Spy Earpice SE51 Bluetooth neckloop User manual

3.5W Amplified Bluetooth Neckloop V3.0
Quick Start
Pair with mobile phone
A. Put Bluetooth neckloop in pairing mode
1) With the Bluetooth neckloop power off, press
and hold Bluetooth switch for 6-10 seconds until
indicator turn on and flash between blue and red.
2) If Bluetooth is switched on or indicator flashing,
press and hold Bluetooth switch for 5 seconds to
turn off Bluetooth, then repeat above step 1).
B. Put Mobile phone in pairing mode
1) Go to mobile phone panel, turn on Bluetooth function
and search for new Bluetooth device.
2) Select “T-Loop” then press “OK” or “YES”.
3) Enter password “0000" and press “OK”.
* Once paired, indicator change from flashing to blue.
Some mobile phone need to “connect” manually after paired.
Note: 1) Bluetooth indicator is nearby “SOS button”.
2) If can not switch on Bluetooth, please recharge for 3 hours and try again (refer to “Recharge and Battery”).
To be continued..
2012 updated design. Version 3.0.
1) Add music control function.
Bluetooth button control play/pause.
Short push “Volume +” to previous song, long push to increase volume.
Short push “Volume -” to next song, long push to reduce volume.
2) Mute button is works while play music.
2) Cancelled alarm notice while change volume.
If volume comes minimum or maximal will make alarm also.
Te51 Bluetooth neckloop is build in F class low consumption audio amplifier.
Defined power of amplifier is 3.5watt. It can supports all kinds of wireless
earpieces and provides very loud audio sounds.
2 colors are available, skin and black.
Package includes:
1 x Amplified Bluetooth Neckloop (black or skin color)
1 x USB recharge cable & 1 x USB AC charger
V3.0 Improvements Neckloop
1
SOS
Microphone
Recharge
SOS Button
Indicator
Bluetooth Switch & Pause / Play
Mute Button
Next / Volume +
Previous / Volume -
PAGE 1www.Spy-Earpiece.com

Wear the neckloop
Hang the neckloop around the neck as shown in image to the right.
site down to drive sensitive earpieces including TE07/TE08P/TE09.
Test and use neckloop
Once connected to mobile phone you should be able to hear any audio within your earpiece (Please check how to use earpiece in
manual of earpiece). The volume can be adjusted via the volume control on the neckloop.
The Bluetooth neckloop has a number of buttons all providing different functions. See below for detailed descriptions:
Power, Battery and recharge
To save battery power, please turn off Bluetooth power if not using for a long time.
Turn off – Press and hold Bluetooth switch until indicator flash then switches off
Turn on — Press and hold Bluetooth switch until indicator turn on Blue color. If already paired with mobile phone and
Bluetooth function in mobile phone is turn on, it will connect to mobile phone automatically.
* Some mobile phone models do not support this function.
The neckloop has build-in 320mah lithium rechargeable battery. The full performance of a new battery is achieved only after two
or three complete charge and discharge cycles. The battery can be charge and discharge hundred of times, but it will eventually
wear out.
When recharge battery use only original default USB recharge cable and default wall charger. Do not leave a full charged device on
recharge power source. Overcharging may shorten battery life. If left unused, a full charged battery will loss its charge over time.
We supply US/EU/UK standard plugs for the wall charger. Please choose correct plug while placing the order.
To be continued...
Can also put neckloop in coat pocket or put on legs when you are
3
2
Hang Neckloop
around the neck
4
SOS
SOS
1.
38db microphone ensures you partner can hear
you clearly even you are whisper to the microphone.
2. Exclusive design – Mute Button
The creative function for avoid earpiece detection.
Simply push mute button it will cut off audio
output and earpiece detection equipment will be
unable to pick up any signals from neckloop.
Works in phone conversation and music player.
Push Mute button again will back to phone conversation.
1.
2.
3.
4.
5.
3.Change volume to get clear sounds.
4. Exclusive design – SOS Button
Contact your partner without
saying a word.
Simply push SOS button to transmit
a beep. Ideal for transmitting
morse code.
The beep noise is also audible in
your earpiece.
5. Bluetooth switch - multiple
function switch to turn on/off
power, reject/answer/make a
phone call etc.
3.5W Amplified Bluetooth Neckloop V3.0
PAGE 2www.Spy-Earpiece.com

Troubleshotting
Q. Why is not the neckloop working with my phone?
A. Please make sure the Bluetooth is switched on in your mobile phone and that the neckloop is in pairing mode. Also mobile phone
need to be within 10 meters from Bluetooth neckloop in open space. Try powering on/off the phone and neckloop and try again.
Q. Why do the answer SOS and mute buttons are no function?
A. Both of SOS and mute functions only work whilst phone conversation is in progress. If you are playing music or mobile phone
not in phone conversation, there 2 functions are not applicable.
Q. How to recharge battery?
A. Please read “Power, Battery and Rechage” step #4 for detailed instructions. When you have successfully connected the
neckloop to a power source the indicator will change to red.
Q. Why do I heard interference in invisible earpiece?
A. If earpiece has no quality problem, the volume is likely too loud. Reduce the volume on the volume controler.
Warranty and return policy
Default warranty is 12 months since ship date.
We do not accept return if product has not quality problem.
If product is within warranty and get broken, you can return back and get free repair. Return shipping cost is on buyer’s behalf.
We will pay the shipping cost for send repaired product.
If product is passed warranty, you need to pay return shipping cost, repair fee and shipping cost for send repaired product.
Warranty will be invalid in below conditions:
1) Passed 12 months since ship date.
2) Open case or and change circuits without our formal authorization.
3) Other kinds of problems caused by wrong operations.
Thank you for reading and Happy eCommerce!
PAGE 3
5Operations
Make a voice dial call
End a call
Receive a call
Reject a call
Redial last call
Answer a second incoming call
Toggle between two active calls
Join a 3-way call (depends on phone)
Put an active call on hold
Transfer a call from phone to BT
Mute or unmute call
Send SOS alarm sound
Press Bluetooth switch and speak name after tone
Tap Bluetooth switch
Tap Bluetooth switch
Press and hold switch until BEEP
Press and hold switch until BEEP
Press and hold switch (1st call on hold)
Press and hold switch
Press and hold both volume swtiches
Press and hold switch until BEEP
Tap Bluetooth switch
Press Mute button
Press SOS button
Indicators
Solid red
(Plugged into Adaptor)
No indicator
with adaptor plugged in
No indicator
without
adaptor plugged in
Flash Blue and
Red
10 rapid flashes
in Blue
Slow pulse
in Blue
Battery
Recharging
Charging
Completed
Power use off
In pairing
mode
Pairing
Successful
Connected
3.5W Amplified Bluetooth Neckloop V3.0
www.Spy-Earpiece.com
