AN2544
Application note
Designing a low cost power supply using a
VIPer12/22A-E in a buck configuration
Introduction
Many appliances today use nonisolated power supply to furnish low output power required
to run a micro, LED display, and a few relays or AC switches. This type of power supply has
a single rectifier so as to reference the neutral to output ground in order to fire TRIACs or AC
switches. This article describes the use of the VIPer12A-E and the VIPer22A-E which are
pin-for-pin compatible and can supply power for many applications. This paper provides an
off-line, nonisolated power supply evaluation board based on the VIPer12/22A-E. Four
different examples are covered. The VIPer12A-E is used for 12 V at 200 mA and 16 V at 200
mA. The VIPer22A-E is used for 12 V at 350 mA and 16 V at 350 mA. The same board can
be used for any output voltage from 10 V to 35 V. For outputs less than 16 V, D6 and C4 are
populated and W1 is omitted. For outputs greater than 16 V, D6 and C4 are omitted and W1
is populated. For more design detail, see AN1357 "VIPower: low cost power sullies using
the VIPer12A-E in nonisolated application." The objective of this application note is to
familiarize the end user with this reference design and to quickly modify it for different
voltage output. This design gives:
■Lowest possible component count
■Integrated thermal overload protection
■About 200 mW at no-load consumption
■Efficiency measured between 70% to 80% at full load
■Integrated Short circuit protection
Figure 1. Evaluation board (STEVAL-ISA035V1)
Table 1. Operating conditions for the four samples
Board version (with changes) Output voltage and current
Input voltage range 85 Vac to 264 Vac
Input voltage frequency range 50/60 Hz
Output version 1 VIPer22ADIP-E 12 V at 350 mA 4.2 W
Output version 2 VIPer12ADIP-E 12 V at 200 mA 2.4 W
Output version 3 VIPer22ADIP-E 16 V at 350 mA 5.6 W
Output version 4 VIPer12ADIP-E 16 V at 200 mA 3.2 W
www.st.com

Contents AN2544
2/17
Contents
1 Circuit operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.1 Input line rectification and line conducted filter . . . . . . . . . . . . . . . . . . . . . . 4
1.2 Start circuit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.3 Inductor selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.4 Design example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.5 Design hints and trade-off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.6 Board layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.7 Burst mode in no-load or very light load . . . . . . . . . . . . . . . . . . . . . . . . . . 11
1.8 Short circuit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
1.9 Performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
1.10 EMI conducted . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2 Conclusion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3 Revision history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

