STAR TRAC FITNESS P-ST Stepper User manual

Star Trac FitnessTM
Star Trac P-ST Stepper
OWNER’SMANUAL

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
About This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
English . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Dutch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
French . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
German . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Italian . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Portuguese . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Spanish . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Swedish . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Chinese . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Japanese . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Assembly and Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Tools Required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Unpacking and Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Operating Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Display Panel Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Soft Trac®. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Hints and Tips for Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Viewing Workout Data During a Program . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Pause Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Cooldown Cycle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Using the Personal Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Heart Rate Monitoring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Quick Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Preset Programs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Heart Rate Control Programs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Fitness Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Preventative Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Daily Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Weekly Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Monthly Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Manager / Maintenance Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Manager Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Maintenance Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Start-Up Service Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Regulatory Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
FCC and Other Domestic Regulations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Canadian DOC and Other Regulations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
European Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
2 STAR TRAC P-ST STEPPER OWNER’SMANUAL
TABLE OF CONTENTS
Copyright 2005. Star Trac by Unisen, Inc. All rights reserved, including those to reproduce this book or parts thereof in any form without first obtaining written permission
from Star Trac.
Every effort has been made to keep this information current; however, periodically, changes are made to the information herein, and these changes will be incorporated into
new editions of this publication. All product names and logos are trademarks of their respective owners. Printed in the USA.

STAR TRAC P-ST STEPPER OWNER’SMANUAL 3

4 STAR TRAC P-ST STEPPER OWNER’SMANUAL
Thank you for choosing the STAR TRAC P-ST STEPPER. The Stepper has been designed to provide the user the most rewarding expe-
rience based upon the carefully planned features it possesses. The design elements of this product will provide you with a comfortable, intu-
itive, safe and reliable experience, guiding you to a habit-forming lifestyle. Our mission is to provide products to mold lifelong habits for
health and fitness, and our Stepper will provide the path to meet your goals. Step to it!
ABOUT THIS MANUAL
This manual is applicable to the STAR TRAC P-ST STEPPER. The manual is divided into eight sections, as follows:
Introduction
Provides an overview of each section within the manual.
Safety Instructions
Provides guidelines, in multiple languages, for safely operating the Stepper.
Assembly and Setup
Provides instructions for unpacking, assembling and setting up the Stepper.
Operating Instructions
Provides a detailed description of the Display Panel, and includes step-by-step instructions for operating the Stepper.
Preventative Maintenance
Describes the preventative maintenance measures required to keep the Stepper in top condition.
Manager / Maintenance Mode
Provides step-by-step instructions for changing universal parameters on the Stepper, and for performing built-in testing procedures.
Troubleshooting
Describes the start-up and shutdown messages provided.
Regulatory Information
Provides regulatory information for the Stepper.
INTRODUCTION

STAR TRAC P-ST STEPPER OWNER’SMANUAL 5
This chapter includes fitness safeguards and precautions for the installation and use of the STAR TRAC P-ST STEPPER. Please read this
chapter carefully before installing or using your equipment.
Safety instructions are provided in the following languages (in the order shown):
IEnglish
IDutch
IFrench
IGerman
IItalian
IPortuguese
ISpanish
ISwedish
IChinese
IJapanese
PRECAUTIONS
These safety notes are directed to you as the owner of the STAR TRAC P-ST STEPPER. Please train all your users and fitness staff to fol-
low these safety instructions.
SAFETY INSTRUCTIONS
Do
IDo encourage each of your users to discuss their health
program or fitness regimen with a healthcare profession-
al.
IDo stop operating your Stepper if you feel dizzy or faint.
IDo perform regular preventative maintenance.
IDo exercise slowly until you reach a level of comfort.
IDo use the Stepper only for its intended use, as described
in this manual.
Do Not
IDo not let unsupervised children operate your Stepper.
IDo not use without athletic shoes.
IDo not use in rainy weather outdoors, or in an enclosed
pool environment.
IDo not drop or insert any object, hands, or feet into any
opening, or underneath your Stepper.
IDo not attempt to remove any shrouds or modify your
Stepper.
WARNING
Your STAR TRAC P-ST STEPPER is designed for aerobic exercise in a commercial or consumer environment.
Please check with your physician prior to beginning any exercise program.
Do not push yourself to excess. Stop if you are feeling faint, dizzy, or exhausted. Use common sense when stepping.
Read the Owner's Manual in its entirety before operating your Stepper.
Failure to obey this warning can result in injury or death.

