Vectair SensaMist S100 User manual

S100
SCENT DIFFUSER
The SensaMist™ scent diffuser creates a fragrant atmosphere for small areas.
The diffuser utilizes advanced atomizer technology to create a fine mist of
fragrance which maximizes coverage, performance and concentration. The unit is
fully programmable.
Technical Specifications
Weight 1.1kg 2.42lb
Voltage DC 12V
Power Level 6W
Noise Level <50 dBa
Scent Coverage 300m310594ft³
User Instructions
1. The SensaMist™mains scent diffuser includes 4 parts: SensaMist™diffuser unit, power
adapter, user manual, installation parts (screws, positioning anchor).
2. The SensaMist™mains scent diffuser has the ability to set different working days,
working periods and diffuser concentration levels to suit your environment.
3. Simply fill the empty fragrance bottle with fragrance oil. Switch on the machine to
enjoy the scent.

Operation Steps
1. CONNECT TO POWER
Connect the power adapter to power socket and [DC POWER IN] on top of the device.
When the power is connected, the ON/OFF LCD shows whether the unit is in operation.
‘ON’shows the SensaMist™mains scent diffuser is in operational state, ‘OFF’ is out of
operational state. For example; if the diffuser is set from 8:00 to 10:00, ‘ON’ shows the
machine is working during this period. ‘OFF’ is in the opposite state.
The WORK/PAUSE LCD can set the SensaMist™mains scent diffuser to working-time or
pause-time. This can be used to control the SensaMist™fragrance oil concentration
according to different preferences.‘WORK’ shows the machine is working,‘PAUSE‘ is to
stop working.
2. WORKING PERIODS SETTING
The SensaMist™mains scent diffuser can be set to four different work periods. Workdays
can also be set to users’requirements.
[MODE] To change from one event to another event.
[SET] Press to choose your setting, (time setting (hour, minutes),
work days etc).
adjust buttons Use to adjust the time data, scent concentration data and the
choice of workdays.
A. Set the Time
Set the correct system time according to your time zone using the 24-hour clock.
1) Press [SET], the hour figure flashes, press the adjust buttons to adjust the hour.
2) Press [SET], the hour setting is saved and the minute figure flashes, press the adjust
buttons to adjust the minute.
3) Press [SET], the minute setting is saved and the work day figure flashes, press the adjust
buttons to set the correct day.
4) Press [SET] to finish setting up the system time and work day.

B. Set the Operation Periods
1) Press [MODE], the LCD screen displays [EVENT 1 ON], press [SET] to adjust the on time of
first operation period. Press the adjust buttons to adjust the hour, minutes and work
days. (Repeat the operation from [SET] to the adjust buttons. Firstly set the hour,
then minutes then work days.)
2) Press [MODE], the LCD screen displays MON TUE WED THU FRI SAT SUN, press the adjust
buttons to adjust the hour, minutes and work days.
3) Press [MODE], the LCD screen displays [EVENT 1 OFF], press [SET] to adjust the off time
of first operation period. Press [SET] to enter to adjust the hours, minutes by pressing
the adjust buttons.
4) To set further operational periods, repeat the above steps. The SensaMist™mains scent
diffuser can be set for up to four operational periods.
Work Days:
IMPORTANT!
1. When setting the work period, the close time is not allowed to be set before
the open time.
2. If the working period needs to cross the ‘00.00’ point, you will need to set two
working periods separately.
Monday to Wednesday Monday to Sunday Friday
Tuesday to Thursday Monday Saturday
Monday to Friday Tuesday Sunday
Saturday to Sunday Wednesday Monday, Wednesday, Friday
Monday to Saturday Thursday Tuesday, Thursday, Saturday

3. FRAGRANCE OIL INSTALLATION AND REPLACEMENT
If using the SensaMist™mains scent diffuser for the first time, please install the oil bottle first
then connect the power and related settings.
Ensure device is off before opening the front cover. Wearing protective gloves, open the
front cover and remove the oil bottle by gently pulling it towards you. Unscrew the cap/
nozzle (anti-clockwise) from the oil bottle and carefully fill the bottle with fragrance oil.
Replace the cap/nozzle (clockwise), align the bottle in the device with the nozzle facing
outwards then gently push the bottle back into the device. Close the front cover and
dispose of the gloves safely.
4. MAINTENANCE
If the equipment will not be used for a long period, the unit must be cleaned with alcohol
before it is packed.
SAMPLE/DEMO
We want to set the device from
Monday to Friday from 8am to 10pm.
However on Saturday and Sunday we
want to set it from 7am to 12pm.
Just set Program 1 from Monday
to Friday and work time from 8am
to 10pm. Then set Program 2 from
Saturday to Sunday and work time
from 7am to 12pm.
C. Set the Fragrance Concentration
After the four operational periods end,
continue to press [MODE], until the LCD
screen displays [SCENT WORK]. Set the
work time in each period i.e. 10, 15, 20 up
to 300 seconds.
Continue pressing [MODE], until the
LCD screen displays [SCENT PAUSE], set
the pause time in each period, from 10
seconds to 300 seconds, press the adjust
buttons to adjust in 5 second intervals,
i.e. 10, 15, 20, up to 300.
www.vectairsystems.com
SAFETY
• When filling or refilling the dispenser please use eye protection and gloves.
• Any spills on surfaces should be cleaned immediately, for more information
please see the label of the fragrance product.
