Ssl SD364B User manual

3.6” Bluetooth-Enabled In-Dash
DVD/MP3/CD Receiver with USB, SD
Memory Card Ports and Front Panel AV Input

E - 1
1. HANDLING COMPACT DISCS
MOISTURE CONDENSATION
NOTES ON CDs
P. 2
P. 3
P. 4
P. 1 P. 6
P. 7
1.
2.
3.
4.
5.
Stickers that are beginning
to peel away leave a
sticky residue (P.6).
Labels are attached (P.7).
On a rainy day or in a very damp area, moisture may condense on the lenses inside the unit.
Should this occur, the unit will not operate properly. In such a case, remove the disc and wait for
about an hour until the moisture has evaporated.
A dirty or defective disc may cause sound
dropouts while playing. To enjoy optimum
sound, handle the disc as follows.
Handle the disc by its edge. To keep the disc
clean, do not touch the surface (P.1).
Do not stick paper or tape on the disc (P.2).
Before playing, clean the discs with an
optional cleaning cloth. Wipe each disc from
the centre out (P.4).
Do not use solvents such as benzine,
thinner,commercially available cleaners, or
antistatic spray intended for analog discs.
Do not expose the discs to direct sunlight or
heat sources such as hot air-ducts, or leave
them in a car parked in direct sunlight where
there can be a considerable rise in
temperature inside the car (P.3).
Do not use CDs with old labels that are
beginning to peel off.
Do not use CDs with labels or stickers
attached.
**************
*******
*******
*******
*******
*******
*******
*******
*******
Do Not Use Special Shape CDs
Be sure to use round shape CDs only. Do
not use any special shape CDs. Use of
special shape CDs may cause the unit to
malfunction.(P.8).
P. 8
CD-Rs and CD-RWs which have not
undergone finalization processing cannot
be played. (For more information on
finalization processing, refer to the manual
for your CD-R/CD-RW writing software or
CD-R/CD-RW recorder.) Additionally,
depending on the recording status, it may
prove impossible to play certain CDs
recorded on CD-R or CD-RW.
E - 1
P. 5
NOTES ON DISCS
If you use the discs explained below, the sticky
residue can cause the CD to stop spinning and
may cause malfunction or ruin your discs.
Do not use CDs that have a sticky residue on the
surface (for example, from peeled-off stickers or
from ink, or glue leaking from under the
stickers).
****
*******
******* *******
*******
Paste or sticky residue.

E - 2
2. INSTALLATION
Before finally installing the unit, connect the wiring temporarily and make sure it is all
connected up properly and the unit and system work properly.
Use only the parts included with the unit to ensure proper installation. The use of
unauthorized parts can cause malfunctions.
Consult with your nearest dealer if installation requires the drilling of holes or other
modifications of the vehicle.
Install the unit where it does not get in the driver's way and cannot injure the passenger if
there is a sudden stop, like an emergency stop.
If installation angle exceeds 30 from horizontal, the unit might not give its optimum
performance.
Avoid installing the unit where it would be subject to high temperature, such as from direct
sunlight, or from hot air, from heater, or where it would be subject to dust dirt or excessive
vibration.
Be sure to remove the front panel before installing the unit.
DIN FRONT/REAR-MOUNT
This unit can be property installed either from “Front” (conventional DIN Front-mount) or
“Rear”(DIN Rear-mount installation, utilizing threaded screw holes at the sides of the unit
chassis). For details, refer to the following illustrated installation methods A and B.
DIN FRONT-MOUNT (Method A)
Installation the unit
1. Dashboard
2. Holder
After inserting the half sleeve into the dashboard,
select the appropriate tab according to the
thickness of the dashboard material and bend
them inwards to secure the holder in place.
3. Screw
30
1
7
4
23
5
61. Dashboard
2. Nut (5mm)
3. Spring washer
4. Screw (4x12mm)
5. Screw
6. Support Strap
Be sure to use the support strap to secure the
back of the unit in place. The strap can be bent by
hand to the desired angle.
7. Plain washer
182
53
12
3
Removing the unit
a. Frame
b. Insert fingers into the groove in the front of frame
and pull out to remove the frame. (When re-
attaching the frame, point the side with a groove
down wards and attach it.)
c. Insert the levers supplied with the unit into the
grooves at both sides of the unit as shown in
figure until they click. Pulling the levers makes it
possible to remove the unit from the dashboard.
a
b
c
Trim Plate Installation:
Push the trim plate against the chassis until it is fitted.
You must do this before you install the front panel, otherwise it can't be attached.
RCA LINE OUT JACK(OPTION)

