Show Tec Sunstrip LED V1 User manual

Sunstrip LED V1
Highlite International B.V. –Vestastraat 2 –6468 EX –Kerkrade –the Netherlands
Ordercode: 30752
MANUAL
ENGLISH

1
Ordercode: 30752
Sunstrip LED
Table of contents
Warning ...............................................................................................................................................................................2
Safety Instructions .........................................................................................................................................................2
Operating Determinations ..........................................................................................................................................4
Rigging ............................................................................................................................................................................4
Connection with the mains.........................................................................................................................................5
Return Procedure..........................................................................................................................................................6
Claims..............................................................................................................................................................................6
Description of the device.................................................................................................................................................7
Front.................................................................................................................................................................................7
Back.................................................................................................................................................................................8
Installation...........................................................................................................................................................................8
Setup and Operation ........................................................................................................................................................8
Control Modes...............................................................................................................................................................9
One Sunstrip (Auto, Manual) ...................................................................................................................................9
Multiple Sunstrips (Master/Slave control) ..............................................................................................................9
Multiple Sunstrips (DMX Control) ...........................................................................................................................10
Fixture Linking...............................................................................................................................................................11
Data Cabling...............................................................................................................................................................11
Control Panel ...............................................................................................................................................................12
Control Mode ..............................................................................................................................................................12
DMX Addressing ..........................................................................................................................................................12
Menu Overview...........................................................................................................................................................13
Main Menu Options....................................................................................................................................................15
1. DMX Address ........................................................................................................................................................16
2. DMX Mode ............................................................................................................................................................16
3. Pixel Invert .............................................................................................................................................................16
4. Dimmer Mode ......................................................................................................................................................17
5. Dimmer Curve ......................................................................................................................................................17
6. Dimmer Speed .....................................................................................................................................................18
7. Control Mode .......................................................................................................................................................18
7.1. DMX Control ......................................................................................................................................................18
7.2. Manual Control.................................................................................................................................................18
7.3. Auto Control ......................................................................................................................................................19
7.4. Master & Slave ..................................................................................................................................................19
7.5. Auto Test.............................................................................................................................................................19
8. Settings...................................................................................................................................................................20
8.1. DMX Fail..............................................................................................................................................................20
8.2. Display ................................................................................................................................................................20
8.3. Temperature......................................................................................................................................................21
8.4. Fixture Hours.......................................................................................................................................................21
8.5. Firmware Version ..............................................................................................................................................21
8.6. Factory Reset.....................................................................................................................................................21
DMX Channels .............................................................................................................................................................22
1 channel ..................................................................................................................................................................22
2 channels .................................................................................................................................................................22
3 channels .................................................................................................................................................................22
10 channels...............................................................................................................................................................22
20 channels...............................................................................................................................................................23
Maintenance....................................................................................................................................................................24
Replacing the Fuse.....................................................................................................................................................24
Troubleshooting ...............................................................................................................................................................25
No Light.........................................................................................................................................................................25
No Response to DMX..................................................................................................................................................25
Product Specifications....................................................................................................................................................27
Dimensions........................................................................................................................................................................28
Notes ..................................................................................................................................................................................29

2
Ordercode: 30752
Sunstrip LED
Warning
Unpacking Instructions
Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure
that all parts are present, and have been received in good condition. Notify the dealer immediately and
retain packing material for inspection if any parts appear damaged from shipping or the carton itself
shows signs of mishandling. Save the carton and all packing materials. In the event that a fixture must be
returned to the factory, it is important that the fixture be returned in the original factory box and packing.
Your shipment includes:
●Showtec Sunstrip LED
●2 mounting brackets incl. screws
●Pro power to Schuko power cable (1,3 m)
●User manual
LED Expected Lifespan
LEDs gradually decline in brightness over time. HEAT is the dominant factor that leads to the acceleration
of this decline. Packaged in clusters, LEDs exhibit higher operating temperatures than in ideal or singular
optimum conditions. For this reason, when all color LEDs are used at their fullest intensity, life of the LEDs is
significantly reduced. If improving the lifespan is of higher priority, place care in providing for lower
operational temperatures. This may include climatic-environmental and the reduction of overall
projection intensity.
Safety Instructions
Every person involved with the installation, operation and maintenance of this device has to:
●be qualified
●follow the instructions of this manual
Before the initial start-up, please make sure that there is no damage caused by transportation.
Should there be any, consult your dealer and do not use the device.
To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to
follow the safety instructions and warning notes contained in this manual.
Please consider that damages caused by manual modifications to the device are not subject to
warranty.
This device contains no user-serviceable parts. Refer servicing to qualified technicians only.