AN2544 List of figures
3/17
List of figures
Figure 1. Evaluation board (STEVAL-ISA035V1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Figure 2. Inductor current: 470 µH VS 1000 µH. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Figure 3. Schematic for 12 V at 350 mA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Figure 4. Schematic for 16 V at 350 mA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Figure 5. Composite. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Figure 6. Top side . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Figure 7. Bottom side and surface mount components (viewed from top). . . . . . . . . . . . . . . . . . . . . . 9
Figure 8. Bad start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Figure 9. Good start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Figure 10. Burst mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Figure 11. Operation during a short . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Figure 12. Load regulations for 12 V output. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Figure 13. Line regulation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Figure 14. Efficiency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Figure 15. VIPer22-E, 12 V at 350 mA output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Figure 16. VIPer12-E, 12 V at 200 mA output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Figure 17. VIPer22-E, 16 V at 350 mA output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Figure 18. VIPer12-E, 16 V at 200 mA output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Circuit operation AN2544
4/17
1 Circuit operation
1.1 Input line rectification and line conducted filter
The circuit operations for all four versions are basically the same. The difference is in the
circuit for startup. Version 1 will be described here with reference to Figure 3. The output of
the converter is not isolated from the input. This makes neutral common to output ground
thus giving a reference back to neutral. The buck is less expensive due to the fact that it
does not use a transformer and an opto coupler. The AC line is applied through D1 which
rectifies the line input every other half cycle.
C1, L0, C2 form a pie filter to reduce EMI noise. The value of the capacitor is chosen to
maintain a reasonable valley, because the caps are charged every other half cycle. Two
diodes can be used in place of D1 to sustain burst pulses of 2 kV. R10 serves two purposes,
one is for inrush limiting and the other is to act as a fuse in case of a catastrophic failure. A
wire wound resistor handles the energy of the inrush. Flame proof resistor and a fuse can be
used depending on system and safety requirements. C7 helps the EMI by balancing line and
neutral noise without using an Xcap. This will pass EN55022 level "B". If the requirement is
less, then this cap can be left out of the circuit.
1.2 Start circuit
The voltage across C2 is fed to the drain, pin 5 through 8. Inside the VIPer, the constant
current source delivers 1mA to the Vdd pin 4. This current charges C3. When the voltage on
the Vdd pin reaches 14.5 V nominal, the current source turns off and the VIPer starts
pulsing. During this time, the energy is being supplied from the Vdd cap. The energy stored
must be greater than the energy needed to supply the output current plus the energy to
charge of the output capacitor, before the Vdd cap falls below 9 V. This can be seen in
Figure 8 and Figure 9. The value of the capacitor is therefore chosen to accommodate the
startup time. During a short circuit, the Vdd cap discharges below the minim value enabling
the internal high voltage current generator to initiate a new startup sequence. The charging
and discharging of the capacitor determine the time period that the power supply is to be on
and off. This reduces the RMS heating effect on all components. The regulation circuit
consists of Dz, C4 and D8. D8 peak charges C4 during the freewheeling time when D5 is
conducting. During this time, the source or reference to the VIPer is one diode drop below
ground, which compensates for the D8 drop. So basically the Zener voltage is the same as
the output voltage. C4 is connected across Vfb and source to filter the regulation voltage. Dz
is a BZT52C12, ½ W Zener with a specified test current of 5 mA. These Zeners that are
specified at a lower current give better accuracy of the output voltage. If the output voltage is
lower than 16 V, the circuit can be configured as in Figure 3 where Vdd is separated from the
Vfb pin. When the internal current source charges the Vdd cap, Vdd can reach 16V at worse
case condition. A 16 V Zener with a 5% low tolerance can be 15.2 V plus the internal
resistance to ground is 1230 Ωwhich is an additional 1.23 V for a total of 16.4 V. For 16 V
output and higher, the Vdd pin and the Vfb pin can share a common diode and capacitor filter
similar to Figure 4.

AN2544 Circuit operation
5/17
1.3 Inductor selection
A starting point for the inductor operating in discontinuous mode can be derived from the
following formula which gives a good approximation of the inductor.
Equation 1
Where Idpeak is the minimum peak drain current, 320 mA for the VIPer12A-E and 560 mA for
the VIPer22A-E, f is the switching frequency at 60 kHz. The maximum peak current limits
the power delivered in the buck topology. Therefore, the calculation above is for an inductor
that operates in discontinuous mode. If the current swings down to zero, than the peak
current is twice the output. This limits the output current to 280 mA for a VIPer22A-E. If the
inductor is a larger value, operating between continuous and discontinuous mode, we can
reach 200 mA comfortably away from the current limit point. C6 has to be a low ESR
capacitor to give the low ripple voltage
Equation 2
D5 needs to be a fast recovery diode but D6 and D8 can be standard diodes. DZ1 is used to
clamp the voltage to 16 V. The nature of the buck topology is to peak charge at no-load. A
Zener 3 to 4 V higher than the output voltage is recommended.
1.4 Design example
Figure 3 is the schematic for the evaluation board. It is set up for 12 V with a maximum
current of 350 mA. If less current is required, then the VIPer22A-E can be changed to a
VIPer12A-E and C2 can be decreased from 10 µf to 4.7 µF. This delivers up to 200 mA.
Figure 4 shows the same board but for 16 V output or higher, D6 and C4 can be left out. The
jumper bridges the output voltage to the Vdd pin.
1.5 Design hints and trade-off
The value of L determines the boundary condition between continuous and discontinuous
mode for a given output current. In order to operate in discontinuous mode, the inductor
value has to be lower than
Equation 3
Where R is the load resistance, T is the switching period, and D is the duty cycle.
There are two points to consider. One is, the more discontinuous the higher the peak
current. This point should be kept lower than the minimum pulse by pulse current limit of the
VIPer22A-E which is 0.56 A. The other is if we use a larger value inductor to run continuous
all of the time, we run into excess heat from switching losses of the MOSFET inside the
VIPer. Of course, the inductor current rating must be higher than the output current to
prevent the risk of saturating the core.
L2 Pout
Idpeak
()
2f•
--------------------------------
•=
Vripple Iripple Cesr•=
L1
2
---RT 1D–()•••=

