Standby MS350 User manual

MS350 - Manual
AM150B 1 Standby AB – standbygroup.se
MS350
Thank you for choosing a product from Standby.
Technical Data
Description Units
Dimensions 44.6 mm x 136.1 mm x 131 mm
Weight Approx. 400 g
Nominal voltage 12 / 24 VDC
Operating voltage 10,8 to 14.4 VDC / 21.6 to 28.8 VDC
Limit voltage -32 to + 32 VDC
Current consumption < 500μA at standby mode
Inputs 7 x < 20mA, active high
1 x < 20mA, active low
Outputs 2 x < 6A
4 x < 2A
Enclosure rating IP 54
Approvals
- Accoustic
- EMC
T046Lu (Swedish approval, only valid together with two KSR350 4Ω(12V)/16Ω(24V) )
ECE R10
Included
Installation
The Control-Unit can be installed as desired in the vehicle interior. Due to the housing design, the
Control-Unit can be variably attached and connected to the vehicle with four screws. Care must be
taken to ensure good accessibility of the connectors.

MS350 - Manual
AM150B 2 Standby AB – standbygroup.se
Connection
Explanation of naming Example
X = Input
Y = Output
S = Supply
The first number in the name describes the connector number and the second
number the pin number.
+ means active high, connect to positive supply to activate.
- means active low, connect to ground to activate.
Connector P1 22p Female
Connector: AMP, 929504-7 22P
Socket: AMP, 927777-1
For more information regarding functions for each pin see BCD-wheel section
Recommended fuses
All active high inputs should be fused with max 1A.
Pin 3 and 4 (S13+ and S14+) should together be fused max 15A fuse.
Connector P2 SUB-D 15P Female
Recommended metal hood: MH Connectors, MHDTZK15-K
Recommended crimp socket: Molex, FL15S7-K121
Recommended crimp contacts: Molex 1731120432, 20-24 AWG
Pin Function Standby
Name
1 Output for external devices Y21+
2 PA microphone PTT + X22+
3 PA microphone + signal, high, 4mV X23+
4 PA microphone shield Shield
5 Audio input + signal, high, 400mV X25+
6 Not used Not used
7 Not used Not used
8 Not used Not used
Pin Function Standby
Name
9 Ground for external devices Y29-
10 Audio PTT + X210+
11 PA microphone - signal, low, 4mV X211-
12 Audio input – signal, low, 400mV X212+
13 CAN Low CANL
14 Not used Not used
15 CAN High CANH

MS350 - Manual
AM150B 3 Standby AB – standbygroup.se
Configuration of DIP-Switch and BCD-wheel
DIP-Switch
DIP No Function
1 Not used, set to off
2 Not used, set to off
3 Not used, set to off
4 Not used, set to off
5 Not used, set to off
6 Not used, set to off
BCD-Wheel
Turn wheel to choose presets for selected country.
Pos 0 CAN
This position is used when the amplifier is connected to a CAN based control system from Standby.
The connected control system sets the functionality of the amplifier. Please see the description for the
control system regarding functionality and connection.

MS350 - Manual
AM150B 4 Standby AB – standbygroup.se
Pos 1 Stand-alone functions Sweden
Connector P1
Pin Function Standby
Name Imax Recommended fuse
1 Beacon left Y11+ 6A
2 Beacon right Y12+ 6A
3 Power supply for outputs
(Y11+, Y12+, Y15+, Y16+, Y17+, Y18+)
S13+ < 20A Common fuse max 15A
(see connection section)
4 Power supply for outputs
(Y11+, Y12+, Y15+, Y16+, Y17+, Y18+)
S14+ < 20A
5 Status ok loudspeaker Y15+ 2A
6 Status ok beacon left Y16+ 2A
7 Status ok beacon right Y17+ 2A
8 Not used Y18+ 2A
9 - Loudspeaker left SP19- 5A
10 + Loudspeaker left SP110+ 5A
11 + Loudspeaker right SP111+ 5A
12 - Loudspeaker right SP112- 5A
13 Yelp SE (horn-signal, edge trigged)
Activate/deactivate the sound. The sound will automatically be
deactivated after 10 seconds. Input X117 or X119 must be active
to be able to use this function.
X113+ < 20 mA max 1A
14 Ground MS-350 S114- 10A
15 Yelp SE (horn-signal, edge trigged)
Activate/deactivate the sound. The sound will automatically be
deactivated after 10 seconds. Input X117 or X119 must be active
to be able to use this function.
X115- < 20 mA max 1A
16 Power Supply Amplifier S116+ 10A 10A
17 Hi/Lo wobbling SE (continuous feed)
Activates the sound AND the output Beacon. This input has
higher priority than X119+.
X117+ < 20 mA max 1A
18 Beacon (continuous feed) X118+ < 20 mA max 1A
19 Hi/Lo clean SE (continuous feed)
Activates the sound AND the output Beacon.
X119+ < 20 mA max 1A
20 Not used X120+ < 20 mA max 1A
21 Not used X121+ < 20 mA max 1A
22 Air Horn (continuous feed)
This sound has higher priority than all other sounds.
X122+ < 20 mA max 1A

