SSANGYONG KYRON 2006.03 User manual

GENERAL INFORMATION
0000-00
GENERAL INFORMATION
GENERAL INFORMATION
1. HOW TO READ ELECTRICAL WIRING
DIAGRAM...............................................
2. LAYOUT OF ELECTRICAL SYSTEM.....
3
6

0-3
GENERAL INFORMATION
KYRON 2006.03
0000-00
GENERAL INFORMATION
1. HOW TO READ ELECTRICAL WIRING DIAGRAM
Position Explanation
A- Upper horizontal lines : Power supply lines
- Power supply lines : 30, 15, 15A, 15C, 58
B
- Ef20 or F2 : Fuse Number
·Ef20 : Fuse No #20 in engine room compartment
·F2 : Fuse No #2 in passenger room compartment
C
- Connector (C101 ~ C903)
·Connector No C203 terminal No1
·Refer to Major Connector Position (Section 2)
D- S201 : Splice pack (S201 ~ S207)
·Refer to Major Splice Pack Position (Section2)
E- Wiring Harness Color
·Refer to Wiring Harness Color Abbreviation
F- Internal circuit of component (Relay)
(Component Name and Terminal Number)
G- Internal circuit of component (Switch)
(Component Name, Terminal Number and Connecting Wiring Circuit)
H
- Lower horizontal line : Ground line
·Ground position (G101 ~ G402)
·B : Body Ground
·Refer to Major Ground Position (Section2)
1) HOW TO READ ELECTRICAL WIRING DIAGRAM
2) CONTENTS OF ELECTRICAL WIRING DIAGRAM (CIRCUIT)

0-4
KYRON 2006.03
0000-00
GENERAL INFORMATION
3) CIRCUIT IDENTIFICATION SYMBOL
Identification Symbol Meaning
C Connector
D Diode
Ef Fuse in engine room fuse & relay box
F Fuse in passenger room fuse box
G Ground
S Splice pack (Junction connector)
5) WIRING HARNESS COLOR IDENTIFICATION
Abbreviation Color Abbreviation Color
Br Brown Sb Sky Blue
G Green R Red
V Violet L Blue
P Pink Y Yellow
W White Gr Gray
Gr Orange B Black
Lg Light Green
6) HOW TO CHECK TERMINAL NUMBER OF CONNECTOR
Terminal number is given based on Female Terminal Male Connector
▶
ex) Terminal Number 4 of C901 connection-
Power supply No. Power supply condition
15 Battery Voltage (B+) supply in Ignition Switch “ON” and “ST” (IGN
1)
15A Battery Voltage (B+) supply in Ignition Switch “ON” (IGN 2)
15C Battery Voltage (B+) supply in Ignition Switch “ON” and “ACC”
30 Battery Voltage (B+) supply directly regardless of Ignition Switch
31 Ground connected to battery (-)
58 Battery Voltage (B+) supply in Head Lamp Switch 1st and 2nd step
(Illumination circuit)
4) FUNCTION OF POWER SUPPLY LINE (NUMBER)

0-5
GENERAL INFORMATION
KYRON 2006.03
0000-00
7) PART LOCATION ACCORDING TO PART NUMBER
Ex.) C 1 0 2
▶
C : Symbol character for connector-
Symbol Character Description
C Connector (Connecting part that connects two wiring harness)
D Diode
G Ground
S Splice pack (Joint connector that connects various wiring harness)
1 : Part location number-
Part number according to locating section-
Part Numbe Location
□ 1□□ Engine compartment
□ 2□□ Instrument panel
□ 3□□ Passenger compartment
□ 4□□ Tailgate
□ 5□□ Underbody
In the locating section, the assignment for part number startsfrom left bottom and
proceeds clockwise.
In the fuse and relay box or the instrument panel, the partnumber is assigned from
left top to light bottom.
-
-
8) ELECTRIC SYMBOLS

0-6
KYRON 2006.03
0000-00
GENERAL INFORMATION
S/Roof Unit / Motor
Rain Sensing Unit
(Auto Light)/ECM Sensor Cluster
Air-Bag ECU
Curtain
Air-Bag Sensor
Incar SensorENG ECU / SSPS Unit
PAS Unit
Driver Seat Memory SW TCCU / TCU
Under the I/P (Driver Seat) SSPS Sensor (D27DT) / Immobilizer
1) POSITION OF INTERIOR UNIT & SENSOR
SSPS Sensor Immobilizer
Curtain Air-Bag
Module
TV ANT AMP Sun Sensor
Curtain Air-Bag
Module
DVD Changer
Sub
Woofer
TV ANT AMP
DSP AMP
TV Tuner
TCCU TCU
SSPS Unit
(Under the ENG ECU)
DR Lock Relay
Chime
PAS
Buzzer STICS
2. LAYOUT OF ELECTRICAL SYSTEM