Circuit operation AN2544
6/17
Figure 2. Inductor current: 470 µH VS 1000 µH
The blue trace is the current with 470 µH inductor and the purple trace is the current with a
1000 µH inductor.
On the above scope plot in Figure 2, the trace represents the current going through the
inductor. Current charges up the inductor during the time the MOSFET is on. At this time,
the source pin is the same as the rectified line input and the current is ramping up. At 350
mA output current, the peak of the current is 550 mA for a 470 µH inductor, the blue trace.
The worse case condition for the VIPer Idlim is 560 mA. So therefore we are close to the
pulse by pulse current limit trip point. This is manifested by the output voltage dropping as
the output current is being raised past the limit. 470 µH inductor is the minimum value that
can be used from the calculations for a 350 mA output. A good compromise is a 1000 µH
making the swing less, keeping the peak at 443 mA, away from the 560 mA current limit.
Looking at the purple trace the turn-on losses are increased and the turn-off losses are
decreased in the MOSFET inside the VIPer.
It is best to choose the inductor to give ½ the ripple current between discontinuous to
continuous. This is the best compromise when working close to the maximum current. The
trade-off is a little more heat for the safety margin away from the current trip point.
VIPer temperature rise with two different inductors at 350 mA is:
Table 2. VIPer temperature rise with different inductors
Inductor Maximum peak current VIPer22ADIP-E temperature rise
470 µH 550 mA 34 °C
1000 µH 443 mA 40.5 °C

AN2544 Circuit operation
7/17
Figure 3. Schematic for 12 V at 350 mA
Neutral
Line
DZ 12 V
L0
470 uH
L1
1 mH
C6 47 uF
50 V
Cx .022 50 V
C2 10 uF 400 V
C1 10 uF 400 V
R0 10 1 W
R1 1K
90 TO 264 VAC 12 V @350 mA
D1 S1MDICT
D8 S1MDICT
D5 STTH1R06A
D6 S1MDICT
U1
VIPer22ADIP-E
Drain
8
Drain
6Drain
7
Drain
5
Source
1Source
2Fb 3
Vdd 4
DZ1 16 V
For 12 V @ 200 ma change: C2 4.7 uF 400 V U1 VIPer12ADIP-E Jumper open
0
J1 2 pin
1 2J2
2 pin
1 2
Jumper = open
C7 0.1 u 1 KV
C3 4.7uF 25 V C4
0.47 uF 25 V

Circuit operation AN2544
8/17
Figure 4. Schematic for 16 V at 350 mA
DZ 16V 1N5246
U1
VIPer 22ADIP-E
Drain
8
Drain
6Drain
7
Drain
5
Source
1
Source
2Fb 3
Vdd 4
L0
470 uH
L1
1 mH
C6 47 uF 50 V
Cx .022
C2 10 uF 400 V
C1 10 uF 400 V
R0 10 1 W
R1 1K
90 TO 264 VAC
16 V @ 350 mA
D1
S1MDICT
D8
S1MDICT
D5 STTH1R06A ST
Line Neutral
DZ1 20 V
For 16 V @ 200 ma change: C2 4.7 uF 400 V U1 VIPer12ADIP-E
Jumper = Short circuit
0
J2 2 p
i
1 2
J1
2 pin 1
2
C7 0.1 u 1 KV
C3 4.7 uF 25 V