MS350 - Manual
AM150B 5 Standby AB – standbygroup.se
Pos 2 Stand-alone functions Norway
Connector P1
Pin Function Standby
Name Imax Recommended fuse
1 Beacon left Y11+ 6A
2 Beacon right Y12+ 6A
3 Power supply for outputs
(Y11+, Y12+, Y15+, Y16+, Y17+, Y18+)
S13+ < 20A Common fuse max
15A(see connection
section)
4 Power supply for outputs
(Y11+, Y12+, Y15+, Y16+, Y17+, Y18+)
S14+ < 20A
5 Status ok loudspeaker Y15+ 2A
6 Status ok beacon left Y16+ 2A
7 Status ok beacon right Y17+ 2A
8 Not used Y18+ 2A
9 - Loudspeaker left SP19- 5A
10 + Loudspeaker left SP110+ 5A
11 + Loudspeaker right SP111+ 5A
12 - Loudspeaker right SP112- 5A
13 Yelp US (horn-signal, edge trigged)
Activate/deactivate the sound. The sound will automatically be
deactivated after 10 seconds. Input X117 must be active to be
able to use this function.
X113+ < 20 mA max 1A
14 Ground MS-350 S114- 10A
15 Yelp US (horn-signal, edge trigged)
Activate/deactivate the sound. The sound will automatically be
deactivated after 10 seconds. Input X117 must be active to be
able to use this function.
X115- < 20 mA max 1A
16 Power Supply Amplifier S116+ 10A 10A
17 Wail US (continuous feed)
Activates the sound AND the output Beacon.
X117+ < 20 mA max 1A
18 Beacon (continuous feed) X118+ < 20 mA max 1A
19 Not used X119+ < 20 mA max 1A
20 Not used X120+ < 20 mA max 1A
21 Not used X121+ < 20 mA max 1A
22 Air Horn (continuous feed)
This sound has higher priority than all other sounds.
X122+ < 20 mA max 1A

