Squareled Storm 300 RGBW User manual

SquareLED - Storm 300 RGBW

Manual | Storm 300 RGBW
INTRODUCTION
Thank you for having chosen our LED lighting. Unpack the device, inside the box you should nd:
• The xture device
• One power cable
• One XLR connection cable
• This manual
Please check carefully that there is no damage caused by transportation.
Should there be any problems, consult your dealer and don’t install this device.
DESCRIPTION
Features
• Easy multi xture hanging system, outdoor version available
• 44pcs RGBW 4in1 LED, no ultraviolet radiation
• More than 50,000 hours for the LED light source
• 12,000 lm
• 35 degree / 25 degree lens
• 1/2/3/4/6/8/9/10ChF/10ChD/14/15 DMX channels
• 16 Bit Dimmer
• DMX Mode /Master-slave mode
• AC 100-240V 50/60Hz 300W
• Diecasting heatsink, convection cooling, fan speed control
• With temperature sensor to extend the lamp life
• 7000 Hz LED scan rate
• L: 490mm H: 285mm W: 105mm,Weight 9Kg
• IP65/IP43 selectable

Manual | Storm 300 RGBW
SAFETY INSTRUCTIONS
This device has left the factory in perfect condition. In order to maintain this condition and to ensure a safe
operation, it is absolutely necessary for the user to follow the safety instructions and warning notes written in
this user manual.
This device falls under protection-class I.Therefore it is essential that the device should be earthed.
The electric connection must carry out by qualied person.
If the external exible cable or cord of this luminaire is damaged, it shall be exclusively replaced by the manufac-
turer or his service agent or a similar qualied person in order to avoid a hazard.
Make sure that the available voltage is not higher than stated at the end of this manual. Make sure the power
cord is never crimped or damaged by sharp edges. If this would be the case, replacement of the cable must be
done by an authorized dealer.
Always disconnect from the mains, when the device is not in use or before cleaning it. Only handle the power
cord by the plug. Never pull out the plug by tugging the power cord.
Never look directly into the light source, as sensitive persons may suer an epileptic shock.
Important: Damages caused by the disregard of this user manual are not subject to warranty. The
dealer will not accept liability for any resulting defects or problems.
DMX-512 control connection
The product has a DMX 512 input tted with 3-pin XLR connectors. Screened cables in compliance with
EIA RS-485 specications and the following characteristics must be used for connections:
- 2 conductors plus screen
- 120 Ohm impedance
- low capacitance
- max. transmission rate 250k Baud.
DMX-512 connection with DMX terminator
For installations where the DMX cable has to run a long distance or is in an electrically noisy environment, such
as in a discotheque, it is recommended to use a DMX terminator. This helps in preventing corruption of the digital
control signal by electrical noise. The DMX terminator is simply an XLR plug with a 120 OHM resistor connected
between pins 2 and 3,which is then plugged into the output XLR socket of the last xture in the chain.

Manual | Storm 300 RGBW
Main menu Sub-menu
address DMX Address Setting
cong
Channel Mode
channel 1Ch
Channel 2Ch
Channel 3Ch
Channel 4Ch
Channel 6Ch
Channel 8ChF
Channel 9ChF
Channel 10ChF
Channel 10ChD
Channel 14ChD
Channel 15ChF
Dimmer Curve
Set Curve Mode L
Set Curve Mode Q
Set Curve Mode I
Set Curve Mode S
Cipher Setup 0-999
Key Mode Lock
Unlock
Temp Unit CS Celsius Degree
Fahrenheit Degree
DMX Status Value Clear
Value Hold
WDMX Mode -
Display Mode Auto
On
Fan Mode
slow
standard
fastest
System Info Temperature
Fixture Time
Color Menu
Red 0-255
Green 0-255
Blue 0-255
White 0-255
White Balance
Set Red 0-255
Set Green 0-255
Set Blue 0-255
Static color Color 0-51 -
Auto Test
Eect Auto 01 -
Eect Auto 02 -
Eect Auto 03 -
Eect Auto 04 -