E - 3
DIN REAR-MOUNT (METHOD B)
Installation using the screw holes on the sides of the unit.
Fastening the unit to the factory radio mounting bracket.
1. Select a position where the screw holes of
the bracket and the screw holes of the main
unit become aligned (are fitted) and tighten
the screws at 2 places on each side.
2. Screw(must not use more than 6mm length)
3. Factory radio mounting bracket.
4. Dashboard or Console
5. Hook (Remove this part)
Note: the mounting box, outer trim ring,
and half-sleeve are not used for method B
installation.
5
2
4
3
25
PANEL OPEN/CLOSE OPERATION
1. Press Open button
2. The CD slot will be accessible.
3. After CD is loaded or unloaded return the panel to its original position.
12
RESET
CDIN

E - 4
Attaching the Detachable Control panel (D.C.P.)
3. DETACHABLE CONTROL PANEL (D.C.P.)
PUSH
B
A
DC
1. Attach the panel at the Left side first,
with point B on the main unit touching
point A on the D.C.P
(As shown on the diagram).
2. And then also attach the panel at the
right side , with point C on the main unit
touching point D on the D.C.P as well
(As shown on the diagram)
3. Then press the left side of D.C.P onto the
main unit until a “click” sound is heard.
Removing The Detachable Control Panel (D.C.P.).
OPEN
BUTTON
D.C.P.
1. Turn the power off.
2. Press the panel open button,
the D.C.P will be fold down.
3. Push hard the D.C.P in the left direction
until the point D at the right side of D.C.P
is came off the main unit
(As shown on the diagram).
3. Remove the D.C.P.
D

CAUTION
DO NOT insert the D.C.P from the right side. Doing so may damage it.
The D.C.P can easily be damaged by shocks. After removing it, place it in a protective case and be careful not
to drop it or subject it to strong shocks.
When the open button is pressed and the D.C.P is unlocked, the car's vibrations may cause it to fall. To prevent
damage to the D.C.P, always store it in a protective case after detaching it.
The rear connector that connects the main unit and the D.C.P is an extremely important part. Be careful not to
damage it by pressing on it with fingernails, pens, screwdrivers, etc.
Note:
If the D.C.P is dirty, wipe off the dirt with soft,
dry cloth only. And use a cotton swab soaked
in isopropyl alcohol to clean the socket on the
back of the D.C.P.
Socket
E - 5

E - 6
4. ELECTRICAL CONNECTION
a. Make sure your car battery is a 12 volt (6 filler caps) negative ground system (if not, a
converter will be necessary).
b. Before starting wiring connections, disconnect the power supply by removing the fuse from
the fuse box.
c. Connect the power wire to one of the extra terminals of the fuse box.
d. Connect the black ground wire to a metal part of the car. It is important to make good contact.
e. Make other wiring connections as shown.
FUSE
Fuse Replacement:
To replace the fuse, pull out the blown fuse
from the socket. Insert a new one with same rating
(CAR UNIT BACK SIDE)
Initial installation of the unit when all wiring is completed.
All the function buttons do not operate.
Error symbol on the display.
RESET BUTTON
RED
WHITE
(REAR)
RCA OUTPUT
RED
WHITE
(FRONT)
RCA OUTPUT
ANTENNA
CONNECTOR
GREY
BLACK
VIDEO OUT (1)/(2)
AUDIO IN RED
WHITE
YELLOW
YELLOW
VIDEO IN YELLOW
REVERSE VIDEO IN YELLOW
GREY
GREY / BLACK
VIOLET
VIOLET / BLACK
FRONT
RIGHT
SPEAKER
REAR
RIGHT
SPEAKER
WHITE
WHITE / BLACK
GREEN
GREEN/BLACK
FRONT
LEFT
SPEAKER
REAR
LEFT
SPEAKER
MAIN UNIT
BLUE
AUTO ANT.
SUB-WOOFER
GOUND ( )
BLUE
(+)
12V+
SWITCHED
12V+
CONSTANT
YELLOW
(FUSED)
BLACK
RED
GREY
PINK
PARKING BRAKE(-)
ORANGE
REVERSE(+12V)
OVERRIDE WIRE
f. If your car does not have ISO connector, you can purchase it from car accessory shops.
Notes: INCORRECT WIRING OR OPERATION WILL VOID THE WARRANTY OF THIS UNIT.
The RESET button is located on the main unit (as shown on the diagram). Press it vertically
with a ballpoint pen or metal object to activate it. The reset button should be activated for the
following reasons:
Note: If you press the RESET button, and the unit still cannot function normally, please use a
cotton swab soaked in isopropyl alcohol to clean the socket on the back of the control panel.