VOORZORGSMAATREGELEN
Deze veiligheidsaantekeningen zijn aan u gericht als eigenaar van de STAR TRAC P-ST STEPPER. Gelieve uw gebruikers en uw personeel
voor conditietraining volledig bekend te maken met deze veiligheidsinstructies.
PRÉCAUTIONS
Ces consignes de sécurités s'adressent aux propriétaires du P-ST STEPPER de STAR TRAC. Veuillez instruire tous vos utilisateurs et instructeurs
à suivre ces consignes.
Doe het volgende:
IMoedig elk van uw gebruikers aan hun gezondheidspro-
gramma of conditietherapie met een professioneel uit de
gezondheidszorg te bespreken.
IStop het gebruik van uw stepper als u zich duizelig of een
flauwte voelt.
IVoer regelmatig preventief onderhoud uit.
IOefen langzaam totdat u een comfortniveau heeft bereikt.
IGebruik de stepper alleen voor zijn bedoelde gebruik,
zoals in deze handleiding staat beschreven.
Doe het volgende NIET:
ILaat kinderen zonder toezicht de stepper niet bedienen.
INiet zonder gymschoenen gebruiken.
INiet buiten bij regenachtig weer gebruiken, of in dichte
ruimte met een zwembad.
ILaat geen enkel voorwerp in de stepper vallen en steek
uw handen of voeten in geen enkele opening van of
onder uw stepper.
IProbeer geen omhulsels te verwijderen of uw stepper te
wijzigen.
WAARSCHUWING
Uw STAR TRAC P-ST STEPPER is ontworpen voor aërobische oefeningen in een commerciële of gebruikersomgeving.
Zie uw arts vóór het beginnen van een oefenprogramma.
Dwing uzelf niet tot buitensporige oefeningen. Stop als u zich duizelig, uitgeput of een flauwte voelt.
Lees de gebruikershandleiding helemaal en aandachtig door alvorens uw stepper te bedienen.
Nalaten deze waarschuwing op te volgen kan letsel of overlijden tot gevolg hebben.
À Faire
IEncouragez tous les utilisateurs à consulter un médecin au
sujet de leur programme de fitness ou régime d'exercice.
ICessez d'utiliser le stepper en cas d'étourdissement ou de
faiblesse.
IExécutez régulièrement la maintenance préventive.
ICommencez l'exercice lentement jusqu'à ce que vous
atteignez un niveau confortable.
IUtilisez le stepper uniquement de la manière prévue, telle
que décrite dans ce manuel.
À éviter
INe laissez pas des enfants utiliser le stepper sans surveil-
lance.
INe l'utilisez pas sans porter de chaussures d'athlétisme.
INe l'utilisez pas en extérieur lors de temps pluvieux, ni en
intérieur dans une salle de piscine.
IÉvitez de laisser tomber tout objet ou d'introduire les
mains ou pieds dans toute ouverture ou en-dessous du
stepper.
INe tentez pas de retirer tout carter de protection ni de
modifier le stepper.
AVERTISSEMENT
Le P-ST STEPPER de STAR TRAC est conçu pour l'exercice aérobique dans un environnement commercial ou privé.
Veuillez consulter un médecin avant de commencer tout programme d'exercice.
Ne vous poussez pas au-delà de vos limites. Arrêtez-vous si vous vous sentez faible, étourdi ou épuisé. Faites preuve
de bon sens lorsque vous vous entraînez.
Lisez le guide de l'utilisateur en entier avant d'utiliser le stepper.
Le non-respect de ces avertissements peut se traduire par des blessures, voire la mort.
6 STAR TRAC P-ST STEPPER OWNER’SMANUAL

