISPLAY
Aer the first start, the welcome screen is displayed, followed by the main
screen. The main screen displays selected voltage and current limits. When
the output is active, the current actual values are also displayed. On the right
side of the screen there are icons and prompts that indicate the system sta-
tus. For a detailed description of the display, refer to the following diagram.
Voltage settings, arrow
upwards, M1 data
group
Data input, extract / save
data from / in data group
Current settings, arrow
downwards, M2 data
group
1,44“ LCD-Display
Rotrary switch,
key lock
Activate / deactivate
output
7
8
Output voltage (default)
Output voltage (current value)
13
10
9
11
12
14
15
16
17
18
Output current (current value)
Output power (current value)
Input voltage
Limit of output current
Lock / enlock keys
Normal / abnormal status
Constant voltage / current
Number of data group
Active / inactive output
Preset output voltage
Main menu Settings

www.joy-it.net
Pascalstr. 8 47506 Neukirchen-Vluyn
19
20
Preset limit of output current
Preset limit of overvoltage
25
22
21
23
24
Preset limit of overcurrent
Preset limit of overload
Preset screen brightness
Preset number of data group
Actual value of output voltage / current
5. USE OF DEVICE
Output voltage and current limitation
Press V/↑ to enter the voltage setting mode. Press the Rotary encoder to
move the cursor to the numeric value you want to change. Turning the knob
clockwise increases the value and counter clockwise decreases the value.
Press V/↑ again to exit. Alternatively, aer 30 seconds of inactivity, the setting
mode will automatically exit. Press A/↓ to set the output current limit in the
same way.
Configuration of data and conservation values
Press SET in the main screen to enter the data settings menu.
Setting the voltage and current limits
Navigate through the menu to go to the U-SET (Voltage) or I-SET
(Voltage Limit) option. Set the Output voltage and/or output current
limitation according to your requirements. You can then use the SET
button to return to the menu options. Press the SET button again to exit
the menu.
Setting the protection values
Navigate through the menu to go to the limit options Option S-OVP
(overvoltage protection), S-OCP (overcurrent protection) or S-OPP
(overpower protection). Use the knob to set the desired value. Press the
SET button to return to the menu options and press the SET button
again to exit. The output is automatically deactivated when one of the
protection value limits is reached.
Attention! These are global limit values and should not be
confused with the preset voltages and currents.
Adjusting the screen brightness
Navigate to the B-LED option to adjust the display brightness.
Turn the Rotary encoder to adjust the brightness from 0 to 5. O defines
the darkest and 5 the brightest setting. Press the SET button to return
to the menu options. Press the SET button again to exit the menu.

www.joy-it.net
Pascalstr. 8 47506 Neukirchen-Vluyn
Configuration of data group
Data groupM0
The M0 data group is a special case. It is the standard data group. Each
time an alternative data group is selected or changes are made to the
existing settings, M0 is immediately overwritten with the newly selected
data. M0 is therefore a real-time duplicate of the currently selected data
group. It is also the data set that is stored when the power is turned o
and recalled the next time the power is turned on. This is done auto-
matically and transparently without user input.
Selecting the processing data group
Navigate to the option M-PRE to edit a data group. Rotate the rotary
switch to choose the number of the data group which should be edited.
Aer finishing the settings hold down SET until the number of the data
group is shown on the right side of the screen. By pressing SET again,
you leave the data group settings.
Activation / deactivation
Navigate to the option M-PRE and press the rotary switch. Aer that
rotate the switch to choose the data group by its number which you
want to see and edit. Press it again to change the status of the option
M-PRE.
By activating this option, the output stays the same by selecting a data
group.
By deactivating this option, the output is automatically switched o by
selecting a data group.
Hold down SET until the number of the data group is shown on the right
side of the screen. The data value will be saved in the data group of the
shown. Press SET again to return to the menu. To leave this menu press
SET.
Data group quick selection
Key combination to choose M1 / M2
Hold down V/↑ or A/↓ for longer than 3 seconds to select the data
group M1 or M2 as a quick selection. The number of the according data
group is shown on the right side of the screen. The data group M1 and
M2 are perfect for frequently used settings because of their quick
selection function.
Selecting an arbitrary data group
Hold down SET for more than 3 seconds to show M0 on the right side of
the screen. Through rotating the rotary switch is it possible to choose
the requested data group (M0 - M9). To activate the chosen data group,
press SET.

www.joy-it.net
Pascalstr. 8 47506 Neukirchen-Vluyn
Editing the chosen data group
To edit the chosen data group press V/↑ or A/↓ to navigate upwards
or downwards through the menu options. Press the rotary switch and
the selected numerical value will be highlighted with the cursor. More
actuations of the rotary switch will lead to scrolling through the
possible characters. Aer the desired value is selected, hold down SET
until the number of the data group is shown on the right side of the
screen. The value of the data will now be saved in the selected data
group. By pressing SET again, you return to the menu. You can leave
the menu by pressing SET.
Status of the selected data group at the starting of the device
You can configure the device to automatically activate the output when
the device is turned on. Navigate to do this in the S-INI option and set
the value to ON to activate the option. Once you have selected the de
sired setting, press and hold the SET button until the
data group number is displayed on the right side of the screen. The data
value is now stored. Press the Set button again to return to the previous
menu. To exit the menu, press the Set button again.
Activating and deactivating the output
You can press the ON/OFF button at any time to activate or deactivate the
output.
Key lock
The keys can be deactivated to avoid unintentional changes. You can hold
the rotary switch longer than 3 seconds to block the keys or to
unlock them again at any time . The status of the key lock is shown with the
lock symbol on the right side of the screen.