5
E - 7
LOCAL/
DX
BUTTON
SCAN
BUTTON
FM
STEREO /
MONO
BUTTON
TALK
BUTTON
POWER/
MUTE
BUTTON
HANG UP/
MODE
BUTTON
PANEL
OPEN
BUTTON
ENCODER
VOLUME
KNOB
PRESET MEMORY BUTTONS
(M1-M6)
AMS
BUTTON
BAND/
LOUDNESS
BUTTON
CD
PAUSE
BUTTON
FUNCTION
SELECT
BUTTON
INFRARED
REMOTE
SENSOR
TUNING /
SEEK
UP/DOWN
NEXT/BACK
BUTTON
CD
SCAN
BUTTON
CD
RANDOM
BUTTON
CD
REPEAT
BUTTON
DSP/
LEFT/
RIGHT
BUTTON
DISPLAY
BUTTON
APL/
NTSC/

E - 8
B. FUNCTION OF REMOTE

6. BASIC OPERATION
E - 9
POWER BUTTON
Press power button to turn on/off the unit.
DISPLAY BUTTON(DISP)
Press this button to remove the control panel.
PANEL RELEASE BUTTON
Press this button briefly,the LCD will display the clock for about 5 seconds, then return to
previous display mode.
Clock Adjustment
Under clock display mode,press DISP button until the LCD flashes,USE VOLUME UP/DOWN to
Adjust hour & minute,press sel button to change the hour & minute.
MUTE BUTTON ( MUTE)
Press MUTE button to mute the sound quickly. the display is flashing Press it again to restore the
previous sound level. When mute is on, the Mute indicator on the LCD will light up.
LOUDNESS BUTTON (LOUD)
Long press this LOUD button control to increase bass output.
MODE BUTTON
Press this button to select radio, DISC/USB/SD/MMC/A/V-IN FRONT/A/V-IN Rear.
(MODE)
SELECT BUTTON (SEL)
press SEL button for less than 1 second to open the Audio menu.
press SEL repeatedly to navigate through the following functions:
VOLUME (VOL) -> BASS (BAS) -> TREBLE (TRE) -> BALANCE (BAL) -> FADER (FAD)->SUB-
WOOFER(SUB-W)
Press Volume Up/Down to adjust desired level within 5 seconds.
NOTE: BASS AND TREBLE WILL BE SKIPPED IF DSP MODE IS ACTIVATED
ENCODER VOLUME KNOB
Turn this knob to adiust desired volumelevel.
PRESET EQUALIZER BUTTON (DSP)
Press this PEQ button then use V-UP / V-DN to toggle the following EQ settings.
POP -> ROCK -> CLASSIC -> DSP OFF
At DSP off mode preset equalizer will be controlled by Bass / Treble setting.
The unit is allowed to connect the with external Audio /
Video system such like Digital Camera or Game Console.
You can connect the external A/V system thru the A/V in
jack on front panel. After connect with external A/V
system, pressing mode to “A/V IN FRONT” to enjoy this
external A/V system on this unit.
FRONT PANEL A/V IN JACK
NOTE: The unit is only support the 3.5mm A/V Jack Pin Assignment shown as the diagram delete
extra "."
3.5mm A/V Cable ( not included )
Video
Right Audio
Left Audio
Ground
1
2
3
4

