Stand Up Desk Store SUDEZ120F-BK/BK User manual

SUDEZ120F-BK/BK
1-855-843-7920
[email protected]
standupdeskstore.com/electric-desk-assembly-videos
Prefer video instructions?
View our video page!
Questions or concerns?
Contact us directly!

HANDSET
“Optimal height” memory position (will go to 720mm)
Second memory position (press and hold* to save)
First memory position (press and hold* to save)
Display screen (640mm - 1290mm)
Down key (push and hold)
Up key (push and hold)
*5 seconds / (1) “BEEP”
Height range: 640-1290 mm / 25.2 x 50.8 in
Weight capacity: 100 kg / 220 lbs
Features: Easy assembly, triple stage, dual motor, C-frame, electric, L-shaped, two memory position handset + home,
expandable frame
Notes: Desktop and casters sold separately, images may vary from purchased desk
SETTINGS
1 cm
2in
EPress
Home key
Maximum height
dPress
Home key
Minimum height
CPress
Home key
Optimal height
bPress
Home key
Unit of measure -
cm / in
+
-
1 Most sensitive
2
3
4Least sensitive
APress
Home key
Anti collision sensitivity -
down movement
Press Home key
*10 seconds / (1) “BEEP”
Press M2 key
Saves settings
Returns to settings categories
Press M2 key (again)
Exits settings
FPress
Home key
Anti collision sensitivity -
up movement
+
-
1 Most sensitive
2
3
4Least sensitive
1

ERROR CAUSE SOLUTION
ER1 Motor issue Disconnect power cable for 3 minutes. Reconnect power cable.
If error continues, motor may be defective.
ER2 Synchronization issue beyond 15 mm Disconnect power cable for 3 minutes. Reconnect power cable.
If RST - push and hold Down key until lowest height.
ER3 Cable issue Make sure all motor cables are connected.
Disconnect power cable for 3 minutes. Reconnect power cable.
ER4 Communication issue Make sure all handset & controller cables are connected.
Disconnect power cable for 3 minutes. Reconnect power cable.
ER5 Load above 180 kg / 397 lbs Lighten load.
Disconnect power cable for 3 minutes. Reconnect power cable.
Hot Continuous use beyond 2 minutes Automatic recovery after 5 minutes.
If not, disconnect power cable for 3 minutes. Reconnect power cable.
MANUAL RESET
1. Make sure all cables are connected.
2. Retry handset.
If issue continues...
1. Disconnect power cable for 3 minutes.
2. Reconnect power cable.
3. Retry handset.
2

3
PARTS INCLUDED NOT TO SCALE
G QTY: 1
F QTY: 1
2 QTY: 8
M8-20
3 QTY: 12
M6-16
1 QTY: 4
M6-12
HARDWARE INCLUDED NOT TO SCALE, COLOR MAY VARY
TOOLS INCLUDED TOOLS REQUIRED
E QTY: 1*
Ships separate box
A QTY: 1 B QTY: 1 C QTY: 1 D QTY: 2
4 QTY: 2
ST3.5-13
M5 M4
OR

4
1
C
A
B

5
2
Be mindful of cable while lifting up leg
Be mindful of cable while lifting up leg

4
1 QTY: 4
M6-12
6
3
1
1
1
1
Tighten pre-inserted bolts

7
2 QTY: 8
M8-20
5D
D
2
2
6
Loosen set screws 1 turn each
to expand desk frame.

8
7
8
3 QTY: 12
M6-16
3
Retighten set scews
Note: Tighten screws only after all
have been inserted.

9
10
9
4 QTY: 2
ST3.5-13
F
G
4
Alternate mounting holes

11
10
With assistance, flip desk over

Keep children away from desk - especially handset, controller / powerbrick, legs, or cables. There is a risk of electric shock
or serious injury.
Do not open any componements - especially handset, controller / powerbrick, legs or cables. There is a risk of electric shock
or serious injury.
Close supervision is necessary when children, elderly, or persons with disabilities are in close proximity.
Keep all electrical components away from liquids or wet areas.
Do not sit or stand on desk. Do not crawl or lie under desk.
Do not place any object taller than 20” (when using glides) 23” (when using casters) under desk.
Never operate desk if cords / plug are wet or damaged.
Make sure there are no obstacles in the path of the desk’s motion.
Make sure all cords are appropriate length to accomodate desk’s motion.
Never exceed noted weight capacity.
Ensure all hardware are properly tightened.
If component needs to be replaced, remove power cord first.
In the event of a power outage or accidental removal of power cord, a manual reset may be necessary. See MANUAL RESET.
Read all instructions before using desk. Keep instructions for reference. Manufacturer does not accept warranty claims
or liability claims for damages caused by improper use or handling.
USE & LIABILITY
1-855-843-7920
[email protected]
standupdeskstore.com/electric-desk-assembly-videos
Prefer video instructions?
View our video page!
Questions or concerns?
Contact us directly!
16