STAR TRAC P-ST STEPPER OWNER’SMANUAL 7
VORSICHTSMASSNAHMEN
Die folgenden Vorsichtsmaßnahmen richten sich an Sie als Besitzer des STAR TRAC P-ST STEPPER. Bitte schulen Sie alle Ihre Benutzer und
Ihr Fitness-Personal in der Beachtung dieser Sicherheitsvorschriften.
PRECAUZIONI
Queste note precauzionali sono dirette a voi, come proprietario dello STAR TRAC P-ST STEPPER. Siete pregati di istruire i vostri utenti e il
vostro personale all'osservanza di queste precauzioni.
Gebote
ILegen Sie jedem Ihrer Benutzer nahe, sein Gesundheits-
oder Fitnessprogramm mit einem medizinischen
Fachmann zu besprechen.
IBeenden Sie den Betrieb Ihres stepper, wenn Sie sich
schwindelig oder schwach fühlen.
IFühren Sie regelmäßige vorbeugende Wartungsmaßnahmen
durch.
ITrainieren Sie langsam, bis Sie eine gewisse Komfortzone
erreichen.
IVerwenden Sie den stepper nur zum vorgesehenen, in
dieser Anleitung beschriebenen Zweck.
Verbote
ILassen Sie den stepper nicht von unbeaufsichtigten
Kindern in Betrieb nehmen.
IBenutzen Sie das Gerät nicht ohne Sportschuhe.
IBenutzen Sie das Gerät bei regnerischen
Witterungsbedingungen nicht im Freien und nicht in einer
geschlossenen Schwimmbadumgebung.
ILassen Sie keine Gegenstände in irgendwelche Öffnun-
gen oder unter den stepper fallen und halten Sie Hände
und Füße von diesen Bereichen fern.
IUnternehmen Sie keinen Versuch, irgendwelche
Abdeckungen zu entfernen oder den stepper zu modi-
fizieren.
ACHTUNG
Der STAR TRAC P-ST STEPPER ist für aerobische Übungen in einer kommerziellen oder Verbraucherumgebung vorge-
sehen.
Bitte holen Sie vor Aufnahme eines jeden Trainingsprogramms den Rat Ihres Arztes ein.
Trainieren Sie nicht übertrieben hart. Hören Sie auf, wenn Sie ein Schwäche-, Schwindel- oder Erschöpfungsgefühl
verspüren. Lassen Sie sich beim Schritttraining von Ihrer Vernunft leiten.
Lesen Sie vor Inbetriebnahme Ihres stepper die Bedienungsanleitung vollständig durch.
Ein Missachten dieses Achtungshinweises kann Verletzungen oder den Tod zur Folge haben.
Da Fare
IIncoraggiate i vostri utenti a discutere il loro programma
di salute o di fitness con uno specialista dell'healthcare.
IInterrompete l'uso dello stepper se avete giramenti di testa
o se vi sentite mancare.
IEseguite periodicamente servizi di manutenzione.
IUtilizzate lo stepper soltanto per l'uso è a cui è destinato,
come descritto nel manuale.
Da Non Fare
INon consentite a bambini di usare lo stepper senza la
supervisione di un adulto.
INon utilizzate lo stepper senza scarpe atletiche.
INon utilizzate lo stepper all'esterno in condizioni piovose
o in un ambiente con piscina interna.
INon lasciate cadere oggetti sullo stepper e non inserite
oggetti, mani o piedi in qualsiasi apertura esterna o sotto
lo Stepper.
INon cercate di rimuovere le coperture o di modificare lo
stepper.
AVVERTENZE
Lo STAR TRAC P-ST STEPPER è stato realizzato per esercizi di aerobica in un ambiente pubblico o privato adeguato.
Prima di iniziare un programma di esercizio fisico, consultate il vostro medico.
Non eccedete i vostri limiti. Fermatevi se vi sentite mancare, se avete giramenti di testa o se vi sentite esausti. Usate
buon senso nell'utilizzo dell'attrezzatura.
Leggete il Manuale dell'utente interamente prima di utilizzare lo stepper.
La mancata osservanza di queste avvertenze può comportare lesioni gravi o morte.

8 STAR TRAC P-ST STEPPER OWNER’SMANUAL
PRECAUÇÕES
Estas notas de segurança destinam-se a você, proprietário do STAR TRAC P-ST STEPPER. Treine todos os usuários e o pessoal da academia
para que sigam estas instruções de segurança.
PRECAUCIONES
Estas notas de seguridad están dirigidas a usted como el dueño de STAR TRAC P-ST STEPPER. Por favor instruya a todos sus usuarios y per-
sonal de entrenamiento para que sigan estas instrucciones de seguridad.
O que fazer
IIncentive todos os usuários a discutirem seu programa de
saúde ou sistema de condicionamento físico com um
profissional da área de saúde.
IPare o funcionamento do stepper se sentir tontura ou ver-
tigem.
IEfetue a manutenção preventiva regular.
IFaça exercícios lentamente até atingir um grau de con-
forto.
IUse o stepper apenas de acordo com a finalidade para
que se destina, conforme descrito neste manual.
O que não fazer
INão deixe crianças sem supervisão operarem o stepper.
INão use sem os sapatos esportivos apropriados.
INão utilize em ambientes externos quando o tempo estiv-
er chuvoso, nem em um ambiente fechado de piscina
interna.
INão deixe cair nem insira nenhum objeto, mãos ou pés
em qualquer abertura ou sob o stepper.
INão tente remover nenhum degrau nem modificar seu
stepper.
ADVERTÊNCIA
Seu STAR TRAC P-ST STEPPER foi projetado para exercícios aeróbicos em um ambiente comercial ou próprio do con-
sumidor.
Consulte seu médico antes de começar qualquer programa de exercícios.
Não se esforce demais. Pare se sentir tontura, vertigem ou exaustão. Tenha bom senso ao fazer o exercício.
Leia todo o Manual do Proprietário antes de operar o seu stepper.
Deixar de observar esta advertência pode resultar em ferimentos ou morte.
Lo que se debe hacer
IDígale a cada uno de sus usuarios que discuta su pro-
grama de salud o régimen de ejercicio con un profesion-
al de la salud.
IDeje de operar su stepper si se siente mareado o como
que va a desmayarse.
ILleve a cabo mantenimiento preventivo a intervalos regu-
lares.
IHaga ejercicio lentamente hasta que alcance un nivel en
el que se sienta cómodo.
IUtilice el stepper solamente para lo que fue diseñado,
como se describe en este manual.
Lo que no se debe hacer
INo permita que los niños operen su stepper sin super-
visión.
INo lo use sin zapatos atléticos.
INo lo utilice afuera en la lluvia ni en un ambiente cerra-
do donde haya una piscina.
INo lo deje caer ni inserte objetos, manos o pies en ningu-
na apertura de su stepper ni debajo de él.
INo intente quitar ninguna cubierta o recubrimiento ni
modificar su stepper.
ADVERTENCIA
Su STAR TRAC P-ST STEPPER está diseñado para el ejercicio aeróbico en un ambiente comercial o de consumo.
Por favor consulte con su médico antes de iniciar cualquier programa de ejercicio.
No haga un esfuerzo excesivo. Deténgase si se siente mareado, exhausto o como si fuera a desmayarse. Use su
sentido común al hacer ejercicio.
Lea completamente el Manual del dueño antes de operar su stepper.
El no cumplir con esta advertencia puede resultar en una lesión o en la muerte.