E - 10
8. RADIO OPERATION
Use this control to select stereo or mono reception for FM radio stations. You can sometimes improve
reception of distant stations by selecting mono mode.
FM MONO / STEREO BUTTON (MONO)
LOCAL / DX BUTTON (LOC)
This control can be used to change between Local and Distant (-DX) tuning mode. Local mode
improves reception in some areas where the signal is too strong.
STATION PRESET BUTTONS (M1-M6)
You can store & recall six preset radio stations by pressing M1-M6 buttons
TO STORE A STATION: 1) select a band (if needed)
2) select a station by tuning up / down button
3) hold a preset button which you want store the station for at least 2
seconds. The preset number will appear on the display accompanied by
a beeps sound.
TO RECALL A STATION: 1) select a band (if needed)
2) press a preset button briefly to recall the stored station.
SCAN BUTTON (SCAN)
Press this button, the radio will tune up to search stations, the available stations will blinking and stay
on the display for a few seconds.
AUTO MEMORY STORE / PRESET SCAN BUTTON (AMS)
PRESET SCAN: press AMS button for less than 1 second to scan all preset stations in the memories
of the current band and stay on each memory stations for about 5 seconds. The
memory location indicator on the LCD will flash during the process. To stop preset
scan, press AMS button again.
AUTO MEMORY STORE: press AMS button for more than 1 second to enter auto store mode. The
radio will automatically store 6 stations to the 6 preset memories of the current band. To stop auto
store, press AMS button again.
BAND BUTTON (BAND)
Press this button to change between band FM1, FM2, FM3 or MW(AM)1, MW(AM)2 bands .
TUNING UP / DOWN BUTTON ( )
Press this button to search for radio stations. Depends on whether SEEK1 or SEEK 2 mode is
selected, different operations can be performed, refer to “SEEK MODE” paragraph for detail.
DUAL FREQUENCY SWITH
Unit is defaulted in U.S.A. Frequency, if EURO frequency is required, a sharp pen is needed to switch
the button on the left side of the chassis to EURO frequency.
US EU

9. Blue Tooth Hand Free Panel / Remote Control Function Key Matrix
E - 11
Panel Function Button Blue Tooth Hand Free Function
TALK
1
2HANG UP/MODE
(short press)
Please refer to the page E-16 Item 1 & 2.
1. Reject Incoming call
2. End a call
Remote control Button Blue Tooth Hand Free Function
1TALK
Make an Outgoing call press “TALK” Button once to ready
input the Tel number what you want to phone and the tel
number you dialed will be showed on the Display. Once you
press the “TALK” again to dial the number and the “DIALING”
will,be showed on display. During the talking mode, the Display
will showed “TALKING”.
2HANG UP/STOP
(short press)
1. Reject incoming call
2. End a call
3Numberic Key
1. For tel dialing (During make an out going call)
2. For “CLEAR/+10” key if you have wrong input the Tel number,
you can use this key to correct the wrong number on the
display before you send the TEL number out.
TALK BUTTON HANG UP/STOP
(short press)
NUMBERIC KEY FOR TEL
DIALING BUTTONS
1
TALK
BUTTON
HANG UP/MODE
BUTTON
(Short Press)
2
12
3