3
Ordercode: 30752
Sunstrip LED
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual or any unauthorized modification to the device.
●Never let the power cord come into contact with other cables! Handle the power cord and all
connections with the mains with particular caution!
●Never modify, bend, mechanically strain, put pressure on, pull or heat up the power cord.
●Never strain the cable. There must always be sufficient cable going to the device. Otherwise, the
cable will be damaged, which can cause serious damage.
●Never remove warning or informative labels from the unit.
●Never use anything to cover the ground contact.
●Never lift the device holding it by the projector-head, as the mechanics may be damaged. Always
hold the device by the transport handles.
●Never place any material over the LEDs or lens.
●Never look directly into the light source.
●Never leave any cables lying around.
●Never use the device during thunderstorms, unplug the device immediately.
●Never leave various parts of the packaging (plastic bags, polystyrene foam, nails, etc.) within
children’s reach, as they are potential sources of danger.
●Do not insert objects into air vents.
●Do not open the device and do not modify the device.
●Do not connect this device to a dimmer pack.
●Do not switch the device on and off in short intervals, as this will reduce the device’s life.
●Do not touch the device’s housing bare-handed during its operation (housing becomes very hot).
Allow the device to cool for at least 5 minutes before handling.
●Do not shake the device. Avoid brute force when installing or operating the device.
●Only use the device indoors, avoid contact with water or other liquids.
●Only operate the device after having checked if the housing is firmly closed and all screws are tightly
fastened.
●Only operate the device after having familiarized with its functions.
●Avoid flames and do not put close to flammable liquids or gases.
●Always keep the case closed while operating.
●Always allow a free air space of at least 80 cm around the unit for ventilation.
●Always disconnect power from the mains, when device is not used or before cleaning! Only handle
the power cord holding it by the plug. Never pull out the plug by tugging the power cord.
●Make sure that the device is not exposed to extreme heat, moisture or dust.
●Make sure that the available voltage is not higher than stated on the rear panel.
●Make sure that the power cord is never crimped or damaged. Check the device and the power
cord from time to time.
●Make sure that the core diameter of extension cords and power cords is sufficient for the required
power consumption of the device.
●If the lens or LEDs are obviously damaged, they need to be replaced to prevent their functions from
being impaired, due to cracks or deep scratches.
●If the external cable is damaged, it has to be replaced by a qualified technician.
●If device was dropped or struck, disconnect mains power supply immediately. Have a qualified
engineer inspect for safety before operating.
●If device has been exposed to drastic temperature fluctuation (e.g. after transportation), do not
switch it on immediately. The arising condensation water might damage your device. Leave the
device switched off until it has reached room temperature.
●If your Showtec device fails to work properly, discontinue the use immediately. Pack the unit securely
(preferably in the original packing material), and return it to your Showtec dealer for service.
●For adult use only. The device must be installed beyond the reach of children. Never leave the unit
running unattended.
●Never attempt to bypass the thermostatic switch or fuses.
●For replacement use fuses of same type and rating only.
●The user is responsible for correct positioning and operating of the device. The manufacturer will not
accept liability for damages caused by the misuse or incorrect installation of this device.
●This device falls under protection class I. Therefore it is essential to connect the yellow/green
conductor to earth.