0-7
GENERAL INFORMATION
KYRON 2006.03
0000-00
2) ENGINE ROOM SWITCH, UNIT & SENSOR
FFH Ass’y
Receiver Dryer/
Tripple Pressure SW
Horn (RH)
AQS Sensor/
Ambient Temp Sensor (FFH)
ESP Pressure Sensor 1,2 ABS (ESP) HECU
IWE Solenoid Valve (4WD)
Fuse & Relay Box
Burglar Horn
(Under the BATT)
Horn (LH)
AQS/
AmbientSensor
Ambient Temp
Sensor (FFH)
(Under the BATT TRAY)

0-8
KYRON 2006.03
0000-00
GENERAL INFORMATION
Steering Wheel Remocon SW
O/S Mirror SW Bezel Ass’y
Driver Seat Memory SW P/Window Main SW (Driver)
Hazard SW Bezel Ass’y
Center Fascia SW
Passenger P/Window SW
4WD SW
Driver Seat
Warmer SW
Passenger Seat
Warmer SW
HDC SW
TRIP SW
Hazard SW
Deicer SW
RR DEF SW/
O/S Mirror DEF SW
ESP OFF
SW
O/S Mirror Fold’g SW
Audio
Remocon SW Audio
Remocon SW
Room Lamp Main SW
S/Roof SW
RR Fog
Lamp SW
O/S
Mirror SW
3) INTERIOR SWITCH O/S Mirror SW Bezel Ass’y Steering
S/Roof SW

0-9
GENERAL INFORMATION
KYRON 2006.03
0000-00
4) AV SYSTEM
DVD + Tape
Woofer
Position: Upper the G/Box panel
Etc Audio Head Unit
6pcs INDASH CD+TAPE+RADIO CD+RAIDIO
6pcs Indash
Tape
CD Insert
AV SYSTEM
DSP/AMP
Tuner
TV ANT AMP (RH)
Radio ANT AMP
Audio
Remocon
Center Speaker
DVD Changer

0-10
KYRON 2006.03
0000-00
GENERAL INFORMATION
A/Con
Module
Ass’y
5) A/CON SYSTEM
Type A/Con Controller
FATC
Manual A/C
Sun Sensor
(Upper the IP LH)
AQS Mode SW Compressor AQS/Ambient
Temp Sensor
Condensor
Coolant Temp Sensor
ENG ECU
Receiver Dryer (LH)
Mode
A
ctuato
r
W/H A/Con
Control Unit W/H Main
Intake Sensor
Power TR
Coolant Temp Sensor
Air Mix Actuator
Intake
Actuator
A/C Filter
AQS
Sensor
Ambient
Temp Sensor
Heater Unit
Blower Unit

0-11
GENERAL INFORMATION
KYRON 2006.03
0000-00
AIR-DUCT LAY-OUT
▶W/H A/CON MODULE ▶
Coolant Temp Sensor
Intake Actuator
Power TR
Blower Motor
Intake Air Temp.
Sensor
Air-Mix
Actuator
W/H Main
Connector
Incar Sensor
A/Con Control Unit
Mode Actuator
A/Con Wiring Setting

CONNECTOR/GROUND
8201-00/8210-00/8210-02/8210-03/8210-09/8210-10/8210-06/8210-07/8210-08
CONNECTOR/GROUND
WIRING
8201-00 WIRING HARNESS,
COMPONENTS LOCATION.........
CONNECTOR/GROUND
8210-00 W/H ENGINE ROOM.....................
8210-02 W/H MAIN.....................................
8210-03 W/H FLOOR..................................
8210-09 W/H ROOF....................................
8210-10 W/H TAIL GATE...........................
8210-06 W/H DRIVER DOOR......................
8210-07 W/H PASSENGER DOOR.............
8210-08 W/H RR DOOR..............................
3
19
20
21
23
23
24
24
25

0-3
CONNECTOR/GROUND
KYRON 2006.03
8201-00
WIRING HARNESS
8201-00 WIRING HARNESS, COMPONENTS LOCATION
1) WIRING HARNESS 2) COMPONENTS LOCATION

0-4
KYRON 2006.03
8201-00
CONNECTOR/GROUND
3) CONNECTOR, GROUND & SPLICE PACK INFORMATION
CONNECTOR
▶

0-5
CONNECTOR/GROUND
KYRON 2006.03
8201-00
GROUND
▶SPLICE PACK ▶

0-6
KYRON 2006.03
8201-00
CONNECTOR/GROUND
4) SPLICE PACK CIRCUIT
S101
▶
S201
▶
S202 (CAN)
▶
S203 (GND)
▶
S204 (ILL+)
▶
S205 (GND)
▶

0-7
CONNECTOR/GROUND
KYRON 2006.03
8201-00
S206
▶
S301 (CAN)
▶
S302
▶
S303
▶

0-8
KYRON 2006.03
8201-00
CONNECTOR/GROUND
5) CONNECTOR
C104
▶
C105
▶
C106
▶
C101
▶
C102
▶
C103
▶