E - 12
3. WHAT DISPLAY CAN SHOW DURING THE INCOMING/OUTGOING CALL MODE
User can use his / her Mobile Phone or remote control to dial and make an outgoing call .
Once the user start dialing, the display should show “DIALING”.
The audio output of the present mode will ONLY be muted after pressing the “TALK” button
as a confirmation to dial the outgoing call.
During talking mode, the LCD Display will display “TALKING”.
To end the conversation, press the “CANCEL (MODE)” button or “(STOP)” at the Remote
control and the “Hang up” will showed on display. The unit and the display on the LCD will
switch back to the previous mode automatically. The mute of the previous mode will be
released at the same time.
When there is an incoming call, the display will display the “Incoming caller telephone
number” If the incoming call has no caller number, the LCD will display “00000000” user can
short press the “TALK” button answer / accept the call and the “Talking”display will be
showed when the call is answered.
To end the conversation, press the “CANCEL(MODE” or “(STOP)” at the Remote control and
the “Hang up” will showed on display. The unit and the display on the LCD will switch back
to the previous mode automatically.
INCOMING CALL
OUTGOING CALL
INSTRUCTION FOR HANDSFREE FUNCTION
BLUETOOTH MODE OPERATION
1. PAIR IT WITH YOUR PHONE (PAIRING)
Before you use your Car HANDSFREE System,you need to pair it with your mobile phone.
1. The Bluetooth set system on the head unit will automatically go into pairing mode when the
Ignition is being turned on and the Bluetooth symbol indicator on the display will
Flash every 1 second.
2. Set your Bluetooth phone to ‘discover’ the “CAR_A2DP_HF”.
3. Your phone will find the “CAR_A2DP_HF”.
Your phone then asks if you want to pair with it. Accept by pressing ‘Yes’ or ‘OK’ on the phone
and confirm with the passkey or PIN=0000 (4 zeros). Your phone will confirm when pairing is
complete. The Bluetooth symbol will stop flashing and stay lit.
In case of unsuccessful pairing, repeat steps 1 to 3 .
2. OPERATION
Call Accept: Single click TALK button during an incoming call to accept the call.
Call Reject: Click “CANCEL”(MODE) or (STOP) on the remote during an incoming call will
reject the call.
Call End: Single click TALK button when communication or dialing an outgoing call to hang
up.
Call Disconnect: Click TALK button about 1.5 seconds when it is not in communication
mode. “And Disconnect” and “No LINK” will showed on the display.
Call Re-connect,Click TALK button again at the Disconnect Status. The connection will be
reconnected and “LINKING” & “LINK OK” will showed on the display.
Call Waiting (Depend on provider feature): Double click TALK button at communicating time,
enter into call waiting, double click it again, enter into communication mode.
Call Transfer (Private mode): Click TALK button about 1.5 seconds at communicating time,
transfer the call to phone, click talk button once again, transfer the call to Bluetooth.
Last Number Redial: Double click TALK button when not in call automatically redial the last
number.
Auto Answer (Depend on mobile phone feature): Pls refer to your own mobile phone manual
for handsfree auto answer setting.
Volume Adjust: User can use the volume up/down to adjust the volume level.

E - 13
4. BLUETOOTH NOTICE
Before you start to use our Bluetooth HEAD UNIT , Please pair the unit with your mobile
phone completely. Please refer to the section of “PAIRING” To ensure the best reception for
Pairing & Re-connection, please make sure the phone Battery is fully charged when making
the pairing or Re-connection.
Every time you turn the ignition key from off to on, the unit will automatically re-connect with
the mobile phone.
By pressing the TALK button the unit will start the Auto-Reconnection . In some conditions,
the user will need to reconnect manually. For example like the following.
If the mobile phone is out of range. (2 meters away from the head unit) the unit will be
disconnected from the mobile phone.
If user wants to re-connect, it will have to be done manually.
LISTENING TO MUSIC USING CAR-A2DP-HF ON THE BT AUDIO MODE
CAR-A2DP-HF is capable of streaming music over Bluetooth from a mobile phone
supporting A2DP. Press the mode button to select Bluetooth BT audio mode, once you have
paired your Car Handsfree with your mobile phone, use your phone to play, pause, stop,
skip forward and backward. When you receive a call, the music will be automatically paused
and you will be able to answer or reject a call through the headset. Once you end a call, the
music will continue. On some phones you may have to press ‘play’ to start the music again.
The LCD display of the head unit should show “A2DP” when playing music with CAR-A2DP-
HF.
And you can also make an outgoing call (This function is compatible with some phones
which can make outgoing calls during the A2DP mode.)
The Bluetooth symbol (...) and the connected symbol (< / >) on the mobile phone will be
different from one to another. Please refer to the corresponding specification.
The LED turns on when an audio connection exists (e.g. talking) or when it is ringing.
When the main unit turns on, if there is a call incoming, it will auto switch to talk state.
When you hang up the phone, the main unit will revert to previous state (radio, CD or other
mode).
When the main unit turns off (with ACC ON), if there is a call incoming, the main unit will
auto turn on and enter into talk mode. When hang up the phone, the main unit will turn off
automatically.
Some Mobile Phone Brands like Sony Ericsson may have "Power Saving Mode" selection
when Blue Tooth mode is switched on. PLEASE DO NOT Switch ON “Power saving Mode”
when operating with this Head Unit, . As some abnormal communication behavior will
happen Power Saving Mode is switched on.
To ensure the best conversation quality / performance, please always keep talking within 1
meter of the Head Unit.
Some Mobile Phones can support “IN BAND RING TONE”, such as Motorola, Nokia. In
such case, the Incoming Ringing Tone will be same as the original Ring-tone of the Mobile
Phone. But some Mobile Phones like Sony Ericsson do not support this feature. The Ring-
tone will be using the standard Ring-tone of the Head unit.
Using voice dialing, please make sure the phone and the ‘head unit within 3 meters of each
other. Also please make sure your mobile phone support voice dialing function. And please
consult with your mobile phone supplier if you want to know the operation further about
voice dialing.
If user wants to Dis-connect the Head unit with the Mobile Phone, please click talk button
long once or switch "OFF" Blue Tooth connectivity on the Mobile Phone.

