Stamina 4650 User manual

Owner's Manual
! WARNING !
Exercisecanpresentahealth
risk. Consult a physician
beforebeginninganyexercise
program with this equipment.
If you feel faint or dizzy,
immediately discontinue use
of this equipment. Serious
bodily injury can occur if this
equipment is not assembled
and used correctly. Serious
bodily injury can also occur if
all instructions are not
followed. Keep others and
pets away from equipment
when in use. Always make
sure all bolts and nuts are
tightened prior to each use.
Followall safetyinstructionsin
this manual.
When calling for parts or
service, please specify the
following number.
Weight on this product should not exceed 250 lbs.
15-4650
STAMINA PRODUCTS
MADE IN TAIWAN
Product May Vary Slightly
From Pictured.
2000, 10
This Product is Produced Exclusively by
2757 S. Austin, Springfield, MO 65807
Customer Service Number
1 [phone]

2
TABLE OF CONTENTS Page
Safety Instructions 2
Before You Begin 4
Hardware Illustrations 5
Assembly Instructions 6
Using The Electronic Meter 8
Conditioning Guidelines 9
Warm-up and Cool-Down 10
Usage Information 11
Product Parts Drawing 12
Parts List 13
Warranty 15
Notes 16
Fax/Mail Ordering Form 18
SAFETY INSTRUCTIONS
WARNING: To reduce the risk of serious injury, read the following Safety Instructions before
using the 4650 Dual-Action Recumbent Cycle.
Use the 4650 Dual-Action Recumbent Cycle only on a level surface.
Wear appropriate clothing when exercising; do not wear loose clothing that could become caught in
the 4650 Dual-Action Recumbent Cycle.
Keep small children and pets away from the 4650 Dual-Action Recumbent Cycle at all times
including while using,folding, unfolding, orassembling the 4650 Dual-Action Recumbent Cycle.
The 4650 Dual-Action Recumbent Cycle should not be used by persons weighing more than
250 lbs.
The 4650 Dual-Action Recumbent Cycle should be used by only one person at a time.
Be careful to maintain your balance while using, mounting, dismounting, folding, unfolding or
assembling the 4650 Dual-Action Recumbent Cycle, loss of balance may result in a fall and
serious bodily injury.
When folding or unfolding the 4650 Dual-Action Recumbent Cycle, keep all children away
from the 4650 Dual-Action Recumbent Cycle and make sure your hands are clear of any
folding or pinch point.
Use the 4650 Dual-Action Recumbent Cycle only as described in the manual.
Edges of knobs should not protrude into areas of normal leg movements.
The adjustment knob(35) and locking knob(45) should be securely tightened prior to use.
Each user should adjust the seat per instructions on page 11.
Do not attempt to adjust the seat while you are on the 4650 Dual-Action Recumbent Cycle.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
WARNING: Before starting any exercise or conditioning program you should consult with your personal
physician to see if you require a complete physical exam. This is especially important if you
are over the age of 35, have never exercised before, are pregnant, or suffer from any
illness. READ AND FOLLOW THE SAFETY INSTRUCTIONS. FAILURE TO FOLLOW
THESE INSTRUCTIONS CAN RESULT IN SERIOUS BODILY INJURY.

THANK YOU FOR PURCHASING THE
4650 Dual-Action Recumbent Cycle
To help you get started, we have pre-assembled most of your
4650 Dual-Action Recumbent Cycle at the factory with the exception
of those few parts left unassembled for shipping purposes. Simply follow
thefewassemblyinstructionsset forth in this manual. Within a fewminutes
you will be getting your body into shape and on your way to achieving a
happier and healthier lifestyle.
3
Should you have any questions, please call our Customer Service
Department toll-free number, 1 [phone], Monday - Friday,
8:00 A.M. - 5:00 P.M., Central Time.

BEFORE YOU BEGIN
4
Thank you for choosing the 4650 Dual-Action
Recumbent Cycle. We take great pride in
producingthis qualityproductand hopeit willprovide
many hours of quality exercise to make you feel
better, look better and enjoy life to its fullest.
Yes, it's a proven fact that a regular exercise
program can improve your physical and mental
health. Too often, our busy lifestyles limit our time
andopportunity toexercise. The4650 Dual-Action
Recumbent Cycle provides a convenient and
simple method to begin your assault on getting your
bodyinshapeand achieving a happier and healthier
lifestyle.
Before reading further, please review the drawing
below and familiarize yourself with the parts that are
labeled.
Read this manual carefully before using the 4650
Dual-Action Recumbent Cycle.
AlthoughStaminatriestomanufacture its products
with the finest materials and uses the highest
standards of manufacturing, occasionally a part that
does not fit, is the incorrect size, or is otherwise
inappropriate is found. Even with the highest
inspection and quality controls in place these things
will happen occasionally. Please do not return the
product. For your convenience, Stamina has a
Customer Service Department with a toll-free
number. If a part is missing, does not fit, is the
incorrect size, or is otherwise inappropriate, please
call1 [phone](in theU.S.)between 8:00A.M.
and 5:00 P.M. Central Time, Monday through Friday.
Our operators will be able to assist you with your
problem and the parts will be mailed directly to your
house.
THE FOLLOWING TOOLS ARE REQUIRED FOR ASSEMBLY : Wrench
Phillips Screwdriver
Rear Stabilizer
Endcap
Left Handlebar
Seat Frame
Back Cushion
Adjustment
Knob Resistance Knob
Left Pedal
Front Frame
Rear Frame
Right Handlebar
Seat
Tension Knob
Right Pedal
Crank
Covers
Wheel Cap