STAR TRAC P-ST STEPPER OWNER’SMANUAL 9
FÖRSIKTIGHETSÅTGÄRDER
Dessa säkerhetsanmärkningar är riktade till dig i egenskap av ägare av STAR TRAC P-ST STEPPER. Var god utbilda alla användare och all
personal att följa dessa säkerhetsanvisningar.
Man ska
Iuppmuntra alla användare att konsultera sitt hälsoprogam
eller sin träningsregim med en läkare.
Isluta använda stepper om man känner sig yr eller svim-
färdig.
Iutföra regelbundet underhåll i förebyggande syfte.
Imotionera långsamt tills man når en komfortnivå.
Iendast använda stepper för dess avsedda användning,
enligt beskrivning i denna handbok.
Man ska inte
Ilåta barn använda stepper utan uppsikt.
Ianvända stepper utan sportskor.
Ianvända stepper utomhus i fuktigt väder eller i ett innes-
lutet bassängområde.
Itappa in eller föra in något föremål, händer eller fötter i
någon öppning, eller under stepper.
Iförsöka att avlägsna några skyddskåpor eller att modi-
fiera stepper.
VARNINGAR
Din STAR TRAC P-ST STEPPER är avsedd för aerobisk träning i kommersiella eller konsumentinriktade miljöer.
Konsultera din läkare innan du inleder något träningsprogram.
Driv inte dig själv för hårt. Sluta om du känner dig yr, svimfärdig eller utmattad. Använd stepper med sunt förnuft.
Läs igenom hela handboken innan du använder stepper.
Underlåtelse att iaktta dessa varningar kan medföra skada eller dödsfall.

10 STAR TRAC P-ST STEPPER OWNER’SMANUAL

STAR TRAC P-ST STEPPER OWNER’SMANUAL 11
ASSEMBLY AND SETUP
The following parts are included with the STAR TRAC P-ST STEPPER :
IP-ST STEPPER Base frame assembly
IDisplay Assembly
ILeft and right side handrails (Note: Both handrails are the same)
IHardware Kit 711-3182 includes:
8 handrail screws PN 110-0506
4 neck screws PN 110-3172
5/32” Hex key PN 290-0040
IOwners Manual
IWarranty Card
UNPACKING AND ASSEMBLY
NOTE: Inspect the shipping carton for any parts that may be missing BEFORE discarding the carton. Items can shift during transporta-
tion, and may be accidentally discarded with the carton. If any parts are missing, please contact Star Trac Support at 800-503-1221.
Have the serial number of the Stepper, and the part number(s) of the missing parts ready so they may be shipped to you.
1. Unpack the Shipping Carton
Remove the shipping straps from the outside of the shipping carton.
Open the top of the carton and remove the inner top cardboard.
Lift the handrail box (the long, thin box on the side) out of the shipping carton.
Step 1A
Step 1B
Step 1C

12 STAR TRAC P-ST STEPPER OWNER’SMANUAL
Remove the display assembly from the shipping carton.
CAUTION: Take care not to damage the display cable (located at the bottom of the
neck).
Remove the remaining cardboard packing materials from around the Stepper base.
Remove the cardboard box from the cardboard pallet.
2. Install the Side Handrails
NOTE: Both side handrails are identical.
Slide one side handrail onto the left side lower handrail on the Stepper base. Make
sure the rubber-coated section of the handrail faces toward the front of the Stepper.
Align the screw holes in the handrail with the mating holes in the lower handrail sup-
port.
Repeat for the right side handrail.
Step 1D
Step 1E
Step 1F
Step 2A

STAR TRAC P-ST STEPPER OWNER’SMANUAL 13
Remove the Stepper base from the cardboard pallet.
Thread two handrail screws, PN 110-0506, into each side handrail, but do not fully
tighten the screws at this time. The screws are tightened during installation of the dis-
play assembly.
3. Install the Display Assembly
CAUTION: Use care to avoid pinching your finger between the display assembly
and the neck of the Stepper.
While holding the display assembly in position near the neck of the Stepper, plug
the display assembly cable into the mating connector at the neck of the Stepper.
Step 2B
Step 2C
Step 3A