MS350 - Manual
AM150B 6 Standby AB – standbygroup.se
Pos 3 Stand-alone functions Denmark
Connector P1
Pin Function Standby
Name Imax Recommended fuse
1 Beacon left Y11+ 6A
2 Beacon right Y12+ 6A
3 Power supply for outputs
(Y11+, Y12+, Y15+, Y16+, Y17+, Y18+)
S13+ < 20A Common fuse max
15A(see connection
section)
4 Power supply for outputs
(Y11+, Y12+, Y15+, Y16+, Y17+, Y18+)
S14+ < 20A
5 Status ok loudspeaker Y15+ 2A
6 Status ok beacon left Y16+ 2A
7 Status ok beacon right Y17+ 2A
8 Not used Y18+ 2A
9 - Loudspeaker left SP19- 5A
10 + Loudspeaker left SP110+ 5A
11 + Loudspeaker right SP111+ 5A
12 - Loudspeaker right SP112- 5A
13 Manually change sound (horn-signal, edge trigged)
When only blue light is ON sound Hi/Lo clean SE will be played
for 2 cycles.
When activating more than one sound at the same time this input
is used to change to next sound manually.
X113+ < 20 mA max 1A
14 Ground MS-350 S114- 10A
15 Manually change sound (horn-signal, edge trigged)
When only blue light is ON sound Hi/Lo clean SE will be played
for 2 cycles.
When activating more than one sound at the same time this input
is used to change to next sound manually.
X115- < 20 mA max 1A
16 Power Supply Amplifier S116+ 10A 10A
17 Hi/Lo clean SE (continuous feed)
Activates the sound AND the output Beacon. This input has
higher priority than X119 and X121 if activated at the same time.
X117+ < 20 mA max 1A
18 Beacon (continuous feed). X118+ < 20 mA max 1A
19 Yelp SE (continuous feed)
Activates the sound AND the output Beacon. This input has
higher priority than X121 if activated at the same time.
X119+ < 20 mA max 1A
20 Automatically change sound (continuous feed)
When activating more than one sound at the same time this input
activates automatically sound change. The sounds will be played
in a loop. Each sound will be played for a minimum of 6 seconds
(the currently played cycle must be completed). Input +/- X113
can be used to force to next sound before the time has ended.
X120+ < 20 mA max 1A
21 Wail US (continuous feed)
Activates the sound AND the output Beacon.
X121+ < 20 mA max 1A
22 Air Horn (continuous feed)
This sound has higher priority than all other sounds.
X122+ < 20 mA max 1A

MS350 - Manual
AM150B 7 Standby AB – standbygroup.se
Pos 4 Stand-alone functions Finland
Connector P1
Pin Function Standby
Name Imax Recommended fuse
1 Beacon left Y11+ 6A
2 Beacon right Y12+ 6A
3 Power supply for outputs
(Y11+, Y12+, Y15+, Y16+, Y17+, Y18+)
S13+ < 20A Common fuse max 15 A
(see connection section)
4 Power supply for outputs
(Y11+, Y12+, Y15+, Y16+, Y17+, Y18+)
S14+ < 20A
5 Status ok loudspeaker Y15+ 2A
6 Status ok beacon left Y16+ 2A
7 Status ok beacon right Y17+ 2A
8 Not used Y18+ 2A
9 - Loudspeaker left SP19- 5A
10 + Loudspeaker left SP110+ 5A
11 + Loudspeaker right SP111+ 5A
12 - Loudspeaker right SP112- 5A
13 Manually change sound (horn-signal, edge trigged)
When only blue light is ON sound Yelp SE will be played for 20
cycles.
When activating more than one sound at the same time this input
is used to change to next sound manually.
X113+ < 20 mA max 1A
14 Ground MS-350 S114- 10A max 1A
15 Manually change sound (horn-signal, edge trigged)
When only blue light is ON sound Yelp SE will be played for 20
cycles.
When activating more than one sound at the same time this input
is used to change to next sound manually.
X115- < 20 mA max 1A
16 Power Supply Amplifier S116+ 10A 10A
17 Hi/Lo clean SE (continuous feed)
Activates the sound AND the output Beacon. This input has higher
priority than X119 and X121 if activated at the same time.
X117+ < 20 mA max 1A
18 Beacon (continuous feed) X118+ < 20 mA max 1A
19 Yelp SE (continuous feed)
Activates the sound AND the output Beacon. This input has higher
priority than X121 if activated at the same time.
X119+ < 20 mA max 1A
20 Automatically change sound (continuous feed)
When activating more than one sound at the same time this input
activates automatically sound change. The sounds will be played
in a loop. Each sound will be played for a minimum of 6 seconds
(the currently played cycle must be completed). Input +/- X113
can be used to force to next sound before the time has ended.
X120+ < 20 mA max 1A
21 Wail US (continuous feed)
Activates the sound AND the output Beacon.
X121+ < 20 mA max 1A
22 Air Horn (continuous feed)
This sound has higher priority than all other sounds.
X122+ < 20 mA max 1A

MS350 - Manual
AM150B 8 Standby AB – standbygroup.se
Compatible Products
For more information regarding compatible products: www.standbygroup.se
Standby will not be held liable for improper installation or use of this product. Please follow all instructions provided. Professional advice and proper installation of the
Standby products by an authorized Standby Partner are recommended to provide maximum safety and function