BLUE TOOTH
Power Consumption
Output Power
Frequency Band
Range
Standard
200mA
0 dBm (Class II)
2.4GHz ~ 2.4835GHz ISM Band
3 meters (free space)
Bluetooth specification
Max.
2.0
Specifications for Blue tooth
Remark:
Our Bluetooth Handsfree System adapts to the Bluetooth spec V2.0 and higher. It is compatible
with profiles such as Handsfree profile and Head Set profile. However the functionality may be
limited due to some phones dedicated interfacing specifications, even with phones of which the
actual Bluetooth specifications and used profiles apply to our Bluetooth Handsfree System
specifications.
Please check the compatibility list or try it out in practice your phone at the local dealer in case
it is not mentioned in the list.
Note:
Compatibility and connectivity with all Bluetooth mobile phones is not guaranteed.
Warning:
Many jurisdictions have laws regarding the use of a phone in a vehicle environment. Obey all
local laws. Always keep your hands free to operate the vehicle while driving. Your first
consideration while driving should be road safety.
Specifications subject to change without notice.
E - 14

10. CD/MULTI-MEDIA FILE
Press this button to select Intro Scan function, the first 10 seconds of each track will be played
sequentially until this button is pressed again, then normal play will resume at the current track.
INTRO SCAN BUTTON (CD SCAN)
Press this button briefly to pause disc play, press again to resume play.
PLAY/PAUSE BUTTON ( )
RANDOM PLAY BUTTON(RDM)
When random play mode is selected, the tracks will be played in random order, press this key one
more time to cancel random play mode.
REPEAT BUTTON(RPT)
Pressing this button will activate Repeat Function in the following order :
Repeat On Repeat Off
The RPT indicator will turn on.
Long press the & buttons under the play mode, the unit will start to forward or rewind. you
can play discs at various speeds. with each consecutive long press the & buttons , the
playback speed increases. there are 5 speed levels for discs in FWD/REV: X2, X4, X8, X16,X20.
there are 4 speed levels for disc types other than disc: X2, X4, X8,X16.
Press PLAY to resume the playback at normal speed.
NEXT/BACK BUTTONS( & )
When NEXT is pressed, the unit will go to the next track and start the playback.
When BACK is pressed, the unit will go back to the previous track and start the playback.
E - 15
NOTE:This will only operate with the SCAN function play on CD.
LOADING THE CD
Press the Panel Open Button to fold down the front panel, insert the disc through CD slot, the
disc will be automatically loaded and playback will also start.
CD EJECT BUTTON
Press this button to eject the CD. Since this button is located behind the front panel, fold down
the panel before accessing this button.
RESET

