Star CFS User manual

1
CAUTION
This equipment is designed and sold for
commercial use only by personnel trained
and experienced in its operation and is
not sold for consumer use in and around
the home nor for use directly by the
general public in food service locations.
For equipment to be used by the general
public, please contact the factory.
These models are equipped for the voltage
and wattage indicated on the nameplate.
These units are designed to operate on
alternating current (A.C.), two wire single
phase service only and are equipped with
an approved lead in cord set with a three
prong grounding type plug. DO NOT
CONNECT TO DIRECT CURRENT (D.C.).
INSTALLATION
For your protection, we recommend that a
qualified electrician install this appliance.
The electrician should be familiar with
electrical installations and your local
electrical requirements. Proper
connections and power supply are
essential for efficient performance. The
supply circuit should be properly fused as
required by local electrical code.
OPERATINGPROCEDURE
Connect your food freshener to a 120 volt
A.C. wall outlet and be sure metal frame
of appliance is grounded. Pull out lower
drawer to where it stops and fill pan with
distilled water. Turn switch on and do not
start to use until pilot light goes out.
Then only, will your Steamswell be hot
enough to work properly. Do not pump
when cold or not up to temperature.
INSTALLATION AND OPERATING
INSTRUCTIONS Open the top food drawer, place food in
pan, close drawer, pump handle 2 to 4
times to heat food. After pumping and
waiting the proper time required to heat
food, open drawer and remove food, never
pump over three times, then wait 30
seconds. Over pumping will damage
steam chamber and will not heat food any
faster. Drawer should be kept closed
when not in use. When not in use, turn
off switch. CAUTION: Do not use soap or
detergent to clean chamber.
CLEANING
To remove water pan, pull out lower
drawer till it stops, press in on stops on
each side and remove pan all the way out.
Clean pan and baffles. Food pan is
removable by pulling drawer out and
lifting pan up. To remove food pan drawer
frame, pull out as far as it will go, then
raise up catches on tracks and pull
forward.
CORD PLUG AND GROUNDING
INSTRUCTIONS
For your protection, this appliance is
equipped with a three conductor cord,
having a grounding type plug. If you use
an adaptor be sure your system is
grounded. Then connect the green wire
of the adaptor to a mounting screw of the
receptacle. For ungrounded systems,
attach the green wire of the adaptor to a
known permanent ground.
MAINTENANCE AND REPAIRS
Contact the factory or one of its
representatives or a local service company
for service or maintenance if required.
RETAIN THIS MANUAL FOR FUTURE
REFERENCE
Part No. 2M-Z1198 Rev. -- 3/05/02

2
NFS & CFS STEAMERS
OPERATING & FOOD PREPARING INSTRUCTIONS
FOR THE TOASTWELL AUTOMATIC FOOD FRESHENERS
THEFOLLOWINGARESUGGESTEDHEATINGTIMES
NOTE: EACH OPERATOR MUST LEARN, THROUGH TRIAL, HIS OWN REQUIREMENTS
TYPE FOOD
SWEET ROLLS
HAMBURGER BUNS
BISCUITS
CORN BREAD
DINNER ROLLS
WAFFLES
BACON (PRECOOKED)
HAMBURGER (PRECOOKED)
FROZEN SLICED MEAT
SAUSAGE (PRECOOKED)
ROAST BEEF (SLICED)
FISH STICKS (PRECOOKED)
TOASTEDCHEESE
BAKED BEANS
VEGETABLES (PRECOOKED)
VEGETABLES (FROZEN)
CHEESEBURGER
HOT DOGS
BEEFSTEW
RICE (PRECOOKED)
PIES, PIZZA PIE
FROZEN PRODUCTS
NUMBER OF TIMES TO
DEPRESS LEVER HEATING TIME DRAWER CLOSED
2
2
2
2
2
*2, WAIT 30 SEC., 2
2
3
*2, WAIT 30 SEC., 2
*2, WAIT 30 SEC., 2
3
*2, WAIT 30 SEC., 2
2
*2, WAIT 30 SEC., 2
*2, WAIT 30 SEC., 2
*2, WAIT 30 SEC., 3
*2, WAIT 30 SEC., 3
*2, WAIT 30 SEC., 2
*2, WAIT 30 SEC., 2
*2, WAIT 30 SEC., 2
*2, WAIT 30 SEC., 2
*2, WAIT 30 SEC., 3
20 TO 30 SECONDS
30 SECONDS
45 SECONDS
60 SECONDS
30 SECONDS
35 SECONDS
60 TO 75 SECONDS
60 SECONDS
3 TO 5 MINUTES
1-1/2 MINUTES
60 TO 75 SECONDS
1-1/2 MINUTES
45 TO 60 SECONDS
1-1/2 TO 2 MINUTES
60 TO 75 SECONDS
1-1/2 MINUTES
1-1/2 TO 2 MINUTES
1-1/2 TO 2 MINUTES
1-1/2 TO 2 MINUTES
75 SECONDS
45 TO 90 SECONDS
1-1/2 TO 5 MINUTES
*DEPRESS HANDLE 2 TIMES, WAIT 20 TO 35 SECONDS AND DEPRESS 2 OR 3 MORE
TIMES,THENWAITREQUIREDTIME.
NOTE: REPEATED AND CONTINUOUS PUMPING IS NOT REQUIRED, STEAM STAYS IN HEATING
PAN UP TO SEVERAL MINUTES. GIVE IT TIME TO HEAT FOOD. NEVER DEPRESS OR PUMP LEVER
MORE THAN (3) TIMES WITHOUT A WAITING PERIOD OF AT LEAST 30 SECONDS.
READ CAREFULLY THE OPERATING INSTRUCTIONS FURNISHED WITH EACH
TOASTWELL UNIT BEFORE USING EITHER MODEL. USE DISTILLED WATER.

