Star Lake SK701 User manual

SK701
DC to DC Power Board
User’s Manual

Safety information
Electrical safety
To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before
relocating the system.
When adding or removing devices to or from the system, ensure that the power cables for the devices
are unplugged before the signal cables are connected. If possible, disconnect all power cables from
the existing system before you add a device.
Before connecting or removing signal cables from the motherboard, ensure that all power cables are
unplugged.
Seek professional assistance before using an adapter or extension cord. These devices could interrupt
the grounding circuit.
Make sure that your power supply is set to the correct voltage in your area.
If you are not sure about the voltage of the electrical outlet you are using, contact your local power
company.
If the power supply is broken, do not try to fix it by yourself. Contact a qualified service technician or
your local distributor.
Operation safety
Before installing the motherboard and adding devices on it, carefully read all the manuals that came
with the package.
Before using the product, make sure all cables are correctly connected and the power cables are not
damaged. If you detect any damage, contact your dealer immediately.
To avoid short circuits, keep paper clips, screws, and staples away from connectors, slots, sockets and
circuitry.
Avoid dust, humidity, and temperature extremes. Do not place the product in any area where it may
become wet.
Place the product on a stable surface.
If you encounter any technical problems with the product, contact your local distributor
Statement
All rights reserved. No part of this publication may be reproduced in any form or by any means,
without prior written permission from the publisher.
All trademarks are the properties of the respective owners.
All product specifications are subject to change without prior notice
1

Revision History
Revision
Date (dd.mm.yyyy)
Changes
Version 1.0
20.03.2015
Initial release
Packing list
SK701 power board
3 pins terminal block
User’s Manual
If any of the above items is damaged or missing, please contact your local distributor.
2

Table of content
SAFETY INFORMAT ION ............................................................................................................................................................... 1
ELECTRICAL SAFETY.............................................................................................................................................................................. 1
OPERATION SAFETY.............................................................................................................................................................................. 1
STATEMENT ................................................................................................................................................................................ 1
REVISION HISTORY ..................................................................................................................................................................... 2
PACKING LIST.............................................................................................................................................................................. 2
TABLE OF CONTENT .................................................................................................................................................................... 3
CHAPTER 1: PRODUCT INFORMATION ........................................................................................................................................ 4
1.1 BLOCK DIAGRAM........................................................................................................................................................................... 4
1.2 KEY FEATURES............................................................................................................................................................................... 5
1.3 BOARD PLACEMENT....................................................................................................................................................................... 5
1.4 ONBOARD CONNECTOR LIST ............................................................................................................................................................ 5
1.5 MECHANICAL DRAWINGS................................................................................................................................................................ 6
CHAPTER 2: ONBOARD CONNECTOR PIN ASSIGNMENT .............................................................................................................. 7
3

Chapter 1: Product Information
1.1 Block Diagram
4

1.2 Key Features
Specification
Input Voltage
9V to 36V
Output Voltage 12V @ 5A, 60W
Performance Characteristic
Ripple: <300m
Line Regulation: <100 mV
Load Regulation: <100 mV
Efficiency: Min. 92%
Operation
Temperature
-20 to 70ºC
Dimension
100(W) x 30(L) mm
1.3 Board Placement
1.4 Onboard Connector List
Label
Function
DC_JACk1 Power output connector
DC_OUT2 Power Input connector
5

1.5 Mechanical Drawings
PCBA Dimension
Thermal heat sink dimension
6

Chapter 2: Onboard Connector Pin Assignment
7