HARDWARE ILLUSTRATIONS
This chart is provided to help identify some of the small parts used in the assembly of this product. This
sheet may not include all the hardware needed to assemble your product. It is intended to be used as a
guide to help simplify your assembly process.
Bushing
Flat Washer
Retainer
Round
Plug Square
Plug
Hex Head Bolt Top
Length
Hex Head Bolt Socket Head Screw
MILLIMETERS
INCHES
Place washers, the end of bolts or screws on
the circles to check for the correct size. Use
the small scale to check the sizes of bolts and
screws.
0 10 20 30 40 50 60 70 mm.
0 1/2 1 1/2 2 1/2 3in.
3/16" 1/4" 5/16" 3/8"
6 8 10
Carriage Bolt
Phillips Head Screw Flat Head Screw
Acorn Nut Standard Nut
Thin Nylock Nut Nylock Nut
Spacer
Lock Washer
Retainer Cap
5

ASSEMBLY INSTRUCTIONS
Place all parts from the box in a cleared area and position them on the floor in front of you. Remove all
packingmaterialsfromyour area and place them backintothebox. Donot dispose of the packing materials
until assembly is completed. Read each step carefully before beginning. If you are missing a part please
call our toll-free number for assistance 1 [phone].
6
1. Whenfoldingand unfoldingthe4650 Dual-Action Recumbent Cycle,keep allchildren
away from the 4650 Dual-Action Recumbent Cycle and make sure your hands are
clear of any folding or pinch point.
2. Firmly tighten the LOCKING KNOB(45) on the BACK SUPPORT(5).
1.
STEP 1
Loosen the ADJUSTMENT KNOB(35) on the FRONT FRAME(1). Slide the REAR FRAME(2)
backward and secure with the ADJUSTMENT KNOB(35). Attache the REAR STABILIZER(3) onto
the REAR FRAME(2) with HEX BOLTS(M8 x 14mm)(58) and WASHERS(M8)(68).
STEP 2
Attach the SEAT(43) onto the SEAT FRAME(4) with ROUND HEAD BOLTS(M8 x 14mm)(56). See
illustration 1.
STEP 3
Unfold the SEAT FRAME ASSEMBLY(4) by lifting up the front edge of the SEAT(43). Then lift up the
BACK SUPPORT(5) andlockin placewiththe LOCKING KNOB(45). AttachtheBACKCUSHION(44)
onto the BACK SUPPORT(5) with BOLTS(M8 x 40)(57). See illustration 2.
WARNING:
2.

ASSEMBLY INSTRUCTIONS
7
STEP 4
Attach the LEFT HANDLEBAR(6) onto the REAR STABILIZER(3) with CARRIAGE BOLT
(5/16" x 2")(55) and RESISTANCE KNOB(41). Repeat on the other side.
NOTE: Thereisa"L" decal on the LEFT HANDLEBAR, anda"R" decal on theRIGHT HANDLEBAR.
STEP 5
NOTE:
ThreadtheRIGHT PEDAL(34) onto therightside of the CRANK(9)as shown. Tighten thepedalsecurely.
Do the same way to attach the LEFT PEDAL(33) onto the left side of the CRANK(9).
STEP 6
Install two "AA" batteries into the ELECTRONIC METER(29). Plug in the SENSOR WIRE(28) to the
ELECTRONIC METER(29). Press the ELECTRONIC METER(29) into the hole on the COVERS
(31, 32).
The RIGHT PEDAL(34) has Rstamped on the end of the pedal shaft. The RIGHT PEDAL(34)
has right hand threads and is tightened by turning clockwise. The LEFT PEDAL(33) has L
stamped on the end of the pedal shaft. The LEFT PEDAL(33) has left hand threads and is
tightened by turning counter clockwise.
R
L

USING THE ELECTRONIC METER
8
FUNCTIONS:
SCAN:
Pedal movement or push any BUTTON.
Automatic shut off after 4 minutes of
inactivity.
POWER OFF :
POWER ON :
FUNCTION BUTTONS:
Push for selecting functions.
To reset all functions to zero.
MODE :
RESET :
CALORIE:
Automaticallyscanseach function of TIME, SPEED,DISTANCE, CALORIE insequence
with change every 6 seconds.
Displays the riding time, from 1 sec up to 99:59 minutes.
Displays the current speed, from zero to 99.9 Mile/Hr.
Displays the distance, from zero to 99.99 miles.
Displays the calorie consumption, from zero to 9999 K cal.
The calorie readout is an estimate for an average user. It should be used only as a
comparison between workouts on this unit.
TIME:
SPEED:
DISTANCE:
The meter will shut off automatically after 4 minutes of inactivity. All function values will
be kept. Push the RESET button to reset the functions to zero.
The electronic meter uses two "AA" or "UM-3" batteries.
NOTE: 1.
2.