CAUTION: Be careful not to pinch the display cable between the display assembly
and the neck of the Stepper.
Slide the display assembly onto the neck of the Stepper, making sure both side
handrails (installed in step 2) properly engage the display assembly handrail. Thread
two handrail screws, PN 110-0506, into each side handrail.
Use the 5/32" hex key, PN 290-0040, and secure the display assembly to the neck
of the Stepper with four neck screws, PN 110-3172.
Use the 5/32" hex key, PN 290-0040, and fully tighten the eight handrail screws
(four at each handrail).
4. Final Assembly and Testing
Check all screws to ensure they are tightened securely.
Make sure the side handrails are tight.
Mount the Stepper, begin stepping, and verify that the display panel turns on.
Operate the unit to check for proper operation.
You have now completed assembly of your
STAR TRAC P-ST STEPPER .
14 STAR TRAC P-ST STEPPER OWNER’SMANUAL
Step 3B
Step 3C
Step 4

STAR TRAC P-ST STEPPER OWNER’SMANUAL 15
Operating the STAR TRAC P-ST STEPPER is very easy. Simply mount the Stepper by stepping on the Soft Trac®pedals, begin step-
ping, and press QUICK START. Learning the features and incorporating the STAR TRAC P-ST STEPPER into your members' fitness pro-
grams is just as easy. In this chapter, you will learn the display functions and how to get the most out of every STAR TRAC P-ST STEP-
PER workout.
IMPORTANT: Before operating the Stepper, you must be familiar with the following equipment limitations:
IMaximum Weight: Your STAR TRAC P-ST STEPPER is designed for a maximum user weight of 350 lbs/158 kg. DO NOT
exceed the maximum user weight.
DISPLAY PANEL FEATURES
Your STAR TRAC P-ST STEPPER is equipped to provide you
and your users unlimited exercise opportunities. Experiment with its
features to find the right combination for your fitness regimen. The
Display Panel provides the operating controls and display ele-
ments described in the following paragraphs.
QUICK START Key: Enables the Stepper for
manual operation using a default weight as set
in Manager/Maintenance Mode, a default
LEVEL of "1", and a default time limit as set in
Manager/Maintenance Mode.
NOTE: Default time and weight are adjustable
through Manager/Maintenance Mode.
Numeric Keypad: Allows you to enter specific values for program parameters during program setup. During a pro-
gram, these keys may be used to change difficulty level.
OK Key: (part of numeric keypad) Allows you to confirm selections during program setup and operation.
ARROW Key: (part of numeric keypad) Allows you to make corrections to values entered during program setup.
Increase LEVEL Key: Increases the difficulty level, in one-level increments; levels are from 1(least difficult) to 20 (most
difficult). Current level setting is shown in the LEVEL display window.
Decrease LEVEL Key: Decreases the difficulty level from 20 (greatest difficulty) to 1(least difficulty), in one-level incre-
ments. Current level setting is shown in the LEVEL display window.
NOTE: During program setup and while in Manager/Maintenance Mode, the Increase LEVEL and Decrease LEVEL
keys increment or decrement the value shown in the Information Window.
Fan Key: Allows you to control the speed of the personal cooling fan, either OFF, HIGH or LOW.
SCROLL Keys: Scrolls the upper and lower data information windows between the three available data displays.
Preset Program Keys: Allow you to access a desired preset workout program.
OPERATING INSTRUCTIONS
PRESET
PROGRAM KEYS
QUICK START
KEY
LEVEL
ADJUST NUMERIC KEYPAD
UPPER DATA
INFORMATION
WINDOW
LOWER DATA
INFORMATION
WINDOW
INFORMATION
WINDOW MOTIVATIONAL TRACK
GRAPHIC
DISPLAY
FAN
CONTROL