4
Ordercode: 30752
Sunstrip LED
●Repairs, servicing and electric connection must be carried out by a qualified technician.
●WARRANTY: Till one year after date of purchase.
Operating Determinations
●This device is not designed for permanent operation. Consistent operation breaks will ensure that the
device will serve you for a long time without defects.
●The minimum distance between light output and the illuminated surface must be bigger than 80 cm
meter.
●To eliminate wear and improve lifespan, during periods of non-use, completely disconnect from
power via breaker or by unplugging.
●The maximum ambient temperature ta= 40 °C must never be exceeded.
●The relative humidity must not exceed 50 % with an ambient temperature of 40 °C.
●If this device is operated in any other way than the one described in this manual, the product may
suffer damages and the warranty becomes void.
●Any other operation may lead to dangers like short-circuit, burns, electric shock, crash, etc.
You endanger your own safety and the safety of others!
Rigging
Please follow the European and national guidelines concerning rigging, trussing and all
other safety issues.
Do not attempt the installation yourself !
Always let the installation be carried out by an authorized dealer !
Procedure:
●If the Sunstrip is lowered from the ceiling or high joists, professional trussing systems have to be used.
●Use a clamp to mount the Sunstrip with the mounting bracket, to the trussing system.
●The Sunstrip must never be fixed swinging freely in the room.
●The installation must always be secured with a safety attachment, e.g. an appropriate safety net or
safety cable.
●When rigging, derigging or servicing the Sunstrip, always make sure, that the area below the
installation site is secured and that there are not any unauthorized people around.

5
Ordercode: 30752
Sunstrip LED
The Sunstrip LED can be placed on a flat stage floor or mounted to any kind of truss with clamps.
Improper installation can cause serious injuries and/or damage of property!
Connection with the mains
Connect the device to the mains with the power-plug.
Always check if the right color cable is connected to the right place.
International
EU Cable
UK Cable
US Cable
Pin
L
BROWN
RED
YELLOW/COPPER
PHASE
N
BLUE
BLACK
SILVER
NEUTRAL
YELLOW/GREEN
GREEN
GREEN
PROTECTIVE
GROUND
Make sure that the device is always properly connected to the earth!
Improper installation can cause serious injuries and/or damage of property!

6
Ordercode: 30752
Sunstrip LED
Return Procedure
Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.
Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned
without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.
Call Highlite 0031-455667723 or mail [e-mail] and request an RMA prior to shipping the
fixture. Be prepared to provide the model number, serial number and a brief description of the cause for
the return. Be sure to properly pack fixture, any shipping damage resulting from inadequate packaging is
the customer’s responsibility. Highlite reserves the right to use its own discretion to repair or replace
product(s). As a suggestion, proper UPS packing or double-boxing is always a safe method to use.
Note: If you are given an RMA number, please include the following information on a piece of paper
inside the box:
01) Your name
02) Your address
03) Your phone number
04) A brief description of the symptoms
Claims
The client has the obligation to check the delivered goods immediately upon delivery for any short-
comings and/or visible defects, or perform this check after our announcement that the goods are at their
disposal. Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be
reported to the carrier upon receipt of merchandise.
It is the customer's responsibility to report and submit claims with the shipper in the event that a fixture is
damaged due to shipping. Transportation damage has to be reported to us within one day after receipt
of the delivery.
Any return shipment has to be made post-paid at all times. Return shipments must be accompanied with
a letter defining the reason for return shipment. Non-prepaid return shipments will be refused, unless
agreed otherwise in writing.
Complaints against us must be prepared in writing or sent by fax within 10 working days after receipt of
the invoice. After this period complaints will not be handled anymore.
Complaints will only then be considered if the client has so far complied with all parts of the agreement,
regardless of the agreement from which the obligation is resulting.

7
Ordercode: 30752
Sunstrip LED
Description of the device
Features
The Sunstrip LED is the successor of the already popular Sunstrip Active. Thanks to Tungsten mode, the
Sunstrip LED works like conventional bulbs while it is still possible to operate it in Warm white, Cool white or
in a combination of both.
●Input voltage: 110–240 V AC, 50/60 Hz
●Power consumption: 120 W
●Light source: 10 x 14W (Warm/Cool Prolight Opto)
●Control modes: Auto, Manual, Master/Slave, DMX
●DMX channels: 1, 2, 3, 10, 20 channels
●OLED display for easy setup
●Control protocol: DMX-512
●Dimmer: 0–100 %
●Strobe: 0–20 Hz
●IP rating: IP20
●Power connector: Pro power connector IN/OUT
●Data connector: 3-pin/5-pin XLR IN/OUT
●Fuse: T2AL/250V
●Dimensions: 1085 x 146 x 166 mm (LxWxH) (incl. brackets)
●Weight: 7 kg
Note: Knowledge of DMX is required to fully utilize this unit.
Optional accessories
D7039 –Case for 12 x Sunstrip Active
D7240 –Case for 8 x Sunstrip Active (Premium Line)
D7510 –Case for 8 x Sunstrip Active
Front
Fig. 01
01) 10 x 14 W (Warm/Cool Prolight Opto)
02) Adjustment screw
03) Mounting bracket