AN2544 Circuit operation
9/17
1.6 Board layout
A composite view of the board shows a double-sided board with surface mount components
on the bottom. The top is a ground plane which helps with EMI. The actual measurements of
the PC board are 55 mm by 23 mm.
Figure 5. Composite
Figure 6. Top side
Figure 7. Bottom side and surface mount components (viewed from top)

Circuit operation AN2544
10/17
The above board can be modified to any voltage output from 10 V to 15 V by changing DZ.
To modify the board to 16 or higher, D6 and C4 can be omitted and the jumper wire can be
installed. For 16 V operation or higher, Vdd and Vf can share the same source without
having the current leak through the Zener and Vf pin path. The output voltage can be
changed by changing DZ from 16 V Zener to a higher value matching the output voltage. If
less current is required, the board can be changed with a VIPer12A-E dip which is pin-for-
pin compatible with the VIPer22ADIP-E.
Also one of the input capacitors, C2, can be reduced to 4.7 µF. Various data and waveforms
from evaluation boards can be seen in the following pages.
The Vdd cap has to be sized according to the output load and the size of the output
capacitor.
Table 3. Bill of material for VIPer22A-E Buck 12 V at 350 mA
Item Qty Ref. Part V/W Description CAT#
1 1 Cx 0.022 50 V X7R +/-10% GP SM Ceramic
2 2 C1,C2 10 µF 400 V 105 C UCC
EKMG401ELL100MJ20S
3 1 C3 4.7 µF 25 V X7R +/-10% TDK C3216X7R1E475K
4 1 C4 0.47 µF 25 V X7R +/-10% TDK C2012X7R1E474K
5 1 C6 47 µF 50 V 105 C Low ESR Low ESR
6 1 C7 0.1 µ 1 kV X7R +/-15% Murata
GRM55DR73A104KW011
7 1 DZ 12 V zener BZT5212FDICT
8 1 DZ1 16 V zener BZT5216FDICT
9 3 D1,D6,D8 S1MDICT SM GP Diode 1 kV 1 A S1MD
10 1 D5 STTH1R06A 600 V 1 A Ultrafast STMicroelectronics
11 2 J1, J2 2 pin Mouser 651-1751099
12 1 L0 470 µH 140 mA JW Miller 5300-33
13 1 L1 1 mH 400 mA C o m p o s t a r Q 3 2 7 7 o r
JW Miller RL895-102K
14 1 R0 10 Ω1 W wire wound ALSR1J-10
15 1 R1 1 kΩ5% SM 1206 CERAMIC
16 1 U1 VIPer22ADIP-E STMicroelectronics
Table 4. Bill of material for VIPer22A-E Buck 16 V at 350 mA
For 16 V or higher operation.
Omit 1 D8 S1MDICT SM GP Diode
1 kV 1A S1MD
Omit 1 C4 0.47 µF 25 V X7R +/-10% TDK C2012X7R1E474K
Add 1 Jumper Wire jumper 24 AWG

AN2544 Circuit operation
11/17
The VIPer internal 1 mA current source charges up the Vdd capacitor. When the voltage on
the Vdd pin reaches the Vdd startup threshold (Worse case is 13 V) the VIPer starts pulsing,
raising the output voltage to the point of bootstrapping. The Vdd capacitor needs to supply
the energy to supply the necessary output current and to charge up the output capacitor,
before the Vdd voltage falls below the Vdd under voltage shutdown threshold (worse case is
9 V). Figure 8 and 9show a Vdd cap that is not large enough to start up the evaluation board
under a resistive load of 350 mA.
In Figure 8 the purple trace is the Vdd voltage rising to ~14 V. The energy with the 2.2 µF
capacitor does not store enough energy. As seen the output voltage (green trace) does not
reach high enough to bootstrap, It succeeds the second time after there is a partial charge
on the output cap. Figure 9 is using a 4.7 µF Vdd cap. With adequate energy the power
supply starts the first time.
1.7 Burst mode in no-load or very light load
At very light load, the on-time becomes so small that some pulses are skipped in order to
stay in regulation and meet energy requirements such as Blue Angel or Energy Star. This
mode is called burst mode. It skips as many cycles as needed to maintain regulation. In the
case below at no-load about 9 cycles are skipped to maintain an output.
Figure 8. Bad start Figure 9. Good start