16 STAR TRAC P-ST STEPPER OWNER’SMANUAL
Upper Data Information Window: Shows current and aggregate data related to your workout. Pressing the associated SCROLL key
scrolls between the following displays:
ICALORIES - Shows your aggregate caloric expenditure thus far in your workout.
ICAL/HR - Shows your current caloric expenditure per hour based on your current difficulty level and stepping rate.
IWATTS - Shows your current watts expenditure at that specific time during your workout.
NOTE: Press the SCROLL key to toggle between data during your workout.
Lower Data Information Window: Shows current and aggregate data related to your workout. Pressing the associated SCROLL key
scrolls between the following displays:
IDISTANCE - Shows the total number of vertical feet or meters you have climbed thus far.
ISPEED - Shows the speed at which you are currently stepping, in steps-per-minute.
IMETS - Shows your current METS expenditure at that specific time during your workout.
NOTE: Press the SCROLL key to toggle between data during your workout.
Graphic Display: Traces your progress through each of the programs and allows you to anticipate changes in difficulty. Display elements
illuminate from left to right across the bottom of the display to indicate your progress through the course. At each step, display elements illu-
minate in columns to indicate your ascent up the gradient that is in effect.
Motivational Track: Shows your progress counter-clockwise around a 10-floor course, starting from the bottom
center.
Information Window: Provides informational messages, prompts during program setup, feedback during your workout, notification
when your workout is complete, and scrolling summarized workout data after your workout. During your workout, the Information Window
shows the following data:
ITIME - Shows the duration of your workout thus far in minutes and seconds.
IFLOORS - Shows the total number of floors you have climbed thus far.
IHEART RATE - Shows your current heart rate in beats-per-minute (BPM) while wearing a heart rate strap or grasping the heart rate
grips.
Depending on the program completed and Stepper settings as set in Manager/Maintenance Mode, workout data may include:
SOFT TRAC® SYSTEM
The Soft Trac®system is the Stepper’s foot comfort and step absorption system consisting of a yielding, durable rubber pad covering
both foot pedals. This system is designed to protect ankles, knees, joints, and back while reducing numbness in toes and feet and
providing a comfortable stepping surface. Whether you place your feet at the front, middle, or rear of the pedals you will enjoy the
benefits of the Soft Trac®system.
HINTS AND TIPS FOR GETTING STARTED
The following hints and tips will assist in training your users to maximize the fitness benefits of your STAR TRAC P-ST STEPPER.
IStep at a rate that feels comfortable and most natural, yet is sufficient to achieve a good cardio workout.
ITry different stepping rhythms. In manual operation, vary your stepping speed from slow to fast, then back to slow. As you
become more comfortable with your Stepper, try stepping faster, varying the difficulty LEVEL, or using the preset programs.
IWatch the Graphic Display to anticipate changes in difficulty. When you use the preset programs, the display shows
changes in difficulty as tall or short columns.
VIEWING WORKOUT DATA DURING A PROGRAM
Workout data is shown in three windows on the Stepper Display Panel: the Information Window (located at the top of the Display Panel)
ITime elapsed
ICalories expended
IDistance traveled - vertical feet or meters
IFloors climbed
IAverage speed - steps per minute
IAverage calories expended per hour
IAverage watts
IAverage METS
IAverage heart rate

STAR TRAC P-ST STEPPER OWNER’SMANUAL 17
and the Upper and Lower Data Information Windows (located inside the Motivational Track, to the right of the Graphic Display).
Information shown in the Information Window during a workout includes elapsed time, number of floors climbed, and heart rate (HR), when
in use. After the workout is complete, workout summary information is shown in the Information Window.
The Information Window also displays important instructions and cues throughout the workout.
The Upper and Lower Data Information Windows also display information during a workout.
To view workout data during your workout:
1. Press the Upper Data Information Window SCROLL key to view the following workout data (the current data display is indicated by
an LED next to the parameter name):
ICALORIES - Shows your aggregate caloric expenditure thus far in your workout.
ICAL/HR - Shows your current caloric expenditure per hour based on your current difficulty level and stepping rate.
IWATTS - Shows your current watts expenditure at that specific time during your workout.
NOTE: Press the SCROLL key to toggle between data during your workout.
2. Press the Lower Data Information Window SCROLL key to view the following workout data (the current data display is indicated by
an LED next to the parameter name):
IDISTANCE - Shows the total number of vertical feet or meters you have climbed thus far.
ISPEED - Shows the speed at which you are currently stepping, in steps-per-minute.
IMETS - Shows your current METS expenditure at that specific time during your workout.
PAUSE MODE
If you come to a complete stop during your workout (SPM is less than 10), the Stepper will enter a “pause” mode. To continue your work-
out, begin stepping before the “pause” timer expires and your workout data will not be lost.
COOLDOWN CYCLE
Once you have completed your workout, the Stepper enters a two-minute Cooldown cycle.
NOTE: The Stepper software is programmed to properly decrease difficulty level to provide a cooldown.
To operate the Stepper during Cooldown:
1. You can adjust the difficulty LEVEL during Cooldown.
IUse the keys to enter a difficulty LEVEL (from 1 to 20); or press the or key, as desired, to increase or decrease
the difficulty LEVEL in 1 unit increments.
IWhen the desired difficulty LEVEL has been entered by using the keys, press the key to accept the displayed LEVEL.
2. When the Cooldown cycle ends, your workout summary displays in the Information Window. If you wish to exit the Cooldown
cycle before it ends automatically, stop stepping.
USING THE PERSONAL FAN
The STAR TRAC P-ST STEPPER is equipped with a built-in personal fan to increase your comfort during a workout. You can control the fan
speed during your workout.
To operate the personal fan:
IPress the key, as necessary, to cycle the personal fan from OFF to HIGH to LOW to OFF. An LED indicator lights to show the
currently selected fan speed.
IThe fan remains set at the set speed if you pause your program, unless your workout was less than two minutes in length.
IThe fan turns off automatically if you exit your workout, or when you complete your workout program.
IThe fan turns off automatically if you pause your program and the time elapsed is less than two minutes.
HEART RATE MONITORING
Heart rate monitoring allows you to determine if your workout is too challenging or not challenging enough. Monitoring your heart rate is