8
Ordercode: 30752
Sunstrip LED
Back
Fig. 02
04) Cooling fan
05) Safety eye
06) 5-pin DMX signal connector OUT
07) 3-pin DMX signal connector OUT
08) Pro power connector Gray OUT
09) Ground/earth connection
10) OLED display + control buttons
11) Fuse T2AL/250V
12) 3-pin DMX signal connector IN
13) 5-pin DMX signal connector IN
14) Pro power connector Blue IN
15) Power switch ON/OFF
Installation
Remove all packing materials from the Sunstrip LED. Check if all foam and plastic padding is removed.
Connect all cables.
Do not supply power before the whole system is set up and connected properly.
Always disconnect from electric mains power supply before cleaning or servicing.
Damages caused by non-observance are not subject to warranty.
Setup and Operation
Follow the directions below, as they pertain to your preferred operation mode.
Before plugging the unit in, always make sure that the power supply matches the product specification
voltage. Do not attempt to operate a 110 V specification product on 240 V power, or vice versa.
Connect the device to the main power supply.

9
Ordercode: 30752
Sunstrip LED
Control Modes
There are 4 modes:
●Auto
●Manual
●Master/Slave
●DMX-512 (1CH, 2CH, 3CH, 10CH, 20CH)
One Sunstrip (Auto, Manual)
01) Fasten the effect light to a firm trussing. Leave at least 0,8 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Plug the end of the electric mains power cord into a proper electric power supply socket.
04) When the Sunstrip is not connected with a DMX cable, it functions as a stand-alone device.
Please see pages 18–19 for more information about Auto mode and Manual mode.
Multiple Sunstrips (Master/Slave control)
01) Fasten the effect light onto firm trussing. Leave at least 0,8 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Use a 3-pin/5-pin XLR cable to connect the Sunstrip.
The pins:
01) Earth
02) Signal –
03) Signal +
01) Earth
02) Signal –
03) Signal +
04) N/C
05) N/C
04) Link the units as shown in fig. 03. Connect the first unit's DMX "out" socket with the second unit's "in"
socket, using a DMX signal cable. Repeat this process to link the second, third and fourth units.
You can use the same functions on the master device as described on page 18–19 (Auto mode,
Manual mode). This means that you can set your desired operation mode on the master device
and all slave devices will react the same as the master device.
Multiple Sunstrips (Master/Slave control)
Fig. 03

10
Ordercode: 30752
Sunstrip LED
Multiple Sunstrips (DMX Control)
01) Fasten the effect light to a firm trussing. Leave at least 0,8 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Use a 3-pin/5-pin XLR cable to connect the Sunstrips and other devices.
04) Link the units as shown in fig. 04. Connect the first unit's DMX "out" socket with the second unit's "in"
socket, using a DMX signal cable. Repeat this process to link the second, third and fourth units.
05) Supply electric power: Plug electric mains power cords into each unit's Pro power socket, then plug
the other end of the mains power cord into proper electric power supply sockets, starting with the
first unit. Do not supply power before the whole system is set up and connected properly.
Multiple Sunstrips DMX Setup
Fig. 04
Note : Link all cables before connecting electric power