PARTS LIST EFFECTIVE
IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED PAGE
INCLUDE MODEL AND SERIAL NUMBER OF
Some items are included for illustrative purposes only and in certain instances may not be available.
Number
Per
Unit Description
Part
Number
Key
Number
MODEL
3-31-06 RB
K5 2R-09-07-0075 1KNOB WATER PAN
K6 SCREW 10-24 FOR WATER PAN KNOB
K9 SCREW 6-32 HEX HEAD
K22A 2P-09-07-0016 1CAP HANDLE
K22B C9-04-FS-0053 1 PUMP HANDLE
K23 2J-05-07-0025 1PILOT LIGHT (SPECIFY 120V OR 230V)
K23A 2S-05-07-0040 1 PILOT L IGHT RECTANGULAR
K26 2E-05-07-0011 1ON-OFF SWITCH
K28 2P-10-07-0016 1INNER SPRING (PUMP TO CASTING)
K28A 2P-10-07-0011 1INNER SPRING (PUMP TO WATER PAN)
K31 2P-09-07-0074 1BALL
K32 C9-30-FS-0008 1BRASS HOUSING
K33 2A-10-FS-0001 1 PUMP C YLINDER
K33A C9-51-FS-0009 1CYLINDER CAP AND SLEEVE
K34 2C-08-07-0101 1COTTER PIN
K35 2P-10-07-0005 1PUMP SPRING
K36 2A-10-07-0012 1BRASS BUSHING
K37 C9-70-FS-0057 1LARGE WELDED PUMP FRAME
K37A C9-04-FS-0056 1SMALL PUMP FRAME BRACKET
K38 C9-52-FS-0008 1PUMP PISTON RING ASSEMBLY LEVER
2A-10-07-0010 1PUMP PLUNGER
2A-10-FS-0002 1PISTON ROD
2C-08-07-0281 1WASHER, #10 x 9/16” SEALING
2C-2566 1NUT, 10-32 HEX STL NP
K38A 2A-10-07-0010 1PISTON RING ONLY
K39 2R-Z5841 1PUMP LEVER
K40 C9-40-FS-0049 1PUMP NUT & SCREW
K42 2A-09-07-0009 4 FOOT
K43 4 RUBBER PLUG (not available)
K89 Z1-30-07-0002 1DRAWER ASSEMBLY INCLUDES FRONT HANDLE
K90 1 HANDLE FOR FOOD PAN
K91 1 DRAWER FRONT
K92 1 DRAWER BACK
K93 2 HANDLE SCREW
K94 C9-04-FS-0033 1 FOOD SCREEN
K95 C9-04-FS-0034 1 FOOD PAN
K96 1 WATER PAN FRONT
K101 1 WATER LINE (PUMP TO STEAM CHAMBER)
K102 1 TOP STEAM PLATE #1
K103 1 TOP CASTING PLATE #2
K104 1 BOTTOM CASTING #4
K105 FLAT HEAD SCREW, 5/16-18
K106 C9-30-FS-0005 1DRAWER FRAME
K109 TEFLON ROLLER
K111 1 STAINLESS TOP
K113 2N-05-FS-0002 1 ELEMENT
K114 1 BOTTOM STEAM PLATE #4
K120 1 TERMINAL BLOCK
K122 CAP FOR METAL LEG
K123 METAL LEG
K124 1 WATER LINE (PUMP TO WATER PAN)
1
1
FOOD STEAMER MODEL CFS
8D