MULTI-MEDIA FILE OR FOLDER SEARCHING
Selecting a Track to Play
1. Use the UP/DOWN/LEFT/RIGHT direction buttons to move to different file/folder
Numbers.
2. Press OK on a file number, and that file will begin to play, or by direct numeric input,
3. Enter a file number with the numeric buttons (0-9) and +10 button to play the input Files
Number.
E - 16
REPEAT A- REPEAT A- B REPEAT A-B CANCEL
REPEAT A-B BUTTON (A-B)
1. Press REPEAT A-B at your chosen starting point.
2. Press REPEAT A-B again at your chosen end point.
The section A and B can be set only within the same track.
The section will now repeat continuously.
3. To exit the sequence, press REPEAT A-B.
The screen willdisplay the followingmessage:
NOTE:This operate is with CD function only.
Stop the current disc playback.
Press STOP two times consecutively to enter the clear stop mode. Under the clear stop mode, if
PLAY is pressed, the disc will resume the playback from the beginning of the disc.
Briefly press the STOP button to stop the unit playback, when the PLAY
button is pressed, normal playback will continue.
STOP BUTTON( )
NUMERIC BUTTONS
When playback CD/MUSICuse for tracknumber or Filenumber direct accessand
Use when functionneed numeric Selectionor Input, likein the Gotofunction, etc.
UP/DOWN/LEFT/RIGHT BUTTON ( / / / )
Use to movecursor up/down/left/right.
OK BUTTON
Use this buttonto confirm theselection.
GO TO BUTTON (GO TO)
Using GO TOfeature to selecttrack number orspecific time.
A. Press GO TO button,the screen will display the following message:
B. Press ArrowLeft/Right buttons tohighlight the tracknumber or thetime option.
C. Use numericbuttons to enterthe track youwant to playor the elapsedtime you want to
go to inthat track.
D. Press OK button to start playback.For example, entering 00:01:56 will start playback one
minutes and fifty-sixseconds into thetitle.
TRK 001/021
A
00:01:56

PROGRAM BUTTON (PROG)
A. For example:Pressnumeric button 2,PROGRAM 0002 appearsit means track2 will be
player first thenpress numeric button4 and PROGRAM0004 appears,press thedifferent
numeric button toselect the correspondingtrack and thenyou can programtracks to your
need if youwant to completeprogram setting pressPLAY buttonto play tracksin
programmed order.
B.Press the ( / / / )buttons to highlightselect program modeor track numberand
press PLAYbutton to confirmit.
C.If you exitprogram mode andprogram off appearspress STOP buttonthen press PLAY
button.
ID3 INFORMATION DISPLAY
If any MUSIC file any ID3-TAG information, user can view these ID3-TAG information such
as Track title, Artist title, Album title, etc, These ID3-TAG information will be displayed on the lower
left hand corner of the TFT monitor.
contains
Press PROG buttonthe screen willdisplay the followingmessage.
PROG
PLAY
1 0002
3 ----
5 ---- 9 ----
13 ----
6 ---- 10 ---- 14 ----
7 ---- 11 ---- 15 ----
4 ---- 8 ---- 12 ---- 16 ----
2 0004
CLEAR
E - 17

11. PLAY MULTI-MEDIA FILES OPERATION
Place a disc into the player, and the player will auto search the directories saved files. After
searching, it will auto go to the first directory saved files (to the disc containing both Music and
photo files; To the disc containing single type of files, it will automatically go to the first directory) and
play the first song in the directory (“01:” is highlighted).The screen displays as the picture below:
Current directory name
Current file name.
The playing file is a Music File.
The playing file is a Photo File.
File Switch Region: Displays the file type of the playing
and the switching.
Use the Arrow ( / / / )buttons to enter the Directory Region and highlight the desired directory, then the
first track under it starts playback; Also you can use the Arrow( / / / ) buttons to enter the File Region and
select the file you want to play.
Press the Left and Right arrow buttons, you can activate Directory Region, File Region and
File Switch Region separately.
The highlight in Directory Region and File Region is shown as the picture above; While it
appears a transparent rectangle in File Switch Region.
You can press the Numeric buttons to select the file you want to play. For example, if you
th th
desire the 15 track in current list, press the “10+” button once, then press “5”, the 15
starts playback.
When a picture , press the Arrow buttons to change the display
angle:
is playing or paused
E - 18
NOTE:
NOTE:
