A) The lock - main unit B) Key x2 C) User tag x4
D) Cutter shield (Note: not included in pack - see label)
E) Batteries x2 F) USB cable G) User manual H) Extended user
manual
FR XX
A) The lock - main unit B) Key x2 C) User tag x4
D) Cutter shield (Note: not included in pack - see label)
E) Batteries x2 F) USB cable G) User manual H) Extended user
manual
DE XX
A) The lock - main unit B) Key x2 C) User tag x4
D) Cutter shield (Note: not included in pack - see label)
E) Batteries x2 F) USB cable G) User manual H) Extended user
manual
IT XX
A) The lock - main unit B) Key x2 C) User tag x4
D) Cutter shield (Note: not included in pack - see label)
E) Batteries x2 F) USB cable G) User manual H) Extended user
manual
SE XX
A) The lock - main unit B) Key x2 C) User tag x4
D) Cutter shield (Note: not included in pack - see label)
E) Batteries x2 F) USB cable G) User manual H) Extended user
manual
ES XX
A) The lock - main unit B) Key x2 C) User tag x4
D) Cutter shield (Note: not included in pack - see label)
E) Batteries x2 F) USB cable G) User manual H) Extended user
manual
DK XX
A) The lock - main unit B) Key x2 C) User tag x4
D) Cutter shield (Note: not included in pack - see label)
E) Batteries x2 F) USB cable G) User manual H) Extended user
manual
GB XX
Key In - Insert or remove mechanical key FR Key In -
Insert or remove mechanical key IT Key In - Insert or
remove mechanical key ES Key In - Insert or remove
mechanical key DE Key In - Insert or remove mechanical
key SE Key In - Insert or remove mechanical key DK Key
In - Insert or remove mechanical key

01
TOP VIEW
BOTTOM VIEW
FRONT
VIEW
SIDE
VIEW
FRONT VIEW 1) Shackle release button 2) Indication LEDs 3) Push button TOP VIEW 4) Mechanical latch 5) Battery cover screw
release 6) Electromechanical latch 7) Shackle protector screw thread BOTTOM VIEW 8) Battery cover 9) User tag slot
SIDE VIEW 10) Key insertion slot 11) USB input
GB
FRONT VIEW 1) Shackle release button 2) Indication LEDs 3) Push button TOP VIEW 4) Mechanical latch 5) Battery cover screw
release 6) Electromechanical latch 7) Shackle protector screw thread BOTTOM VIEW 8) Battery cover 9) User tag slot
SIDE VIEW 10) Key insertion slot 11) USB input
FR
FRONT VIEW 1) Shackle release button 2) Indication LEDs 3) Push button TOP VIEW 4) Mechanical latch 5) Battery cover screw
release 6) Electromechanical latch 7) Shackle protector screw thread BOTTOM VIEW 8) Battery cover 9) User tag slot
SIDE VIEW 10) Key insertion slot 11) USB input
IT
FRONT VIEW 1) Shackle release button 2) Indication LEDs 3) Push button TOP VIEW 4) Mechanical latch 5) Battery cover screw
release 6) Electromechanical latch 7) Shackle protector screw thread BOTTOM VIEW 8) Battery cover 9) User tag slot
SIDE VIEW 10) Key insertion slot 11) USB input
DE
FRONT VIEW 1) Shackle release button 2) Indication LEDs 3) Push button TOP VIEW 4) Mechanical latch 5) Battery cover screw
release 6) Electromechanical latch 7) Shackle protector screw thread BOTTOM VIEW 8) Battery cover 9) User tag slot
SIDE VIEW 10) Key insertion slot 11) USB input
ES
FRONT VIEW 1) Shackle release button 2) Indication LEDs 3) Push button TOP VIEW 4) Mechanical latch 5) Battery cover screw
release 6) Electromechanical latch 7) Shackle protector screw thread BOTTOM VIEW 8) Battery cover 9) User tag slot
SIDE VIEW 10) Key insertion slot 11) USB input
SE
FRONT VIEW 1) Shackle release button 2) Indication LEDs 3) Push button TOP VIEW 4) Mechanical latch 5) Battery cover screw
release 6) Electromechanical latch 7) Shackle protector screw thread BOTTOM VIEW 8) Battery cover 9) User tag slot
SIDE VIEW 10) Key insertion slot 11) USB input
DK
1
2 8 9
4
6 7 10
11
5
3








THANK YOU FOR CHOOSING THE STANLEY GUARD ACCESS CONTROL SYSTEM.
INSTALLING THE
BATTERY
SET UP AND INSTALLATION
2
Insert the mechanical key and


1
4 5
6

Place battery cover back on and
close the screw tightly in clockwise


with the ACS BT
3
02


1.
2. In case of key is lost, contact the 
3. There is a spare key so you can 
4. In case there is no key and also 


INSTALLING THE
BATTERY 2
Insert the mechanical key and rotate
it counter-clockwise to "Pairing /

Insert new user tag - After
successful pairing1the green led
will blink and buzzer will sound


1
ADDING NEW USERS
(TAGS)
NOTE: YOU CAN ENTER UP TO 100 USER TAGS, IF YOU EXCEED THIS NUMBER THE NEW USER TAG WILL NOT BE PAIRED
AND THE RED LED WILL BLINK 3 TIMES TOGETHER WITH BUZZER “ERROR” NOTIFICATION .
DELETING
ALL AUTHORIZED USERS
2
4
3


Insert the mechanical key and rotate it clockwise till mechanical latch




1
NOTE: YOU CAN ABORT THIS OPERATION BY CHANGING KEY POSITION TO
“KEY IN” DURING THE “WARNING” NOTIFICATION.
NOTE: WHEN LOCK IS IN “TEMPORARY AUTHORIZATION FREEZE MODE” (SEE
BELOW) USERS CAN’T BE DELETED, IF YOU WILL ATTEMPT PERFORMING THIS
OPERATION RED LED WILL BLINKS TWICE FOR NOTIFICATION.
03
1

OPEN / CLOSE LOCK
USING THE USER TAG
2
3
NOTE: INSERTION OF UNIDENTIFIED/ UNPAIRED USER TAG WILL NOT OPEN
THE LOCK. THE LOCK WILL NOTIFY UNAUTHORIZED ACCESS ATTEMPT BY
PLAYING “ERROR” NOTIFICATION AND BLINKING RED LED THREE TIMES.
NOTE: WHEN LOCK IS IN “TEMPORARY AUTHORIZATION FREEZE MODE” AND
TAG IS INSERTED RED LED WILL BLINK TWICE NOTIFYING THAT ACCESS IS
DENIED FOR ALL USERS.


If identified tag is inserted the electromechanical latch will open/close
(depending on previous state), Approving buzzer will sound together with

1
04 2
DELETING A SPECIFIC
USER
2
4
3
If tag is identified, the lock will sound melody and green LED will blink once,

Insert the mechanical key and rotate it clockwise till mechanical latch


If tag is not identified or was previously deleted, the lock will play error

1

THIS OPERATION WILL RELEASE THE LOCK FROM "FREEZE" MODE.
RELEASE
AUTHORIZATION FREEZE
1
2

Insert the mechanical key and rotate it counter-clockwise to "Pairing /

Long press the push button on the front panel until buzz sound heard and

3
05
TEMPORARY
AUTHORIZATION FREEZE
USING THIS OPTION THE LOCK
SHALL BE OPENED/CLOSED ONLY
BY USING MECHANICAL KEY.
THIS WILL PREVENT OTHER USERS
FROM ACCESSING THE LOCK UNIT.
FOR ACS-BT ONLY
FOR ACS-BT ONLY
1
2

Insert the mechanical key and rotate it counter-clockwise to "Pairing /

Long press on the push button on the front panel until buzz sound is heard

3
NOTE: IF “TEMPORARY AUTHORIZATION FREEZE MODE” WAS SET USING
SMART PHONE APP THIS OPERATION WILL OVERRIDE AUTOMATIC SETTINGS
(SEE SMART PHONE APPLICATION MANUAL/HELP).
NOTE: THIS MODE ALLOWS ALL OPERATIONS EXCEPT OPENING/CLOSING
LOCK USING USER TAGS AND DELETING ALL AUTHORIZED USER TAGS (SEE
“DELETING ALL AUTHORIZED USERS”).
NOTE: IF “TEMPORARY AUTHORIZATION FREEZE MODE” WAS SET USING
SMART PHONE APP THIS OPERATION WILL OVERRIDE AUTOMATIC SETTINGS
(SEE SMART PHONE APPLICATION MANUAL/HELP).

3
NOTE: IF YOU WERE PREVIOUSLY CONNECTED TO BLUETOOTH, CONNECTION
TO PC WILL TERMINATE BLUETOOTH COMMUNICATION.
WARNING: DON’T CHANGE KEY POSITION DURING DATA TRANSFER - THIS
MAY CAUSE DATA LOSS.
06
PC CONNECTION
BLUETOOTH
CONNECTION
CONNECT THE LOCK TO THE PC USING A USB CABLE IN ORDER TO DOWNLOAD
AND UPLOAD HISTORY LOG AND AUTHORIZATIONS.
CONNECT LOCK TO SMART PHONE USING BLUETOOTH TO MANAGE USERS AND
LOCK SETTINGS (DETAILS IN SMART PHONE APP HELP).
NOTE: BLUETOOTH PAIRING CODE IS "1234"
1
1
2
2
3

Insert the mechanical key and rotate it counter-clockwise to the

Insert the mechanical key and rotate it counter-clockwise to the


Press and hold push button until buzzer beeps and green led blinks - this




STST1-79226
STST320000
FOR ACS-BT ONLY

NOTE: YOU CAN’T ACTIVATE BLUETOOTH WHEN CONNECTED TO PC USING
USB, CONNECTION TO PC WILL TERMINATE BLUETOOTH CONNECTION.
NOTE: BLUETOOTH WILL SHUT DOWN AUTOMATICALLY WHEN THERE IS NO
CONNECTION ESTABLISHED DURING 5 MINUTE (SAVES BATTERY POWER),
YOU CAN ACTIVATE BLUETOOTH AGAIN BY PRESSING THE PUSH BUTTON IN
“COMMUNICATION” MODE.
NOTE: BLUETOOTH COMMUNICATION WILL WORK IN A RANGE NO LONGER
THAN 15 METERS.
WARNING: DON’T CHANGE KEY POSITION DURING DATA TRANSFER - THIS
MAY CAUSE DATA LOSS.



LOW BATTERY
INDICATION
REPLACING BATTERY
4
To disconnect from Bluetooth change key position (any other position than

REMOVING/CHANGING
SHACKLE 2
Insert the mechanical key and rotate


Press shackle release button and

1
3 4
Insert new shackle in the same

07

Please make sure you have the supplied screw+washer and a

CUTTER SHIELD
INSTALLATION
1
2



3
4

08
