InWin White Edition P Series User manual

User Manual

Product Story
The P Series White Edition is an
80 PLUS®Gold certified power
supply that focuses its features on
efficiency, reliability and overall PC
building experience. The P Series’ low
noise output and its modern white
aesthetic becomes a great choice for
monochromatic or white themed PC
builds.

1. Beautiful Sight to See the P Series in
White!
2. 80 PLUS® Gold Certified for High
Efficiency
3. Ultra Quiet Zero RPM Fan Mode
4. Highly Reliable Japanese Aluminum
Electrolytic Capacitors
5. 5V and 3.3V DC to DC Design
6. Fully Modular Cables for Quick and
Easy Installation
7. Multi-Protection Safeguards
8. 5-Year Warranty
Features

Specications
* InWin products comply with RoHS regulations.
* Speci󽗉cations may vary based on di󽗈erent regions.
Model
AC INPUT 100-240 Vac, 10A, 50-60Hz
DC OUTPUT +12V +5V +3.3V -12V +5VSB Total Power
P85
Max. Output Current 70.9A 22A 22A 0.3A 3A
850W
Max. Combined Power 850W 120W 3.6W 15W
Model P85
Model Number IW-PS-P850W-WHI
Total Power 850W
Materials SECC
Type ATX12V V2.4 / EPS12V V2.92
Cable Management Fully Modular
PFC Active PFC (> 0.95)
Eciency 80 PLUS® Gold (Up to 90%)
MTBF (Hours) > 100,000 hrs.
AC Input 100 - 240Vac, 10A, 50-60Hz
Fan 135 mm FDB Fan
Typical Load Fan Noise (dBA)
(50% Loading) < 25 dB(A)
Operating Temperature Range (°C) 0 - 40°C
Full Protection OCP / OVP / UVP / SCP / OTP / OPP
Safety Certications cTUVus / TUV / CB / BSMI / CE / FCC / CCC / EAC / RCM
Product Dimensions (L x W x H) 160 x 150 x 86 mm
Package Dimensions (L x W x H) 210 x 325 x 105 mm
Net Weight 2.64 kg
Gross Weight 3.12 kg
Warranty 5 Years
Connectors
20+4 Pin Motherboard 1
8 (4+4) Pin CPU 2
8 (6+2) Pin PCI-E 6
4 Pin Peripheral 4
SATA (90 Degree) 12
Floppy 1

Package Contents
QR Code Card x1
Modular Cables Box x1
P Series White Edition
Power Supply Unit x1

Modular Cables Box
X8
Cable TiesPower Cord Mounting Screws
X4
X1
SATA (90 Degree) Floppy
8 (6+2) Pin PCI-E 4 Pin Peripheral
20+4 Pin Motherboard 8 (4+4) Pin CPU
X1
X1X3
X1X3
X1

Cable Information
650mm
600mm
100mm
550mm
100mm100mm100mm
550mm
100mm
150mm
650mm
100mm
20+4 Pin Motherboard
8 (4+4) Pin CPU
SATA (90 Degree)
8 (6+2) Pin PCI-E
4 Pin Peripheral
Floppy

1.Make sure the power supply's AC
power cable is not connected
before installation.
2.Place the power supply unit into
the space provided in the case and
secure the power supply unit with
the screws.
3.Connect 24-pin power to the 24-pin
socket on the motherboard.
4.Connect the 8-pin +12V cable to
the motherboard.
A.If your motherboard has an 8-pin
+12V socket, connect the 8-pin
cable directly to your
motherboard.
B.If your motherboard has a 4-pin
socket, detach the 4-pin from the
8-pin cable, and plug the 4-pin
cable directly to your
motherboard.
Installation

5.Connect the peripheral cables, PCI-
Express cables, and the SATA
cables to the appropriate socket.
6.Make sure all the cables are tightly
connected and save any unused
modular cables for future usage.
7.Connect the AC power cord to
the power supply and turn it on by
switching the power button to the
"I" position.
Installation

These troubleshooting points will help
you diagnose and solve problems
with your power supply if the unit fails
to operate properly:
1.Please make sure the power supply
and power cord are connected
properly.
2.Please make sure the power cord is
plugged into the power socket.
3.Please make sure the power supply
I/O button is switched to the "I"
position.
4.Please check if all the connectors
(motherboard and peripheral) are
connected properly.
5.Please allow a 5-second interval
before turning the power on again
when power supply is switched off
manually.
6.If you are still experiencing
difficulties, please contact your
local distributor for RMA support.
Troubleshooting

■ Notices
1.Please use the anti-static precautions
while installing the components to
prevent damage and injury.
2.Install in accordance with the user
manual’s instructions and safety
warnings.
3.High voltages are present in the
power supply. Do not open the
power supply case. Any modifications
may damage the product and may
place the user at risk.
4.Do not use the power supply if it has
been wet or damaged to avoid
electric shock or injury.
5.Do not install the power supply near
any heat sources such as: radiators,
heat registers, or other apparatus
that produces heat.
Notices and Warranty

6.Do not insert any objects into the
open ventilation or fan grill area.
7.Please use only this product's
exclusively supplied cables. Other
cables may not be compatible and
could cause serious damage to your
system and power supply.
8.Do not modify the cables and/or
connectors included with the power
supply.
Notices and Warranty

■ Warranty
1.InWin provides a 5-year warranty
toward the product. The warranty
covers malfunctions or flaws before
customer use. The warranty starts
from your initial purchase
(according to the date on your
receipt). Please note that we do not
honor the warranty for the product
if it is not purchased personally
or if it is purchased through an
unauthorized distribution channel.
2.This limited warranty shall not apply
if the defect was caused through
any of the following:
1) Abuse and misuse,
2) Operation outside of product
specification,
3) Unauthorized service or
modification,
4) Any and all alteration of the
product.
Notices and Warranty

3.For more detailed warranty
information, please visit the InWin
retail website at www.in-win.com.
4.The actual product is subject to
change without prior notice. In Win
Development Inc. reserves the right
to make final modifications.
Notices and Warranty