Manual | Storm 300 RGBW
Auto speed 00 - 40
Load Default Yes
No
Firmware Version Vers 5.8
Main functions
1. address:Current DMX address
A. Setting DMX address by button
press ENTER button when show the address menu, then adjust the DMX address by pressing
[UP] or [DOWN] button
Press [ENTER] to conrm or pressing [ESC] to return to main menu
B. Setting DMX address by controller
1. Set Set the DMX value of channel 5 to 10-15,channel 17 to 20-26, channel 7 to 30-36,
channel 8 to 40-46,then the devices connected to the controller will enter to the setting
address mode
2. Set Set the DMX value of channel 1 from 0-59,then you will see the the rst number of
the Address change to (channel 1 vaule)/10. For example, when set the value of channel 1 to 20,
the rst DMX address number will be 2(20/10=2)
3. Set Set the DMX value of channel 2 from 0-99,then you will see the the sencond number of
the Address change to (channel 2 vaule)/10. For example, when set the value of channel 2 to 30,
the rst DMX address number will be 2(30/10=3)
4. Set the DMX value of channel 3 from 0-99,then you will see the the third number of the
Address change to (channel 3 vaule)/10. For example, when set the value of channel 1 to 40,
the rst DMX address number will be 3(40/10=4). And the DMX address you set by conctroller
will be 234.
5. Set Set the DMX value of channel 4 to 255,then you will save the DMX address setted by the
controller. Caution: It won’t save the address if the address number is over 512
6. set the value of channel 5-8 out of the value range show on the step 1,and the device will exit
the setting address mode

Manual | Storm 300 RGBW
2. cong
Setting DMX mode
press ENTER button when show the channel menu,
then select the DMX mode by pressing [UP] or [DOWN] button
Setting Dimmer Curve
press ENTER button when show the dimmer curve menu, then select the dimmer curve
by pressing [UP] or [DOWN] button
Setting Cipher
press ENTER button when show the cipher setup menu, then setup cipher by pressing
[UP] or [DOWN] button
Key mode
press ENTER button when show the key mode menu, then select lock or unlock by
pressing [UP] or [DOWN] button
Show Temperature
press ENTER button when show the Temp Uint CS menu, select the way of showing
the xture’s temperature in ´C´ or ´F´ by pressing [UP] or [DOWN] button
DMX status
press ENTER button when show the DMX Status menu, then select clear value or hold
value by pressing [UP] or [DOWN] button
Display mode
press ENTER button when show the Display Mode menu, then select auto or on by
pressing [UP] or [DOWN] button
3. System info
Temperature
press ENTER button when show the Temperature menu, then it will show the
temperature of the xture
Fixture time
press ENTER button when show the Fixture time menu, then it will show how long
time of the xture already used

Manual | Storm 300 RGBW
4. Color menu
press ENTER button when show the Color menu, press Enter button to select the
color mode, then adjust the color by pressing [UP] or [DOWN] button
5. White balance
press ENTER button when show the white balance menu, press Enter button to select
the color mode, then adjust the color by pressing [UP] or [DOWN] button
6. Auto test
press ENTER button when show the auto test menu, select test mode by pressing [UP]
or [DOWN] button
DMX functions and values
1CH Mode
Ch Value Function
1 0-255 Static color
2CH Mode
Ch Value Function
10-7 Blackout
8-15 Shutter Open
16-151 Strobe
152-175 Fade In
175-199 Fade Out
200-244 Random Strobe
245-255 Shutter Open
20-255 Master Dimmer
3CH Mode
Ch Value Function
1 0-255 Red
2 0-255 Green
3 0-255 Blue

