Ssl DD888 User manual

To ensure safety while driving
and to comply with laws,
drivers should not watch video or
operate the video device while driving.

-1-
Content.................................................................................................
Installation diagram..............................................................................
Wiring diagram......................................................................................
General knowledge about remote control...............................................
Locations and Names of controls on main unit......................................
Locations and Names of controls on remote control..............................
Same functions in any work source........................................................
Radio operation....................................................................................
Disc/USB/card operation......................................................................
1. Loading or unloading a disc, USB or card........................................
1.1 Loading a disc, USB or card...........................................................
1.2 Unloading a disc, USB or card.......................................................
2. Popping up Function Icons-board...................................................
2.1 Function Icons-board of Digital Video/VCD/MPEG4/Image
/MP3/WMA.....................................................................................
2.2 CD interface..................................................................................
3. Function of controls on the touch screen/main unit/remote
control............................................................................................
AUX/AV operation..................................................................................
Rear View Camera................................................................................
Troubleshooting..................................................................................
Specification.......................................................................................
1
2
3
4
5
6
7
10
13
13
13
14
14
14
15
16
25
26
27
28
Content

-2-
Installation diagram
MOUNTING BRACKET
MOUNTING BRACKET
MOUNTING BOLTS
Installation diagram
HEX NUT
SPRING WASHER
PLAIN WASHER
TAPPING SCREW
DASH BOARD
METAL MOUNTING
STRAP
CONSOLE
HEX BOLT
PLASTIC FRAME

-3-
Wiring diagram
NOTE:
1. Must use 4 ohms impedance of speakers.
2. After connecting parking Line, video on screen of control panel
will be displayed only after
3. Before finishing wiring, do not attach control panel onto chassis.
applying parking brake.
IGNITION SWITCH
RED
WHITE
WHITE/BLACK
GREY
GREY/BLACK
GREEN
GREEN/BLACK
VIOLET
VIOLET/BLACK
YELLOW
CONSTANT 12 VOLTS
BLACK
GROUND(B-)
BLUE
AUTO ANTENNA
FRONT
Lch SPK.
REAR
Lch SPK.
FRONT
Rch SPK.
REAR
Rch SPK.
BROWN
(B-) PARKING BRAKE
PINK
RADIO ANTENNA JACK
(B+) 12V
REAR CAMERA SWITCH
REAR CAMERA INPUT
YELLOW
GREY
SUB WOOFER
AUDIO R OUT (red)
AUDIO L OUT (white)
VIDEO OUTPUT (brown)
FUSE
Wiring diagram
ISO CONNECTOR
RCH IN RED
LCH IN WHITE
VIDEO IN YELLOW
AUX 2

1. Removing insulating sheet
If
)
)
)
.
)
)
)
.
)
)
using remote control for the first time, you
can see an insulating sheet at the bottom
side of remote control as right.
you must remove the insulating sheet as right.
Otherwise, the remote control is disabled.
2. Replace lithium cell
If the electric energy of lithium cell is weak,
replace it.
1 Press and hold the movable block as direction
indicated by arrow 1 as right, at one time pull
cell holder out of remote control as direction
indicated by arrow 2 as right.
2 Replace the old cell by a new one with (+)
polarity side upward as right.
3 Insert the cell holder into remote control again
as right.
3 Note about using remote control
1 You should face the emitting window of remote control towards the sensor
window of the unit.
2 Operation angle for front panel: About 30 degree
3 The distance between the emitting window of remote control and the sensor
window of the unit : < 5M .
4 Warning for lithium cells of remote control
leakage may cause damage to remote control.1 Cell
2Do not throw cells into fire, it may cause explosion.
.
3.To avoid risk of accident, keep cells out of reach of children.
GENERAL KNOWLEDGE ABOUT REMOTE CONTROL
-4-
General knowledge about remote control

-5-
Locations and names of controls on main unit
Control Panel
Top Front View Drawi ng after Flipping down Control Panel
1. POWER or SOURCE BUTTON
2.
4.
MUTE BUTTON
>|| or CH1~6 BUTTON
3. RESET BUTTON
SEL BUTTON and VOL KNOB
5. OPEN BUTTON
6. USB PORT and COVER
7. AUX IN JACK
8.
9. EQ BUTTON
10. BAND BUTTON
11. REL BUTTON
12. IR SENSOR WINDOW
13. DISC SLOT
14. EJECT BUTTON
15. CARD SLOT
Front View Drawi ng after Removing Control Panel
14
13
15
1
7
2
3
4
6
9
8
10
11
12
5