Circuit operation AN2544
12/17
Figure 10. Burst mode
1.8 Short circuit
The VIPer has pulse-by-pulse current limit. When the current ramps up to the current limit,
the pulse is terminated. This is manifested by reducing the output voltage as the current is
increased. The voltage decreases until it falls below the undervoltage shutdown threshold of
9 V, (pin4). During a short circuit the VIPer turns on and off. When the Vdd reaches the
starting voltage, the current is limited by the pulse-by-pulse current limit. The voltage falls to
the undervoltage shutdown point and the cycle repeats itself at a 16% duty cycle. This
reduces the RMS current going through the circuit as seen in Figure 11.
Figure 11. Operation during a short

AN2544 Circuit operation
13/17
1.9 Performance
Regulation for the VIPer22A-E and VIPer12A-E can be seen below. Keep in mind that the
buck topology will peak charge at zero load. DZ1 will clamp the voltage to 3 - 4 V above the
output. Load regulation is taken from 0.03 A to 0.35 A.
Note: The following measurements were taken on the appropriate version of the boards.
Discrepancy of measurements can be present, which is to be expected due to the 5%
tolerance of the Zener and equipment used for the measurements. The measurements
shown are at room temperature. If higher operating temperatures are used, current loads
must be adjusted accordingly.
Table 5. VIPer22ADIP-E, 12 V at 350 mA
VIPer22 buck 12 V / 350 mA
Vin 12 V load 12 V W in Efficiency
90 Vac 0 15.81 0.12
90 Vac 0.03 12.58 0.45
90 Vac 0.35 11.7 5.64 72.6%
264 Vac 0.35 12.21 6.12 69.8%
MIN 11.7
MAX 12.58
DELTA 0.88
Line reg. 6.0%
+/- % load reg (.03 to max) 3.8%
Ripple mv pp at 120 Vac 52
Blue Angel at no-load at 115 Vac in W 0.12
Short circuit ok
Table 6. VIPer12ADIP-E, 12 V at 200 mA
VIPer12 buck 12 V / 200 mA #1
Vin 12 V load 12 V W in Efficiency
90 Vac 0 15.6 0.15
90 Vac 0.03 12.7 0.495
90 Vac 0.2 11.85 3.06 77.5%
264 Vac 0.2 12.1 3.25 74.5%
MIN 11.85
MAX 12.7
DELTA 0.85
Line Reg. 2.9%
+/- % load reg (.03 to max) 3.6%

Circuit operation AN2544
14/17
12 V output load regulation for VIPer12-E and VIPer22A-E is shown in Figure 12.
Figure 12. Load regulations for 12 V output
Line regulation shown at three different current levels: 100 mA, 200 mA, and 350 mA.
Figure 13. Line regulation
Ripple mv pp at 120 Vac 50
Blue Angel at no-load at 115 Vac in W 0.15
Short circuit ok
Table 6. VIPer12ADIP-E, 12 V at 200 mA (continued)
VIPer12 buck 12 V / 200 mA #1
Vin 12 V load 12 V W in Efficiency
Load regulation for 12V output
10
11
12
13
14
15
16
17
0 0.05 0.1 0.15 0.2 0.25 0.3 0.35
Load
Voltage
V12 @12V V22 @ 12V
Line regulation
11
11.2
11.4
11.6
11.8
12
12.2
12.4
12.6
12.8
13
80 130 180 230
Line Voltage
Output Voltage
Vout @ 100ma Vout @ 200ma Vout @ 350ma

AN2544 Circuit operation
15/17
Figure 14. Efficiency
Efficiency is about 75% at 120 Vac. Efficiency is better at higher output voltages.
1.10 EMI conducted
EMI was checked for all four versions for maximum peak reading.
Efficiency VS Input Line for 12V output
60%
65%
70%
75%
80%
85%
80 100 120 140 160 180 200 220 240 260
Input Line
Efficiency
effic. @ 100ma effic. @ 200ma effic. @ 350ma
Figure 15. VIPer22-E, 12 V at 350 mA output Figure 16. VIPer12-E, 12 V at 200 mA output