11
Ordercode: 30752
Sunstrip LED
Fixture Linking
You will need a serial data link to run light shows of one or more fixtures using a DMX-512 controller or to
run synchronized shows of two or more fixtures set to a master/slave operating mode. The combined
number of channels required by all the fixtures on a serial data link determines the number of fixtures the
data link can support.
Important:
Fixtures on a serial data link must be daisy-chained in a single line. To comply with the
EIA-485 standard, no more than 30 devices should be connected on one data link.
Connecting more than 30 fixtures on one serial data link without the use of a DMX optically
isolated splitter may result in deterioration of the digital DMX signal.
Maximum recommended DMX data link distance: 100 meters
Maximum recommended number of fixtures on a DMX data link: 30 fixtures
Maximum recommended number of fixtures on a power link @ 110V: 14 fixtures
Maximum recommended number of fixtures on a power link @ 240V: 28 fixtures
Data Cabling
To link fixtures together, you must obtain data cables. You can purchase DAP Audio certified DMX cables
directly from a dealer/distributor or construct your own cable. If you choose to create your own cable,
please use data-grade cables that can carry a high quality signal and are less prone to electromagnetic
interference.
DAP Audio DMX Data Cables
●DAP Audio Basic microphone cable for allround use. bal. XLR/M 3-pin > XLR/F 3-pin.
Ordercode FL01150 (1,5 m), FL013 (3 m), FL016 (6 m), FL0110 (10 m), FL0115 (15 m), FL0120 (20 m).
●DAP Audio X-type data cable XLR/M 3-pin > XLR/F 3-pin. Ordercode FLX0175 (0,75 m),
FLX01150 (1,5 m), FLX013 (3 m), FLX016 (6 m), FLX0110 (10 m).
●DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL71150 (1,5 m), FL713 (3 m), FL716 (6 m), FL7110 (10 m).
●DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL7275 (0,75 m), FL72150 (1,5 m), FL723 (3 m), FL726 (6 m), FL7210 (10 m).
●DAP Audio 110 Ohm cable with digital signal transmission. Ordercode FL0975 (0,75 m),
FL09150 (1,5 m), FL093 (3 m), FL096 (6 m), FL0910 (10 m), FL0915 (15 m), FL0920 (20 m).
●DAP Audio data cable FL08 DMX/AES-EBU, XLR/M 5-pin > XLR/F 5-pin.Ordercode FL08150 (1,5 m),
FL083 (3 m), FL086 (6 m), FL0810 (10 m), FL0820 (20 m).
●DAP Audio DMX adapter: 5-pin/3-pin. Ordercode FLA29.
●DAP Audio DMX adapter: 3-pin/5-pin. Ordercode FLA30.
●DAP Audio DMX Terminator 3-pin. Ordercode FLA42.
●DAP Audio DMX Terminator 5-pin. Ordercode FLA43.

12
Ordercode: 30752
Sunstrip LED
The Sunstrip LED can be operated with a controller in control mode or without the controller in stand-
alone mode.
Control Panel
A) OLED display
B) MENU button
C) UP button
D) DOWN button
E) ENTER button
Fig. 05
Control Mode
The fixtures are individually addressed on a data-link and connected to the controller.
The fixtures respond to the DMX signal from the controller. (When you select the DMX address and save it,
the controller will display the saved DMX address, next time.)
DMX Addressing
The control panel on the back side of the device allows you to assign DMX fixture addresses, which is the
first channel with which the Sunstrip will respond to the controller.
Please note, when you use the controller, the unit has 20 channels.
When using multiple Sunstrips, make sure you set the DMX addresses right.
Therefore, the DMX address of the first Sunstrip should be 1(001); the DMX address of the second Sunstrip
should be 1+20=21 (021); the DMX address of the third Sunstrip should be 21+20=41 (041), etc. Please, be
sure that you do not have any overlapping channels in order to control each Sunstrip correctly. If two or
more Sunstrips are addressed similarly, they will work similarly.
Controlling:
After having addressed all Sunstrips, you may now start operating these via your lighting controller.
Note: After switching on, the Sunstrip will automatically detect whether DMX 512 data is received or not.
If there is no data received at the DMX input, the “LED“ on the control panel will not flash.
If not, the problem may be:
●The XLR cable from the controller is not connected with the input of the Sunstrip.
●The controller is switched off or defective, the cable or connector is detective, or the signal wires are
swapped in the input connector.
Note: It is necessary to insert an XLR termination plug (with 120 Ohm) in the last fixture in order to ensure
proper transmission on the DMX data link.
Display Off after 60 seconds
The display turns off after 60 seconds of inactivity. See 8.2. Display on page 20 for further information.
Press the MENU, UP, DOWN or ENTER button to light up the display.