CONDITIONING GUIDELINES
How you begin your exercise program depends on your physical condition. If you have been inactive for
several years, or are severely overweight, you must start slowly and increase your time on the
4650 Dual-Action Recumbent Cycle gradually: a few minutes per workout.
Initially, you may be able to exercise only for a few minutes in your target zone, however, your aerobic
fitness will improve over the next six to eight weeks. Don't be discouraged if it takes longer. It's important
to work at your own pace. Ultimately, you'll be able to exercise continuously for 30 minutes. The better your
aerobic fitness, the harder you will have to work to stay in your target zone. Please remember these
essentials:
EXERCISE INTENSITY
To maximize the benefits of exercising, it is important to exercise with the proper intensity. The proper
intensity level can be found by using your heart rate as a guide. For effective aerobic exercise, your heart
rate should be maintained at a level between 70% and 85% of your maximum heart rate as you exercise.
This is known as your target zone. You can find your target zone in the table below. Target zones are listed
for both unconditioned and conditioned persons according to age.
During the first few months of your exercise program, keep your
heart rate near the low end of your target zone as you exercise.
After a few months, your heart rate can be increased gradually
until it is near the middle of your target zone as you exercise.
To measure your heart rate, stop
exercising but continue moving your
legs or walking around and place two
fingers on your wrist. Take a six-
second heartbeat count and multiply
theresults by10 tofind yourheart rate.
For example, if your six-second
heartbeat count is 14, your heart rate
is 140 beats per minute. (A six-
second count is used because your heart rate will drop rapidly
when you stop exercising.) Adjust the intensity of your exercise
until your heart rate is at the proper level.
9
Have your doctor review your training and diet programs to advise you of a workout routine you
should adopt.
Begin your training program slowly with realistic goals that have been set by you and your doctor.
Monitor your pulse frequently. Establish your target heart rate base on your age and condition.
Set up your 4650 Dual-Action Recumbent Cycle on a flat, even surface at least 3 feet from
walls and furniture.
AGE
UNCONDITIONED
TARGET ZONE
(BEATS/MIN.)
CONDITIONED
TARGET ZONE
(BEATS/MIN.)
20 138~167 133~162
25 136~166 132~160
30 135~164 130~158
35 134~162 129~156
40 132~161 127~155
45 131~159 125~153
50 129~156 124~150
55 127~155 122~149
60 126~153 121~147
65 125~151 119~145
70 123~150 118~144
75 122~147 117~142
80 120~146 115~140
85 118~144 114~139

WARM-UP and COOL-DOWN
Warm-up The purpose of warming up is to prepare your body for exercise and to minimize injuries. Warm
up for two to five minutes before strength-training or aerobic exercising. Perform activities that raise your
heart rate and warm the working muscles. Activities may include brisk walking, jogging, jumping jacks,
jump rope, and running in place
Stretching Stretching while your muscles are warm after a proper warm-up and again after your strength
or aerobic training session is very important. Muscles stretch more easily at these times because of their
elevated temperature, which greatly reduces the risk of injury. Stretches should be held for 15 to 30
seconds. Do not bounce.
Suggested Stretching Exercises
Lower Body Stretch
Place feet shoulder-width
apart and lean forward.
Keep this position for 30
seconds using the body as a
natural weight to stretch the
backs of the legs. DO NOT
BOUNCE!
When the pull on the back of
the legs lessen, try a lower
position gradually.
Floor Stretch
While sitting on the floor,
open the legs as wide as
possible. Stretch the upper
body toward the knee on the
right leg by using your arms
to pull your chest to your
thighs. Hold this stretch 10
to 30 seconds. DO NOT
BOUNCE! Do this stretch
10 times. Repeat the stretch
with the left leg.
Bent Over Leg Stretch
Stand with feet shoulder-
width apart and lean forward
as illustrated. Using the
arms, gently pull the upper
body towards the right leg.
Let the head hang down.
DO NOT BOUNCE! Hold the
position a minimum of 10
seconds. Repeat pulling the
upper body to the left leg.
Do this stretch several times
slowly.
Remember always to check with your physician before starting any exercise program.
Cool-Down The purpose of cooling down is to return the body to its normal, or near normal, resting state
at the end of each exercise session. A proper cool-down slowly lowers your heart rate and allows blood to
return to the heart. Your cool-down should include the stretches listed above and should be completed
after each strength-training session.
Bent Torso Pulls
While sitting on the floor,
have legs apart one leg
straight and one knee bent.
Pull the chest down to touch
the thigh on the leg that is
bent and twist at the waist.
Hold this position at least 10
seconds. Repeat 10 times
on each side.
10