Conclusion AN2544
16/17
2 Conclusion
Using the VIPer in the buck mode has its benefits for appliances and other industrial
equipment which require a reference to neutral. For currents up to 350 mA and voltages
greater than 10 V, it is beneficial to use this inexpensive power supply. The cost savings
compared to a transformer, opto-coupler, and low parts count, makes this solution very
attractive.
3 Revision history
Figure 17. VIPer22-E, 16 V at 350 mA output Figure 18. VIPer12-E, 16 V at 200 mA output
Table 7. Document revision history
Date Revision Changes
06-Jul-2007 1 First issue
13-Sep-2007 2 – Note added in Section 1.9: Performance
– Minor text changes
21-Sep-2007 3 Modified: Figure 1
22-Nov-2007 4 Modified: the titles of Ta b l e 5 -6and the titles of Figure 15-17

AN2544
17/17
Please Read Carefully:
Information in this document is provided solely in connection with ST products. STMicroelectronics NV and its subsidiaries (“ST”) reserve the
right to make changes, corrections, modifications or improvements, to this document, and the products and services described herein at any
time, without notice.
All ST products are sold pursuant to ST’s terms and conditions of sale.
Purchasers are solely responsible for the choice, selection and use of the ST products and services described herein, and ST assumes no
liability whatsoever relating to the choice, selection or use of the ST products and services described herein.
No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted under this document. If any part of this
document refers to any third party products or services it shall not be deemed a license grant by ST for the use of such third party products
or services, or any intellectual property contained therein or considered as a warranty covering the use in any manner whatsoever of such
third party products or services or any intellectual property contained therein.
UNLESS OTHERWISE SET FORTH IN ST’S TERMS AND CONDITIONS OF SALE ST DISCLAIMS ANY EXPRESS OR IMPLIED
WARRANTY WITH RESPECT TO THE USE AND/OR SALE OF ST PRODUCTS INCLUDING WITHOUT LIMITATION IMPLIED
WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE (AND THEIR EQUIVALENTS UNDER THE LAWS
OF ANY JURISDICTION), OR INFRINGEMENT OF ANY PATENT, COPYRIGHT OR OTHER INTELLECTUAL PROPERTY RIGHT.
UNLESS EXPRESSLY APPROVED IN WRITING BY AN AUTHORIZED ST REPRESENTATIVE, ST PRODUCTS ARE NOT
RECOMMENDED, AUTHORIZED OR WARRANTED FOR USE IN MILITARY, AIR CRAFT, SPACE, LIFE SAVING, OR LIFE SUSTAINING
APPLICATIONS, NOR IN PRODUCTS OR SYSTEMS WHERE FAILURE OR MALFUNCTION MAY RESULT IN PERSONAL INJURY,
DEATH, OR SEVERE PROPERTY OR ENVIRONMENTAL DAMAGE. ST PRODUCTS WHICH ARE NOT SPECIFIED AS "AUTOMOTIVE
GRADE" MAY ONLY BE USED IN AUTOMOTIVE APPLICATIONS AT USER’S OWN RISK.
Resale of ST products with provisions different from the statements and/or technical features set forth in this document shall immediately void
any warranty granted by ST for the ST product or service described herein and shall not create or extend in any manner whatsoever, any
liability of ST.
ST and the ST logo are trademarks or registered trademarks of ST in various countries.
Information in this document supersedes and replaces all information previously supplied.
The ST logo is a registered trademark of STMicroelectronics. All other names are the property of their respective owners.
© 2007 STMicroelectronics - All rights reserved
STMicroelectronics group of companies
Australia - Belgium - Brazil - Canada - China - Czech Republic - Finland - France - Germany - Hong Kong - India - Israel - Italy - Japan -
Malaysia - Malta - Morocco - Singapore - Spain - Sweden - Switzerland - United Kingdom - United States of America
www.st.com