13
Ordercode: 30752
Sunstrip LED
Menu Overview

14
Ordercode: 30752
Sunstrip LED

15
Ordercode: 30752
Sunstrip LED
Main Menu Options
01) Upon start-up, the display will show the current version of the device.
02) After 3 seconds, the display will show the current device status.
03) You can now view whether or not the Sunstrip receives a DMX signal. You can also view the currently
selected operation mode, the DMX starting address, the dimmer mode and the dimming curve type.
04) Press the MENU button to open the main menu. The display will show:
05) Press the UP/DOWN buttons to toggle through the 8 menus.
06) Press the ENTER button to open the desired menu.

16
Ordercode: 30752
Sunstrip LED
1. DMX Address
In this menu you can set the desired DMX starting address.
01) Press the ENTER button to open the menu. The display will show:
02) Press the UP/DOWN buttons to set the desired DMX address. The adjustment range is between 001–
512.
03) Press the ENTER button to confirm.
2. DMX Mode
In this menu you can set the desired DMX channel mode.
01) Press the UP/DOWN buttons to choose one of the 5 DMX channel modes:
●1-channel mode
●2-channel mode
●3-channel mode
●10-channel mode
●20-channel mode
02) Press the ENTER button to confirm.
3. Pixel Invert
In this menu you can set the pixel direction.
01) Press the UP/DOWN buttons to select NORMAL or INVERT.
02) Press the ENTER button to confirm.

17
Ordercode: 30752
Sunstrip LED
4. Dimmer Mode
In this menu you can set the dimmer mode.
01) Press the UP/DOWN buttons to choose one of the 3 dimmer modes:
●WARM
●COOL
●TUNGSTEN
02) Press the ENTER button to confirm.
5. Dimmer Curve
In this menu you can set the dimming curves.
01) Press the UP/DOWN buttons to choose one of the 4 dimming curves:
●LINEAR
●S-CURVE
●SQUARE
●TUNGSTEN
02) Press the ENTER button to confirm.

18
Ordercode: 30752
Sunstrip LED
6. Dimmer Speed
In this menu you can set the dimmer speed.
01) Press the UP/DOWN buttons to choose one of the 2 dimmer speeds:
●NORMAL
●SMOOTH
02) Press the ENTER button to confirm.
7. Control Mode
In this menu you can set the desired control mode.
01) Press the UP/DOWN buttons to choose one of the 5 control modes:
●DMX CONTROL
●MANUAL CONTROL
●AUTO CONTROL
●MASTER & SLAVE
●AUTO TEST
02) Press the ENTER button to confirm.
7.1. DMX Control
In this menu you can control the Sunstrip with a DMX controller.
01) Press the ENTER button to confirm.
7.2. Manual Control
In this menu you can set levels of Cool and Warm.
01) Press the UP/DOWN buttons to choose one of the 2 options:
●WARM LEVEL
●COOL LEVEL
02) Press the ENTER button to confirm.
03) Press the UP/DOWN buttons to set the intensity of cool or warm light. The adjustment range is
between 0–255, from dark to brightest.

19
Ordercode: 30752
Sunstrip LED
7.3. Auto Control
In this menu you can set the built-in programs and a fade.
01) Press the UP/DOWN buttons to choose one of the 10 built-in programs or the fade.
02) Press the ENTER button to confirm.
03) Press the UP/DOWN buttons to set the program speed. The adjustment range is between 0–100%,
from slow to fast.
04) Press the ENTER button to confirm.
7.4. Master & Slave
In this menu you can set the device as a master or a slave.
01) Press the UP/DOWN buttons to choose MASTER or SLAVE.
02) Press the ENTER button to confirm.
03) If you have chosen MASTER, the device will send DMX signals to the connected slave devices.
04) If you have chosen SLAVE, the device will receive DMX signals from the master device and will react
the same as the master device.
7.5. Auto Test
In this menu, the device will run a function test.
01) Press the ENTER button to start the test.
02) Press the ENTER button again, to stop the test.