18 STAR TRAC P-ST STEPPER OWNER’SMANUAL
easy with the STAR TRAC P-ST STEPPER . You may use a heart
rate strap, or you can simply grasp the silver contact heart
rate grips. Your goal will be to keep your exercise heart rate
between 60 and 90 percent of the theoretical maximum for
your age, as shown in the accompanying Target Heart Rate
table.
NOTE: The Heart Rate monitor is not a medical test, nor is it
designed as a medical test. It is simply a guide to target heart
rate training. Please consult with your physician prior to
engaging in any strenuous physical activity.
NOTE: If both the heart rate grips and a heart rate strap are
being used, the heart rate grips will override and be dis-
played in the HR window.
IMPORTANT: The manufacturer does not warrant the heart rate system performance on this product, as the heart rate system perform-
ance varies, based on a user's physiology, fitness level, age, method of use and other factors. Furthermore, the heart rate system is not for
medical use.
CONTACT HEART RATE MONITORING
You may use the heart rate contact grips to automatically check your heart rate while stepping. Just follow these steps.
1. Grasp the stainless steel heart rate contact grips; you do not have to squeeze tightly.
IWhen the heart rate contact grips are grasped, the will display and an audible “beep” will sound to indicate that a heart
rate has been detected.
2. It may take from 30 to 60 seconds for the heart rate system to acquire and display your heart rate.
3. When your heart rate has been acquired, the indicator and your heart rate in beats per minute (BPM) display in the HEART
RATE field of the Information Window.
4. Release the Heart Rate grips if you wish to remove your heart rate reading from the display.
CHEST STRAP HEART RATE MONITORING
You may use the heart rate strap to automatically check your heart rate. Just follow these steps:
1. Before beginning your workout, or during a pause, moisten the back of the transmitter on the heart rate strap. Place the strap snug-
ly around your chest with the transmitter resting directly over your sternum.
2. When your heart rate has been acquired, the indicator and your heart rate in beats per minute (BPM) display in the HEART
RATE field of the Information Window.
3. Remove the heart rate strap if you wish to remove your heart rate reading from the display.
NOTE: The performance of the transmitter may be affected by body types, body oils, metal in clothing, and outside electrical interference.
Always be sure that the transmitter and skin are in good contact. Avoid operating other electrical equipment near your Stepper when you
use the heart rate strap.
QUICK START
Quick Start lets you begin your workout by simply pressing one key, or by stepping for approximately 13 seconds without pressing any key.
Quick Start uses a default weight as set in Manager/Maintenance Mode, a difficulty LEVEL of 1, and a time limit as set in
Manager/Maintenance Mode. YOU control resistance LEVEL during the entire program.
To operate the Quick Start program:
1. Mount the Stepper, begin stepping, and press the QUICK START key.
2. If desired, you can use the personal fan during your workout (see “Using the Personal Fan” for details).
To calculate your training zone, use the following formulas:
(theoretical max HR = 220 - Age)
Heart Rate Training Range Upper Level
_____________________x 0.90 = ___________________________
Your Theoretical Max Training Range Upper Limit
Heart Rate Training Range Lower Level
_____________________x 0.60 = ___________________________
Your Theoretical Max Training Range Lower Limit
NOTE: Calculating your theoretical maximum heart rate using age
is an approximation. For more information, please contact a fitness
professional or doctor.