Manual | Storm 300 RGBW
4CH Mode
Ch Value Function
1 0-255 Red
2 0-255 Green
3 0-255 Blue
4 0-255 White
6ch Mode
Ch Value Function
1 0-7 Blackout
8-15 Shutter Open
16-151 Strobe
152-175 Fade In
176-199 Fade Out
200-244 Random Strobe
245-255 Shutter Open
2 0-255 Master dim
3 0-255 Red
4 0-255 Green
5 0-255 Blue
6 0-255 White
8chF Modee
Ch Value Function
1 0-255 Red
2 0-255 Fine Red
3 0-255 Green
4 0-255 Fine Green
5 0-255 Blue
6 0-255 Fine Blue
7 0-255 White
8 0-255 Fine White
9chF Modeet
Ch Value Function
1 0-255 Master Dimmer
2 0-255 Red
3 0-255 Fine Red
4 0-255 Green

Manual | Storm 300 RGBW
5 0-255 Fine Green
6 0-255 Blue
7 0-255 Fine Blue
8 0-255 White
9 0-255 Fine White
10 chF Mode
Ch Value Function
10-255 Master Dimmer
2 0-255 Fine Master Dimmer
3 0-255 Red
4 0-255 Red dimmer ne
5 0-255 Green
6 0-255 Green dimmer ne
7 0-255 Blue
8 0-255 Blue dimmer ne
9 0-255 White
10 0-255 White dimmer ne
10 chD Mode
Ch Value Function
1
0-7 Blackout
8-15 Shutter Open
16-151 Strobe
152-175 Fade In
175-199 Fade Out
200-244 Random Strobe
245-255 Shutter Open
20-255 Master dim
30-255 Red1
40-255 Green1
50-255 Blue1
60-255 White1
70-255 Red2
80-255 Green2
90-255 Blue2
10 0-255 White2

Manual | Storm 300 RGBW
14CH Mode
Ch Value Function
10-255 Master Dimmer
2 0-255 Red1
3 0-255 Green1
4 0-255 Blue1
5 0-255 White1
6 0-255 Red2
7 0-255 Green2
8 0-255 Blue2
9 0-255 White2
10 0-15 Shutter Open
16-255 Strobe (fast to slow)
11 0-255 Color macro, color+black
12
0-35 Shutter Open
36-71 Fade Out
72-107 Fade In
108-143 Fade In and Out
144-179 Color mix
180-215 Four Color Flow
216-255 Eight Leds Flow
13 0-255 Dimmer Speed
14
0-63 Linear
64-127 Square
128-191 Invert Square
192-255 S-Curve
15CH Mode
Ch Value Function
10-255 Master dim
2 0-255 Master Dimmer ne
3 0-255 Red
4 0-255 Red dimmer ne
5 0-255 Green
6 0-255 green dimmer ne
70-255 Blue
8 0-255 blue dimmer ne
9 0-255 White
10 0-255 white dimmer ne
11 0-15 No strobe
16-255 Strobe (fast to slow)
12 0-255 Color Macro color+black

Manual | Storm 300 RGBW
13
0-35 Shutter Open
36-71 Fade Out
72-107 Fade In
108-143 Fade In and Out
144-179 Fade By SIN Curve
180-215 Four Color Flow
216-255 Eight Leds Flow
14 216-255 Dimmer speed
15
0-63 Linear
64-127 Square
128-191 Invert square
192-255 S-curve
CLEANING AND MAINTENANCE
We recommend a frequent cleaning of the device. Please use a soft lint-free and moistened cloth. Never use
alcohol or solvents!
CAUTION! Disconnect from mains before starting maintenance operation.
There are no servicable parts inside the device. Maintenance and service operations are only to be carried out
by authorized dealers. If you need any spare parts, please use genuine parts.
If the power supply cable of this device becomes damaged, it has to be replaced by authorized dealers only in
order to avoid hazards. If you have further questions, please contact your dealer.
INSTALLATION
The device must only be installed at a vibration-free, oscilation-free and re-resistant location.

Manual | Storm 300 RGBW
Das Lichttechnikhaus Vertriebs GmbH
Rudolf-Diesel-Str. 3, D-89312 Günzburg
Telefon [phone]
Fax [phone]
E-Mail [email protected]
Web www.lth-gmbh.de