Locations and Names of Controls on Remote Control
-6-
16. VOL- BUTTON
17. SEL BUTTON
18. SETUP BUTTON
19. GOTO BUTTON
20. >|| BUTTON
21. STOP BUTTON
22. AUDIO or MO/ST BUTTON
23. ANGLE BUTTON
24. EQ BUTTON
25. CLK BUTTON
26. ^ BUTTON
27. >>| BUTTON
29. > BUTTON
30. V BUTTON
31. |<< BUTTON
32. INT or 3 BUTTON
33. 6 BUTTON
34. +10 BUTTON
35. AF or 9 BUTTON
36. TA or 0 BUTTON
37. 2 BUTTON
38. 5 BUTTON
39. 7 and 8 BUTTON
28. ENTER BUTTON
1. POWER BUTTON
2. MUTE BUTTON
3. REPEAT BUTTON
4. ZOOM BUTTON
5. SOURCE BUTTON
6. MENU or SW BUTTON
7. >> BUTTON
8. SUBTITLE or LO/DX BUTTON
9. < BUTTON
BAND or OSD
<< BUTTON
12. A/PS or TITLE/PBC BUTTON
13. TOP or 1 BUTTON
14. VOL+ BUTTON
15. RDM or 4 BUTTON
10. BUTTON
11.
1
2
6
10
11
3
20
21
33
9
12
17
34
23
4
5
7
8
13
14
15 16
18
19
22
24
25
26
27
28
29
30
31
32
35
36
37
38
39
SRC

-7-
Same functions in any work source
Same functions in any work source
1. POWER button and icon
In power off mode, pressing POWER button on remote control or pressing POWER button on
control panel powers on main unit.
In power on mode, pressing POWER button on remote control or long pressing POWER button
on control panel or touching icon on source menu(see Source menu fig.on next page)
powers off main unit.
2. VOL knob & VOL+/VOL- buttons
To adjust volume level, rotate VOL knob on control panel or press or hold VOL+ or VOL- button
on remote control.
3. SEL button
To switch between BASS,TREBLE,BALANCE, FADE,COLOR,BRIGHTNESS,CONTRAST, TINT
and VOLUME, briefly and repeatedly press SEL button.
After switching on the desired mode above, rotate VOL knob or press VOL+/VOL- buttons to set it.
To switch between REG, PI, TA, AF, LOUD, SWF, EQ, DX/LOCAL(in radio mode), STEREO/
MONO(in radio mode), TIME 12H/24H, CLOCK, BUZZ,EUR/USA FREQ,ANIMATION and BG,
long press SEL button to switch on REG, then briefly and repeatedly press SEL button.
After switching on the desired mode above, rotate VOL knob or press VOL+/VOL- buttons to set it.
4. MUTE button
To switch MUTE mode on or off, press MUTE button on remote control or on control panel.
5. EQ button
To select a desired preset EQ mode from JAZZ, CLASSIC, POP , ROCK and USER, press EQ
button on remote control or on control panel continuously.
6. To switch LOUD mode
To switch on or off LOUD mode, long press EQ button on remote control .
7. SW button
To switch on or off SUBWOOFER mode, long press SW button on remote control.
8. CLK button
Press CLK button on remote control to display clock time .
9. SOURCE button and source menu
To switch work source between RADIO, DISC(after inserting a disc), USB(after inserting a USB
storage), CARD(after inserting a card), AUX IN and AV IN. Press SOURCE button on remote control or
on control panel continuously.
During disc(non-CD)/USB/card playback, touch screen to pop up Function Icons-board and then
touch the icon in the Function Icons-board to enter the source menu(refer to Disc/USB/Card
Operation) .
During AUX IN or AV IN playback, touch screen to pop up AUX interface and then touch icon to
enter the source menu(refer to AUX/AV Operation).
In radio or CD mode, touch icon to enter the source menu(refer to Radio Operation and Disc/
USB/Card Operation).

-8-
Same functions in any work source
The source menu displays as follows:
In source menu, touch one icon of AUX, RADIO, DISC, SD CARD and USB to enter one
work source of RADIO, DISC, AUX IN, AV IN,SD CARD and USB.
10. SETUP icon
1) SETTING SYSTEM
In source menu, touch SETUP icon to display SYSTEM page of SETUP menu as follows:
In the SYSTEM page of SETUP menu, repeatedly touch the or icon to highlight one setting
item of BRIGHTNESS, CONTRAST, COLOR, TINT, ANIMATION and WALLPAPER. After highlighting a
desired setting item, touch the or icon to set it.
2) SETTING SOUND
In SETUP menu, touch SOUND icon to display SOUND page of SETUP menu as follows:
Source Menu
System page of SETTING menu
Sound page of SETTING menu
COLOR
TINT
CONTRAST
16
BASS
TREBLE
+03
BALANCE