STAR TRAC P-ST STEPPER OWNER’SMANUAL 19
3. You can adjust the difficulty LEVEL during the program, using either of the following methods.
IUse the keys to enter a difficulty LEVEL (from 1 to 20). When the desired level has been entered, press the key to
confirm the difficulty LEVEL.
IPress the or key, as desired, to increase or decrease the difficulty LEVEL in 1 unit increments.
4. You can scroll through workout data during the program (see “Viewing Workout Data During a Program” for details).
5. If you wish to pause the program, stop stepping. The Stepper will enter pause mode and display your workout results for one entire
cycle.
6. When you have reached your workout goal, the Stepper enters the Cooldown cycle (see “Cooldown Cycle” for details). If you
wish to exit the program before you have reached your workout goal, stop stepping and allow the Pause timer to expire. If you
wish to skip the Cooldown cycle, press the key to view your workout summary.
PRESET PROGRAMS
The STAR TRAC P-ST STEPPER offers 8 preset programs to add variety and challenge to your workout. Additionally, the HR TRAINING fea-
ture lets you select one of two cardio-intensive training programs, or a Fitness Test.
Pre-set programs include:
Allows the user to pre-program a time goal and user weight. Difficulty is determined by the user during the program.
Provides a high intensity interval workout.
Provides a workout designed to target the thigh muscles.
Provides a workout designed to target the gluteal muscles.
Provides a motivational workout in which the user can climb one of nine famous landmarks.
Advanced programs that offer the user the ability to train in specific HR zones, or perform a Fitness Test.
NOTE: When entering setup data for any program, if the key is not pressed, the system will “auto-advance” through
the prompts.
MANUAL PROGRAM
The MANUAL program allows the user to pre-program a time goal, difficulty LEVEL and user weight. Difficulty LEVEL can be adjusted by the user
during the program.
To operate the MANUAL program:
1. Mount the Stepper, begin stepping, and press the key.
2. You are prompted to enter your weight. The Stepper displays a default weight as set in Manager/Maintenance Mode. You may
enter any weight from 1 to 350 pounds (1 to 158 kg).
IUse the keys to enter your current weight; or press the or key, as necessary, to increase or decrease the dis-
played weight in 1 pound (or 1 kg) increments.
IWhen your correct weight has been entered, press the key to accept the displayed value.
3. You are prompted to enter a time goal. The default time is 20 minutes, or equal to the time parameter set in Manager/
Maintenance Mode if less than 20 minutes. You may enter any time from 1 to 99 minutes.
IUse the keys to enter your desired time goal; or press the or key, as necessary, to increase or decrease the
displayed value in 1 minute increments.
IWhen your desired goal has been entered, press the key to accept the displayed value.
4. You are prompted to enter a difficulty LEVEL.
IUse the keys to enter a difficulty LEVEL (from 1 to 20) or press the or key, as desired, to increase or decrease
the difficulty LEVEL in 1 unit increments.
IWhen the desired difficulty LEVEL has been entered, press the key to accept the displayed LEVEL.

20 STAR TRAC P-ST STEPPER OWNER’SMANUAL
5. If desired, you can use the personal fan during your workout (see “Using the Personal Fan” for details).
6. You can adjust the difficulty LEVEL during the program, using either of the following methods:
IUse the keys to enter a difficulty LEVEL (from 1 to 20). When the desired level has been entered, press the key to
confirm the difficulty LEVEL.
IPress the or key, as desired, to increase or decrease the difficulty LEVEL in 1 unit increments.
7. You can scroll through workout data during the program (see “Viewing Workout Data During a Program” for details).
8. If you wish to pause the program, stop stepping. The Stepper will enter pause mode and display your workout results for one entire
cycle.
9. When you have reached your workout goal, the Stepper enters the Cooldown cycle (see “Cooldown Cycle” for details). If you
wish to exit the program before you have reached your workout goal, stop stepping and allow the Pause timer to expire.
FAT BURNER PROGRAM
The FAT BURNER program provides a high intensity interval workout.
To operate the program:
1. Mount the Stepper, begin stepping, and press the key.
2. You are prompted to enter your weight. The Stepper displays a default weight as set in Manager/Maintenance Mode. You may
enter any weight from 1 to 350 pounds (1 to 158 kg).
IUse the keys to enter your current weight; or press the or key, as necessary, to increase or decrease the dis-
played weight in 1 pound (or 1 kg) increments.
IWhen your correct weight has been entered, press the key to accept the displayed value.
3. You are prompted to enter a time goal. The Stepper displays a default time of 20 minutes, or equal to the time parameter set in
Manager/Maintenance Mode if less than 20 minutes. You may enter any time from 1 to 99 minutes.
IUse the keys to enter the desired time goal, or press the or key, as necessary, to increase or decrease the
displayed value in 1 minute increments.
IWhen your desired time goal has been entered, press the key to accept the displayed value.
4. You are prompted to enter a difficulty LEVEL.
IUse the keys to enter a difficulty LEVEL (from 1 to 20) or press the or key, as desired, to increase or decrease
the difficulty LEVEL in 1 unit increments.
IWhen the desired difficulty LEVEL has been entered, press the key to accept the displayed LEVEL.
5. If desired, you can use the personal cooling fan during your workout (see “Using the Cooling Fan” for details).
6. You can adjust the difficulty LEVEL during the program using either of the following methods:
IUse the keys to enter a difficulty LEVEL (from 1 to 20). When the desired difficulty LEVEL has been entered, press the
key to confirm the difficulty LEVEL.
IPress the or key, as desired, to increase or decrease the difficulty LEVEL in 1 unit increments.
7. You can scroll through workout data during the program (see "Viewing Workout Data During a Program” for details).
8. If you wish to pause the program, stop stepping. The Stepper will enter pause mode and display your workout results for one entire
cycle.
9. When you have reached your workout goal, the Stepper enters the Cooldown cycle (see “Cooldown Cycle” for details). If you
wish to exit the program before you have reached your workout goal, stop stepping and allow the Pause timer to expire.
